ASROCK 970 Extreme3 Manual de usuario

970 Extreme3

User Manual

Version 1.0

Published August 2011

No part of this manual may be reproduced, transcribed, transmitted, or translated in

any language, in any form or by any means, except duplication of documentation by

the purchaser for backup purpose, without written consent of ASRock Inc.

Products and corporate names appearing in this manual may or may not be regis-

tered trademarks or copyrights of their respective companies, and are used only for

identiﬁcation or explanation and to the owners’ beneﬁt, without intent to infringe.

Disclaimer:

Speciﬁcations and information contained in this manual are furnished for informa-

tional use only and subject to change without notice, and should not be constructed

as a commitment by ASRock. ASRock assumes no responsibility for any errors or

omissions that may appear in this manual.

With respect to the contents of this manual, ASRock does not provide warranty of

any kind, either expressed or implied, including but not limited to the implied warran-

ties or conditions of merchantability or ﬁtness for a particular purpose.

In no event shall ASRock, its directors, ofﬁcers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of proﬁts, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from

any defect or error in the manual or product.

This device complies with Part 15 of the FCC Rules. Operation is subject to the fol-

lowing two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

The Lithium battery adopted on this motherboard contains Perchlorate, a toxic

substance controlled in Perchlorate Best Management Practices (BMP) regulations

passed by the California Legislature. When you discard the Lithium battery in Cali-

fornia, USA, please follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see

www.dtsc.ca.gov/hazardouswaste/perchlorate”

ASRock Website: http://www.asrock.com

Contents

1. Introduction................................................................. 5

1.1 Package Contents ..................................................................... 5

1.2 Speciﬁcations............................................................................. 6

1.3 Motherboard Layout ................................................................. 12

1.4 I/O Panel .................................................................................. 13

2. Installation................................................................... 15

Pre-installation Precautions................................................................ 15

2.1 CPU Installation......................................................................... 16

2.2 Installation of CPU Fan and Heatsink ...................................... 16

2.3 Installation of Memory Modules (DIMM).................................... 17

2.4 Expansion Slots (PCI and PCI Express Slots)........................... 19

2.5 CrossFireXTM and Quad CrossFireXTM Operation Guide............ 20

2.6 Surround Display Information.................................................... 23

2.7 ASRock Smart Remote Installation Guide................................. 24

2.8 Jumpers Setup........................................................................... 25

2.9 Onboard Headers and Connectors ....................................... 26

2.10 SerialATA3 (SATA3) Hard Disks Installation ......................... 31

2.11 Hot Plug and Hot Swap Functions for SATA3 HDDs................. 31

2.12 SATA3 HDD Hot Plug Feature and Operation Operation Guide 32

2.13 Driver Installation Guide ............................................................ 34

2.14 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit With RAID Functions.................................................. 34

2.14.1 Installing Windows®XP / XP 64-bit With RAID

Functions....................................................................... 34

2.14.2 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

With RAID Functions..................................................... 35

2.15 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP /

XP 64-bit Without RAID Functions............................................. 36

2.15.1 Installing Windows®XP / XP 64-bit Without RAID

Functions....................................................................... 36

