ASROCK J3160TM-ITX Manual de usuario

Version 1.1

Published August 2016

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 5

1.4 I/O Panel 7

Chapter 2 Installation 8

2.1 Installing Memory Modules (SO-DIMM) 9

2.2 Expansion Slots (PCI Express Slots) 11

2.3 Jumpers Setup 12

2.4 Onboard Headers and Connectors 13

Chapter 3 Software and Utilities Operation 19

3.1 Installing Drivers 19

3.2 ASRock Live Update & APP Shop 20

3.2.1 UI Overview 20

3.2.2 Apps 21

3.2.3 BIOS & Drivers 24

3.2.4 Setting 25

Chapter 4 UEFI SETUP UTILITY 29

4.1 Introduction 29

4.1.1 UEFI Menu Bar 29

4.1.2 Navigation Keys 30

4.2 Main Screen 31

4.3 Advanced Screen 32

4.3.1 CPU Conguration 33

4.3.2 Chipset Conguration 34

4.3.3 Storage Conguration 36

4.3.4 IntelRMT Conguration 38

4.3.5 Super IO Conguration 39

4.3.6 ACPI Conguration 40

4.3.7 USB Conguration 42

4.3.8 Trusted Computing 43

4.4 Tools 44

4.5 Hardware Health Event Monitoring Screen 46

4.6 Security Screen 47

4.7 Boot Screen 48

4.8 Exit Screen 51

English

J3160TM-ITX

Chapter 1 Introduction

ank you for purchasing ASRock J3160TM-ITX motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock J3160TM-ITX Motherboard (in Mini-ITX Form Factor)

• ASRock J3160TM-ITX Quick Installation Guide

• ASRock J3160TM-ITX Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x SATA 1 to 2 Power Cable (Optional)

• 2 x I/O Panel Shields

• 1 x WiFi Module Screw

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • in Mini-ITX Form Factor

• Solid Capacitor design

CPU • Intel® Quad-Core Processor J3160 (up to 2.24 GHz)

Memory • Dual Channel DDR3/DDR3L Memory Technology

• 2 x DDR3/DDR3L SO-DIMM Slots

• Supports DDR3/DDR3L 1600/1066 non-ECC, un-buered

memory

• Max. capacity of system memory: 16GB

(see CAUTION)

* If only one SO-DIMM module is installed, please install it into

DDR3_A1.

Expansion

Slot

• 1 x PCI Express 2.0 x1 Slot

• 1 x Half-size Mini-PCI Express Slot

* Due to the power limitation and PCIe bandwidth (x1), the VGA

card is not supported.

Graphics • Integrated Intel® HD Graphics 400: 12 EUs inside (Up to

700MHz)

• DirectX 11.1, Pixel Shader 5.0

• ree graphics output options: D-Sub, HDMI and LVDS

• Supports Triple Monitor

• Supports HDMI with max. resolution up to 2560x1600 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports LVDS with max. resolution up to 1920x1200 @

60Hz

• Supports Auto Lip Sync, xvYCC and HBR (High Bit Rate

Audio) with HDMI Port (Compliant HDMI monitor is

required)

• Supports HW Accelerated Decoders: H.264 @ level 5.2, H.265/

HEVC @ level 5 (GPU accelerated), JPEG, VP8

• Supports HDCP with HDMI Port

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

Port

English

J3160TM-ITX

Audio • 7.1 CH HD Audio with Content Protection (Realtek ALC892

Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

• Premium Blu-ray Audio support

• Supports Surge Protection (ASRock Full Spike Protection)

• ELNA Audio Caps

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Wake-On-WAN

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports LAN Cable Detection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x DC Jack (Compatible with the 19V power adapter)

• 1 x D-Sub Port

• 1 x HDMI Port

• 4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Microphone / Front Speaker (Supports

SPDIF Optical)

Storage • 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

Connector • 1 x Backlight Power Selection Jumper

• 1 x Panel Power Selection Jumper

• 1 x Backlight Control Header

• 1 x Digital Input / Output Pin Header

• 1 x Digital Input / Output Power Selection Jumper

• 1 x Home eater PC Header

• 1 x Monitor Switch Header

• 1 x Digital MIC Header

• 1 x 3W Audio AMP Output Wafer Header

• 1 x LVDS Connector

• 1 x CIR Header

English

• 1 x COM Port Header

• 1 x Power LED Header

• 1 x TPM Header

• 1 x CPU Fan Connector (4-pin)

