ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

No part of this installation guide may be reproduced, transcribed, transmitted, or trans-

lated in any language, in any form or by any means, except duplication of documen-

tation by the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this guide may or may not be registered

trademarks or copyrights of their respective companies, and are used only for identifica-

tion or explanation and to the owners’ benefit, without intent to infringe.

Disclaimer:Disclaimer:

Disclaimer:

Specifications and information contained in this guide are furnished for informational

use only and subject to change without notice, and should not be constructed as a

commitment by ASRock. ASRock assumes no responsibility for any errors or omissions

that may appear in this guide.

With respect to the contents of this guide, ASRock does not provide warranty of any kind,

either expressed or implied, including but not limited to the implied warranties or

conditions of merchantability or fitness for a particular purpose. In no event shall

ASRock, its directors, officers, employees, or agents be liable for any indirect, special,

incidental, or consequential damages (including damages for loss of profits, loss of

business, loss of data, interruption of business and the like), even if ASRock has been

advised of the possibility of such damages arising from any defect or error in the guide

or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

PublishedDecember 2007

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in

California, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

2ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

Motherboard LMotherboard L

Motherboard Layoutayout

ayoutayout

ayout

1 PS2_USB_PW1 Jumper 19 USB 2.0 Header (USB6_7, Blue)

2 ATX 12V Connector (ATX12V1) 20 USB 2.0 Header (USB8_9, Blue)

3 CPU Fan Connector (CPU_FAN1) 21 Serial ATAII Connector

4 ATX Power Connector (ATXPWR1) (SATAII_BLUE (PORT 4))

5 AM2 940-Pin CPU Socket 22 Chassis Fan Connector (CHA_FAN1)

6 CPU Heatsink Retention Module 23 System Panel Header (PANEL1)

7 2 x 240-pin DDR2 DIMM Slots 24 Chassis Speaker Header (SPEAKER 1)

(Dual Channel A: DDRII_1, DDRII_2; Yellow) 25 Floppy Connector (FLOPPY1)

8 2 x 240-pin DDR2 DIMM Slots 26 Front Panel Audio Header (HD_AUDIO1)

(Dual Channel B: DDRII_3, DDRII_4; Orange) 27 PCI Slots (PCI1- 3)

9 IDE1 Connector (IDE1, Blue) 28 HDMI_SPDIF Header (HDMI_SPDIF1)

10 North Bridge Controller 29 BIOS LPC Chip

11 Clear CMOS Jumper (CLRCMOS1) 30 Infrared Module Connector (IR1)

12 PCI Express x16 Slot (PCIE3) 31 PCIE Express Slot (PCIE2/PCIE SWITCH)

13 South Bridge Controller 32 PCI Express x1 Slot (PCIE1)

14 Serial ATAII Connector (SATAII_ORANGE (PORT 2))33 SLI / XFIRE Power Connector

15 Serial ATAII Connector (SATAII_RED (PORT 1)) 34 Internal Audio Connector: CD1 (Black)

16 Serial ATAII Connector (SATAII_BLACK (PORT 3)) 35 eSATAII Connector (eSATAII_TOP)

17 USB 2.0 Header (USB2_3, Blue) 36 eSATAII Connector (eSATAII_BOTTOM)

18 USB 2.0 Header (USB4_5, Blue)

ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

ASRASR

ASRock 6CH_eSAock 6CH_eSA

ock 6CH_eSAock 6CH_eSA

ock 6CH_eSATT

TAII I/OAII I/O

AII I/OAII I/O

AII I/O

1 Parallel Port 7 Microphone (Pink)

2 RJ-45 Port 8 USB 2.0 Ports (USB01)

3 Rear Speaker (Black) 9 eSATAII Ports

4 Central / Bass (Orange) 10 COM Port

5 Line In (Light Blue) 11 PS/2 Keyboard Port (Purple)

*6 Front Speaker (Lime) 12 PS/2 Mouse Port (Green)

* If you use 2-channel speaker, please connect the speaker’s plug into “Front Speaker Jack”.

