Asko DW95 Manual de usuario

INDEX

DW95

DISHWASHERS

Content Page

Dishwashers

DW950, 951 952 95C 1-7

DW953, 354 955, 95FI 8-16

DW 950 / 951 / 952 / 95C

1. PROGRAMS DW 950, 951, 952, 95C

Rinse & Hold program

One rinse without heat.

Intensive wash program

3 pre-washes, main wash, 2 rinses and drying.

Basictemperature:65°Cinfirstpre-wash,mainwashandlast

rinse.30°Cinsecondpre-wash . 70°C in drying.

Normal wash program

Two pre-washes, main wash, 2 rinses and drying.

Basictemperature:30°Cinpre-wash, 55°C in main wash and

lastrinse.70°Cindrying.

Light wash program

One pre-wash, main wash, 2 rinses and drying.

Basictemperature:55°Cinmain wash and last rinse. 70°C in drying.

Rinse program

One rinse and drying.

Basictemperature:55°Cin rinse. 70°C in drying.

Plate heating

One drying sequence.

Basictemperature:65°C.

DW 950 / 951 / 952 / 95C

2. PROGRAM OPTIONS BUTTONS

Thedishwashercanhave1,2or3,optionpushbuttonsand 1 rotary switch for

watersoftner setting.

Drying heat

You can select drying with or without heat.

Temperature

Selectionbetween55°Cand 65°C in main wash, last rinse and in pre-washin

theIntensivewashprogram.

Program without heat (Pika pesu)

You can getaprogramwithout heat.

Setting of water softner (just softner machines)

Theopening time for the softener inletvalvecanbeadjusted to suit diffrent

degreesofwater hardness.

(3settingswhich can be set with screw driver).

123Pos 1 Waterhardness < 20°dH .

Pos2 Water hardness 20—35 °dH

Pos3 Water hardness > 35 °dH

DW 950 / 951 / 952 / 95C

CONTROL UNIT

DW951,952,95C hasan electro-mechanical timer.

CIRCULATION PUMP

The circulation pump consists of an asynchronous motor and pump,

constructedinanintegrated unit.A4µFcapacitoris fitted toensure

reliable starting of the circulation pump.

OUTLET PUMP

The outlet pump consists of a synchronous motor and pump, constructed

in anintegrated unit.

INLET VALVE

Dependingon model, there are three typesofinletvalves:

1.Withsafety valve:Two solenoids independant fromeachotheror valve

seatsareconnectedtoaunit.

2.Single-unit type:Asolenoidandvalve seat.

3.Softener valve:Twovalves inshunt,onefor theregenerationofthe softe

nerand theotherfornormal inlet.

HEATING ELEMENT

Heatingelementswiththe following capacities: 1800 W alt. , 2500 W

THERMOSTAT

Differentthermostats are mounted, depending onmodel:

30/70°C Thermostatwith twoswitch-off functionswiththe temperatures

30°C (reset at 22°C) and 70°C (reset at 62°C) for temperature

stopin pre-wash or drying,respectively.

64153° Thermostatwith twoswitch-off functionswiththe temperatures

64° C (reset at 56° C) and 53° C (reset at 45° C) for temperature

stopinmain wash and last rinse at high, or low temperature,

alternately.

60°C Thermostatwithoneswitch-offfunctions withthetemperatures

60°C(resetat52°C) for temperature stop in main-wash and last

rinseon models withouttemperatureselction.

HIGH TEMPERATURE CUTOUT

Thermostatwith switch-off-functionat 88°C,190°Fprevents theheating

elementfrom remaining continously energisedifthecontrol unit or thetimer

shouldfail.

ELECTRICAL FUNCTION

DW 950 / 951 / 952 / 95C

DOOR SWITCH

Amicroswitch senses that the door has been opened. Thisinterruptsthepro

gramand cutsthepower to all control components(motor, valves etc.). See

faultindicationsonpage7.

LEVEL SWITCH

Thelevel switch providesprotectionagainstoverfilling, interrupting thepower

supplyto theinletvalve andstartingthe outlet pump.

OVERFILL SWITCH

Afloat influencesamicroswitch which shutstheinlet valve andstartsthe outlet

pump.

COMBI DISPENSER

The combi doser doses both detergent and rinse aid .

Inthe doser there is an adjustable volume chamberforsettingofthede~ired

amountofrinseaid. On certain models there is a sensor for rinseaid level

mountedon thedoser.

MAIN SWITCH

Themain switch is a 2-poleswitch,interruptingboth the phase and neutral

supplies.

ELECTRICAL CORD

Themachines are fitted with 3x1,0mm2connectioncordsand earthed plugs.

