Atlas Copco RT-3 Manual de usuario

RT-3

TORQUE CHART

This chart shows the correlation

between pump gauge psi reading

and torque output for your Rapid-Torc

RT-3 hydraulic torque wrench.

PSI FT.LB.

1500 485

1600 517

1800 581

2000 646

2200 7 11

2400 775

2600 840

2800 904

3000 969

3200 1034

3400 1098

3600 11 6 3

3800 1227

4000 1292

4200 1357

4400 1421

4600 1486

4800 1550

5000 1615

5200 1680

5400 1744

5600 1809

PSI FT.LB.

5800 1873

6000 1938

6200 2003

6400 2067

6600 2132

6800 2196

7000 2261

7200 2326

7400 2390

760 0 2455

7800 2519

8000 2584

8200 2649

8400 2713

8600 2778

8800 2842

9000 2907

9200 2972

9400 3036

9600 3101

9800 3165

10000 3230

BAR NM

104 657

110 701

124 788

138 876

152 963

165 1051

179 11 3 9

193 1226

207 1314

220 1401

234 1489

248 1577

262 1664

276 1752

290 1839

303 1927

317 2014

331 2102

345 2190

358 2277

372 2365

386 2452

BAR NM

400 2540

414 2628

427 2715

441 2803

455 2890

468 2978

482 3066

496 3153

510 3241

524 3328

538 3416

552 3503

565 3591

579 3679

593 3766

607 3854

620 3941

634 4029

648 4 11 7

662 4204

676 4292

690 4379

Set the pressure on the pump that

corresponds to the torque value.

1Find the closest torque value for

your application, either in ft-lbs

or in Nm.

FOOT-POUNDS NEWTON-METERS

RT-PTCen-RT-3 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised October 2014

The above torque values are only applicable when using a calibrated RT-3 hydraulic torque wrench powered by a 10,000 psi pump

ﬁtted with a calibrated class 1 gauge.

QUICK SETUP

GUIDE

Setting up your hydraulic torque wrench for use is easy.

Please read the included user manual and safety instruc-

tion booklet for additional guidelines.

Wear personal protec-

tive equipment, such as

eyeglasses and steel-toe

shoes.

SET PRESSURE

Make sure the hoses are

free of any defects. The

couplers are on pump

and the tool should be

securely connected.

Place tool on at surface.

Turn pump on. Cycle the

tool. Press the “ON’ but-

ton on the remote, hold

until tool clicks. Release,

wait for the tool to click.

Repeat the cycle. Ensure

there is no leak.

Use the torque conver-

sion chart to set the psi

for the torque you need.

Press the remote’s “ON”

button and slowly turn

the pressure regulator

clockwise to reach the

right pressure.

FOUR BASIC STEPS TO OPERATE YOUR RT-3

Scan the code to see a brief overview video on how to use the document or go to

rapidtorc.com/torque_setup

RT-PTCen-RT-3 Copyright Rapid-Torc®. Part of the Atlas Copco Group Revised September 2014

CYCLE YOUR TOOL

CONNECT HOSES

WEAR PPE