See the table below for connection details in accordance with the type of speaker you use.

TABLE for Audio Output Connection

* To enable Multi-Streaming function, you need to connect a front panel audio cable to the front

panel audio header. Please refer to below steps for the software setting of Multi-Streaming.

For Windows®XP:

After restarting your computer, you will find “Mixer” tool on your system. Please select “Mixer

ToolBox” , click “Enable playback multi-streaming”, and click “ok”. Choose “2CH” or

“4CH” and then you are allowed to select “Realtek HDA Primary output” to use Rear Speaker

and Front Speaker, or select “Realtek HDAAudio 2nd output” to use front panel audio. Then

reboot your system.

For Windows®VistaTM:

After restarting your computer, please double-click “Realtek HD Audio Manager” on the

system tray. Set “Speaker Configuration” to “5.1 Speaker”. Click “Device advanced settings”,

choose “Make front and rear output devices playbacks two different audio streams

simultaneously”, and click “ok”. Then reboot your system.

Audio Output Channels Front Speaker Rear Speaker Central / Bass

(No. 6) (No. 3) (No. 4)

2 V -- --

4VV--

6VVV

4ASRock ALiveXFire-eSATA2 Motherboard

1.1.

1. IntroductionIntroduction

IntroductionIntroduction

Introduction

Thank you for purchasing ASRock ALiveXFire-eSATA2 motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control. It de-

livers excellent performance with robust design conforming to ASRock’s commit-

ment to quality and endurance.

This Quick Installation Guide contains introduction of the motherboard and step-by-

step installation guide. More detailed information of the motherboard can be found in

the user manual presented in the Support CD.

Because the motherboard specifications and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modifications of this manual occur, the updated

version will be available onASRock website without further notice. You

may find the latest VGA cards and CPU support lists on ASRock

website as well.

ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please

visit our website for specific information about the model you are

using.

www.asrock.com/support/index.asp

1.11.1

1.1 PP

Packack

ackack

ackage Contentsage Contents

age Contentsage Contents

age Contents

1 xASRock ALiveXFire-eSATA2 Motherboard

(ATX Form Factor: 12.0-in x 8.2-in, 30.5 cm x 20.8 cm)

1 xASRock ALiveXFire-eSATA2 Quick Installation Guide

1 xASRock ALiveXFire-eSATA2 Support CD

1 x UltraATA 66/100/133 IDE Ribbon Cable (80-conductor)

1 x 3.5-in FloppyDrive Ribbon Cable

2 x SerialATA(SATA)Data Cables (Optional)

1 x SerialATA(SATA) HDDPower Cable (Optional)

1 x HDMI_SPDIF Cable (Optional)

1 xASRock 6CH_eSATAII I/O Shield

1 x USB Bracket

1 x PCIE Switch Card

This motherboard is bundled with one PCIE Switch card installed on PCIE2/

PCIE SWITCH slot, which allows you better flexibility to choose PCIE

functions between one PCIE x16 slot and two PCIE slots for ATITM

CrossFireTM without setting up jumpers.

EnglishEnglish

English

ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

1.21.2

1.2 SpecificationsSpecifications

SpecificationsSpecifications

Specifications

Platform - ATX Form Factor: 12.0-in x 8.2-in, 30.5 cm x 20.8 cm

CPU - Socket AM2 forAMDPhenomTM X4 / X2,Athlon 64FX / 64X2 /

X2 / 64 and Sempron processors

-AMD LIVE!TM Ready

- SupportsAMD’s Cool ‘n’ QuietTM Technology

- FSB 1000 MHz (2.0GT/s)

- Supports Untied Overclocking Technology (see CAUTION 1)

- Supports Hyper-Transport Technology

Chipset -Northbridge: AMD480X CrossFireTM

- Southbridge:ATITM SB600

Memory - Dual ChannelDDR2 Memory Technology (see CAUTION 2)

- 4 xDDR2DIMM slots

- SupportDDR2 1066/800/667/533 (see CAUTION 3)

- Max. capacity: 16GB (see CAUTION 4)

Hybrid Booster - CPU Frequency Stepless Control (see CAUTION 5)

-ASRock U-COP (see CAUTION 6)

- Boot FailureGuard (B.F.G.)