2.15.2 Installing Windows®7 / 7 64-bit / VistaTM / VistaTM 64-bit

Without RAID Functions................................................ 37

2.16 Untied Overclocking Technology ............................................ 37

3. UEFI SETUP UTILITY.......................................................... 38

3.1 Introduction................................................................................ 38

3.1.1 UEFI Menu Bar................................................................ 38

3.1.2 Navigation Keys............................................................... 39

3.2 Main Screen............................................................................... 39

3.3 OC Tweaker Screen................................................................... 40

3.4 Advanced Screen ...................................................................... 44

3.4.1 CPU Conﬁguration........................................................... 45

3.4.2 North Bridge Conﬁguration.............................................. 46

3.4.3 South Bridge Conﬁguration ............................................. 47

3.4.4 Storage Conﬁguration...................................................... 48

3.4.5 Super IO Conﬁguration.................................................... 49

3.4.6 ACPI Conﬁguration.......................................................... 50

3.4.7 USB Conﬁguration........................................................... 52

3.5 Hardware Health Event Monitoring Screen ............................... 53

3.6 Boot Screen............................................................................... 54

3.7 Security Screen ......................................................................... 55

3.8 Exit Screen ................................................................................ 56

4. Software Support......................................................... 57

4.1 Install Operating System............................................................ 57

4.2 Support CD Information............................................................. 57

4.2.1 Running Support CD ....................................................... 57

4.2.2 Drivers Menu................................................................... 57

4.2.3 Utilities Menu................................................................... 57

4.2.4 Contact Information......................................................... 57

1. Introduction

Thank you for purchasing ASRock 970 Extreme3 motherboard, a reliable mother-

board produced under ASRock’s consistently stringent quality control. It delivers

excellent performance with robust design conforming to ASRock’s commitment to

quality and endurance.

In this manual, chapter 1 and 2 contain introduction of the motherboard and step-

by-step guide to the hardware installation. Chapter 3 and 4 contain the conﬁguration

guide to BIOS setup and information of the Support CD.

Because the motherboard speciﬁcations and the BIOS software might

be updated, the content of this manual will be subject to change without

notice. In case any modiﬁcations of this manual occur, the updated ver-

sion will be available on ASRock website without further notice. You may

ﬁnd the latest VGA cards and CPU support lists on ASRock website as

well. ASRock website http://www.asrock.com

If you require technical support related to this motherboard, please visit

our website for speciﬁc information about the model you are using.

www.asrock.com/support/index.asp

1.1 Package Contents

ASRock 970 Extreme3 Motherboard

(ATX Form Factor: 12.0-in x 8.6-in, 30.5 cm x 21.8 cm)

ASRock 970 Extreme3 Quick Installation Guide

ASRock 970 Extreme3 Support CD

2 x Serial ATA (SATA) Data Cables (Optional)

1 x I/O Panel Shield

ASRock Reminds You...

To get better performance in Windows®7 / 7 64-bit / VistaTM / VistaTM 64

bit, it is recommended to set the BIOS option in Storage Conﬁguration

to AHCI mode. For the BIOS setup, please refer to the “User Manual” in

our support CD for details.

1.2 Specifications

Platform - ATX Form Factor: 12.0-in x 8.6-in, 30.5 cm x 21.8 cm

- All Solid Capacitor design (100% Japan-made high-quality

Conductive Polymer Capacitors)

CPU - Support for Socket AM3+ processors

- Support for Socket AM3 processors: AMD PhenomTM II X6 /

X4 / X3 / X2 (except 920 / 940) / Athlon II X4 / X3 / X2 /

Sempron processors

- Supports 8-Core CPU

- Supports UCC feature (Unlock CPU Core) (see CAUTION 1)

- V4 + 1 Power Phase Design

- Supports CPU up to 140W

- Supports AMD’s Cool ‘n’ QuietTM Technology

- FSB 2400 MHz (4.8 GT/s)

- Supports Untied Overclocking Technology (see CAUTION 2)

- Supports Hyper-Transport 3.0 (HT 3.0) Technology

Chipset - Northbridge: AMD 970

- Southbridge: AMD SB950

Memory - Dual Channel DDR3 Memory Technology (see CAUTION 3)

- 4 x DDR3 DIMM slots

- Support DDR3 2100(OC)/1866(OC)/1800(OC)/1600(OC)/

1333/1066/800 non-ECC, un-buffered memory

(see CAUTION 4)

- Max. capacity of system memory: 32GB (see CAUTION 5)

Expansion Slot - 2 x PCI Express 2.0 x16 slots

(PCIE2 @ x16 mode; PCIE4 @ x4 mode)

- 2 x PCI Express 2.0 x1 slots

- 2 x PCI slots

- Supports AMDTM Quad CrossFireXTM and CrossFireXTM

Audio - 7.1 CH HD Audio with Content Protection

(Realtek ALC892 Audio Codec)

