Asus AP1720-E1 Manual de usuario

Dual Intel

Xeon 5U Rackmount Server

533MHz Front Side Bus

AP1720-E1

User Guide

1-1

ASUS AP1720-E1 user guide

This chapter describes the general features

of the barebone server. It includes sections

on front panel and rear panel specifications.

Chapter 1

Product introduction

Chapter 1: Product introduction

1-2

1.1 System package contents

Check your ASUSAP1720-E1 package with the items on the following

table. The package contents vary for 8-SCSI, 4-SCSI, and 4-IDE HDD

configurations. Contact your dealer immediately if any of the items is

damaged or missing.

HDD Bays

Item Description AS8 (8 SCSI ) AS4 (4 SCSI) AI4 (4 IDE)

1) ASUSAK25 5U rackmount chassis with:

•ASUS PC-DL Deluxe motherboard

•450W power supply

•SCSI backplane board

(2 pieces)

(1 piece)

•ASUS U160/320 SCSI card/SCSI cable

•52x CD-ROM drive

•floppy disk drive

•chassis fan

•HDD fan

(2 units)

(1 unit)

•hot-swap SCSI HDD trays

(8 units, including screws for HDDs)

(4 units, including screws for HDDs)

•internal HDD rails (4 pairs)

•chassis roller wheels (4 sets)

•CPU heatsink and fan assembly (2 sets)

•front I/O board

•HDD dummy covers (for IDE bays)

2) AC power cable

3) System screws and cables

4) System keys ( 2 pcs.)

5) Bundled CDs

•AP1720-E1 support CD

•ASWM software CD

•TrendMicro

ServerProtect

6) Documentation

•ASUS AP1720-E1 user guide

•ASUS PC-DL Deluxe user guide

7) Optional items

•ASUS AK25 rackmount rail kit

•AK25 internal HDD cage (non-hot swap)

ASUS AP1720-E1 barebone server

1-3

1.2 System specifications

The ASUS AP1720-E1 is a barebone server system featuring the ASUS

PC-DL Deluxe motherboard. The server supports dual Intel

Xeon™

processors in 604-pin sockets, and includes the latest technologies

through the chipsets embedded on the motherboard.

Refer to the motherboard user guide for more information on internal connectors.

Chassis Pedestal or rackmount 5U with removable front door

bezel and chassis foot stand or roller-wheels.

Motherboard ASUS PC-DL Deluxe (ATX form factor: 12 in x 9.6 in)

Chipset Intel

82875 Memory Controller Hub (MCH)

Intel

82801ER I/O Controller Hub (ICH5R)

Processor Supports dual Intel

Xeon™CPUs up to 3.06+ GHz

with 533MHz FSB

Memory 4 x 184-pin DDR sockets for up to 4GB memory

Supports PC2700/PC2100 unbuffered ECC or

non-ECC DDR DIMMs

LAN Intel

82547EI Gigabit LAN controller

IEEE 1394 TI TSB43AB22A IEEE 1394 controller

RAID Promise

PDC20378 controller

(supports RAID 0/RAID 1/RAID 0+1/Multi-RAID)

Expansion slots 1 x AGP Pro/8X slot

5 x 32-bit/33Mhz 5V PCI slots

Drive bays 1 x 3.25-inch FDD bay

3 x 5.25-inch drive bays

Front I/O 4 x USB 2.0

1 x IEEE 1394 port

Line Out/Microphone ports

Rear panel I/O 1 x Parallel port

2 x Serial ports

1 x RJ-45 port

1 x IEEE 1394 port

4 x USB 2.0 ports

1 x PS/2 keyboard port

1 x PS/2 mouse port

Line In/Line Out/Microphone ports

Management ASUS Server Web-based Management (ASWM) 2.0

Hardware monitors Voltage, temperature, and fan speed monitoring

Automatic System Restart (ASR) feature

Power supply SSI-type 450W power supply

(with 24-pin and 8-pin power plugs)

Chapter 1: Product introduction

1-4

1.3 Front panel features

The AP1720-E1 chassis displays a stylish front bezel with lock. The bezel

covers the system components on the front panel and serves as security.

Open the bezel to access the front panel components.

The drive bays, power and reset

buttons, LED indicators, CD-ROM

drive, floppy drive, and four USB ports

are located on the front panel. For

future installation of 5.25-inch devices,

two drive bays are available.

CD-ROM drive

Floppy disk drive

2 empty 5.25-inch bays

Reset button

Power button

Message LED

HDD access LED

Power LED

4 USB 2.0 ports

Microphone jack

Line Out jack

IEEE 1394 port

Security lock

Drive bays

ASUS AP1720-E1 barebone server

1-5

1.4 ear panel features

The rear panel includes a slot for the motherboard rear I/O ports,

expansion slots, a chassis lock and intrusion switch, a vent for the system

fan, and power supply module.

Power supply module

Expansion slots

Power connector

12cm fan vent

Chassis lock

P/S2 mouse port

P/S2 keyboard port

4 USB 2.0 ports

Parallel port

Gigabit LAN port

SCSI port (optional)

Serial ports

IEEE 1394 port

Audio ports

If you wish to access front I/O ports and floppy disk drive without opening

the bezel, hold the tab and move the sliding panel (rightmost panel) to the

left as shown.

Chapter 1: Product introduction

1-6

1.5 Internal features

The barebone server system includes the basic components as shown.

1. Power supply cage

2. CD-ROM drive

3. 2 x 5.25-inch drive bays

4. first drive cage (upper)

5. second drive cage (lower)

6. HDD fan 1

7. HDD fan 2 (optional)

8. Chassis fan

9. Expansion card lock

10.PC-DL Deluxe motherboard

The lower 4-bay hot swap SCSI drive cage may be changed to an

internal IDE drive cage (non-hot swap) if you wish to install long PCI

cards. The internal drive cage is optional and purchased separately.

AS8 (8-SCSI configuration)

ASUS AP1720-E1 barebone server

1-7

AS4 (4-SCSI configuration)

AI4 (4-IDE configuration)

Chapter 1: Product introduction

1-8

1.6 LED information

The barebone system comes with five LED indicators. Refer to the

following table for the LED status description.

The Power, HDD Access, and Message LEDs are visible even if the

system front bezel is closed.

Power LED (blue)

HDD Access LED (green)

Message LED (red)

Drive status LED (green/red)

Drive activity LED

*SCSI Access Fault-Tolerant Enclosure

LED Icon Display status Description

System

Power LED ON System power ON

Blinking Suspend mode

HDD Access LED OFF No activity

Blinking Read/write data into the HDD

Message LED OFF System is normal; no incoming event

Blinking ASMS indicates a HW monitor event

Hard disk drives

Drive Status LED Green Bridge board connected to backplane

Installed HDD is in good condition

Red HDD failure

Red-Blinking HDD rebuilding using the RAID card

SAF-TE* function

Drive Activity LED Blinking Read/write data into the HDD

3-1

ASUS AP1720-E1 barebone server

This appendix gives information on the

power supply that came with the barebone

server.

Appendix

Power supply
