Operating Instructions

Tumble dryer

ASKO T754HP

Dear Customer,

Thank you for choosing this quality product from ASKO.

We hope it will meet your expectations and fulll your needs for many years

to come. Scandinavian design combines clean lines, everyday functionality,

and high quality. These are key characteristics of all our products and the

reason they are greatly appreciated throughout the world.

To ensure that you get the most out of your new machine, we recommend

that you read the operating instructions before using the machine. The

operating instructions also contain information on how to avoid damaging

the environment.

WARNING: Read the instructions before using the machine.

Before using your machine for

the rst time 3

Laundry labels 3

Safety instructions 4

Safety 4

Transport/Winter storage 4

Packing material 4

Recycling 4

Vented dryers 5

Child safety 6

General 6

Description of the tumble dryer 7

Advice and tips before you tumble-dry 8

Materials that can be tumble-dried 8

Materials that must not be tumble-dried 8

Static electricity 8

Tumble drying 9

1Sort your fabrics 9

2Press the main power switch until the

display lights. 9

3Open the door, load the items and then

close the door 9

4Select the program 10

5Selecting Options 12

6Press the Start button 12

7Drying program nished 13

Care and cleaning 14

Cleaning the lint lter 14

Emptying the condensed water container 15

Cleaning the evaporator lter and evaporator

Cleaning the outside of the machine 16

Troubleshooting 17

The machine will not start 17

The machine loses all power during a

program 17

Drying takes too long 17

Error messages 17

Technical information 18

Technical data 18

Standard tests 18

Service 19

Before contacting the service division 19

Installation 20

Positioning the tumble dryer 20

Adjusting the feet 21

Condensed water 22

Electrical installation 22

Door hanging 23

Follow these instructions: 24

Quick guide 28

Contents

Before using your machine for the rst time

Laundry labels

Certain materials are not suitable for tumble-

drying. Always check and follow the instructions

on each item’s laundry label. You can nd more

information in the Advice and tips before you

tumble-dry chapter.

NOTE!

When starting the tumble dryer for the rst time

or after a long period without use, you may

notice a slight thumping noise. This noise is

completely normal and will disappear after a few

loads.

Read the operating instructions and

keep them in a safe place!

• Electrical installation, if required, should be

carried out by a qualied electrician.

• The machine should only be used for tumble-

drying as described in these instructions.

• Repairs and maintenance must be carried

out by a qualied professional.

• Damaged mains cables must only be

replaced by a qualied electrician.

• Sucient ventilation is required to prevent

smoke from open res or fumes from

equipment burning other fuels being sucked

into the room when the tumble dryer is

running.

• Do not dry dirty laundry in the tumble dryer.

• Items that are stained with e.g. cooking oil,

acetone, alcohol, petrol, kerosene, stain

remover, turpentine, wax and wax remover

should be washed in hot water with extra

detergent before they go in the tumbler dryer.

• Items such as foam rubber, latex, plastic,

waterproof textiles, rubber-coated items and

clothes and foam-rubber lled cushions must

not be dried in the tumbler dryer.

• Fabric softener or similar products should

be used as per the recommendations of the

detergent manufacturer.

• The machine is not designed to be used by

persons (even children) that are physically

or mentally handicapped or lack experience

and knowledge. Such persons must receive

instruction in how to use the machine from

the person responsible for their safety.

• Children must be watched to ensure they do

not play with the machine.

Safety

• The machine must not be used for drying

items that have been dry-cleaned at home

or fabrics that may contain residues of

ammable liquids.

• The appliance is not intended for use by

young children or inrm persons without

supervision.

• The machine automatically cuts o if the

condenser water tank is full or outlet hose is

blocked.

WARNING!

When the tumble dryer is operating, the back

of the tumble dryer will get very hot. Leave the

machine to cool completely before touching the

back.

Installation

See the section Installation.

WARNING!