- Premium Blu-ray audio support

- Supports THX TruStudioTM

LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s

- Realtek RTL8111E

- Supports Wake-On-LAN

- Supports LAN Cable Detection

- Supports Energy Efﬁcient Ethernet 802.3az

- Supports PXE

Rear Panel I/O I/O Panel

- 1 x PS/2 Mouse Port

- 1 x PS/2 Keyboard Port

- 1 x Coaxial SPDIF Out Port

- 1 x Optical SPDIF Out Port

- 4 x Ready-to-Use USB 2.0 Ports

- 2 x Ready-to-Use USB 3.0 Ports

- 1 x eSATA3 Connector

- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED

LED)

- HD Audio Jack: Side Speaker/Rear Speaker/Central/Bass/

Line in/Front Speaker/Microphone (see CAUTION 6)

SATA3 - 5 x SATA3 6.0 Gb/s connectors, support RAID (RAID 0,

RAID 1, RAID 5 and RAID 10), NCQ, AHCI and "Hot Plug"

functions

USB 3.0 - 2 x USB 3.0 ports by Etron EJ168A, support USB 1.0/2.0/3.0

up to 5Gb/s

Connector - 5 x SATA3 6.0Gb/s connectors

- 1 x IR header

- 1 x CIR header

- 1 x COM port header

- 1 x HDMI_SPDIF header

- 1 x Power LED header

- CPU/Chassis/Power FAN connector

- 24 pin ATX power connector

- 8 pin 12V power connector

- Front panel audio connector

- 3 x USB 2.0 headers (support 6 USB 2.0 ports)

BIOS Feature - 32Mb AMI UEFI Legal BIOS with GUI support

- Supports “Plug and Play”

- ACPI 1.1 Compliance Wake Up Events

- Supports jumperfree

- SMBIOS 2.3.1 Support

- CPU, VCCM, NB, SB Voltage Multi-adjustment

Support CD - Drivers, Utilities, AntiVirus Software (Trial Version),

CyberLink MediaEspresso 6.5 Trial, AMD OverDriveTM Utility,

AMD Fusion, AMD Fusion Media Explorer, ASRock Software

Suite (CyberLink DVD Suite - OEM and Trial; ASRock

MAGIX Multimedia Suite - OEM)

Unique Feature - ASRock Extreme Tuning Utility (AXTU) (see CAUTION 7)

- ASRock Instant Boot

- ASRock Instant Flash (see CAUTION 8)

- ASRock APP Charger (see CAUTION 9)

- ASRock SmartView (see CAUTION 10)

- ASRock XFast USB (see CAUTION 11)

- ASRock XFast LAN (see CAUTION 12)

- ASRock On/Off Play Technology (see CAUTION 13)

- Hybrid Booster:

- CPU Frequency Stepless Control (see CAUTION 14)

- ASRock U-COP (see CAUTION 15)

- Boot Failure Guard (B.F.G.)

- Turbo UCC

Hardware - CPU Temperature Sensing

Monitor - Chassis Temperature Sensing

- CPU/Chassis/Power Fan Tachometer

- CPU/Chassis Quiet Fan

- CPU/Chassis Fan Multi-Speed Control

- Voltage Monitoring: +12V, +5V, +3.3V, Vcore

OS - Microsoft® Windows® 7 / 7 64-bit / VistaTM / VistaTM 64-bit / XP

/ XP 64-bit compliant

Certiﬁcations - FCC, CE, WHQL

- ErP/EuP Ready (ErP/EuP ready power supply is required)

(see CAUTION 16)

* For detailed product information, please visit our website: http://www.asrock.com

WARNING

Please realize that there is a certain risk involved with overclocking, including adjusting the

setting in the BIOS, applying Untied Overclocking Technology, or using the third-party over-

clocking tools. Overclocking may affect your system stability, or even cause damage to the

components and devices of your system. It should be done at your own risk and expense.

We are not responsible for possible damage caused by overclocking.

CAUTION!

1. ASRock UCC (Unlock CPU Core) feature simpliﬁes AMD CPU activa-

tion. As long as a simple switch of the UEFI option “ASRock UCC”, you

can unlock the extra CPU core to enjoy an instant performance boost.

