ASROCK A320M-HD Manual de usuario

Version 1.0

Published October 2017

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Contents

Chapter 1 Introduction 1

1.1 Package Contents 1

1.2 Specications 2

1.3 Motherboard Layout 6

1.4 I/O Panel 8

Chapter 2 Installation 10

2.1 Installing the CPU 11

2.2 Installing the CPU Fan and Heatsink 13

2.3 Installing Memory Modules (DIMM) 21

2.4 Expansion Slots (PCI Express Slots) 24

2.5 Jumpers Setup 25

2.6 Onboard Headers and Connectors 26

2.7 M.2_SSD (NGFF) Module Installation Guide 30

Chapter 3 Software and Utilities Operation 34

3.1 Installing Drivers 34

3.2 ASRock Live Update & APP Shop 35

3.2.1 UI Overview 35

3.2.2 Apps 36

3.2.3 BIOS & Drivers 39

3.2.4 Setting 40

Chapter 4 UEFI SETUP UTILITY 41

4.1 Introduction 41

4.1.1 UEFI Menu Bar 41

4.1.2 Navigation Keys 42

4.2 Main Screen 43

4.3 OC Tweaker Screen 44

4.4 Advanced Screen 45

4.4.1 CPU Conguration 46

4.4.2 North Bridge Conguration 47

4.4.3 South Bridge Conguration 48

4.4.4 Storage Conguration 49

4.4.5 Super IO Conguration 50

4.4.6 ACPI Conguration 51

4.4.7 Trusted Computing 52

4.5 Tools 53

4.6 Hardware Health Event Monitoring Screen 55

4.7 Security Screen 56

4.8 Boot Screen 57

4.9 Exit Screen 59

A320M-HD

English

Chapter 1 Introduction

ank you for purchasing ASRock A320M-HD motherboard, a reliable

motherboard produced under ASRock’s consistently stringent quality control.

It delivers excellent performance with robust design conforming to ASRock’s

commitment to quality and endurance.

In this manual, Chapter 1 and 2 contains the introduction of the motherboard

and step-by-step installation guides. Chapter 3 contains the operation guide of the

soware and utilities. Chapter 4 contains the conguration guide of the BIOS setup.

1.1 Package Contents

• ASRock A320M-HD Motherboard (Micro ATX Form Factor)

• ASRock A320M-HD Quick Installation Guide

• ASRock A320M-HD Support CD

• 2 x Serial ATA (SATA) Data Cables (Optional)

• 1 x I/O Panel Shield

Because the motherboard specications and the BIOS soware might be updated, the

content of this manual will be subject to change without notice. In case any modica-

tions of this manual occur, the updated version will be available on ASRock’s website

without further notice. If you require technical support related to this motherboard,

please visit our website for specic information about the model you are using. You

may nd the latest VGA cards and CPU support list on ASRock’s website as well.

ASRock website http://www.asrock.com.

English

1.2 Specications

Platform • Micro ATX Form Factor

• Solid Capacitor design

CPU • Supports AMD Socket AM4 A-Series APUs (Bristol Ridge)

and Ryzen Series CPUs (Summit Ridge, Raven Ridge and

Pinnacle Ridge)

• Digi Power design

• 7 Power Phase design

• Supports CPU up to 65W

Chipset • AMD Promontory A320

Memory • Dual Channel DDR4 Memory Technology

• 2 x DDR4 DIMM Slots

• AMD Ryzen series CPUs (Pinnacle Ridge) support DDR4

3200+(OC)/2933/2667/2400/2133 ECC & non-ECC, un-

buered memory*

• AMD Ryzen series CPUs (Summit Ridge) support DDR4

3200+(OC)/2933(OC)/2667/2400/2133 ECC & non-ECC, un-

buered memory*

• AMD Ryzen series CPUs (Raven Ridge) support DDR4

3200+(OC)/2933/2667/2400/2133 non-ECC, un-buered

memory*

• AMD 7th Gen A-Series APUs support DDR4 2400/2133 ECC

& non-ECC, un-buered memory*

* For Ryzen Series CPUs (Raven Ridge), ECC is only supported

with PRO CPUs.

* Please refer to Memory Support List on ASRock’s website for

more information. (http://www.asrock.com/)

* Please refer to page 21 for DDR4 UDIMM maximum

frequency support.

• Max. capacity of system memory: 32GB

• 15μ Gold Contact in DIMM Slots

Expansion

Slot

AMD Ryzen series CPUs (Summit Ridge and Pinnacle Ridge)

• 1 x PCI Express 3.0 x16 Slot (PCIE2: x16 mode)*

AMD 7th A-Series APUs

• 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode)*

AMD Ryzen series CPUs (Raven Ridge)

A320M-HD

English

• 1 x PCI Express 3.0 x16 Slot (PCIE2: x8 mode) (If you use

Athlon 200GE APU, PCIE2 slot will run at x4 mode.)*

* Supports NVMe SSD as boot disks

• 1 x PCI Express 2.0 x1 Slot

Graphics • Integrated AMD RadeonTM R7 Series Graphics in A-series /

E-series APU

• DirectX 12, Pixel Shader 5.0

• Shared memory default 2GB, Max Shared memory supports

up to 16GB.

* e Max shared memory 16 GB requires 32 GB system memory

installed.

