Asus P5VDC-TVM SE Manual de usuario

Motherboard

P5VDC-TVM

No part of this manual, including the products and software described in it, may be reproduced,

transmitted, transcribed, stored in a retrieval system, or translated into any language in any form

or by any means, except documentation kept by the purchaser for backup purposes, without the

express written permission of ASUSTeK COMPUTER INC. (“ASUS”).

Product warranty or service will not be extended if: (1) the product is repaired, modied or

altered, unless such repair, modication of alteration is authorized in writing by ASUS; or (2)

the serial number of the product is defaced or missing.

ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER

EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE IMPLIED WARRANTIES

OR CONDITIONS OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

IN NO EVENT SHALL ASUS, ITS DIRECTORS, OFFICERS, EMPLOYEES OR AGENTS BE

LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES

(INCLUDING DAMAGES FOR LOSS OF PROFITS, LOSS OF BUSINESS, LOSS OF USE

OR DATA, INTERRUPTION OF BUSINESS AND THE LIKE), EVEN IF ASUS HAS BEEN

ADVISED OF THE POSSIBILITY OF SUCH DAMAGES ARISING FROM ANY DEFECT OR

ERROR IN THIS MANUAL OR PRODUCT.

SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED

FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME

WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY

ASUS. ASUS ASSUMES NO RESPONSIBILITY OR LIABILITY FOR ANY ERRORS OR

INACCURACIES THAT MAY APPEAR IN THIS MANUAL, INCLUDING THE PRODUCTS

AND SOFTWARE DESCRIBED IN IT.

Products and corporate names appearing in this manual may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identication or

explanation and to the owners’ benet, without intent to infringe.

E2569

First Edition

April 2006

iii

Contents

Notices ................................................................................................. v

Safety information .............................................................................. vi

P5VDC-TVM specications summary ..................................................vii

Chapter 1: Product introduction

1.1 Before you proceed .............................................................. 1-2

1.2 Motherboard overview .......................................................... 1-3

1.2.1 Placement direction ................................................ 1-3

1.2.2 Screw holes............................................................. 1-3

1.2.3 Motherboard layout ................................................ 1-4

1.2.4 Layout contents ..................................................... 1-5

1.3 Central Processing Unit (CPU) .............................................. 1-6

1.3.1 Installing the CPU .................................................... 1-6

1.3.2 Installing the CPU heatsink and fan......................... 1-9

1.3.3 Uninstalling the CPU heatsink and fan................... 1-11

1.4 System memory.................................................................. 1-13

1.4.1 DIMM sockets location .......................................... 1-13

1.4.2 Memory Congurations ......................................... 1-13

1.4.3 Installing a DDR2 DIMM ......................................... 1-15

1.4.4 Removing a DDR2 DIMM ........................................ 1-15

1.5 Expansion slots ................................................................... 1-16

1.5.1 Installing an expansion card .................................. 1-16

1.5.2 Conguring an expansion card .............................. 1-16

1.5.3 Interrupt assignments........................................... 1-17

1.5.4 PCI slots ................................................................ 1-18

1.6 Jumpers .............................................................................. 1-19

1.7 Connectors ......................................................................... 1-21

1.7.1 Rear panel connectors .......................................... 1-21

1.7.2 Internal connectors ............................................... 1-22

Contents

Chapter 2: BIOS Setup

2.1 BIOS setup program.............................................................. 2-2

2.2 BIOS menu screen................................................................. 2-3

2.3 Standard BIOS Features ........................................................ 2-5

2.4 Advanced BIOS Features....................................................... 2-9

2.5 Integrated Peripherals......................................................... 2-11

2.6 Power Management Setup .................................................. 2-15

2.7 PC Health Status................................................................. 2-17

2.8 Other items......................................................................... 2-18

Notices

Federal Communications Commission Statement

This device complies with Part 15 of the FCC Rules. Operation is subject to

the following two conditions:

•

This device may not cause harmful interference, and

•

This device must accept any interference received including

interference that may cause undesired operation.

