ASROCK A320M-HDV Manual de usuario

Version 1.0

Published February 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 9

Chapter 2 Installation 12

2.1 Installing the CPU 13

2.2 Installing the CPU Fan and Heatsink 15

2.3 Installing Memory Modules (DIMM) 23

2.4 Expansion Slots (PCI Express Slots) 25

2.5 Jumpers Setup 26

2.6 Onboard Headers and Connectors 27

2.7 M.2_SSD (NGFF) Module Installation Guide 31

Chapter 3 Software and Utilities Operation 35

3.1 Installing Drivers 35

3.2 ASRock Live Update & APP Shop 36

3.2.1 UI Overview 36

3.2.2 Apps 37

3.2.3 BIOS & Drivers 40

3.2.4 Setting 41

Chapter 4 UEFI SETUP UTILITY 42

4.1 Introduction 42

4.1.1 UEFI Menu Bar 42

4.1.2 Navigation Keys 43

4.2 Main Screen 44

4.3 OC Tweaker Screen 45

4.4 Advanced Screen 46

4.4.1 CPU Conguration 47

4.4.2 North Bridge Conguration 48

4.4.3 South Bridge Conguration 49

4.4.4 Storage Conguration 50

4.4.5 Super IO Conguration 51

4.4.6 ACPI Conguration 52

4.4.7 Trusted Computing 53

4.5 Tools 54

4.6 Hardware Health Event Monitoring Screen 56

4.7 Security Screen 57

4.8 Boot Screen 58

4.9 Exit Screen 60

AB350M-HDV/A320M-HDV/A320M-DGS

English

Chapter 1 Introduction

ank you for purchasing ASRock AB350M-HDV/A320M-HDV/A320M-DGS

motherboard, a reliable motherboard produced under ASRock’s consistently

stringent quality control. It delivers excellent performance with robust design

conforming to ASRock’s commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock AB350M-HDV/A320M-HDV/A320M-DGS Motherboard (Micro ATX Form

Factor)

• ASRock AB350M-HDV/A320M-HDV/A320M-DGS Quick Installation Guide

• ASRock AB350M-HDV/A320M-HDV/A320M-DGS Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this manual will be subject to change without notice. In case any modica-

tions of this manual occur, the updated version will be available on ASRock’s website

without further notice. If you require technical support related to this motherboard,

please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well.

ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

• Solid Capacitor design

CPU • Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)

and Ryzen Series CPUs (Summit Ridge)

• Digi Power design

• 7 Power Phase design

• Supports CPU up to 65W

Chipset • AMD Promontory B350 (AB350M-HDV)

• AMD Promontory A320 (A320M-HDV/A320M-DGS)

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 DIMM Slots

• AMD Ryzen series CPUs support DDR4 3200+(OC)/2933

(OC)/2667/2400/2133 ECC & non-ECC, un-buered

memory*

• AMD 7th Gen A-Series APUs support DDR4 2133 ECC &

non-ECC, un-buered memory*

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

* Please refer to page 23 for DDR4 UDIMM maximum

frequency support.

• Max. capacity of system memory: 32GB

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

• 1 x PCI Express 3.0 x16 Slot (PCIE2 @ x16 mode)*

* Supports NVMe SSD as boot disks

* AMD Ryzen series CPUs support PCIE2: x16 mode

* AMD 7th A-Series APUs support PCIE2: x8 mode

• 1 x PCI Express 2.0 x1 Slot

Graphics • Integrated AMD RadeonTM R7 Series Graphics in A-series /

E-series APU

• DirectX 12, Pixel Shader 5.0

• Max. shared memory 2GB

AB350M-HDV/A320M-HDV:

• ree graphics output options: D-Sub, DVI-D and HDMI

AB350M-HDV/A320M-HDV/A320M-DGS

English

• Supports Triple Monitor

• Supports HDMI with max. resolution up to 4K x 2K

(4096x2160) @ 24Hz / (3840x2160) @ 30Hz

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports D-Sub with max. resolution up to 2048x1536 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with DVI-D and HDMI Ports

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

and HDMI Ports

A320M-DGS:

• Supports DVI-D with max. resolution up to 1920x1200 @

60Hz

• Supports HDCP with DVI-D Port

• Supports Full HD 1080p Blu-ray (BD) playback with DVI-D

Port

Audio • 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

• Supports Surge Protection

• ELNA Audio Caps

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports LAN Cable Detection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 2 x USB 2.0 Ports (Supports ESD Protection)

• 4 x USB 3.0 Ports (Supports ESD Protection)

English

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

AB350M-HDV/A320M-HDV:

• 1 x D-Sub Port

• 1 x DVI-D Port

1 x HDMI Port

A320M-DGS:

• 1 x DVI-D Port

Storage • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

RAID 1 and RAID 10), NCQ, AHCI and Hot Plug

• 1 x Ultra M.2 Socket, supports type 2242/2260/2280 M.2

SATA3 6.0 Gb/s module and M.2 PCI Express module up to

Gen3 x4 (32 Gb/s) (with Ryzen Series CPU) or Gen3 x2

(16 Gb/s) (with A-Series APU)*

* Supports NVMe SSD as boot disks

* Supports ASRock U.2 Kit

Connector • 1 x Print Port Header

• 1 x COM Port Header

• 1 x TPM Header

• 1 x Chassis Intrusion and Speaker Header

• 1 x CPU Fan Connector (4-pin)

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)

* e CPU Fan Connector supports the CPU fan of maximum

1A (12W) fan power.

• 1 x 24 pin ATX Power Connector

• 1 x 4 pin 12V Power Connector

• 1 x Front Panel Audio Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD

Protection)

• 1 x USB 3.0 Header (Supports 2 USB 3.0 ports) (Supports ESD

Protection)

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

• Supports “Plug and Play”

• ACPI 5.1 compliance wake up events

• Supports jumperfree

• SMBIOS 2.3 support

• DRAM Voltage multi-adjustment

AB350M-HDV/A320M-HDV/A320M-DGS

English

* For detailed product information, please visit our website: http://www.asrock.com

Please realize that there is a certain risk involved with overclocking, including adjust-

ing the setting in the BIOS, applying Untied Overclocking Technology, or using third-

party overclocking tools. Overclocking may aect your system’s stability, or even cause

damage to the components and devices of your system. It should be done at your own

risk and expense. We are not responsible for possible damage caused by overclocking.

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan

• CPU/Chassis Fan multi-speed control

• CASE OPEN detection

• Voltage monitoring: +12V, +5V, +3.3V, Vcore

OS • Microso® Windows® 10 64-bit

* For the updated Windows® 10 driver, please visit ASRock’s

website for details: http://www.asrock.com

Certica-

tions

• FCC, CE, WHQL

• ErP/EuP ready (ErP/EuP ready power supply is required)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK K7VM3 Manual de usuario

ASROCK

ASROCK 775Dual-VSTA Manual de usuario

ASROCK

ASROCK GE PRO-HT Manual de usuario

ASROCK

ASROCK H61M-GS Manual de usuario

ASROCK

ASROCK H61M - ANNEXE 392 Manual de usuario

ASROCK

ASROCK 970A-G3.1 Manual de usuario

ASROCK

ASROCK P4DUAL-915GL Manual de usuario

ASROCK

ASROCK N68C-S Manual de usuario

ASROCK

ASROCK J3455-ITX Manual de usuario

ASROCK

ASROCK 970 Extreme4 Manual de usuario

ASROCK

ASROCK P4VM900-SATA2 Manual de usuario

ASROCK

ASROCK J4125-ITX Manual de usuario

ASROCK

ASROCK Z170 Extreme7+ Manual de usuario

ASROCK

ASROCK 880G Pro3 Manual de usuario

ASROCK

ASROCK P5B PRO - QUICK Manual de usuario

ASROCK

ASROCK P55 PRO/USB3 - Manual de usuario

ASROCK

ASROCK AOD790GX-128M Manual de usuario

ASROCK

ASROCK H570 PHANTOM GAMING 4 Manual de usuario

ASROCK

ASROCK CONROE945PL-GLAN Manual de usuario

ASROCK

ASROCK Z77 OC Formula Manual de usuario

ASROCK

ASROCK H77M Manual de usuario

ASROCK

ASROCK H61M-HVGS Manual de usuario

ASROCK

ASROCK P43DE3 Manual de usuario

ASROCK

ASROCK 990FX EXTREME3 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