-AM2 Boost:ASRock Patented Technology to boost memory

performance up to 12.5% (see CAUTION 7)

Expansion Slot - SupportsATITM CrossFireTM graphics cards

(see CAUTION 8)

- 1 x PCI Express x16 slot with PCIE Switch card or 2 x PCI

Express Graphics slots for ATITM CrossFireTM

(see CAUTION 9)

- 1 x PCI Express x1 slot

- 3 x PCI slots

Audio - 5.1 CH Windows®VistaTM Premium Level HDAudio

(ALC662Audio Codec)

LAN - PCIE x1Gigabit LAN10/100/1000 Mb/s

- Realtek RTL8111B

- Supports Wake-On-LAN

Rear Panel I/O ASRock6CH_eSATAII I/O

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Serial Port: COM1

- 1 x Parallel Port (ECP/EPP Support)

- 2 x Ready-to-Use USB 2.0 Ports

- 2 x eSATAII Ports

- 1 x RJ-45 Port

6ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

- HDAudio Jack: Rear Speaker / Central/Bass / Line in / Front

Speaker / Microphone (see CAUTION 10)

Connector - 4 x SATAII 3.0Gb/s connectors, support RAID(RAID0,

RAID1 and RAID10),NCQ,AHCI and “Hot Plug” functions

(see CAUTION 11)

- 2 x eSATAII 3.0Gb/s connectors (shared with 2 SATAII ports),

support RAID(RAID 0 and RAID1), NCQ,AHCI and “Hot Plug”

functions (see CAUTION 12)

- 1 xATA133 IDE connector (supports 2 x IDE devices)

- 1 x Floppy connector

- 1 x IR header

- 1 x HDMI_SPDIF header

- CPU/Chassis FANconnector

- 20 pinATX power connector

- 4 pin 12V power connector

- SLI/XFire power connector

- CD in header

- Front panel audio connector

- 4 x USB 2.0 headers (support 8 USB 2.0 ports)

(see CAUTION 13)

BIOS Feature - 4MbAMI BIOS

-AMI Legal BIOS

- Supports “Plug and Play”

-ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

Support CD -Drivers, Utilities,AntiVirus Software (TrialVersion)

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU Fan Tachometer

- Chassis Fan Tachometer

- CPU Quiet Fan

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft® Windows® 2000 / XP / XP Media Center / XP 64-bit

/ VistaTM / VistaTM 64-bit compliant

Certifications - FCC, CE, Microsoft®WHQL Certificated

ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

WARNING

Please realize that there is a certain risk involved with overclocking, including adjusting

the setting in the BIOS, applying Untied Overclocking Technology, or using the third-

party overclocking tools. Overclocking may affect your system stability, or even

cause damage to the components and devices of your system. It should be done at

your own risk and expense. We are not responsible for possible damage caused by

overclocking.

CAUTION!

1. This motherboard supports Untied Overclocking Technology. Please read

“Untied Overclocking Technology” on page 37 for details.

2. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read

the installation guide of memory modules on page 11 for proper

installation.

3. Whether 1066MHz memory speed is supported depends on the AM2+

CPU you adopt. If you want to adopt DDR2 1066 memory module on this

motherboard, please refer to the memory support list on our website for

the compatible memory modules.

ASRock website http://www.asrock.com

4. Due to the operating system and chipset limitation, the actual memory

size may be less than 4GB for the reservation for system usage under

Windows®XP, Windows®VistaTM, and Windows®VistaTM 64-bit. For

Windows®XP 64-bit with 64-bit CPU, there is no such limitation.

5. Although this motherboard offers stepless control, it is not recommended to

perform over-clocking. Frequencies other than the recommended CPU bus

frequencies may cause the instability of the system or damage the CPU.

