Version 1.0

Published May 2020

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian

Consumer Law. You are entitled to a replacement or refund for a major failure and

compensation for any other reasonably foreseeable loss or damage caused by our

goods. You are also entitled to have the goods repaired or replaced if the goods fail

to be of acceptable quality and the failure does not amount to a major failure. If

you require assistance please call ASRock Tel : +886-2-28965588 ext.123 (Standard

International call charges apply)

e terms HDMI® and HDMI High-Denition Multimedia Interface, and the

HDMI logo are trademarks or registered trademarks of HDMI Licensing LLC in the

United States and other countries.

CE Warning

is device complies with directive 2014/53/EU issued by the Commision of the European

Community.

is equipment complies with EU radiation exposure limits set forth for an uncontrolled

environment.

is equipment should be installed and operated with minimum distance 20cm between

the radiator & your body.

Operations in the 5.15-5.35GHz band are restricted to indoor usage only.

Radio transmit power per transceiver type

Function Frequency Maximum Output Power (EIRP)

WiFi

2400-2483.5 MHz 18.5 + / -1.5 dbm

5150-5250 MHz 21.5 + / -1.5 dbm

5250-5350 MHz 18.5 + / -1.5 dbm (no TPC)

21.5 + / -1.5 dbm (TPC)

5470-5725 MHz 25.5 + / -1.5 dbm (no TPC)

28.5 + / -1.5 dbm (TPC)

Bluetooth 2400-2483.5 MHz 8.5 + / -1.5 dbm

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 9

1.4 I/O Panel 11

1.5 WiFi-802.11ax Module and ASRock WiFi 2.4/5 GHz

Antenna 14

1.6 ASRock Thunderbolt™ 3 Module 15

Chapter 2 Installation 19

2.1 Installing the CPU 20

2.2 Installing the CPU Fan and Heatsink 23

2.3 Installing Memory Modules (DIMM) 24

2.4 Expansion Slots (PCI Express Slots) 26

2.5 Onboard Headers and Connectors 27

2.6 Smart Switches 33

2.7 Dr. Debug 35

2.8 CrossFireXTM , 3-Way CrossFireXTM and Quad CrossFireXTM

Operation Guide 41

2.8.2 Installing Three CrossFireXTM-Ready Graphics Cards 43

2.9 M.2_SSD (NGFF) Module Installation Guide

(M2_1 and M2_2 ) 45

2.10 M.2_SSD (NGFF) Module Installation Guide (M2_3) 50

Chapter 3 Software and Utilities Operation 54

3.1 Installing Drivers 54

3.2 ASRock Motherboard Utility (A-Tuning) 55

3.2.1 Installing ASRock Motherboard Utility (A-Tuning) 55

3.2.2 Using ASRock Motherboard Utility (A-Tuning) 55

3.3 ASRock Live Update & APP Shop 58

3.3.1 UI Overview 58

3.3.2 Apps 59

3.3.3 BIOS & Drivers 62

3.3.4 Setting 63

3.4 Nahimic Audio 64

3.5 ASRock Polychrome SYNC 65

Chapter 4 UEFI SETUP UTILITY 68

4.1 Introduction 68

4.2 EZ Mode 69

4.3 Advanced Mode 70

4.3.1 UEFI Menu Bar 70

4.3.2 Navigation Keys 71

4.4 Main Screen 72

4.5 OC Tweaker Screen 73

4.6 Advanced Screen 83

4.6.1 CPU Conguration 84

4.6.2 Chipset Conguration 86

4.6.3 Storage Conguration 89

4.6.4 Intel(R) Thunderbolt 91

4.6.5 ACPI Conguration 92

4.6.6 USB Conguration 93

4.6.7 Trusted Computing 94

4.7 Tools 95

4.8 Hardware Health Event Monitoring Screen 97

4.9 Security Screen 101

4.10 Boot Screen 102

4.11 Exit Screen 105

English

W480 Creator

Chapter 1 Introduction

ank you for purchasing ASRock W480 Creator motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock W480 Creator Motherboard (ATX Form Factor)

• ASRock W480 Creator Quick Installation Guide

• ASRock W480 Creator Support CD

• 4 x Serial ATA (SATA) Data Cables (Optional)

