ASROCK H81 Pro BTC Manual de usuario

User Manual

Version 1.0

Published October 2013

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

e terms HDMITM and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Unique Features 6

1.4 Motherboard Layout 9

1.5 I/O Panel 11

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 16

2.3 Installing Memory Modules (DIMM) 17

2.4 Expansion Slots (PCI Express Slots) 19

2.5 Jumpers Setup 20

2.6 Onboard Headers and Connectors 21

Chapter 3 Software and Utilities Operation 25

3.1 Installing Drivers 25

3.2 A-Tuning 26

3.3 Intel® Smart Connect Technology 30

3.4 Start8 35

Chapter 4 UEFI SETUP UTILITY 38

4.1 Introduction 38

4.1.1 UEFI Menu Bar 38

4.1.2 Navigation Keys 39

4.2 Main Screen 40

4.3 OC Tweaker Screen 41

4.4 Advanced Screen 49

4.4.1 CPU Conguration 50

4.4.2 Chipset Conguration 52

4.4.3 Storage Conguration 54

4.4.4 Intel® Smart Connect Technology 55

4.4.5 Super IO Conguration 56

4.4.6 ACPI Conguration 58

4.4.7 USB Conguration 60

4.4.8 Trusted Computing 61

4.5 Tools 62

4.6 Hardware Health Event Monitoring Screen 65

4.7 Boot Screen 66

4.8 Security Screen 69

4.9 Exit Screen 70

Chapter 1 Introduction

ank you for purchasing ASRock H81 Pro BTC motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock H81 Pro BTC Motherboard (ATX Form Factor)

• ASRock H81 Pro BTC Quick Installation Guide

• ASRock H81 Pro BTC Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

H81 Pro BTC

English

Chapter 1 Introduction

ank you for purchasing ASRock H81 Pro BTC motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock H81 Pro BTC Motherboard (ATX Form Factor)

• ASRock H81 Pro BTC Quick Installation Guide

• ASRock H81 Pro BTC Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • ATX Form Factor

• All Solid Capacitor design

CPU • Supports 4th Generation Intel® CoreTM i7 / i5 / i3 / Xeon® /

Pentium® / Celeron® in LGA1150 Package

• Digi Power design

• 4 Power Phase design

• Supports Intel® Turbo Boost 2.0 Technology

Chipset • Intel® H81

Memory • Dual Channel DDR3 Memory Technology

• 2 x DDR3 DIMM Slots

• Supports DDR3 1600/1333/1066 non-ECC, un-buered

memory

• Max. capacity of system memory: 16GB

(see CAUTION1)

• Supports Intel® Extreme Memory Prole (XMP)1.3/1.2

Expansion

Slot

• 1 x PCI Express 2.0 x16 Slot (PCIE2: x16 mode)

• 5 x PCI Express 2.0 x1 Slots

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs can

be supported only with processors which are GPU integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 4400/4600

• Pixel Shader 5.0, DirectX 11.1

• Max. shared memory 1792MB

• Dual Graphics Output: support HDMI and D-Sub ports by

independent display controllers

• Supports HDMI Technology with max. resolution up to

1920x1200 @ 60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

H81 Pro BTC

English

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with HDMI Port

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

Port

Audio • 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Realtek RealWoW! Technology (see CAUTION2)

• Supports Wake-On-LAN

• Supports LAN Cable Detection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse Port

• 1 x PS/2 Keyboard Port

• 1 x Serial Port: COM1

• 1 x Parallel Port (ECP/EPP support)

• 1 x D-Sub Port

• 1 x HDMI Port

• 2 x USB 2.0 Ports

• 2 x USB 3.0 Ports

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage • 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

• 2 x SATA2 3.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

English

Connector • 1 x IR Header

• 1 x COM Port Header

• 1 x Power LED Header

• 1 x TPM Header

• 2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)

• 1 x Power Fan Connector (3-pin)

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 2 x SLI/XFire Power Connectors

• 1 x Front Panel Audio Connector

• 1 x SPDIF Out Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports)

BIOS

Feature

• 32Mb AMI UEFI Legal BIOS with multilingual GUI support

• ACPI 1.1 Compliant wake up events

• SMBIOS 2.3.1 support

• CPU, DRAM, PCH 1.05V Voltage multi-adjustment

Support

• Drivers, Utilities, AntiVirus Soware (Trial Version), Google

Chrome Browser and Toolbar, Start8 (30 days trial)

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis/Power Fan Tachometer

• CPU Quiet Fan (Auto adjust chassis fan speed by CPU tem-

perature)

• CPU/Chassis Fan multi-speed control

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 8.1 32-bit / 8.1 64-bit / 8 32-bit / 8 64-

bit / 7 32-bit / 7 64-bit

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

H81 Pro BTC

English

Please realize that there is a certain risk involved with overclocking, including adjust-

ing the setting in the BIOS, applying Untied Overclocking Technology, or using third-

party overclocking tools. Overclocking may aect your system’s stability, or even cause

damage to the components and devices of your system. It should be done at your own

risk and expense. We are not responsible for possible damage caused by overclocking.