6. While CPU overheat is detected, the system will automatically shutdown.

Before you resume the system, please check if the CPU fan on the

motherboard functions properly and unplug the power cord, then plug it

back again. To improve heat dissipation, remember to spray thermal grease

between the CPU and the heatsink when you install the PC system.

7. This motherboard supports ASRock AM2 Boost overclocking technology. If

you enable this function in the BIOS setup, the memory performance will

improve up to 12.5%, but the effect still depends on the AM2 CPU you

adopt. Enabling this function will overclock the chipset/CPU reference clock.

However, we can not guarantee the system stability for all CPU/DRAM

configurations. If your system is unstable after AM2 Boost function is enabled,

it may not be applicative to your system. You may choose to disable this

function for keeping the stability of your system.

8. Please remove PCIE Switch card from PCIE2/PCIE SWITCH slot before

you use ATITM CrossFireTM function. In CrossFireTM mode, the two ATITM graph-

ics cards you install should be from the same GPU family.

8ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

9. This motherboard is bundled with one PCIE Switch card installed on PCIE2/

PCIE SWITCH slot, which allows you better flexibility to choose PCIE func-

tions between one PCIE x16 slot and two PCIE slots for ATITM CrossFireTM

without setting up jumpers. To avail of the PCI Express x16 graphics card

installed on PCIE3 slot work at PCIE x16 bandwidth, please make sure that

PCIE Switch card is installed on PCIE2/PCIE SWITCH slot. Please refer to

page 15 for details of installing a single graphics card.

10. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-channel

and 6-channel modes. Please check the table on page 3 for proper

connection.

11. Before installing SATAII hard disk to SATAII connector, please read the “SATAII

Hard Disk Setup Guide” on page 30 to adjust your SATAII hard disk drive to

SATAII mode. You can also connect SATA hard disk to SATAII connector

directly.

12. This motherboard supports eSATAII interface, the external SATAII

specification. Please read “eSATAII Interface Introduction” on page 27

for details about eSATAII and eSATAII installation procedures.

13. Power Management for USB 2.0 works fine under Microsoft®Windows®

VistaTM 64-bit / VistaTM / XP 64-bit / XP SP1 or SP2 / 2000 SP4.

1.31.3

1.3 Minimum Hardware RMinimum Hardware R

Minimum Hardware RMinimum Hardware R

Minimum Hardware Requirement Tequirement T

equirement Tequirement T

equirement Table for Wable for W

able for Wable for W

able for Windowsindows

indowsindows

indows®®

®®

VistaVista

VistaTMTM

TMTM

TM Premium 2007 and Basic LogoPremium 2007 and Basic Logo

Premium 2007 and Basic LogoPremium 2007 and Basic Logo

Premium 2007 and Basic Logo

For system integrators and users who purchase this motherboard and

plan to submit Windows®VistaTM Premium 2007 and Basic logo, please

follow below table for minimum hardware requirements.

CPU Sempron 2800+

Memory 1GB system memory (Premium)

512MB Single Channel (Basic)

VGA DX9.0 with WDDM Driver

with 128bit VGA memory (Premium)

with 64bit VGA memory (Basic)

* After June 1, 2007, all Windows®VistaTM systems are required to meet above

minimum hardware requirements in order to qualify for Windows®VistaTM Premium

2007 logo.

ASRock ALiveXFire-eSATA2 Motherboard

EnglishEnglish

English

2.2.

2. InstallationInstallation

InstallationInstallation

Installation

This is an ATX form factor (12.0-in x 8.2-in, 30.5 cm x 20.8 cm) motherboard.

Before you install the motherboard, study the configuration of your chassis to en-

sure that the motherboard fits into it.

Pre-installation PrecautionsPre-installation Precautions

Pre-installation Precautions

Take note of the following precautions before you install motherboard

components or change any motherboard settings.

Before you install or remove any component, ensure that the

power is switched off or the power cord is detached from the

power supply. Failure to do so may cause severe damage to the

motherboard, peripherals, and/or components.

1. Unplug the power cord from the wall socket before touching any

component.