• Dual graphics output: Support HDMI and D-Dub ports by

independent display controllers

• Supports HDMI with max. resolution up to 4K x 2K

(4096x2160) @ 24Hz / (3840x2160) @ 30Hz

• Supports D-Sub with max. resolution up to 2048x1536 @

60Hz

• Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and

HBR (High Bit Rate Audio) with HDMI Port (Compliant

HDMI monitor is required)

• Supports HDCP with HDMI Port

• Supports Full HD 1080p Blu-ray (BD) playback with HDMI

Port

Audio • 7.1 CH HD Audio (Realtek ALC887 Audio Codec)

* To congure 7.1 CH HD Audio, it is required to use an HD

front panel audio module and enable the multi-channel audio

feature through the audio driver.

• Supports Surge Protection

• ELNA Audio Caps

LAN • PCIE x1 Gigabit LAN 10/100/1000 Mb/s

• Realtek RTL8111GR

• Supports Wake-On-LAN

• Supports Lightning/ESD Protection

• Supports LAN Cable Detection

• Supports Energy Ecient Ethernet 802.3az

• Supports PXE

English

Rear Panel

I/O

• 1 x PS/2 Mouse/Keyboard Port

• 2 x USB 2.0 Ports (Supports ESD Protection)

• 4 x USB 3.1 Gen1 Ports (Supports ESD Protection)

• 1 x D-Sub Port

• 1 x HDMI Port

• 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

• HD Audio Jacks: Line in / Front Speaker / Microphone

Storage • 4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,

RAID 1 and RAID 10), NCQ, AHCI and Hot Plug

• 1 x Ultra M.2 Socket, supports M Key type 2242/2260/2280

M.2 SATA3 6.0 Gb/s module and M.2 PCI Express module up

to Gen3 x4 (32 Gb/s) (with Summit Ridge, Raven Ridge and

Pinnacle Ridge) or Gen3 x2 (16 Gb/s) (with A-Series APU)*

* Supports NVMe SSD as boot disks

* Supports ASRock U.2 Kit

Connector • 1 x Print Port Header

• 1 x COM Port Header

• 1 x TPM Header

• 1 x Chassis Intrusion and Speaker Header

• 1 x CPU Fan Connector (4-pin)

• 2 x Chassis Fan Connectors (1 x 4-pin, 1 x 3-pin)

* e CPU Fan Connector supports the CPU fan of maximum

1A (12W) fan power.

• 1 x 24 pin ATX Power Connector

• 1 x 4 pin 12V Power Connector

• 1 x Front Panel Audio Connector

• 2 x USB 2.0 Headers (Support 4 USB 2.0 ports) (Supports ESD

Protection)

• 1 x USB 3.1 Gen1 Header (Supports 2 USB 3.1 Gen1 ports)

(Supports ESD Protection)

BIOS

Feature

• AMI UEFI Legal BIOS with GUI support

• Supports “Plug and Play”

• ACPI 5.1 compliance wake up events

• Supports jumperfree

• SMBIOS 2.3 support

• DRAM Voltage multi-adjustment

A320M-HD

English

* For detailed product information, please visit our website: http://www.asrock.com

Please realize that there is a certain risk involved with overclocking, including adjust-

ing the setting in the BIOS, applying Untied Overclocking Technology, or using third-

party overclocking tools. Overclocking may aect your system’s stability, or even cause

damage to the components and devices of your system. It should be done at your own

risk and expense. We are not responsible for possible damage caused by overclocking.

Hardware

Monitor

• CPU/Chassis temperature sensing

• CPU/Chassis Fan Tachometer

• CPU/Chassis Quiet Fan

• CPU/Chassis Fan multi-speed control

• CASE OPEN detection

• Voltage monitoring: +12V, +5V, +3.3V, Vcore

OS • Microso® Windows® 10 64-bit

* For the updated Windows® 10 driver, please visit ASRock’s

website for details: http://www.asrock.com

Certica-

tions

• FCC, CE

• ErP/EuP ready (ErP/EuP ready power supply is required)

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK X299 OC Formula Manual de usuario

ASROCK

ASROCK Fatal1ty Z170 Gaming K4 Series Manual de usuario

ASROCK

ASROCK H61M-S1 PLUS Manual de usuario

ASROCK

ASROCK AM2XLI-ESATA2 Manual de usuario

ASROCK

ASROCK N3700-ITX Manual de usuario

ASROCK

ASROCK IMB-183 Manual de usuario

ASROCK

ASROCK 775VM800 Manual de usuario

ASROCK

ASROCK A785GM Manual de usuario

ASROCK

ASROCK P55DE PRO - Manual de usuario

ASROCK

ASROCK Z97 Pro4 Manual de usuario

ASROCK

ASROCK SOM-P101 Manual de usuario

ASROCK

ASROCK 870iCafe Manual de usuario

ASROCK

ASROCK 960GM-VGS3 FX Manual de usuario

ASROCK

ASROCK Z87 Extreme6 Manual de usuario

ASROCK

ASROCK AB350 Pro4 Manual de usuario

ASROCK

ASROCK B85M-GL Manual de usuario

ASROCK

ASROCK H410M-H/M.2 SE Manual de usuario

ASROCK

ASROCK PENRYN1600SLI-110DB Manual de usuario

ASROCK

ASROCK Q1900B-ITX Manual de usuario

ASROCK

ASROCK 4Core1333-eSATA2 Manual de usuario

ASROCK

ASROCK RACK EP2C612D16C-4L Manual de usuario

ASROCK

ASROCK AB350M Pro4 Manual de usuario

ASROCK

ASROCK H55M R2.0 Manual de usuario

ASROCK

ASROCK B75M-DGS R2.0 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
