ASROCK H610TM-ITX Manual de usuario

Version 1.0

Published October 2022

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure.

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

English

H610TM-ITX

Motherboard Layout

Audio

CODEC

HDLED RESET

PLED PWRBTN

PANEL1

VGA1

DC Jack

HDMI1

HDMI2

Super

I/O

BIOS

ROM

CPU_FAN1

H610TM-ITX

RoHS

19 18

DDR4_B1

DDR4_A1

SATA_1

USB2_1_2

LVDS1

BKT_PWR1

BLT_VOL1

SPK_OUT1

USB 3.2 Gen2

T: USB3_3

B: USB_TC_1

USB 2.0

T: USB_3

B: USB_4

RJ-45

Line out

Mic In

ATX_PWR1

HD_AUDIO1

SATA_2

CLR_MOS1

TH1

PNL_PWR1

Intel

H610

SATAPWR1

M.2 WiFi

M.2 SSD

M2_1_CT2

M2_1_CT1

NUT1

CI1

PANEL_SW1

DMIC1

SATAPWR2

USB3_1_2

Top Side View

English

M.2 SSD

Back Side View

English

H610TM-ITX

No. Description

1 4 pin 19V Power Connector (ATX_PWR1)

2 SATA Power Connector (SATAPWR2)

3 SATA Power Connector (SATAPWR1)

4 SATA3 Connector (SATA_1)

5 SATA3 Connector (SATA_2)

6 Clear CMOS Jumper (CLR_MOS1)

7 USB 3.2 Gen1 Header (USB3_1_2)

8 USB 2.0 Header (USB2_1_2)

9 FPD Brightness Header (BLT_VOL1)

10 Backlight Inverter Voltage Selection Header (BKT_PWR1)

11 Panel Voltage Selection Header (PNL_PWR1)

12 Panel O Header (PANEL_SW1)

13 LVDS Connector (LVDS1)

14 2 x 260-pin DDR4 SO-DIMM Slots (DDR4_A1, DDR4_B1)

15 CPU Fan Connector (CPU_FAN1)

16 Chassis Intrusion Header (CI1)

17 Digital MIC Header (DMIC1)

18 System Panel Header (PANEL1)

19 Internal Speaker Header (SPK_OUT1)

20 Front Panel Audio Header (HD_AUDIO1)

21 ermal Sensor Header (TH1)

English

I/O Panel

No. Description No. Description

1 DC Jack** 6 LAN RJ-45 Port*

2HDMI Port (HDMI1) 7 USB 2.0 Ports (USB_3_4)

3D-Sub Port 8Microphone (Pink)

4 USB 3.2 Gen2 Type-A Port (USB3_3) 9 Line out (Lime)

5 USB 3.2 Gen2 Type-C Port (USB_TC_1)

*ere are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications.

Activity / Link LED Speed LED

Status Description Status Description

O No Link O 10Mbps connection

Blinking Data Activity Green 100Mbps connection

On Link Green 1Gbps connection

** Please use a 19V power adapter for the DC jack. is jack accepts dual barrel plugs with an inner diameter of 2.5

mm and an outer diameter of 5.5 mm, where the inner contact is +19 (±10%) DC and the shell is (centre positive).

DELTA DELTA-ADP-150TB-150W/19V

HP HP-TBC-BA52-150W/19V

FSP FSP-FSP150-ABAN1-150W/19V

DELL FA130PE1-00-130W/19.5V

DELL LA90PE0-01-90W/19.5V

DELTA DELTA-ADP-180TB-180W/19V

FSP FSP-FSP180-ABBN3-180W/19V

is motherboard is available with support for either 4-pin ATX 19V power or DC-in power supplies. Please do

not use two kinds of power supplies at the same time! Doing so may damage the motherboard components and

devices. When you use the DC-in power adapter, please use the onboard SATA power connector to get the power

for HDDs.

ACT/LINK LED

SPEED LED

LAN Port

982 64

31 7

Chapter 1 Introduction

ank you for purchasing H610TM-ITX motherboard. In this documentation,

Chapter 1 and 2 contains the introduction of the motherboard and step-by-step

installation guides.

1.1 Package Contents

• H610TM-ITX Motherboard (in Mini-ITX Form Factor)

• 1 x in-Mini ITX I/O Shield (Optional)

• 1 x Mini ITX I/O Shield (Optional)

• 1 x Serial ATA (SATA) Data Cable (Optional)

• 1 x SATA Power Cable (Optional)

• 3 x Screws for M.2 Sockets (M2*2) (Optional)

• 1 x Stando for M.2 Socket (Optional)

English

H610TM-ITX

Chapter 1 Introduction

ank you for purchasing H610TM-ITX motherboard. In this documentation,

Chapter 1 and 2 contains the introduction of the motherboard and step-by-step

installation guides.

