ASROCK 970 Pro2 Manual de usuario

970 Pro2

User Manual

Version 1.0

Published August 2012

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identication or explanation and to the owners’ benet, without intent to infringe.

Disclaimer:

Specications and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or tness for a particular purpose.

In no event shall ASRock, its directors, ofcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction ................................................................ 5

1.1 Package Contents ..................................................................... 5

1.2 Specications ............................................................................. 6

1.3 Unique Features ........................................................................ 9

1.4 Motherboard Layout ................................................................. 12

1.5 I/O Panel .................................................................................. 13

2. Installation .................................................................. 14

Pre-installation Precautions ................................................................ 14

2.1 CPU Installation ......................................................................... 15

2.2 Installation of CPU Fan and Heatsink ...................................... 15

2.3 Installation of Memory Modules (DIMM) .................................... 16

2.4 Expansion Slots (PCI and PCI Express Slots) ........................... 18

2.5 Jumpers Setup ........................................................................... 19

2.6 Onboard Headers and Connectors ....................................... 20

2.7 Serial ATA2 (SATA2) Hard Disks Installation ......................... 25

2.8 Hot Plug and Hot Swap Functions for Serial ATA2 (SATA2)

HDDs ........................................................................................ 25

2.9 SATA / SATA2 HDD Hot Plug Feature and Operation Operation

Guide ........................................................................................ 26

2.10 Driver Installation Guide ............................................................ 28

2.11 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit With RAID Functions .................................................. 28

2.11.1 Installing Windows® XP / XP 64-bit With RAID

Functions ....................................................................... 28

2.11.2 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

With RAID Functions ..................................................... 29

2.12 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit Without RAID Functions ............................................. 30

2.12.1 Installing Windows® XP / XP 64-bit Without RAID

Functions ....................................................................... 30

2.12.2 Installing Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit

Without RAID Functions ................................................ 31

2.13 Untied Overclocking Technology ............................................ 31

3. BIOS SETUP UTILITY ................................................. 32

3.1 Introduction ................................................................................ 32

3.1.1 BIOS Menu Bar ............................................................... 32

3.1.2 Navigation Keys ............................................................... 33

3.2 Main Screen ............................................................................... 33

3.3 OC Tweaker Screen................................................................... 34

3.4 Advanced Screen ...................................................................... 38

3.4.1 CPU Conguration ........................................................... 39

3.4.2 Chipset Conguration ...................................................... 40

3.4.3 ACPI Conguration .......................................................... 41

3.4.4 Storage Conguration ...................................................... 43

3.4.6 PCIPnP Conguration...................................................... 44

3.4.6 Floppy Conguration ....................................................... 45

3.4.5 Super IO Conguration .................................................... 46

3.4.7 USB Conguration ........................................................... 47

3.5 Hardware Health Event Monitoring Screen ............................... 48

3.6 Boot Screen ............................................................................... 49

3.7 Security Screen ......................................................................... 50

3.8 Exit Screen ................................................................................ 51

4. Software Support ....................................................... 52

4.1 Install Operating System ............................................................ 52

4.2 Support CD Information ............................................................. 52

4.2.1 Running Support CD ....................................................... 52

4.2.2 Drivers Menu ................................................................... 52

4.2.3 Utilities Menu ................................................................... 52

4.2.4 Contact Information ......................................................... 52

1. Introduction

Thank you for purchasing ASRock 970 Pro2 motherboard, a reliable motherboard

produced under ASRock’s consistently stringent quality control. It delivers excellent

performance with robust design conforming to ASRock’s commitment to quality and

endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conguration

guide to BIOS setup and information of the Support CD.

Because the motherboard specications and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modications of this manual occur, the updated ver-

sion will be available on ASRock website without further notice. You may

nd the latest VGA cards and CPU support lists on ASRock website as

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for specic information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock 970 Pro2 Motherboard

(ATX Form Factor: 12.0-in x 7.5-in, 30.5 cm x 19.1 cm)

ASRock 970 Pro2 Quick Installation Guide

ASRock 970 Pro2 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows® 7 / 7 64-bit / VistaTM / VistaTM 64

bit, it is recommended to set the BIOS option in Storage Conguration to

AHCI mode.