1. Due to limitation, the actual memory size may be less than 4GB for the reserva-

tion for system usage under Windows® 32-bit operating systems. Windows® 64-bit

operating systems do not have such limitations. You can use ASRock XFast RAM to

utilize the memory that Windows® cannot use.

2. Realtek RealWoW! Technology allows you to wake up this system from remote

mobile devices, such as smart phones, tables, or other PCs. It needs third-party

sowares and applications to utilize this feature. Please visit our website for Home

Cloud topic.

English

1.3 Unique Features

ASRock A-Tuning

A-Tuning is ASRock’s multi purpose soware suite with a new interface, more new

features and improved utilities, including XFast RAM, Dehumidier, Good Night

LED, FAN-Tastic Tuning, OC Tweaker and a whole lot more.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded in Flash ROM. is conve-

nient BIOS update tool allows you to update the system BIOS in a few clicks without

preparing an additional oppy diskette or other complicated ash utility. Just save

the new BIOS le to your USB storage and launch this tool by pressing <F6> or

<F2> during POST to enter the BIOS setup menu to access ASRock Instant Flash.

Please be noted that the USB ash drive or hard drive must use FAT32/16/12 le

system.

ASRock APP Charger

Simply by installing the ASRock APP Charger makes your iPhone/iPad/iPod Touch

charge up to 40% faster than before on your computer. ASRock APP Charger allows

you to quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Suspend to RAM

(S3), hibernation mode (S4) or power o (S5).

ASRock XFast LAN

ASRock XFast LAN provides faster internet access, which includes the benets

listed below. LAN Application Prioritization: You can congure your application’s

priority ideally and add new programs to the list. Lower Latency in Game: Aer

setting online game’s priority higher, it can lower the latency in games. Trac

Shaping: You can watch Youtube HD videos and download simultaneously. Real-

Time Analysis of Your Data: With the status window, you can easily recognize

which data streams you are currently transferring.

ASRock XFast RAM

ASRock XFast RAM is included in A-Tuning. It fully utilizes the memory space

that cannot be used under Windows® 32-bit operating systems. ASRock XFast RAM

shortens the loading time of previously visited websites, making web surng faster

than ever. And it also boosts the speed of Adobe Photoshop 5 times faster. Another

advantage of ASRock XFast RAM is that it reduces the frequency of accessing your

SSDs or HDDs in order to extend their lifespan.

Otros manuales para H81 Pro BTC

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK FATAL1TY P67 PROFESSIONAL Manual de usuario

ASROCK

ASROCK X299 creator Manual de usuario

ASROCK

ASROCK 4Core1600P35-WiFi Manual de usuario

ASROCK

ASROCK 775Dual-VSTA Manual de usuario

ASROCK

ASROCK H61M-GS Manual de usuario

ASROCK

ASROCK WOLFDALE1333-GLAN/M Manual de usuario

ASROCK

ASROCK X370M Pro4 R2.0 Manual de usuario

ASROCK

ASROCK Q87WSA-DL Manual de usuario

ASROCK

ASROCK SBC-210N Manual de usuario

ASROCK

ASROCK 890GX Extreme3 Manual de usuario

ASROCK

ASROCK H61M-DPS Manual de usuario

ASROCK

ASROCK P43R1600TWINS-WIFI Manual de usuario

ASROCK

ASROCK A75M-DGS Manual de usuario

ASROCK

ASROCK M3A790GXH/USB3 Manual de usuario

ASROCK

ASROCK H110M Combo-G Manual de usuario

ASROCK

ASROCK Z590 OC Formula Manual de usuario

ASROCK

ASROCK B450 Steel Legend Manual de usuario

ASROCK

ASROCK IMB-153 Manual de usuario

ASROCK

ASROCK H470 Steel Legend Manual de usuario

ASROCK

ASROCK H310CM-HG4 Manual de usuario

ASROCK

ASROCK B760M Steel Legend WiFi Manual de usuario

ASROCK

ASROCK X79 Extreme11 Manual de usuario

ASROCK

ASROCK Fatal1ty Z170 Gaming K4 Series Manual de usuario

ASROCK

ASROCK FM2A88X Pro Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