1.1 Package Contents

• H610TM-ITX Motherboard (in Mini-ITX Form Factor)

• 1 x in-Mini ITX I/O Shield (Optional)

• 1 x Mini ITX I/O Shield (Optional)

• 1 x Serial ATA (SATA) Data Cable (Optional)

• 1 x SATA Power Cable (Optional)

• 3 x Screws for M.2 Sockets (M2*2) (Optional)

• 1 x Stando for M.2 Socket (Optional)

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice.

English

1.2 Specications

Platform • in Mini-ITX Form Factor (Compatible with Mini-ITX)

• Solid Capacitor design

CPU • Supports 13th Gen & 12th Gen Intel® CoreTM Processors

(LGA1700)

• 4 Power Phase design

• Supports Intel® Hybrid Technology

• Supports Intel® Turbo Boost Max 3.0 Technology

Chipset • Intel® H610

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 SO-DIMM Slots

• Supports DDR4 non-ECC, un-buered memory up to 3200*

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

• Max. capacity of system memory: 64GB

• Supports Intel® Extreme Memory Prole (XMP) 2.0

Expansion

Slot • 1 x M.2 Socket (Key E), supports type 2230 WiFi/BT module

Graphics • Intel® UHD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

• Intel® XeGraphics Architecture (Gen 12)

• Four graphics output options: 2 x HDMI, 1 x LVDS, 1 x D-Sub

ports

• Supports 2 x HDMI 2.1 TMDS Compatible with max.

resolution up to 4K x 2K (4096x2160) @ 60Hz

HDMI x 1 port (Rear)

HDMI x 1 port (Internal)

* (Optional) DisplayPort 1.4 with DSC (compressed) max.

resolution up to 8K (7680x4320) @ 60Hz / 5K (5120x3200) @

120Hz

English

H610TM-ITX

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports LVDS with max. resolution up to 1920x1080 @ 60Hz

• Supports HDCP 2.3 with HDMI 2.1 TMDS Compatible and

DisplayPort 1.4 Ports

Audio • Realtek ALC269 Audio Codec

• 1 x MIC IN

• 1 x Line out

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111H

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

I/O • 1 x DC Jack (Compatible with the 19V power adapter)

• 1 x D-Sub Port

* (Optional) 1 x COM Port

• 2 x HDMI Ports: HDMI1 (Rear), HDMI2 (Internal)

* (Optional) 1 x DisplayPort 1.4

• 1 x USB 3.2 Gen2 Type-A Port (Supports ESD Protection)

• 1 x USB 3.2 Gen2 Type-C Port (Supports ESD Protection)

* (Optional) 2 x USB 3.2 Gen2 Type-A Ports (Supports ESD

Protection)

• 2 x USB 2.0 Ports (Support ESD Protection)

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line out / Microphone

Storage • 2 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and Hot

Plug

• 1 x Blazing M.2 Socket (M2_1), supports M Key type

2260/2280 M.2 PCI Express module up to Gen5 x4

* Supports NVMe SSD as boot disks

• 1 x M.2 Socket (M2_3), supports M Key type 2280 M.2 SATA3

6.0 Gb/s module

English

Connector • 1 x Chassis Intrusion Header

• 1 x Panel Voltage Selection Header

• 1 x Backlight Inverter Voltage Selection Header

• 1 x FPD Brightness Header

• 1 x Panel O Header

• 1 x LVDS Connector

• 1 x CPU Fan Connector (4-pin)

* e CPU Fan Connector supports the CPU fan of maximum 1A

(12W) fan power.

• 1 x 4 pin 19V Power Connector (2-Pin)

• 1 x ermal Sensor Header

• 1 x Front Panel Audio Connector

• 1 x Internal Speaker Header (4-Pin)

• 1 x Digital MIC Header

• 2 x SATA Power Connectors

• 1 x USB 2.0 Header (Supports 2 USB 2.0 ports) (Supports ESD

Protection)

• 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)

(Supports ESD Protection)

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

• ACPI 6.0 Compliant wake up events

• SMBIOS 2.7 Support

Hardware

Monitor

• CPU Temperature Sensing

• CPU Fan Tachometer

• CPU Quiet Fan (Auto adjust chassis fan speed by CPU

temperature)

• CPU Fan Multi-Speed Control

• CASE OPEN detection

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore

OS • Microso® Windows® 10 64-bit / 11 64-bit

Power • 1 x DC Jack (Supports 19V DC Power Adapters)