1.2 Specications

Platform - ATX Form Factor: 12.0-in x 7.5-in, 30.5 cm x 19.1 cm

- All Solid Capacitor design

CPU - Support for Socket AM3+ processors

- Support for Socket AM3 processors: AMD PhenomTM II X6 /

X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 /

Sempron processors

- Supports 8-Core CPU

- Digi Power Design

- Supports CPU up to 140W

- Supports AMD OverDriveTM with ACC feature (Advanced

Clock Calibration)

- Supports AMD’s Cool ‘n’ QuietTM Technology

- FSB 2600 MHz (5.2 GT/s)

- Supports Untied Overclocking Technology

- Supports Hyper-Transport 3.0 (HT 3.0) Technology

Chipset - Northbridge: AMD 770

- Southbridge: AMD SB710

Memory - Dual Channel DDR3 Memory Technology

- 4 x DDR3 DIMM slots

- Support DDR3 1866(OC)/1600(OC)/1333/1066/800

non-ECC, un-buffered memory (see CAUTION 1)

- Max. capacity of system memory: 32GB (see CAUTION 2)

Expansion Slot - 1 x PCI Express 2.0 x16 slot (PCIE3 @ x16 mode)

- 3 x PCI Express 2.0 x1 slots

- 2 x PCI slots

Audio - 5.1 CH HD Audio (Realtek ALC662 Audio Codec)

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Serial Port: COM1

- 6 x Ready-to-Use USB 2.0 Ports

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Line in / Front Speaker / Microphone

Connector - 6 x SATA2 3.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 10 and JBOD), NCQ, AHCI and “Hot Plug”

functions

- 1 x ATA133 IDE connector (supports 2 x IDE devices)

- 1 x Floppy connector

- 1 x IR header

- 1 x HDMI_SPDIF header

- 1 x Power LED header

- 1 x CPU Fan connector (4-pin)

- 1 x Chassis Fan connector (4-pin)

- 1 x Power Fan connector (4-pin)

- 24 pin ATX power connector

- 8 pin 12V power connector

- CD in header

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

BIOS Feature - 8Mb AMI Legal BIOS

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU, VCCM, NB Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version), AMD

OverDriveTM Utility, CyberLink MediaEspresso 6.5 Trial,

ASRock MAGIX Multimedia Suite - OEM

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU Quiet Fan

- CPU/Chassis/Power Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP

/ XP Media Center / XP 64-bit compliant

Certications - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

* For detailed product information, please visit our website: http://www.asrock.com

CAUTION!

1. Whether 1866/1600MHz memory speed is supported depends

on the AM3/AM3+ CPU you adopt. If you want to adopt DDR3

1866/1600 memory module on this motherboard, please refer

to the memory support list on our website for the compatible

memory modules.

ASRock website: http://www.asrock.com

2. Due to the operating system limitation, the actual memory size

may be less than 4GB for the reservation for system usage un-

der Windows® 7 / VistaTM / XP. For Windows® 64-bit OS with 64-

bit CPU, there is no such limitation.

WARNING

Please realize that there is a certain risk involved with overclocking,

including adjusting the setting in the BIOS, applying Untied Overclocking

Technology, or using third-party overclocking tools. Overclocking may

affect your system’s stability, or even cause damage to the components

and devices of your system. It should be done at your own risk and

expense. We are not responsible for possible damage caused by

overclocking.

1.3 Unique Features

ASRock OC Tuner

ASRock OC Tuner is a user-friendly overclocking tool which al-

lows you to surveil your system by hardware monitor function

and overclock your hardware devices to get the best system

performance under Windows® environment.

ASRock Intelligent Energy Saver

Featuring an advanced proprietary hardware and software de-

sign, Intelligent Energy Saver is a revolutionary technology that

delivers unparalleled power savings. The voltage regulator can

reduce the number of output phases to improve efciency when

the CPU cores are idle. In other words, it is able to provide ex-

ceptional power saving and improve power efficiency without

sacrificing computing performance. To use Intelligent Energy

Saver function, please enable Cool ‘n’ Quiet option in the BIOS

setup in advance.

ASRock Instant Boot

ASRock Instant Boot allows you to turn on your PC in just a few

seconds, provides a much more efcient way to save energy,

time, money, and improves system running speed for your sys-

tem. It leverages the S3 and S4 ACPI features which normally

enable the Sleep/Standby and Hibernation modes in Windows®

to shorten boot up time. By calling S3 and S4 at specic timing

during the shutdown and startup process, Instant Boot allows

you to enter your Windows® desktop in a few seconds.

