ASROCK Z77 Pro4 Manual de usuario

Z77 Pro4

User Manual

Version 1.1

Published July 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1 Introduction......................................................... 5

1.1 Package Contents ......................................................... 5

1.2 Specications................................................................. 6

1.3 Motherboard Layout....................................................... 13

1.4 I/O Panel ...................................................................... 14

2 Installation........................................................... 16

2.1 Screw Holes................................................................... 16

2.2 Pre-installation Precautions ......................................... 16

2.3 CPU Installation ............................................................. 17

2.4 Installation of Heatsink and CPU fan ............................. 19

2.5 Installation of Memory Modules (DIMM) ........................ 20

2.6 Expansion Slots (PCI and PCI Express Slots) .................... 22

2.7 CrossFireXTM and Quad CrossFireXTM Operation Guide 23

2.8 Dual Monitor and Surround Display Features................ 27

2.9 ASRock Smart Remote Installation Guide ..................... 30

2.10 Jumpers Setup .......................................................... 31

2.11 Onboard Headers and Connectors ............................ 32

2.12 Serial ATA (SATA) / Serial ATA2 (SATA2) Hard Disks

Installation ................................................................. 38

2.13 Serial ATA3 (SATA3) Hard Disks Installation ............. 38

2.14 Hot Plug and Hot Swap Functions for SATA / SATA2

HDDs ............................................................................ 39

2.15 Hot Plug and Hot Swap Functions for SATA3 HDDs ..... 39

2.16 SATA / SATA2 / SATA3 HDD Hot Plug Feature and

Operation Guide ........................................................ 40

2.17 Driver Installation Guide ............................................ 42

2.18 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM

64-bit With RAID Functions ....................................... 42

2.19 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

/ XP / XP 64-bit Without RAID Functions ................... 43

2.19.1 Installing Windows®XP / XP 64-bit Without RAID

Functions............................................................ 43

2.19.2 Installing Windows®7 / 7 64-bit / VistaTM /

VistaTM 64-bit Without RAID Functions............... 44

3 UEFI SETUP UTILITY ................................................. 45

3.1 Introduction .................................................................... 45

3.1.1 UEFI Menu Bar .................................................... 45

3.1.2 Navigation Keys ................................................... 46

3.2 Main Screen................................................................... 46

3.3 OC Tweaker Screen ...................................................... 47

3.4 Advanced Screen........................................................... 52

3.4.1 CPU Conguration ............................................... 53

3.4.2 North Bridge Conguration................................... 55

3.4.3 South Bridge Conguration.................................. 56

3.4.4 Intel(R) Rapid Start Technology ........................... 57

3.4.5 Intel(R) Smart Connect Technology ..................... 58

3.4.6 Storage Conguration .......................................... 59

3.4.7 Super IO Conguration ........................................ 60

3.4.8 ACPI Conguration............................................... 61

3.4.9 USB Conguration ............................................... 62

3.5 Hardware Health Event Monitoring Screen ................... 63

3.6 Boot Screen ................................................................... 64

3.7 Security Screen ............................................................. 65

3.8 Exit Screen .................................................................... 66

4 Software Support................................................. 67

4.1 Install Operating System................................................ 67

4.2 Support CD Information ................................................. 67

4.2.1 Running Support CD............................................ 67

4.2.2 Drivers Menu........................................................ 67

4.2.3 Utilities Menu........................................................ 67

4.2.4 Contact Information.............................................. 67

Chapter 1: Introduction

Thank you for purchasing ASRock Z77 Pro4 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contains introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contains the congura-

tion guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might be

updated, the content of this manual will be subject to change without no-

tice. In case any modications of this manual occur, the updated version

will be available on ASRock website without further notice. You may nd

the latest VGA cards and CPU support lists on ASRock website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock Z77 Pro4 Motherboard

(ATX Form Factor: 12.0-in x 7.9-in, 30.5 cm x 20.1 cm)

ASRock Z77 Pro4 Quick Installation Guide

ASRock Z77 Pro4 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-

bit, it is recommended to set the BIOS option in Storage Conguration to

AHCI mode. For the BIOS setup, please refer to the “User Manual” in our

support CD for details.