• 1 x ASRock WiFi 2.4/5 GHz Antenna (Optional)

• 3 x Screws for M.2 Sockets (Optional)

• 2 x Standos for M.2 Sockets (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any modi-

cations of this documentation occur, the updated version will be available on ASRock’s

website without further notice. If you require technical support related to this mother-

board, please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well. ASRock

website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• 2oz Copper PCB

CPU • Supports 10th Gen and future generation Intel® CoreTM

Processors and Xeon W Processors (WE3/WE2/WE1)(Socket

1200), up to 10 Cores and 125W

• Digi Power design

• 17 Power Phase design

• Supports Intel® Turbo Boost Max 3.0 Technology

• Supports Intel® K-Series CPUs

• Supports ASRock BCLK Full-range Overclocking

• Supports ASRock Hyper BCLK Engine III

Chipset • Intel® W480

Memory • Dual Channel DDR4 Memory Technology

• 4 x DDR4 DIMM Slots

• Supports DDR4 4600+(OC)*/4500/4400/4333/4266(OC)/

4133(OC)/4000(OC)/3866(OC)/3800(OC)/3733(OC)/3600

(OC)/3200(OC)/2933/2800/2666/2400/2133 non-ECC, un-

buered memory

* Please refer to Memory Support List on ASRock's website for

more information. (http://www.asrock.com/)

* Xeon W(WE3/WE2) support DDR4 up to 2933, Xeon W(WE1)

support DDR4 up to 2666.

• Supports ECC UDIMM memory modules with Intel® Xeon®

processors

• Supports DDR4 ECC, un-buered memory with Intel® Xeon®

processors W series in the LGA 1200 Socket

• Max. capacity of system memory: 128GB (with 10th Gen and

Xeon® CPU)

• Supports Intel® Extreme Memory Prole (XMP) 2.0

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 3 x PCI Express 3.0 x16 Slots (PCIE1/PCIE4/PCIE5: single

at x16 (PCIE1); dual at x8 (PCIE1) / x8 (PCIE4); triple at x8

(PCIE1) / x8 (PCIE4) / x4 (PCIE5))*

English

W480 Creator

* PCIE5, M2_3 and SATA3_3 share lanes. If either one of them

is in use, the others will be disabled.

* Supports NVMe SSD as boot disks

• 2 x PCI Express 2.0 x1 Slots

• Supports AMD Quad CrossFireXTM, 3-Way CrossFireXTM

and CrossFireXTM

• 1 x Vertical M.2 Socket (Key E) with the bundled WiFi-

802.11ax module (on the rear I/O)

• 15μ Gold Contact in VGA PCIe Slot (PCIE1 and PCIE4)

Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

• Hardware Accelerated Codecs: AVC/H.264, HEVC/H.265

8bit, HEVC/H.265 10bit, VP8, VP9 8bit, VP9 10bit, MPEG 2,

MJPEG, VC-1

* VP9 10bit and VC-1 are for decode only.

* VP8 and VP9 encode are not supported by Windows OS.

• Graphics, Media & Compute: Microso DirectX 12, OpenGL

4.5, Intel® Built In Visuals, Intel® Quick Sync Video, Hybrid /

Switchable Graphics, OpenCL 2.1

• Display & Content Security: Rec. 2020 (Wide Color Gamut),

Microso PlayReady 3.0, Intel® SGX Content Protection,

UHD/HDR Blu-ray Disc

• Supports HDMI 1.4 with max. resolution up to 4K x 2K

(4096x2160) @ 30Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI 1.4 Port (Compliant

HDMI monitor is required)

• Supports HDCP 2.3 with HDMI 1.4 Port

• Supports 4K Ultra HD (UHD) playback with HDMI 1.4 Port

Thunder-

boltTM

• Intel® JHL7540 underboltTM 3 Controller (Titan Ridge)

• Supports underboltTM 3 interface with max. resolution of

5K (5120 x 2880) @ 60Hz for one display over a single cable

connection

• Supports underboltTM 3 interface with max. resolution of

4K x 2K (4096x2160) @ 60Hz for dual displays over a single

cable connection