Do not start the machine until it has been in

position for 24 hours. If for some reason the

tumble dryer needs to be laid down for transport

or service, it must be laid on its left side viewed

from the front.

Transport/Winter storage

If you need to move your machine or store it

over the winter in unheated premises, make

sure that you drain the condensed water

container beforehand.

Packing material

Sort waste materials in accordance with local

guidelines.

Recycling

This machine is manufactured and labelled for

recycling. In order to prevent personal injury,

the machine must be made inoperable after

deciding to take it out of service. Contact your

local authority for information about where and

how your machine should be correctly recycled.

Safety instructions

To minimize the risk of re in a tumble

dryer, the following should be observed:

• Items that have been spotted or soaked

with vegetable or cooking oil constitute a

re hazard and should not be placed in a

tumble dryer.Oil-aected items can ignite

spontaneously, especially when exposed to

heat sources such as in a tumble dryer.

The items become warm, causing an

oxidation reaction in the oil. Oxidation

creates heat. If the heat cannot escape, the

items can become hot enough to catch re.

Piling, stacking or storing oil-aected items

can prevent heat from escaping and so

create a re hazard. If it is unavoidable that

fabrics that contain vegetable or cooking

oil or have been contaminated by hair care

products be placed in a tumble dryer they

should rst be washed in hot water with

extra detergent - this will reduce, but not

eliminate, the hazard. The ’cool down’ cycle

of tumble dryers should be used to reduce

the temperature of the items. They should not

be removed from the tumble dryer or piled or

stacked while hot.

• Items that have been previously cleaned in,

washed in, soaked in or spotted with petrol/

gasoline, dry-cleaning solvents or other

ammable or explosive substances should

not be placed in a tumble dryer. Highly

ammable substances commonly used in

domestic environments include acetone,

denatured alcohol, petrol/gasoline, kerosene,

spot removers (some brands), turpentine,

waxes and wax removers.

• Items containing foam rubber (also known

as latex foam) or similarly textured rubberlike

materials should not be dried in a tumble

dryer on a heat setting. Foam rubber

materials can, when heated, produce re by

spontaneous combustion.

• Fabric softeners or similar products should

not be used in a tumble dryer to eliminate

the eects of static electricity unless this

practice is specically recommended by

the manufacturer of the fabric softener or

product.

• Undergarments that contain metal

reinforcements should not be placed in a

tumbledryer. Damage to the tumble dryer

can result if metal reinforcements come

loose during drying. When available a drying

rack could be used for such items.

• Plastic articles such as shower caps or

babies’ waterproof napkin covers should not

be placed in a tumble dryer. Rubber-backed

articles, clothes tted with foam rubber pads,

pillows, galoshes and rubber-coated tennis

shoes should not be placed in a tumble

dryer.

Vented dryers

• There has to be adequate ventilation to avoid

the back ow of gases into the room from

appliances burning other fuels, including

open res, when operating the tumble dryer.

• The exhaust air must not be discharged into

a ue which is used for exhausting fumes

from appliances burning gas or other fuels.

CAUTION!

Air from the tumble dryer must not be fed

through ducts used for equipment that burns

gas or other fuels.

General

WARNING!

Do not allow children to play with the

tumble dryer.

• If the door is opened when a program is

running the garments may be very hot, with a

risk of burn injuries.

• The tumble dryer does not start automatically

when the door is closed (if a child pulls the

door shut from the inside, for example).

Child safety

Description of the tumble dryer

1. Main power switch

2. Condensed water container

3. Panel

4. Serial Number

5. Lint lter

6. Outer door

7. Evaporator and lter

1 2 3 4 5 6

Advice and tips before you tumble-dry

Here are some tips that may help you before

you begin tumble-drying.

Have the clothes been spun?

Items to be tumble-dried should be spun at

1000 rpm or faster. Higher spin speeds save

energy and reduce drying time.

Materials that can be tumble-dried

This symbol means that the material is

suitable for tumble-drying. Fabrics best suited

to¨tumble-drying are cotton fabrics, terry cloth

and synthetic bres. Garments will be softer and

lighter when tumbled than when hung out to dry.

