Operating and Safety Instructions
1. GENERAL INFORMATION
1.1. INTRODU TION
The user’s manual given by the manu acturer contains necessary in ormation about the
machine parts. Each machine operator should read these instructions care ully, and the
machine should be operated a ter ully understanding them.
Sa e and e icient use o the machine or long term depends on understanding and
ollowing the instructions contained in this manual. The technical drawings and details
contained in this manual constitute a guide or the operator.
1.2. DISTRIBUTOR
ATech Machine, Inc.
429 E. Diamond Ave. #F – Gaithersburg, MD 20877 USA
Phone: +1-301-556-9789 Toll Free: 1-866-80A-TECH Fax: +1-301-542-0140
In case o any technical problem please contact your nearest ATECH dealer, or ATECH
head o ice through the above mentioned phone ax or e-mail address.
Technical labels with the model description o the machine are ixed onto the ront side
o each machine.
The machine’s serial number and manu acturing year are stipulated on the technical
label.
2. MA HINE’S DES RIPTION AND PURPOSE OF USE
2.1. MA HINE’S DES RIPTION
Portable miter saw or serial cutting o PVC, aluminum and wooden pro iles in desired
angles. The operator has the possibility to adjust the cutting speed o the saw blade via
knob according to material type and size.
Cutting at ixed angles o 15
0
-22.5
0
-30
0
-45
0
-90
0
, and at intermediate angles via ixing
arm. Machine has been designed according to CE Sa ety Directives.
PEGASUS-02 M / SKAT-02 M : Manual system with base and pneumatic clamps.
PEGASUS-02 P / SKAT-02 P : Portable manual system.