When UCC feature is enabled, the dual-core or triple-core CPU will boost

to the quad-core CPU, and some CPU, including quad-core CPU, can

also increase L3 cache size up to 6MB, which means you can enjoy the

upgrade CPU performance with a better price. Please be noted that UCC

feature is supported with AM3/AM3+ CPU only, and in addition, not every

AM3/AM3+ CPU can support this function because some CPU’s hidden

core may be malfunctioned.

2. This motherboard supports Untied Overclocking Technology. Please read

“Untied Overclocking Technology” on page 37 for details.

3. This motherboard supports Dual Channel Memory Technology. Before

you implement Dual Channel Memory Technology, make sure to read the

installation guide of memory modules on page 17 for proper installation.

4. Whether 2100/1866/1800/1600MHz memory speed is supported de-

pends on the AM3/AM3+ CPU you adopt. If you want to adopt DDR3

2100/1866/1800/1600 memory module on this motherboard, please refer

to the memory support list on our website for the compatible memory

modules. Non OC mode’s DDR3 1866 is supported byAM3+ CPU.

ASRock website: http://www.asrock.com

5. Due to the operating system limitation, the actual memory size may be

less than 4GB for the reservation for system usage under Windows®7 /

VistaTM / XP. For Windows®64-bit OS with 64-bit CPU, there is no such

limitation.

6. For microphone input, this motherboard supports both stereo and mono

modes. For audio output, this motherboard supports 2-channel, 4-chan-

nel, 6-channel, and 8-channel modes. Please check the table on page 13

for proper connection.

7. ASRock Extreme Tuning Utility (AXTU) is an all-in-one tool to ne-tune

different system functions in a user-friendly interface, which is including

Hardware Monitor, Fan Control, Overclocking, OC DNA and IES. In Hard-

ware Monitor, it shows the major readings of your system. In Fan Control,

it shows the fan speed and temperature for you to adjust. In Overclock-

ing, you are allowed to overclock CPU frequency for optimal system

performance. In OC DNA, you can save your OC settings as a proﬁle

and share with your friends. Your friends then can load the OC proﬁle to

their own system to get the same OC settings. In IES (Intelligent Energy

Saver), the voltage regulator can reduce the number of output phases to

improve efﬁciency when the CPU cores are idle without sacriﬁcing com-

puting performance. Please visit our website for the operation procedures

of ASRock Extreme Tuning Utility (AXTU).

ASRock website: http://www.asrock.com

8. ASRock Instant Flash is a BIOS ﬂash utility embedded in Flash ROM.

This convenient BIOS update tool allows you to update system BIOS

without entering operating systems ﬁrst like MS-DOS or Windows®. With

this utility, you can press <F6> key during the POST or press <F2> key to

BIOS setup menu to access ASRock Instant Flash. Just launch this tool

and save the new BIOS ﬁle to your USB ﬂash drive, ﬂoppy disk or hard

drive, then you can update your BIOS only in a few clicks without prepar-

ing an additional ﬂoppy diskette or other complicated ﬂash utility. Please

be noted that the USB ﬂash drive or hard drive must use FAT32/16/12 ﬁle

system.

9. If you desire a faster, less restricted way of charging your Apple devices,

such as iPhone/iPod/iPad Touch, ASRock has prepared a wonderful solu-

tion for you - ASRock APP Charger. Simply installing the APP Charger

driver, it makes your iPhone charged much quickly from your computer

and up to 40% faster than before. ASRock APP Charger allows you to

quickly charge many Apple devices simultaneously and even supports

continuous charging when your PC enters into Standby mode (S1), Sus-

pend to RAM (S3), hibernation mode (S4) or power off (S5). With APP

Charger driver installed, you can easily enjoy the marvelous charging

experience than ever.

ASRock website: http://www.asrock.com/Feature/AppCharger/index.asp

10. ASRock SmartView, a new function of internet browser, is the smart start

page for IE that combines your most visited web sites, your history, your

Facebook friends and your real-time newsfeed into an enhanced view for

a more personal Internet experience. ASRock motherboards are exclu-

sively equipped with the ASRock SmartView utility that helps you keep in

touch with friends on-the-go. To use ASRock SmartView feature, please

make sure your OS version is Windows®7 / 7 64 bit / VistaTM / VistaTM 64

bit, and your browser version is IE8.

