:: Introduction
:: RC14B / 14T RTR Features
:: Additional
:: Other Helpful Items
Thank you for purchasing this Team Associated product. This assembly manual contains instructions and tips for building and
maintaining your new vehicle. Please take a moment to read through the manual and familiarize yourself with the steps.
We are continually changing and improving our designs; therefore, actual parts may appear slightly different than the illustrations.
New parts will be noted on supplementary sheets located in the appropriate parts bags. Check each bag for these sheets before
you start to build.
• 2.4GHz 2-channel radio system
• High-Torque Digital Servo with spring-style servo saver
• Powerful Reedy 4500kV Brushless Motor
• Water-resistant high-power Reedy brushless speed control with T-plug connector and LiPo low-voltage cutoff
• Three sealed differentials
• Threaded coil over shock absorbers
• Adjustable turnbuckles
• Adjustable inserts for caster blocks and rear hubs
• Aluminum steering rack
• Front universal driveshafts
• Sleek and stylish body
• Molded tub chassis with covered center driveshaft
• Aluminum center driveshaft
Associated Electrics, Inc.
26021 Commercentre Dr.
Lake Forest, CA 92630
http://www.RC10.com · http://twitter.com/Team_Associated · http://www.instagram.com/teamassociatedrc/ · http://www.facebook.com/TeamAssociated/
Customer Service
Tel: 949.544.7500
Fax: 949.544.7501
Your new Reflex 14B/14T RTR comes assembled. The following items are needed for completion
• 6-cell NiMh or 2 LiPo battery • Suitable battery charger • (4) AA batteries
Tools included: • Multi-wrench
• Silicone Shock Fluid (Refer to catalog for complete listings) • Silicone Diff Fluid (Refer to catalog for complete listings)
• Body Scissors (AE Part # 1737) • Reamer / Hole Punch (#1499) • Shock Pliers (#1675) • Wire Cutters
• FT Hex/Nut Wrenches (AE Part # 1519)• Needle Nose Pliers • Hobby Knife • Soldering Iron
• Calipers or a Precision Ruler • Green Slime shock lube (AE Part # 1105)
• FT Dual Turnbuckle Wrench (#1114) • FT Universal Tire Balancer (#1498)
:: Table of Contents
1................... Cover
2................... Introduction
3...................1:1 Hardware “Fold Out”
4 - 5............. Quick Start Guide
6 - 17............Steps 1- 36
18.................Tuning Tips
19 - 25....... Catalog
26................Back Cover
:: Notes
This symbol indicates a special note or instruction in the manual.
!
There is a 1:1 hardware foldout page in the front of the manual. To check
the size of a part, line up your hardware with the correct drawing until you
find the exact size. Each part in the foldout has a number assigned to it
for ordering replacement parts.
3
:: Hardware - 1:1 Scale View
3x2.5mm (31500)
3x3mm (25225)
3x8mm (4670)
Set Screws
Notes:
M2.5 Locknut (89215, 21546)
M4 Locknuts:
Serrated Steel (Silver)(91826)
Flanged (Black) (91148)
FT Aluminum (Blue) (31551)
Serrated Aluminum (Black) (91738)
Nuts (lock/plain)
Flat Head (fhcs)
2.5x10mm (31350)
2.5x6mm (31520)
Button Head (bhcs)
2.6x6mm (21546)
2.6x8mm (21546)
2.6x10mm (21546)
Button Head (bhst)
Ball Bearings
4x7x2.5mm (21512)
4x8x3mm (21512)
8x12x3.5mm (21512)
2.7x6.7x0.5mm (21546)
4x8x0.5mm (21516)
Shims and Washers
Flat Head (fhst)
2x8mm (21546)
2.6x8mm (21546)
2.6x10mm (21546)
Cap Head (shcs)
2.5x12mm (8691)
4
:: Quick Start Guide
:: Quick Start Guide - (cont.)
:: Quick Start Guide - (cont.)
Battery Charging Steps and Safety:
Remove the battery from the vehicle before charging.
Place battery on a fire resistant surface.
Avoid any contact with water or other liquids.
Be sure to select the correct charging mode for the type
of battery you are charging.
ALWAYS use a compatible charger for charging your batteries.
Caution: Never leave the battery unattended while charging.
Always disconnect the charger from the power source when
finished charging.
Caution: Always disconnect the battery when you are
finished driving the vehicle.
Battery Installation:
1. Install the battery with the battery wires directed
towards the rear of the vehicle.
2. Secure the battery strap using two body clips.
Peak Detection
Quick Charger
1 2
Battery Notes and Tip:
Connect the battery as shown.
Disconnect the battery when not in use!
LiPo: LiPo batteries (lithium polymer) are high current
rechargeable batteries. LiPo batteries offer extended run time
and peak performance over NiMH batteries. They require a
peak detection charger designed specifically for LiPo batteries.
These batteries require special care and handling.
LiPo batteries are recommended for advanced users only!
ALWAYS charge a LiPo battery in LiPo mode.
5
7/18
:: Quick Start Guide - (cont.)
:: Quick Start Guide - (cont.)