ASRock Instant Flash

ASRock Instant Flash is a BIOS ash utility embedded in Flash

ROM. This convenient BIOS update tool allows you to update

system BIOS without entering operating systems rst like MS-

DOS or Windows®. With this utility, you can press the <F6> key

during the POST or the <F2> key to enter into the BIOS setup

menu to access ASRock Instant Flash. Just launch this tool and

save the new BIOS le to your USB ash drive, oppy disk or

hard drive, then you can update your BIOS only in a few clicks

without preparing an additional oppy diskette or other compli-

cated ash utility. Please be noted that the USB ash drive or

hard drive must use FAT32/16/12 le system.

ASRock OC DNA

The software name itself – OC DNA literally tells you what it

is capable of. OC DNA, an exclusive utility developed by AS-

Rock, provides a convenient way for the user to record the OC

settings and share with others. It helps you to save your over-

clocking record under the operating system and simplies the

complicated recording process of overclocking settings. With

OC DNA, you can save your OC settings as a prole and share

with your friends! Your friends then can load the OC prole to

their own system to get the same OC settings as yours! Please

be noticed that the OC prole can only be shared and worked

on the same motherboard.

ASRock APP Charger

If you desire a faster, less restricted way of charging your

Apple devices, such as iPhone/iPad/iPod Touch, ASRock has

prepared a wonderful solution for you - ASRock APP Charger.

Simply install the APP Charger driver, it makes your iPhone

charge much quickly from your computer and up to 40% faster

than before. ASRock APP Charger allows you to quickly charge

many Apple devices simultaneously and even supports continu-

ous charging when your PC enters into Standby mode (S1),

Suspend to RAM (S3), hibernation mode (S4) or power off (S5).

With APP Charger driver installed, you can easily enjoy the

marvelous charging experience.

ASRock XFast USB

ASRock XFast USB can boost USB storage device perfor-

mance. The performance may depend on the properties of the

device.

ASRock XFast LAN

ASRock XFast LAN provides a faster internet access, which

includes the benefits listed below. LAN Application Prioritiza-

tion: You can congure your application’s priority ideally and/or

add new programs. Lower Latency in Game: After setting online

game’s priority higher, it can lower the latency in games. Trafc

Shaping: You can watch Youtube HD videos and download si-

multaneously. Real-Time Analysis of Your Data: With the status

window, you can easily recognize which data streams you are

transferring currently.

Otros manuales para 970 Pro2

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK B460M Steel Legend Manual de usuario

ASROCK

ASROCK H61ICAFE Manual de usuario

ASROCK

ASROCK K7S41 Manual de usuario

ASROCK

ASROCK FM2A75M-ITX R2.0 Manual de usuario

ASROCK

ASROCK Z170M-PIO2 Manual de usuario

ASROCK

ASROCK P55 EXTREME Manual de usuario

ASROCK

ASROCK AD525PV3 Manual de usuario

ASROCK

ASROCK G41M-VS3 Manual de usuario

ASROCK

ASROCK Fatal1ty Z97 Manual de usuario

ASROCK

ASROCK X58 DELUXE Manual de usuario

ASROCK

ASROCK P43R1600TWINS - V1.0 Manual de usuario

ASROCK

ASROCK WRX80D8-2T Manual de usuario

ASROCK

ASROCK H310CM-HG4 Manual de usuario

ASROCK

ASROCK H81 Pro BTC Manual de usuario

ASROCK

ASROCK 939Dual-VSTA Manual de usuario

ASROCK

ASROCK X79 Extreme9 Manual de usuario

ASROCK

ASROCK J3455-NUC IPC Manual de usuario

ASROCK

ASROCK B85M-GL Manual de usuario

ASROCK

ASROCK P67 TRANSFORMER - Manual de usuario

ASROCK

ASROCK N61P-GS - Manual de usuario

ASROCK

ASROCK Z77 Extreme3 Manual de usuario

ASROCK

ASROCK P4I45E R3.0 Manual de usuario

ASROCK

ASROCK H370M-HDV Manual de usuario

ASROCK

ASROCK G41C-GS Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
