Asko BO4PY4T2-12 Manual de usuario

Instructions for use

OVEN

OP8478G / BO4PY4T2-12

OP8678G / BO6PY4T2-12

EN 2

EN Manual EN 3 - EN 48

Pictograms used

Important information

Tip

EN 3

CONTENTS

Your oven

Introduction 4

Control panel 5

Description 6

Touch screen 9

Main displays 10

Function-setting display 12

Stand-by display 13

Initial use

Initial use 14

Operation

Using the ‘Plus’ menu 16

Opening the keyboard 18

Use

Oven function 19

Using the ‘Extras’ functions 21

Fast preheat 22

Functions table 23

Culisensor 27

Delayed start 30

Stage cooking 31

Additional functions 34

Settings 38

Cleaning

Cleaning the appliance 40

Steam clean 40

Pyrolysis 41

Removing and cleaning the guide rails 42

Replacing the oven light bulb 42

Removing the oven door 43

Removing the oven window 44

Solving problems

General 45

Technical specifications 47

Your oven and the environment

Disposal of the appliance and packaging 48

EN 4

Introduction

Congratulations on choosing this Asko oven.

This product is designed to offer simple operation and optimum

user-friendliness. The oven has a wide range of settings enabling you to

select the correct cooking method every time.

This manual shows how you can best use this oven. In addition to

information about operating the oven, you will also find background

information that may be useful when using the appliance.

Please read the separate safety instructions

carefully before using the appliance!

Read this manual before using the appliance and keep it in a safe

place for future use.

Installation instructions are supplied separately.

YOUR OVEN

EN 5

YOUR OVEN

Control panel

01. On/Off key; use to:

▷switch on the appliance.

▷switch to stand-by

▷switch off the appliance. Keep the ‘On/Off’ key pressed until the

appliance switches off.

02. X key; use to:

▷go a step back in the menu.

▷close or answer ‘No’ to a pop-up.

▷close or cancel a menu or function.

03. Key lock key; use to:

▷Lock all the keys to clean the dashboard or to prevent that the

appliance gets into progress accidentally. Hold the key pressed

until the key lock is enabled.

04. Confirm key; use to:

▷confirm settings

▷start a function.

▷close or answer ‘Yes’ to a pop-up.

05. Touch screen/display

10 15

10 10 2015

040502

01 03

EN 6

YOUR OVEN

Description

1. Control panel

2. Shelf levels

▷OP8678G: 5 levels*

▷OP8478G: 4 levels

3. Oven door

4. Door handle

The following accessories are supplied with your oven:

• Baking tray; used for pastries and cakes.

• Oven rack; mainly used for grilling.

A dish or pan with food can also be placed on the oven rack.

This oven rack is equipped with a safety peg. Lift the rack at the

front slightly to slide this out of the oven space.

• Deep baking tray; used for roasting meat and baking moist cakes.

The deep baking tray can also be used as a drip tray. Place the

deep baking tray on the first level to grill or to use as a drip tray.

Level 1

Level 2

Level 3

Level 4

Level 5*

EN 7

Culisensor

• Culisensor; can be used to measure the core temperature of

the dish. When the desired temperature is reached, the cooking

process will be stopped automatically.

Guide rails

• The oven has four or five shelf levels, depending on the model.

Level 1 is mainly used in combination with bottom heat.

Levels 3 and 4/5 are used mainly for the grill function.

• Place the oven rack or baking tray in the gap between the guide

rail sliders.

Telescopic guide rail

• A number of shelf levels have a fully-retractable telescopic guide

rail.

• Pull the telescopic guide rails out of the oven cavity completely

and place the oven rack or baking tray. Then slide the oven rack or

baking tray, on the telescopic guide rails, back into the oven cavity.

Only close the oven door when the telescopic guide rails are returned

completely back into the oven cavity.

Pyrolysis guide rail

• Only use for pyrolysis cleaning. If you also want to clean the baking

tray with pyrolysis, then place these guide rails.

• Please note; the high temperature during pyrolysis can cause the

guide rails to discolour.

YOUR OVEN

EN 8

YOUR OVEN

Rotisserie

This is used for roasting all kinds of dishes such as rolled meats or

chicken. The rotisserie comprises a spit with 2 clamps, a detachable

handle and a spit roast that fits in the centre of the oven. The spit fits in

the rotisserie motor in the back wall of the oven.

• Slide the deep baking tray in at level 1 to catch juices or fat.

• Slide one of the clamps onto the spit and then slide the meat you

wish to roast onto the spit.

• Place the spit roast in the central oven level with the ‘v’ shape to

the front.

• The handle can be screwed onto the blunt end of the spit to make

positioning the spit easier.

• Place the spit on the spit roast with the pointed end away from you.

Push gently until the spit fits in the rotisserie motor in the back wall.

The blunt end of the spit needs to fit in the ‘v’ shape. (The spit has

two notches, both of which need to be mounted on the oven door

side so that the spit stays in position. The notches also serve as a

grip for the handle.)

• The rotisserie motor starts running when a function with grill has

been started

• Remove the handle prior to baking or roasting. You can then

reattach the handle to the spit to remove this from the oven easily.

Door

• The door switches interrupt the operation of the oven when the oven

door is opened during use. The oven resumes operation when the

door is closed.

• This oven has a ‘Soft close door system’. When closing the oven

door, this system dampens the movement, from a certain angle, and

silently closes the oven door.

EN 9

YOUR OVEN

Cooling fan

• The appliance is equipped with a cooling fan that cools the casing

and control panel.

Touch screen

• Operate your oven’s touch screen by tapping or swiping it.

• Tap the display to open a function or adjust a setting.

• Swipe the display for further information/show options or adjust

a setting.

Tapping: Swiping:

EXTRASOVEN FAST PREHEAT

10:15

Hot air

352*5$06

180 30

°C

10:15

For the best response, touch the keys with the main part of your

fingertip. Every time you tap a key during use, a short tone will sound

(unless this is adjusted in the settings).

EN 10

YOUR OVEN

Main displays

Start display

EXTRASOVEN FAST PREHEAT

10:15

Plus menu (01)

• Tap the plus symbol to open the ‘Plus’ menu. The contents of this

menu change according to the control options available at that time.

Oven (02)

• Tap ‘OVEN’ to open the oven function menu.

Egg timer (03)

• Tap the egg timer symbol to open the egg timer menu. The egg

timer can be used independently from the oven function.

▷The longest possible alarm time is 24 hours.

▷When an egg timer goes off, a pop-up will appear and an

acoustic signal will sound.

▷Tap on the X key, confirm key or the display to switch off

the signal and close the pop-up. The sound signal will stop

automatically after approximately 1 minute.

Extras (04)

• Tap on ‘EXTRAS’ to show the appliance’s extra functions.

Time (05)

• The time is shown here.

Fast preheat (06)

• Tap on ‘FAST PREHEAT’ to open the fast preheat function.