This equipment has been tested and found to comply with the limits for a

Class B digital device, pursuant to Part 15 of the FCC Rules. These limits

are designed to provide reasonable protection against harmful interference

in a residential installation. This equipment generates, uses and can radiate

radio frequency energy and, if not installed and used in accordance with

manufacturer’s instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will

not occur in a particular installation. If this equipment does cause harmful

interference to radio or television reception, which can be determined by

turning the equipment off and on, the user is encouraged to try to correct

the interference by one or more of the following measures:

•

Reorient or relocate the receiving antenna.

•

Increase the separation between the equipment and receiver.

•

Connect the equipment to an outlet on a circuit different from that to

which the receiver is connected.

•

Consult the dealer or an experienced radio/TV technician for help.

Canadian Department of Communications Statement

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus set out in the Radio Interference

Regulations of the Canadian Department of Communications.

This class B digital apparatus complies with Canadian

ICES-003.

The use of shielded cables for connection of the monitor to the graphics

card is required to assure compliance with FCC regulations. Changes

or modications to this unit not expressly approved by the party

responsible for compliance could void the user’s authority to operate

this equipment.

Safety information

Electrical safety

•

To prevent electrical shock hazard, disconnect the power cable from

the electrical outlet before relocating the system.

•

When adding or removing devices to or from the system, ensure that

the power cables for the devices are unplugged before the signal

cables are connected. If possible, disconnect all power cables from the

existing system before you add a device.

•

Before connecting or removing signal cables from the motherboard,

ensure that all power cables are unplugged.

•

Seek professional assistance before using an adapter or extension

cord. These devices could interrupt the grounding circuit.

•

Make sure that your power supply is set to the correct voltage in your

area. If you are not sure about the voltage of the electrical outlet you

are using, contact your local power company.

•

If the power supply is broken, do not try to fix it by yourself. Contact

a qualified service technician or your retailer.

Operation safety

•

Before installing the motherboard and adding devices on it, carefully

read all the manuals that came with the package.

•

Before using the product, make sure all cables are correctly connected

and the power cables are not damaged. If you detect any damage,

contact your dealer immediately.

•

To avoid short circuits, keep paper clips, screws, and staples away from

connectors, slots, sockets and circuitry.

•

Avoid dust, humidity, and temperature extremes. Do not place the

product in any area where it may become wet.

•

Place the product on a stable surface.

•

If you encounter technical problems with the product, contact a

qualified service technician or your retailer.

The symbol of the crossed out wheeled bin indicates that the product

(electrical and electronic equipment) should not be placed in municipal

waste. Check local regulations for disposal of electronic products.

vii

P5VDC-TVM specications summary

(continued on the next page)

CPU

Chipset

Front Side Bus

Memory

Expansion slots

Storage

Audio

LAN

USB

BIOS features

Rear panel

LGA775 socket for Intel®Pentium®4/Celeron processor

Compatible with Intel®Mainstream/Value FMB

processors

Supports Intel®Hyper-Threading Technology

Northbridge: VIA P4M800 PRO

Southbridge: VIA VT8237R Plus

800/533 MHz

2 x 240-pin DIMM sockets support unbufferred and

non-ECC

533 MHz DDR memory modules

3 x PCI slots

VIA VT8237R Plus Southbridge supports:

- 4 x Ultra ATA 133/100/66 hard disk drives

- 2 x Serial ATA hard disk drives

Realtek®ALC655 6-channel CODEC

Realtek®RTL 8110C 10/100 Mbps LAN controller

Supports up to 8 USB 2.0 ports

4 MB LPC Flash ROM, Award BIOS, Green, PnP, DMI, WfM

2.0, ACPI 2.0a, SM BIOS 2.3

1 x PS/2 mouse port

1 x Parallel port

1 x LAN (RJ-45) port

6-channel audio ports

4 x USB 2.0 ports

1 x VGA port

1 x Serial port

1 x PS/2 keyboard port

viii

1 x Floppy disk drive connector

2 x IDE connectors

2 x Serial ATA connectors

1 x CPU fan connector

1 x Chassis fan connector

4 x USB 2.0 connectors

1 x 20-pin ATX power connector

1 x 4-pin ATX 12 V power connector

1 x Front panel audio connector

1 x CD/AUX audio connector

1 x S/PDIF Out connector

1 x Serial port connector

System panel connector

ATX power supply (with 20-pin and 4-pin 12 V plugs)

ATX 12 V 2.0 compliant

Micro ATX form factor: 9.6 in x 9.0 in (24.5 cm x 23.0 cm)

P5VDC-TVM specications summary

*Specications are subject to change without notice.

Internal

connectors

Power

requirement

Form factor

1-1ASUS P5VDC-TVM

Product

introduction

This chapter describes the motherboard

features and the new technologies

it supports.

1-2 Chapter 1: Hardware information

Onboard LED

The motherboard comes with a standby power LED that lights up to

indicate that the system is ON, in sleep mode, or in soft-off mode.

This is a reminder that you should shut down the system and unplug

the power cable before removing or plugging in any motherboard

component. The illustration below shows the location of the onboard

LED.

•

Unplug the power cord from the wall socket before touching any

component.

•

Use a grounded wrist strap or touch a safely grounded object or

a metal object, such as the power supply case, before handling

components to avoid damaging them due to static electricity.

•

Hold components by the edges to avoid touching the ICs on them.

•

Whenever you uninstall any component, place it on a grounded

antistatic pad or in the bag that came with the component.

•

Before you install or remove any component, ensure that the ATX

power supply is switched off or the power cord is detached from

the power supply. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

1.1 Before you proceed

Take note of the following precautions before you install components into

the system.

P5VDC-TVM Onboard LED

SB_PWR

Standby

Power

OFF

Powered

Off

P5VDC-TVM

Otros manuales para P5VDC-TVM SE

Tabla de contenidos

Otros manuales de Placa madre de Asus

Asus

Asus M2NBP-VM CSM Manual de usuario

Asus

Asus PRIME A320M-R Manual de usuario

Asus

Asus TUF X470-PLUS GAMING Manual de usuario

Asus

Asus A7V8X-MX SE Manual técnico

Asus

Asus PRIME B460M-AJ Manual de usuario

Asus

Asus P8H61-M EVO Manual de usuario

Asus

Asus P I-P55TP4N Manual de usuario

Asus

Asus P2B-VM Manual de usuario

Asus

Asus PRIME X670E-P Manual de usuario

Asus

Asus K8V Deluxe Manual de usuario

Asus

Asus B85-PRO GAMER Manual de usuario

Asus

Asus P5KPL/1600 Manual de usuario

Asus

Asus PRIME Z270-P Manual de usuario

Asus

Asus TUF GAMING B560M-PLUS WIFI Manual de usuario

Asus

Asus TX97-N Manual de usuario

Asus

Asus F1A75-M PRO R2.0 Manual de usuario

Asus

Asus PRIME H410M-K Manual de usuario

Asus

Asus PRIME B360M-C Manual de usuario

Asus

Asus Rambus P3C-E Manual de usuario

Asus

Asus H81-M2 Manual de usuario

Asus

Asus P5G41-M LX2 Manual de usuario

Asus

Asus MEB-VM Manual de usuario

Asus

Asus SK8N Manual de usuario

Asus

Asus EX-B360M-V Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

ASROCK

ASROCK ROMED8-2T Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

EPC

EPC EPC9147C Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario

Epson

Epson S5U13700P00C000 Manual de usuario

Gigabyte

Gigabyte GA-K8N Ultra-SLI Manual de usuario

Albatron

Albatron PX925XE Series Manual de usuario