Variationsoccur for differentmarkets.

DW 950 / 951 / 952 / 95C

ELECTRICAL SUPPLY

Asdelivered , the machines arewired forconnection to asingle-phase, 230V,

10Asupply, with aheaterMAINSWITCH

Themain switch is a 2-poleswitch,interruptingboth the phase and neutral

supplies. power of 1800 W, giving a total power requirement of 2000 W.

Alternative:single-phase,230V, 16A, heater power 3000 W totalpower

requirement 3200 W . Altemative: 2-phase, 400 V, 10A, heater power 3000

Wtotalpower requirement 3200 W.

SOFTNER

Oncertainmodelssensorforrinseaidlevelis mounted on the softner.This

indicatesbylackof salt.

FAN

Evacuatesthemoistairfrom the machine during the drying phase of the pro-

gram.

Thefansystem consistsofafanmotorwhichrunsa two partimpeller.Dryair

issuckedinfromthedoor into one of the impeller halves.Avax motor opens a

valve,and themoistairstreamsintotheotherpartof the impeller. Dry and moist

airaremixed and led into a channel to thelower part of the door, where it is let

out.

DW 950 / 951 / 952 / 95C

WATER SOFTENING

Thewatersofteneroperatesasfollows:

During rinse, pre-wash and main wash:

1. Inletvalve1opensandadmitswater.

2. Thewaterflows

•through hose 3 to air-brekdevice, no1

• passes an airgap

•leavesthe air-breakdevicethroughno.3

•passes hose 7 to theresin containerof thesofte-

ner,no3.

Therethewaterissoftenedandthesoftwaterflows

•outthroughno.4

• through hose 8 back to the air-break device no. 4

•entersthemachinethroughno.6.

1 Inletvalve1

2. Inletvalve2(regenerationvalve)

3. Hose IV1 - air-break device

4. Hose IV2 - air-break device

5. Air-break device

6. Inletopening

7. Hose air-break device no. 3- resin

containerno.3

8. Hose air-break device no. 4 – resin

containerno.4

9. Hose air-break device no. 5 - salt

containerno.5

10.Saltcontainer

11.Resincontainer

Hard water, containing lime,

Ca(HCO3)2flows into the resin

container. The Ca ions are

replaced by Na. Soft water,

containing Na(HCO3) flows

into the machine.

Regeneration during the main wash:

3. Whenthemachinehasadmittedwater,asdescribedabove,forthemainwash,inlet

valve2opensfor20,30or50seconds, dependingon thesetting.Thewaterflows

throughhose4totheair-breakdevice5,onthroughhose9andintosaltcontainerno.5.

Thesalt-saturatedwaterflowsintotheresincontainer,whereitregeneratestheresin,so

thatitcansoftenfurtherwater.

Na(HCO )

Ca(HCO )

Resin container

DW 950 / 951 / 952 / 95C

THE SALT CONTAINER

Rinses

Rinse1startsbyflushingthewatersoftenersystemfor40-90seconds,

dependingonsetting, atthesametimeasthemachinepumpsout. This

is then followed by rinses as described in 1) and 2) above.

Ifhardwater(i.e.containinglime)isallowedtodryonthedishes,glasses

etc.,insolubledepositsof limewill beleft.

Ca(HCO3)2CaCO3+ CO2+ H2O

Insolublelime

Ifthewaterissoftenedwithsalt,sodiumcarbonateandcalciumchloride

areformed.Thesetwosaltsarewater-soluble,andleavenodeposits.

Ca(HCO3)2 + 2 NaCl = 2NaHCO3+ CaCl2

2NaHCO3Na2CO3+ CO2+H2O

Soluble soda

0,05 - 0,23 litres

ofwater flow

intothe salt

container,where

the Ca is

replacedby Na.

CaCl2isflushed

intothe

machine.

2NaCl

Na Cl

CaCl

Na Cl

DW 953, 954, 955, 95FI

Start

Stop

DW 95.FI

DW 953

DW 954

DW 955

PROGRAMS DW 953, 954, 955, 95FI

Pots & Pans program

Two pre-washes, mainwash,4rinses and drying.

Basictemperature:45°Cinfirst pre-wash 70°C in main wash,

65°Cinlastrinse.

Strong wash program

Two pre-washes, main wash, 3 rinses and drying.

Basictemperature:45°Cinfirstpre-wash, 65°C in main wash and last rinse.

Normal wash program

Two pre-washes, main wash, 2 rinses and drying.

Basictemperature:30°Cinpre-wash,65°C in main wash and last rinse.

Light wash program

One pre-wash, main wash, 2 rinses and drying.

Basic temperature: 65°C in main wash and last rinse.