2. To avoid damaging the motherboard components due to static

electricity, NEVER place your motherboard directly on the carpet or

the like. Also remember to use a grounded wrist strap or touch a

safety grounded object before you handle components.

3. Hold components by the edges and do not touch the ICs.

4. Whenever you uninstall any component, place it on a grounded anti-

static pad or in the bag that comes with the component.

5. When placing screws into the screw holes to secure the motherboard

to the chassis, please do not over-tighten the screws! Doing so may

damage the motherboard.

1010

10 ASRock ALiveXFire-eSATA2 Motherboard

2.12.1

2.1 CPU InstallationCPU Installation

CPU InstallationCPU Installation

CPU Installation

Step 1. Unlock the socket by lifting the lever up to a 90oangle.

Step 2. Position the CPU directly above the socket such that the CPU corner with

the golden triangle matches the socket corner with a small triangle.

Step 3. Carefully insert the CPU into the socket until it fits in place.

The CPU fits only in one correct orientation. DO NOT force the CPU

into the socket to avoid bending of the pins.

Step 4. When the CPU is in place, press it firmly on the socket while you push

down the socket lever to secure the CPU. The lever clicks on the side tab

to indicate that it is locked.

2.22.2

2.2 Installation of CPU Fan and HeatsinkInstallation of CPU Fan and Heatsink

Installation of CPU Fan and HeatsinkInstallation of CPU Fan and Heatsink

Installation of CPU Fan and Heatsink

After you install the CPU into this motherboard, it is necessary to install a

larger heatsink and cooling fan to dissipate heat. You also need to spray

thermal grease between the CPU and the heatsink to improve heat

dissipation. Make sure that the CPU and the heatsink are securely fas-

tened and in good contact with each other. Then connect the CPU fan to

the CPU FAN connector (CPU_FAN1, see Page 2, No. 3). For proper

installation, please kindly refer to the instruction manuals of the CPU fan

and the heatsink.

STEP 1:

Lift Up The Socket Lever

STEP 2 / STEP 3:

Match The CPU Golden Triangle

To The Socket Corner Small

Triangle

STEP 4:

Push Down And Lock

The Socket Lever

Lever 90° Up CPU Golden Triangle

Socket Corner Small Triangle

EnglishEnglish

English

Otros manuales para ALIVEXFIRE-ESATA2

Tabla de contenidos

Idiomas:

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK X79 Extreme4-M Manual de usuario

ASROCK

ASROCK Z690 Taichi Manual de usuario

ASROCK

ASROCK H55 PRO - V1.0 Manual de usuario

ASROCK

ASROCK Z590 Phantom Gaming-ITX/TB4 Manual de usuario

ASROCK

ASROCK PV530 Manual de usuario

ASROCK

ASROCK ALIVENF7G-HD720P Manual de usuario

ASROCK

ASROCK P5B-DE Manual de usuario

ASROCK

ASROCK Z590 Phantom Gaming-ITX/TB4 Manual de usuario

ASROCK

ASROCK 4CORE1600-GLAN/M Manual de usuario

ASROCK

ASROCK H67DE Manual de usuario

ASROCK

ASROCK H61M-S1 PLUS Manual de usuario

ASROCK

ASROCK Z690 Extreme Manual de usuario

ASROCK

ASROCK Z170 Extreme7+ Manual de usuario

ASROCK

ASROCK G41M-VS Manual de usuario

ASROCK

ASROCK P4I45GV R5.0 Manual de usuario

ASROCK

ASROCK B650M-H/M.2+ Manual de usuario

ASROCK

ASROCK IMB-181-D Manual de servicio

ASROCK

ASROCK 970 Extreme3 R2.0 Manual de usuario

ASROCK

ASROCK J4105B-ITX Manual de usuario

ASROCK

ASROCK Z690 Extreme WiFi 6E Manual de usuario

ASROCK

ASROCK K8NF6G-VSTA Manual de usuario

ASROCK

ASROCK J3355M Manual de usuario

ASROCK

ASROCK B75 Pro3 Manual de usuario

ASROCK

ASROCK 985GM-GS3 FX Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