ASRock website: http://www.asrock.com/Feature/SmartView/index.asp

11. ASRock XFast USB can boost USB storage device performance. The

performance may depend on the property of the device.

12. ASRock XFast LAN provides a faster internet access, which includes be-

low beneﬁts. LAN Application Prioritization: You can conﬁgure your appli-

cation priority ideally and/or add new programs. Lower Latency in Game:

After setting online game priority higher, it can lower the latency in game.

Traffic Shaping: You can watch Youtube HD video and download files

simultaneously. Real-Time Analysis of Your Data: With the status window,

you can easily recognize which data streams you are currently transfer-

ring.

13. ASRock On/Off Play Technology allows users to enjoy the great audio ex-

perience from the portable audio devices, such like MP3 player or mobile

phone to your PC, even when the PC is turned off (or in ACPI S5 mode)!

This motherboard also provides a free 3.5mm audio cable (optional) that

ensures users the most convenient computing environment.

Otros manuales para 970 Extreme3

Tabla de contenidos

Otros manuales de Placa madre de ASROCK

ASROCK

ASROCK Z790 PG SONIC Manual de usuario

ASROCK

ASROCK Z68 Extreme4 Gen3 Manual de usuario

ASROCK

ASROCK Rack MT-C224 Manual de usuario

ASROCK

ASROCK WRX80D8-2T Manual de usuario

ASROCK

ASROCK Z590 Steel Legend Manual de usuario

ASROCK

ASROCK ALIVEN570SLI-ESATA2 Manual de usuario

ASROCK

ASROCK A55 Pro Manual de usuario

ASROCK

ASROCK QC5000-ITX/WiFi Manual de usuario

ASROCK

ASROCK 890GX Extreme3 Manual de usuario

ASROCK

ASROCK P45XE Manual de usuario

ASROCK

ASROCK H61M-GE Manual de usuario

ASROCK

ASROCK Fatal1ty Z97M Killer Series Manual de usuario

ASROCK

ASROCK B660-ITX Manual de usuario

ASROCK

ASROCK FM2A88M Extreme4+ Manual de usuario

ASROCK

ASROCK IMB-150 Manual de servicio

ASROCK

ASROCK A520M-ITX/ac Manual de usuario

ASROCK

ASROCK P4I945GC Manual de usuario

ASROCK

ASROCK 970A-G3.1 Manual de usuario

ASROCK

ASROCK X533 Manual de usuario

ASROCK

ASROCK Fatal1ty FM2A88X+ Killer Series Manual de usuario

ASROCK

ASROCK IMB-A160 Manual de servicio

ASROCK

ASROCK Intel N100 Series Manual de usuario

ASROCK

ASROCK Z77 OC Formula Manual de usuario

ASROCK

ASROCK FM2A78M-HD+ R2.0 Manual de usuario

Manuales populares de Placa madre de otras marcas

DFI

DFI SD170 Manual de usuario

Asus

Asus P2L97A Manual de usuario

Winmate

Winmate IC70 Manual de usuario

Asus

Asus MES-B Manual de usuario

Grantech

Grantech SYS8F377VGGA-3OMN Manual de usuario

Telit Wireless Solutions

Telit Wireless Solutions SL869-3DR Manual de usuario

Gigabyte

Gigabyte GA-9IVDT Manual de usuario

Texas Instruments

Texas Instruments ADS8372EVM Manual de usuario

Commell

Commell MS-C73 Manual de usuario

IBT Technologies

IBT Technologies MB860 Manual de usuario

Nvidia

Nvidia TEGRA DG-04927-001_V01 Manual de usuario

Biostar

Biostar M7VIT Bravo Instrucciones de funcionamiento e instalación

Intel

Intel D33217CK Manual de usuario

Asus

Asus F1A55-M LX PLUS R2.0 Manual de usuario

EPC

EPC EPC9147C Manual de usuario

Asus

Asus EX-B760M-V5 D4 Manual de usuario

EPOX

EPOX MU-8KHA0010 Manual de usuario

Ski-Doo

Ski-Doo Bombardier MPEM 219 700 090 Manual de usuario
