Astro Pneumatic Tool 78340 Manual de usuario
78340
MODEL: PRODUCT TYPE:
Page 1
WARNING
www.astrotools.com
WARNING
MADE IN TAIWAN
Study, understand and follow all instructions provided with this
product. Read these instructions carefully before installing,
operating, servicing or repairing this tool. Keep these instructions
in a safe accessible place.
INTENDED USE OF THE TOOL
DO NOT DISCARD – GIVE TO USER
8PC 3/8" DRIVE NANO
PINLESS UNIVERSAL IMPACT SOCKETS
- SAE
• Pinless design allows a full 360° of freedom for the
universal head to angle and rotate
• Astro’s Nano form factor, up to 11% shorter than
standard low-profile universal impact sockets
• Forged CRO-MO with lifetime warranty
PLEASE DO NOT RETURN ANY PRODUCT WITHOUT CALLING
1-800-221-9705 FOR INSTRUCTIONS
PRODUCT INFORMATION:
LIFETIME WARRANTY
Before Use
When unpacking, check the parts diagram and part
number listing on page 2 to make sure all parts are
included. If any parts are missing or damaged, please
call your distributor.
• Astro Pneumatic Tool Co. warrants our products to the original user against
defective material or workmanship for Lifetime Warranty (except where noted
on our price schedule) from the date of 1st use. Astro reserves the right to
determine whether the product failed because of defective material,
workmanship or other causes and to charge back for missing parts. Astro
Pneumatic Tool Co., at its discretion, will repair products covered under this
warranty free of charge.
The distributor should direct the original user to return the product (with the
exceptions listed below) with the distributor’s name, address, adequate proof
of date of purchase or a copy of warranty card, and a short note explaining
the problem. Failures caused by accident, alteration, or misuse are not
covered by this warranty.
• If one part of this product fails, please do not return the entire product.
Astro will replace free of charge component parts of this product.
Items included in this category include but are not limited to kits, hand
tool kits and any other product where there are multiple items or
components that make up the unit. Please contact the phone number
below in order to obtain the replacement components covered under
warranty.
• Astro Pneumatic Tool Co. or its authorized service representatives must
perform all warranty repairs. Any repair to the product by unauthorized
service representatives voids this warranty. The rights under this warranty
are limited to the original user and may not be transferred to subsequent
owners.
• This warranty is in lieu of all other warranties, expressed or implied, including
warranties of merchantability and fitness for a particular purpose. Some
states do not allow the exclusion of limitations of incidental or consequential
damages so the above limitations may not apply to you.
The 78340 Nano Pinless Universal impact Socket Set is
designed to be used with a 3/8" drive impact wrench to drive
hex fasteners. Do not use this tool outside of the designed
intent. Never modify the tool for any other purpose or use.
• Use of this product can expose you to chemicals
including ethylene glycol, gasoline vapors and
engine exhaust, which are known to the State of
California to cause cancer, birth defects, or
reproductive harm. For more information, visit
www.P65Warnings.ca.gov. Always wear ANSI
approved safety equipment, safety glasses and
clothing when using this product. Study,
understand, and follow all instructions provided
with this product. Failure to read and follow all
warnings and operating instructions may result in
damages and serious injury or death.
• Always wear ANSI approved goggles when using
this product. (Users and Bystanders).
• Never use this tool for any application other than
for
which it was designed.
• Only use accessories designed for this tool.
• Never alter or modify this tool in any way.
•Improper operation and/or maintenance of the tool,
modification of the tool, or use of the tool with
accessories not designed for it could result in
serious injury or death.
• Always select the correct accessories of the
correct size and design for the job that you are
attempting to perform.
• Always work in a clean, safe, well-lit, organized and
adequately equipped area.
•Do not begin repairs without assurance that
vehicle is in secure position, and will not move
during repair.
8PC 3/8" DRIVE NANO
PINLESS UNIVERSAL IMPACT SOCKETS - SAE
5/16 3/8 7/16 1/2 9/16 5/8 3/4
11/16
5/16
3/8 7/16
1/2
9/16
5/8 3/4
11/16
78340
Call 1.800.221.9705 for questions concerning performance of the product
or other inquiries.
372 Old US Highway 52 South
Mount Airy, NC 27030
Page 2
MODEL: PRODUCT TYPE:
PARTS BREAKDOWN
901
1
2
3
4
5
6
7
8
9
10
Index Part No. Description Qty
Parts List
1
1
1
1
1
1
1
1
1
2
1 2 3 4 5 6 7 8
910 10
7834001
7834002
7834003
7834004
7834005
7834006
7834007
7834008
7831011
7831012
5/16"Nano Impact Socket
3/8"Nano Impact Socket
7/16"Nano Impact Socket
1/2"Nano Impact Socket
9/16"Nano Impact Socket
5/8"Nano Impact Socket
11/16"Nano Impact Socket
3/4"Nano Impact Socket
Aluminum Socket Holder
Black Rubber Sheath
8PC 3/8" DRIVE NANO
PINLESS UNIVERSAL IMPACT SOCKETS
- SAE
5/16
5/16
3/8
3/8
1/2
1/2
9/16
9/16
5/8
5/8
11/16
11/16
3/4
3/4
7/16
7/16
