Atlantis Land NET POWER 302AV Manual de usuario

ITALIANO

Questo prodotto è coperto da garanzia Atlantis Land della durata di 2 anni. Per

maggiori dettagli in merito o per accedere alla documentazione completa in Italiano

fare riferimento al sito www.atlantis-land.com.

ENGLISH

This product is covered by Atlantis Land 2 years warranty. For more detailed

informations please refer to the web site www.atlantis-land.com.

For more detailed instructions on configuring and using this device, please refer to the

online manual.

FRANCAIS

Ce produit est couvert par une garantie Atlantis Land de 2 ans. Pour des informations

plus détaillées, référez-vous svp au site Web www.atlantis-land.com.

DEUTSCH

Dieses Produkt ist durch die Atlantis Land 2 Jahre Garantie gedeckt. Für weitere

Informationen, beziehen Sie sich bitte auf Web Site www.atlantis-land.com.

ESPAÑOL

Este producto esta cubierto por Atlantis Land con una garantía de 2 años. Para mayor

información diríjase a nuestro sitio Web www.atlantis-land.com.

INDEX

1. Introduction........................................................................................9

2. Package Contents................................................................................9

3. System Requirements........................................................................10

3.1 System Required for Utility..........................................................10

4. Device Design ...................................................................................11

5. Hardware Installation ........................................................................13

6. SYNC Button .....................................................................................15

6.1 Application Scenarios..................................................................15

7. Utility ...............................................................................................17

7.1 Opening Net Power 302 AV Utility ...............................................18

8. Support ............................................................................................28

APPENDIX A: Frequently Asked Questions ..............................................29

APPENDIX B: Technical Features............................................................33

A02-PL302Kit(v1.0)_ME01 (v1.0 June 2009)

No part of this publication may be reproduced, stored in a retrieval system, or

transmitted in any form or by any means, whether electronic, mechanical,

photocopying, recording or otherwise without the prior writing of the publisher.

Windows™ 98SE/2000/ME/XP/VISTA are trademarks of Microsoft® Corp. Pentium is

trademark of Intel. All copyright reserved.

The Atlantis Land logo is a registered trademark of Atlantis Land. All other names

mentioned mat be trademarks or registered trademarks of their respective owners.

Subject to change without notice. No liability for technical errors and/or omissions.

CE Mark Warning

In a domestic environment, this product may cause radio interference, in which case

the user may be required to take adequate measures.

CE/EMC Restriction of Liability

The product described in this handbook was designed, produced and approved

according to the EMC-regulations and is certified to be within EMC limitations.

If the product is used in an uncertified PC, the manufacturer undertakes no warranty

in respect to the EMC limits. The described product in this handbook was constructed,

produced and certified so that the measured values are within EMC limitations. In

practice and under special circumstances, it may be possible, that the product may be

outside of the given limits if it is used in a PC that is not produced under EMC

certification. It is also possible in certain cases and under special circumstances,

which the given EMC peak values will become out of tolerance. In these cases, the

user himself is responsible for compliance with the EMC limits.

Declaration of Conformity

Hereby, Sidin SpA, declares that this product is in compliance to all relevant essential

requirements of the Electromagnetic Compatibility Directive 2004/1008/CE and Safety

(2006/95/CE). CE Declaration is available on the web site www.atlantis-land.com.

Important information for the correct recycle/treatment

procedures of this equipment

The mentioned information are reported herewith in compliance with directive

2002/95/CE, 2002/96/CE and 2003/108/CE which requires a separate collection

system and specific treatment and disposal procedures for the waste of electric and

electronic equipments.

The crossed-out wheeled bin symbol printed on the unit label or unit packaging

indicates that this equipment must not be disposed of as unsorted municipal waste but

it should be collected separately.

The waste of electric and electronic equipment must be treated separately, in order to

ensure that hazardous materials contained inside the equipment are not buried

thereby providing potential future problems for the environment and human health.

Moreover, it will be possible to reuse and recycle some parts of the waste of electric

and electronic equipment, contributing to reduce the quantities of waste to be

disposed of and the depletion of natural resources.

As user of this equipment, you are responsible to contact the producer to know the

correct procedure in the separate collection system for the waste of electric and

electronic equipments.

Your rôle in participating to the separate collection of waste of electric and electronic

equipment is essential to ensure that environmental protection and human health

objectives connected to a responsible treatment and recycling activities are achieved.