Radio System Tuning and Controls:
RULE: Transmitter on First/Vehicle on Second,
Vehicle off First/ Transmitter off Last!
1) Slide the battery cover to remove cover.
2) Install alkaline or rechargeable AA size
batteries into the battery holder.
3) Slide the battery cover back into place making
sure it is completely closed and secure.
4) Turn the power ON. If the power indicator LED
fails to light, check the batteries for insufficient
contact or incorrect polarity.
On/Off Switch
Radio System Tuning and Controls:
DO NOT hold the trigger when turning on the radio.
If using optional battery for transmitter, be sure to plug
it in correctly. Plugging in a battery backwards can
cause damage.
Refer to Radio owners manual for more in-depth
instructions on radio operation and functions.
Throttle set to Neutral!
Adjust steering
trim so front
wheels point
straight.
Neutral
Push trigger
for Brake
Pull trigger
for Throttle Install body and body clips.
Ready to go!
Adjust steering
trim so front
wheels point
straight.
Install body and body clips.
:: Step 3
:: Step 2
6
:: Step 1
Build 2 (1 front, 1 rear)
#6588
black grease
21529
Diff
case
21530
O-Ring
3.8 x 1mm
21530
O-Ring
3.8 x 1mm
21516
Washer
4x8x0.5mm
21516
Washer
4x8x0.5mm
21524
Diff
outdrive
21529
Diff
cap
21524
Diff
outdrive
x3
x3 x2
21529
Diff
planetary
gear
21546
M2x8mm
FHST
21512
8x12x3.5mm
bearing
21526
Diff ring
gear (37T)
21529
Diff
cross pin
21529
Diff sun
gear
21529
Diff sun
gear
21516
Pin
1.5 x 6mm
21516
Pin
1.5 x 6mm
:: Step 6
:: Step 5
7
:: Step 4
#6588
black grease
21529
Diff
case
21530
O-Ring
3.8 x 1mm
21516
Washer
4x8x0.5mm
21516
Washer
4x8x0.5mm
21530
O-Ring
3.8 x 1mm
21529
Diff
cap
21524
Diff
outdrive
21524
Center
diff
shaft
21529
Diff
cross pin
x3
x3
21512
8x12x3.5mm
bearing
21512
4x8x3mm
bearing
21512
8x12x3.5mm
bearing
21546
M2x8mm
FHST
21529
Diff
planetary
gear
21516
Pin
1.5 x 6mm
21516
Pin
1.5 x 6mm
21516
Pin
1.5 x 6mm
21529
Diff sun
gear
21526
Pinion
gear
(15T)
21529
Diff sun
gear
8
:: Step 9
:: Step 8
:: Step 7
21524
Center
diff
outdrive
x10
x4
x2
21546
M2.6x8mm
BHST
21504
Gear box
cap, front
21504
Drive shaft
cover
21504
Drive shaft
cap
21504
Gear box
cap, rear
4670
3x8mm
set screw
21500
Chassis
21512
4x8x3mm
bearing
21516
Pin
1.5 x 6mm
21520
Drive
shaft
21526
Pinion
gear
(15T)
Top of set screw head
should be flush with
the top of the chassis
!
9
:: Step 12
:: Step 11
:: Step 10
14B 14T
x2
x3
x3
x2 x2
x2
x4
x2
x2
x2
x2
x2
21546
M2.6x8mm
BHST
21546
M2.6x8mm
BHST 21546
M2.6x8mm
BHST
21546
Washer
2.7x0.5mm
21546
Washer
2.7x0.5mm
21505
Wire clip
21505
Servo
Mount
21504
Body mount,
front (14B)
21504
Body mount,
front (14T)
21509
Hat
bushing
21510
Steering
post
21512
4x7x2.5mm
bearing
31520
M2.5x6mm
BHCS
31520
M2.5x6mm
BHCS
21504
Top plate 21504
Top plate
89215
M2.5
locknut
21522
Ball stud
12.5mm
21509
Steering
rack
21505
Steering
bellcrank
(left)
21505
Steering
bellcrank
(right)
x2
x2
x4
x2
21546
M2.5x10mm
FHST
31350
M2.5x10mm
FHCS
21546
M2.5x10mm
FHST
21546
M2.6x10mm
BHST
21505
ESC mount
21505
Battery
Mount,
(rear)
21505
Battery
Mount,
(front)
10
:: Step 15
:: Step 14
:: Step 13
x4
x2
x2
x2
x2
x4
x2
21546
M2.6x8mm
BHST
21546
M2.6x8mm
BHST
21511
Inner
hinge pin,
3x47mm
21502
Front
arms
21502
Front arm
spacers
21501
Arm
mount, A
21501
Arm
mount, B
21546
M2.6x8mm
BHST
21503
Wing
mount
brace
21546
M2.6x10mm
BHST
21503
Shock
tower,
front
21503
Shock
tower,
rear
21505
Shock
tower
support,
rear
x2
x2
x2
x2
21522
Ball stud
12.5mm
21522
Ball stud
12.5mm
21501
Arm mount
bushing
21503
Wing
mounts
(right, left)
x4
21546
M2.6x10mm
BHST