NOTE!

The tumble dryer does not cause any signicant

wear on fabrics. The lint that collects in the lint

lter consists of dust and bre residues formed

when the items are used.

Materials that must not be tumble-

dried

This symbol means that the material is not

suitable for tumble-drying. Certain materials

may melt or become a re hazard if exposed to

heat, and others can lose their shape or shrink.

And do not tumble-dry

• materials labelled "Do not dry near heat".

• garments that have been dry-cleaned at

home.

• plastic foam.

• breglass material.

• wool because of the risk of felting.

Static electricity

To reduce the risk of static electricity in the

laundry after tumble drying you can:

• Use fabric softener when washing.

• Wait ve minutes after the drying program

ends before opening the door and removing

the laundry from the dryer.

NOTE!

You can stop the tumble dryer by pressing the

Stop button for three seconds or by opening the

door. In both cases the program is stopped and

starts from the beginning if restarted.

If you do not want to restart the program then

immediately remove all laundry and spread it

out to allow the heat to dissipate.

Below are step-by-step instructions to help you

achieve the best possible tumble-drying results.

1Sort your fabrics

You will achieve the most uniform drying

results if the items are made of the same

type of material. Do up zips and buttons, fasten

belts, sort the items and adjust the load and

temperature.

Do not overload the drum!

Overloading the dryer will result in poor drying

results and wrinkling.

2Press the main power switch

until the display lights.

NOTE:

Power on

Press the on/o button for min. 1 sec and max.

5 sec.

Power o

Press the on/o button for min. 5 sec.

If the ON/OFF command is not correctly

accepted by the machine, wait min. 8 sec before

any further press.

3Open the door, load the items

and then close the door

Make sure that objects e.g. detergent

dispensing balls, have been removed from the

laundry. They could melt and cause damage to

the dryer or the laundry.

To save energy, always observe the maximum

load for each program (see Program chart).

Tumble drying

4Select the program

Tumble drying

Guidelines as to what specic

programs can be used for:

Auto extra dry

This program is for items that are particularly

dicult to dry, e.g. jeans with very thick seams.

NOTE!

Knitted fabrics in particular are prone to

shrinkage. Use the Auto dry, Auto normal dry or

Auto Iron dry programs for these items. Stretch

clothes back into shape immediately after

drying.

Auto dry and Auto normal dry

These programs end automatically when the

load is dry. The Auto dry program gives slightly

drier laundry than Auto normal dry.

Auto Iron dry

This program shuts o the heat once the load is

just damp enough for ironing or pressing.

Timed dry

The most suitable program time depends

on what you intend to do with the items after

tumble-drying them. Use trial and error to nd

out what works best. When you use Timed dry

to tumble-dry a load of mixed fabrics, some of

the garments may remain damp. Tumble-dry

any damp garments for a further 30 minutes or

so using the Timed dry program.

Select the desired time by pressing the Delayed

Start button. A program time between 30

minutes and 3 hours can be selected and each

button press changes the time by 15 minutes.

NOTE!

When using the Timed dry program with a

program time that is too long, the garments

can become “over-dry”. This can cause items

to shrink or crease and feel rough to the touch.

Synthetic materials can also become charged

with static electricity.

Revitalise

Use the Air u program when you just want to

refresh, air or soften up items.

Select the desired time by pressing the Delayed

Start button. A program time between 15

minutes and 3 hours can be selected and each

button press changes the time by 15 minutes.

Select a program by turning the program selector. An LED lights next to the selected program. Use the

option buttons to select any options.

Programme selector

Main power switch Display windowOptions buttons

StopStart

Otros manuales para T754HP

Tabla de contenidos

Otros manuales de Secadora de Asko

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario

Frigidaire

Frigidaire CAQE7077KW0 Manual del propietario

Bosch

Bosch WTX8HKM9SN Manual de usuario