• 1 x Chassis Fan Connector (4-pin)

• 1 x SATA Power Connector

• 1 x Internal Power Header

• 1 x Front Panel Audio Connector

• 1 x Analog Surround Audio Connector

• 3 x USB 2.0 Headers (Support 5 USB 2.0 ports) (Supports ESD

Protection (ASRock Full Spike Protection))

• 1 x USB 3.0 Header by Etron EJ188 (Supports 2 USB 3.0 ports)

(Supports ESD Protection (ASRock Full Spike Protection))

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

• Supports Plug and Play

• ACPI 5.0 compliant wake up events

• Supports jumperfree

• SMBIOS 2.7 support

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by

CPU temperature)

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 10 32-bit / 10 64-bit / 8.1 32-bit / 8.1 64-

bit / 7 32-bit / 7 64-bit

* To install Windows® 7 64-bit OS, a modied installation disk

with xHCI drivers packed into the ISO le is required. Please

refer to page 26 for more detailed instructions.

* For the updated Windows® 10 driver, please visit ASRock's

website for details: http://www.asrock.com

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

Due to limitation, the actual memory size may be less than 4GB for the reservation

for system usage under Windows® 32-bit operating systems. Windows® 64-bit operat-

ing systems do not have such limitations. You can use ASRock XFast RAM to utilize

the memory that Windows® cannot use.

English

J3160TM-ITX

1.3 Motherboard Layout

AUDIO

SATA_POW1

DDR3_B1

J3160TM-ITX

PCIE1

CMOS

Battery

RoHS

Front USB 3.0

BIOS

ROM

MINI_PCIE1

LAN

USB3_4_5

SATA3_2 SATA3_1

CIR1

HDLED RESET

PLED PWRBTN

PANEL1

LVDS1

BKT_PWR1

JGPIO_PWR1

PNL_PWR1

11 1

PLED1

CPU_FAN1 CHA_FAN1

BLT_VOL1

COM1

USB7_8

TPMS1

CLRCMOS1

HD_AUDIO2

SPEAKER1

HD_AUDIO1

JGPIO

DMIC1

HTPC1

Front

Speaker

Mic In

USB 3.0

T: USB2

B: USB3

USB 3.0

T: USB0

B: USB1

DC Jack

HDMI1

VGA1

RJ-45

MONITOR_SWITCH1

USB4_5

USB6

ATX19V_IN1

DDR3_A1

Otros manuales para J3160TM-ITX

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK P55 PRO Manual de usuario

ASROCK

ASROCK 775VM800 Manual de usuario

ASROCK

ASROCK ZH77 Pro3 Manual de usuario

ASROCK

ASROCK Q1900TM-ITX Manual de usuario

ASROCK

ASROCK Z790 Series Manual de usuario

ASROCK

ASROCK 939SLI32-ESATA2 Manual del operador

ASROCK

ASROCK FM2A55M-VG3 Manual de usuario

ASROCK

ASROCK B85M BTC Manual de usuario

ASROCK

ASROCK N68-VS3 UCC - Manual de usuario

ASROCK

ASROCK X399M Taichi Manual de usuario

ASROCK

ASROCK FM2A75M-ITX R2.0 Manual de usuario

ASROCK

ASROCK IMB-A182 Instrucciones de uso

ASROCK

ASROCK X58 EXTREME - V1.1 Manual de usuario

ASROCK

ASROCK Taichi Razer Edition B550 Manual de usuario

ASROCK

ASROCK B650M PRO RS Manual de usuario

ASROCK

ASROCK X399D8A-2T Manual de usuario

ASROCK

ASROCK C226 WS+ Manual de usuario

ASROCK

ASROCK H55M/USB3 R2.0 Manual de usuario

ASROCK

ASROCK G43TWINS-FULLHD Manual de usuario

ASROCK

ASROCK K8A8X-M Manual de usuario

ASROCK

ASROCK Z690M-ITX/ax Manual de usuario

ASROCK

ASROCK A55iCafe Manual de usuario

ASROCK

ASROCK X99 WS Manual de usuario

ASROCK

ASROCK B550D4M Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