1.2 Specifications

Platform - ATX Form Factor: 12.0-in x 7.9-in, 30.5 cm x 20.1 cm

- All Solid Capacitor design

CPU - Supports 3rd and 2nd Generation Intel®CoreTM i7 / i5 / i3 in

LGA1155 Package

- Digi Power Design

- 4 + 2 Power Phase Design

- Supports Intel®Turbo Boost 2.0 Technology

- Supports Intel®K-Series unlocked CPU

- Supports Hyper-Threading Technology (see CAUTION 1)

- Supports Intel®Rapid Start Technology and Smart Connect

Technology with Intel®Ivy Bridge CPU

Chipset - Intel®Z77

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 2)

- 4 x DDR3 DIMM slots

- Supports DDR3 2800+(OC)/2400(OC)/2133(OC)/1866(OC)/

1600/1333/1066 non-ECC, un-buffered memory

- Max. capacity of system memory: 32GB (see CAUTION 3)

- Supports Intel® Extreme Memory Prole (XMP)1.3/1.2

Expansion Slot - 1 x PCI Express 3.0 x16 slot (PCIE2: x16 mode)

(see CAUTION 4)

* PCIE 3.0 is only supported with Intel®Ivy Bridge CPU. With

Intel®Sandy Bridge CPU, it only supports PCIE 2.0.

- 1 x PCI Express 2.0 x16 slot (PCIE3: x4 mode)

- 1 x PCI Express 2.0 x 1 slot

- 3 x PCI slots

- Supports AMD Quad CrossFireXTM and CrossFireXTM

Graphics * Intel®HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU

integrated.

- Supports Intel®HD Graphics Built-in Visuals: Intel®Quick

Sync Video, Intel®InTruTM 3D, Intel®Clear Video HD

Technology, Intel®InsiderTM, Intel®HD Graphics 2500/4000,

Intel® Advanced Vector Extensions (AVX)

- Pixel Shader 5.0, DirectX 11 with Intel®Ivy Bridge CPU.

Pixel Shader 4.1, DirectX 10.1 with Intel®Sandy Bridge CPU

- Max. shared memory 1760MB (see CAUTION 5)

- Three VGA Output options: D-Sub, DVI-D and HDMI

(see CAUTION 6)

- Supports HDMI 1.4a Technology with max. resolution up to

1920x1200 @ 60Hz

- Supports DVI with max. resolution up to 1920x1200 @ 60Hz

- Supports D-Sub with max. resolution up to 2048x1536 @

75Hz

- Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI (Compliant HDMI

monitor is required) (see CAUTION 7)

- Supports HDCP function with DVI and HDMI ports

- Supports Full HD 1080p Blu-ray (BD) / HD-DVD playback

with DVI and HDMI ports

Audio - 7.1 CH HD Audio with Content Protection

(Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

- Supports THX TruStudioTM

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Keyboard Port

- 1 x D-Sub Port

- 1 x DVI-D Port

- 1 x HDMI Port

- 1 x Optical SPDIF Out Port

- 6 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Rear Speaker/Central/Bass/Line in/Front

Speaker/Microphone (see CAUTION 8)

SATA3 - 2 x SATA3 6.0 Gb/s connectors by Intel®Z77, support RAID

(RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage and

Intel Smart Response Technology), NCQ, AHCI and Hot

Plug functions

- 2 x SATA3 6.0 Gb/s connectors by ASMedia ASM1061,

support NCQ, AHCI and Hot Plug functions

USB3.0 - 2 x Rear USB 3.0 ports, support USB 1.0/2.0/3.0 up to

5Gb/s

- 1 x Front USB 3.0 header (supports 2 USB 3.0 ports),

supports USB 1.0/2.0/3.0 up to 5Gb/s

Connector - 4 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5, RAID 10, Intel Rapid Storage and Intel

Smart Response Technology), NCQ, AHCI and Hot Plug

functions

- 4 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x COM port header

- 1 x HDMI_SPDIF header

- 1 x Power LED header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 2 x USB 2.0 headers (support 4 USB 2.0 ports)

- 1 x USB 3.0 header (supports 2 USB 3.0 ports)

BIOS Feature - 64Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU Core, IGPU, DRAM, 1.8V PLL, VTT, VCCSA Voltage

Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, ASRock MAGIX

Multimedia Suite - OEM

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 9)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 10)

- ASRock APP Charger (see CAUTION 11)

- ASRock SmartView (see CAUTION 12)

- ASRock XFast USB (see CAUTION 13)

- ASRock XFast LAN (see CAUTION 14)

- ASRock XFast RAM (see CAUTION 15)

- ASRock Crashless BIOS (see CAUTION 16)

- Lucid Virtu Universal MVP (see CAUTION 17)

* Lucid Virtu Universal MVP can be supported only with

processors which are GPU integrated.