Important Safety Instructions

Please read these instructions carefully:

Unplug the PowerLine HD Ethernet Adapter from the wall outlet before cleaning.

Do not use liquid cleaners or aerosol cleaners. Use a damp cloth for cleaning.

Do not use the PowerLine HD Ethernet Adapter near water.

The PowerLine HD Ethernet Adapter should never be placed near or over a

radiator or heat register, or in a built-in installation unless proper ventilation

provided.

The PowerLine HD Ethernet Adapter should be operated from the type of power

indicated on the marking label. If you are not sure of the type of power

available, consult your dealer or local power company.

The PowerLine HD Ethernet Adapter relies on the building’s electrical installation

for short-circuit (over current) protection. Ensure that a fuse or circuit breaker

no larger than 230 VAC is used on the phase conductors (all current-carrying

conductors).

Plug the PowerLine HD Ethernet Adapter directly into a 96-230V AC wall outlet.

Do not use an extension cord between the adapter and the AC power source.

Do not attempt to service the PowerLine HD Ethernet Adapter yourself, as

opening or removing covers may expose you to dangerous voltage points or

other risks as well as ruin product warranty. Refer all servicing to qualified

service personnel.

Unplug the PowerLine HD Ethernet Adapter from the wall outlet and refer the

product to qualified service personnel for the following conditions:

If liquid has been spilled into the product.

If the product has been exposed to rain or water

If the product does not operate normally whenthe operating instructions

are followed

If the product exhibits a distinct change in performance

Product warranty does not apply to damage caused lightning, power

surges or wrong voltage usage.

Check voltage before connecting to the power supply. Connecting to the

wrong voltage will damage the equipment.

High voltage is used in the equipment. Do not open enclosure, service,

or change any part of the equipment. Service can only be carried out by

qualified technical specialists. Observe safety precautions to avoid

electric shock.

Congratulations on your purchase of this Net Power 302 AV. This manual helps to get

familiar with the Adapter. This manual contains detailed instructions in operation of

this product. Please keep this manual for future reference.

1. Introduction

NetPower 302AV utilizes the existing electrical wiring in the house as a path to create

a secured network of computers and Ethernet devices. With a maximum data rate of

up to 200 Mbps, NetPower 302AV can reliably handle high requirement applications

like broadband Internet, high definition video streaming, and Voice over IP.

HomePlug AV converts digital signals to a complex analog signal that traverses along

the electrical wires. When receiving the analog signal, HomePlug AV converts the

analog signal back to digital. To make the signal secured, a 128-bit AES encryption is

applied.

A HomePlug AV device can only communicate with other HomePlug AV devices that

use the same Private Network Name. The Private Network Name can be changed

manually using the HomePlug AV Utility software on a computer with a Windows

operating system. When you use the software, you have to manually type the Private

Network Name for the device. Another way to change the Private Network Name is to

use the Simple Connect button SYNC (this feature automatically creates an encrypted

Private Network Name). It can also be used to reset the Private Network Name or to

add a device into an existing HomePlug AV network.

When a HomePlug AV communicates with another device, the Powerline Activity LED

will give you an idea about the status.

2. Package Contents

Open the box of the device and carefully unpack it. The box should contain the

following items:

2 Powerline 302AV (2 PowerLine HD Ethernet Adapter)

2 CAT-5 UTP Straight Ethernet Network cables (RJ45)

1 Quick Start Guide

1 CD-Rom with Utility and Manuals

1 Warranty

If any item is found missing or damaged, please contact your local reseller

for replacement.

3. System Requirements

NetPower 302AV is applicable with all TCP/IP operating systems with Ethernet port.

Drivers are not required for this adapter. But the supplied Configuration Utility

software to assign the network password operates only with Windows operating

systems.

Your computer must meet the following requirements in order to use the PowerLine

HD Ethernet Adapter Configuration Utility. Another way to change the Private Network

Name is to use the Simple Connect button (SYNC).

3.1 System Required for Utility

Windows 2000, Windows XP or Vista with Ethernet connection

Pentium III 600 MHz MMX-Compatible PC or greater

At least 256MB hard disk space and memory

.NET Framework

Your computer or the device to which you want to connect the

Powerline HD Ethernet Adapter must have an Ethernet port,

i.e. a network card or a network adapter.
