ASROCK B150M-DVS R2.0 Manual de usuario

Version 1.0

Published April 2016

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 8

Chapter 2 Installation 10

2.1 Installing the CPU 11

2.2 Installing the CPU Fan and Heatsink 14

2.3 Installing Memory Modules (DIMM) 15

2.4 Expansion Slots (PCI Express Slots) 17

2.5 Onboard Headers and Connectors 18

Chapter 3 Software and Utilities Operation 22

3.1 Installing Drivers 22

3.2 ASRock Live Update & APP Shop 23

3.2.1 UI Overview 23

3.2.2 Apps 24

3.2.3 BIOS & Drivers 27

3.2.4 Setting 28

3.3 Enabling USB Ports for Windows® 7 Installation 29

Chapter 4 UEFI SETUP UTILITY 32

4.1 Introduction 32

4.2 EZ Mode 33

4.3 Advanced Mode 34

4.3.1 UEFI Menu Bar 34

4.3.2 Navigation Keys 35

4.4 Main Screen 36

4.5 OC Tweaker Screen 37

4.6 Advanced Screen 45

4.6.1 CPU Conguration 46

4.6.2 Chipset Conguration 48

4.6.3 Storage Conguration 50

4.6.4 Super IO Conguration 51

4.6.5 ACPI Conguration 52

4.6.6 USB Conguration 54

4.6.7 Trusted Computing 55

4.7 Tools 56

4.8 Hardware Health Event Monitoring Screen 59

4.9 Security Screen 61

4.10 Boot Screen 62

4.11 Exit Screen 65

English

B150M-DVS R2.0

Chapter 1 Introduction

ank you for purchasing ASRock B150M-DVS R2.0 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this documentation, Chapter 1 and 2 contains the introduction of the

motherboard and step-by-step installation guides. Chapter 3 contains the operation

guide of the soware and utilities. Chapter 4 contains the conguration guide of

the BIOS setup.

1.1 Package Contents

• ASRock B150M-DVS R2.0 Motherboard (Micro ATX Form Factor)

• ASRock B150M-DVS R2.0 Quick Installation Guide

• ASRock B150M-DVS R2.0 Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this documentation will be subject to change without notice. In case any

modications of this documentation occur, the updated version will be available on

ASRock’s website without further notice. If you require technical support related to

this motherboard, please visit our website for specic information about the model

you are using. You may nd the latest VGA cards and CPU support list on ASRock’s

website as well. ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

• Solid Capacitor design

CPU • Supports 6th Generation Intel® CoreTM i7/i5/i3/Pentium®/

Celeron® Processors (Socket 1151)

• Supports CPU up to 91W

• Digi Power design

• 5 Power Phase design

• Supports Intel® Turbo Boost 2.0 Technology

Chipset • Intel® B150

• Supports Intel® Small Business Basics

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 DIMM Slots

• Supports DDR4 2133 non-ECC, un-buered memory

• Supports ECC UDIMM memory modules (operate in non-

ECC mode)

• Max. capacity of system memory: 32GB

• Supports Intel® Extreme Memory Prole (XMP) 2.0

Expansion

Slot

• 1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*

* Supports NVMe SSD as boot disks

• 2 x PCI Express 3.0 x1 Slots

Graphics • Intel® HD Graphics Built-in Visuals and the VGA outputs

can be supported only with processors which are GPU

integrated.

• Supports Intel® HD Graphics Built-in Visuals : Intel® Quick

Sync Video with AVC, MVC (S3D) and MPEG-2 Full

HW Encode1, Intel® InTruTM 3D, Intel® Clear Video HD

Technology, Intel® InsiderTM, Intel® HD Graphics 510/530

• Pixel Shader 5.0, DirectX 12

• Max. shared memory 1024MB

* e size of maximum shared memory may vary from dierent

operating systems.

English

B150M-DVS R2.0

• Dual graphics output: Support DVI-D and D-Sub ports by

independent display controllers

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 1920x1200 @

60Hz

• Supports Accelerated Media Codecs: HEVC, VP8, VP9

• Supports HDCP with DVI-D Port

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

Port

Audio • 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

• Supports Surge Protection (ASRock Full Spike Protection)

• ELNA Audio Caps

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR/RTL8111C

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection (ASRock Full Spike

Protection)

• Supports LAN Cable Detection

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 1 x D-Sub Port

• 1 x DVI-D Port

• 2 x USB 2.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))*

• 4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full

Spike Protection))*

* ACPI wake-up function is supported on the rear USB ports

only.

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

English

Storage • 6 x SATA3 6.0 Gb/s Connectors, support NCQ, AHCI and

Hot Plug

Connector • 1 x Print Port Header

• 1 x COM Port Header

• 1 x TPM Header

• 1 x Chassis Intrusion and Speaker Header

• 1 x CPU Fan Connector (4-pin)

• 2 x Chassis Fan Connectors (4-pin)

* e CPU Fan Connector supports the CPU fan of maximum

1A (12W) fan power.

• 1 x 24 pin ATX Power Connector

• 1 x 8 pin 12V Power Connector

• 1 x Front Panel Audio Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports

ESD Protection (ASRock Full Spike Protection))

• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports

ESD Protection (ASRock Full Spike Protection))

BIOS

Feature

• AMI UEFI Legal BIOS with multilingual GUI support

• ACPI 5.0 Compliant wake up events

• SMBIOS 2.7 Support

• CPU, DRAM, PCH 1.0V, VCCIO Voltage Multi-adjustment

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan (Auto adjust chassis fan speed by

CPU temperature)

• CPU/Chassis Fan multi-speed control

• CASE OPEN detection

• Voltage monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,

VPPM, PCH 1.0V, VCCIO

English

B150M-DVS R2.0

OS • Microso® Windows® 10 64-bit / 8.1 64-bit / 7 32-bit / 7 64-

bit

* To install Windows® 7 OS, a modied installation disk with

xHCI drivers packed into the ISO le is required. Please refer to

page 29 for more detailed instructions.

* For the updated Windows® 10 driver, please visit ASRock’s

website for details: http://www.asrock.com

Certica-

tions

• FCC, CE, WHQL

Please realize that there is a certain risk involved with overclocking, including

adjusting the setting in the BIOS, applying Untied Overclocking Technology, or using

third-party overclocking tools. Overclocking may aect your system’s stability, or

even cause damage to the components and devices of your system. It should be done

at your own risk and expense. We are not responsible for possible damage caused by

overclocking.

* For detailed product information, please visit our website: http://www.asrock.com