- ASRock On/Off Play Technology (see CAUTION 18)

- Hybrid Booster:

WARNING

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may affect your system’s stability, or

even cause damage to the components and devices of your system. It should be

done at your own risk and expense. We are not responsible for possible damage

caused by overclocking.

- CPU Frequency Stepless Control (see CAUTION 19)

- ASRock U-COP (see CAUTION 20)

- Boot Failure Guard (B.F.G.)

- Combo Cooler Option (C.C.O.) (see CAUTION 21)

- Good Night LED

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan (Allows Chassis Fan Speed Auto-

Adjust by CPU Temperature)

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore

OS - Microsoft®Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit /

XP / XP 64-bit compliant (see CAUTION 22)

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 23)

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. About the settings of “Hyper Threading Technology”, please check page

53.

2. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 20 for proper installation.

3. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows®7 /

VistaTM / XP. For Windows®OS with 64-bit CPU, there is no such limita-

tion. You can use ASRock XFast RAM to utilize the memory that Win-

dows®cannot use.

4. Only PCIE2 slot supports Gen 3 speed. To run the PCI Express in Gen

3 speed, please install an Ivy Bridge CPU. If you install a Sandy Bridge

CPU, the PCI Express will run only at PCI Express Gen 2 speed.

5. The maximum shared memory size is dened by the chipset vendor and

is subject to change. Please check Intel®website for the latest informa-

tion.

6. You can choose to use two of the three monitors only. D-Sub, DVI-D and

HDMI monitors cannot be enabled at the same time. Besides, with the

DVI-to-HDMI adapter, the DVI-D port can support the same features as

the HDMI port.

7. xvYCC and Deep Color are only supported under Windows®7 64-bit /

7. Deep Color mode will be enabled only if the display supports 12bpc

in EDID. HBR is supported under Windows®7 64-bit / 7 / VistaTM 64-bit /

VistaTM.

8. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 14

for proper connection.

9. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune dif-

ferent system functions in a user-friendly interface, which includes Hard-

ware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hardware

Monitor, it shows the major readings of your system. In Fan Control, it

shows the fan speed and temperature for you to adjust. In Overclocking,

you are allowed to overclock CPU frequency for optimal system per-

formance. In OC DNA, you can save your OC settings as a prole and

share it with your friends. Your friends then can load the OC prole to

their own system to get the same OC settings. In IES (Intelligent Energy

Saver), the voltage regulator can reduce the number of output phases to

improve efciency when the CPU cores are idle without sacricing com-

puting performance. Please visit our website for the operation procedures

of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

10. ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

Otros manuales para Z77 Pro4

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK TRX40 CREATOR Manual de usuario

ASROCK

ASROCK A785GXH128M Manual de usuario

ASROCK

ASROCK M3A790GXH 128M - V1.0 Manual de usuario

ASROCK

ASROCK P55 DELUXE - V1.1 Manual de usuario

ASROCK

ASROCK P81 Pro3 Manual de usuario

ASROCK

ASROCK B75M R2.0 Manual de usuario

ASROCK

ASROCK Z690 PRO RS Manual de usuario

ASROCK

ASROCK 880GM-LE FX Manual de usuario

ASROCK

ASROCK M3A785GM-LE Manual de usuario

ASROCK

ASROCK N68-VGS3 FX Manual de usuario

ASROCK

ASROCK N68-GS4 FX R2.0 Manual de usuario

ASROCK

ASROCK Super Alloy B660M PG Riptide Manual de usuario

ASROCK

ASROCK K8NF4G-VSTA Manual de usuario

ASROCK

ASROCK K7VT2 Manual de usuario

ASROCK

ASROCK A75M-HVS Manual de usuario

ASROCK

ASROCK IMB-380-D Manual de usuario

ASROCK

ASROCK IMB-192 Manual de servicio

ASROCK

ASROCK ALIVENF6P-VSTA Manual de usuario

ASROCK

ASROCK K10N78HSLI-GLAN Manual de usuario

ASROCK

ASROCK FM2A88M Pro3+ Manual de usuario

ASROCK

ASROCK B75M-DGS Manual de usuario

ASROCK

ASROCK SBC-311 Manual de usuario

ASROCK

ASROCK K10N750SLI-110DB Manual de usuario

ASROCK

ASROCK Q1900M Pro3 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
