ATCOM EC64 Manual de usuario

AXE2D+EC64 User Manual

ATCOM®Digital Card AXE2D

User Manual

Version: 2.0

2013-06-03

AXE2D User Manual

www.atcom.cn Email: [email protected]

Release note

Version Changed note Editor Date

1.0 First Release Robert 2011-01-20

2.0 Release the User manual Deniel 2013-06-03

AX1D User Manual

www.atcom.cn Email: [email protected]

Content

Chapter 1 The Introduction of AXE2D...............................................................................................1

Chapter 2 Hardware Introduction........................................................................................................3

Chapter 3 Test Environment................................................................................................................7

Chapter 4 Software Installation...........................................................................................................8

Chapter 5 Software Configuration.................................................................................................... 10

Chapter 6 Reference.......................................................................................................................... 13

AXE2D User Manual

www.atcom.cn Email: [email protected]

Contact ATCOM

The Introduction of ATCOM

ATCOM is the leading VoIP hardware manufacturer in global market. We have been keeping

innovating with customer’s needs oriented , working with partners to establish a total solution for

SMB VoIP with IP phone , IP PBX and Asterisk cards.

With over 10 years’ experience of R&D, manufacturing and service in network and VoIP filed;

mission of creating the biggest value for IP terminals, we commit ourselves in supplying the

competitive IP phone and other terminals for IP PBX, softswitch, IMS, NGN providers and

carriers; supplying the competitive total VoIP solution for SMB market. We keep improving the

customer’s experience and creating the bigger value with our reliable products. Until now , our

VoIP products has been sold to over 60 countries and used by millions of end users.

Contact sales:

Address District C, east of 2nd floor, #3, Crown industry buildings, Chegongmiao

Industry area, Futian district, Shenzhen, China

Tel +(86)755-23487618

Fax +(86)755-23485319

E-mail sales@atcomemail.com

Contact Technical Support:

Tel +(86)755-23481119

E-mail Support@atcomemail.com

Website address: http://www.atcom.cn/

Download Center: http://www.atcom.cn/download.html

AXE2D User Manual

www.atcom.cn Email: [email protected]

Chapter 1 The Introduction of AXE2D

Overview of the AXE2D

AXE2D Asterisk card is the telephony PCI card which supports four ISDN PRI E1/T1/J1 ports,

optional with teleco-grade hardware echo cancellation. Using AXE2D digital PRI card, open

source Asterisk PBX and stand alone PC, users can create their IP PBX telephony solution include

all the sophisticated features of traditional PBX, and extend features such as voicemail in IP PBX.

Features

AXE2D: Dual ISDN PRI E1/T1/J1 ports

Support original Dahdi, Zaptel(No patch)

Support Asterisk, Freeswitch, Yate

Support Elastix, Trixbox, AsteriskNOW, PBX in a Flash

100% compatible with all features of Asterisk PBX

32-bit bus master DMA data exchanges across PCI interface at 132 Mbytes/sec for minimum host

processor intervention

Supports standard telephony and data protocols(Including PRI, CAS, CCS for voice and PPP,

HDLC, Cisco HDLC and Frame Relay for data modes)

Supports chan_ss7 and Openr2

Optional hardware echo cancellation

Select the hardware echo cancellation direction

Applications

ISDN PRI IP PBX

ISDN least cost router

Calling Card Platforms

IVR system

Call Center

Traditional Calls/VoIP Calls Conference

VoIP Gateway

Callback Service

Optional DSP Hardware Echo Cancellation Module

G.168–2002 echo cancellation in hardware

1024 taps/128 ms tail per channel on all channel densities

DTMF decoding and tone recognition

Voice quality enhancement: music protection, acoustic echo control, and adaptive noise reduction

Does not increase the physical size of the card, and no additional slot is required

AXE2D User Manual

www.atcom.cn Email: [email protected]

Voice Modes

Pri CPE and PRI NET:

EuroISDN

4ESS(AT&T)

5ESS(Lucent)

DMS100

Hardware Requirement

1.6-Ghz Pentium IV

512 MB RAM

3.3V or 5V PCI 2.2 slot

PCI Card Dimension

131.5mm (Length)*94mm (height)

Operating System

Linux (all versions, releases and distributions from 1.0 up)

AXE2D User Manual

www.atcom.cn Email: [email protected]

Chapter 2 Hardware Introduction

AXE2D

The Front and Rear View of EC128

LED Red: If the driver of the card is loaded correctly and the /etc/dahdi/system.conf file is

configured correctly, the LED Red of the four ports will be red clearly.

LED Green: If the PRI line is connected correctly, and it synchronizes to the other end

successfully, then the LED Green will be green clearly.

If the PRI line is connected correctly, and it is synchronizing to the other end, then both of the

AXE2D User Manual

www.atcom.cn Email: [email protected]

LED Green and LED Red will be on clearly.

SW1: It is used for selecting E1, T1, J1 mode, by default ATCOM will set it up according to your

requirement before shipping out. Customer can set up E1, T1/J1 like the following:

For E1 Mode For T1 and J1 Mode

SW2: It is used when you have more than one PRI card in your server, if you have two cards in

your server, then turn it to 0 in one card, and turn it to 1 in the other card; if you have four cards in

your server, then turn it to 0,1,2,3 respectively.

SW3: It is used to select the hardware echo cancelation direction, by default we set it up to delete

the echo for local side, if customers want to delete the echo for the far end side, please turn the

buttons to on state.

AXE2D User Manual

www.atcom.cn Email: [email protected]

Delete the echo for local side Delete the echo for the far end side

J17, J18: They are used to connect to other cards, when you have several cards in your server.

Using clock line to connect each other, all of the cards work in one server can synchronize

accurately. If customer have PRI card and analog card in one server, the analog card can

synchronize accurately with telecom in this way, and it is useful for fax.

J18 and J17

JP5: It is used for selecting the PCI power feeding for the card, by default we choose the 3.3v for

the card, customer do not need to reset the jumper; the card can also choose 5.0v for power feedin

g in the case that the 3.3v in the motherboard of PC is not enough for the card, but this

phenomenon happens rarely.

For Choosing 3.3v Power For Choosing 5.0v Power

AXE2D User Manual

www.atcom.cn Email: [email protected]

JP4: It is used for selecting the power feeding for the hardware echo cancellation module, by

default we choose the 3.3v; the module can also choose 5.0v for power feeding in the case that the

3.3v in the motherboard of PC is not enough for the module, but this phenomenon happens rarely.

For the latest version, the module does not need this jumper.

For Selecting 3.3v Power

For Selecting 5.0v Power
