ATCA-8330

Quick Start Guide

P/N:6806800S67B (August 2014)

Observe ESD-safe

measures

What’s in the box?

Install the DIMM

When installing or servicing the mod-

ule or accessories, strictly observe the

safety precautions in the Safety Notes

Summary. Otherwise, personal injury

or property damage may occur.

• Use either a properly grounded ESD wrist

strap or make sure that you are working in

an ESD-safe environment.

• Connect to the ESD connector at the front

or the rear of the system.

Make sure you receive all items of your

shipment:

• One ATCA-8330 blade

• One printed copy of Quick Start Guide

(this document)

• One printed Safety Notes Summary

• Any optional items ordered

Prepare the installation

site

• For information on the environmental and

power requirements, see the ATCA-8330

Installation and Use manual.

• Operating temperatures refer to the tem-

perature of the air circulating around the

blade and not to the actual component

temperature.

Notes:

• Some blade variants come with the DIMM

already installed.

• For thermal safety concerns, no 4-rank

DIMMs and stacked DIMMS are allowed.

1. If necessary, remove the blade from the sys-

tem.

2. Open the locks of the memory module

socket.

3. Press the memory module carefully into the

socket. As soon as the memory module is

fully inserted, the locks automatically close.

4. If necessary, repeat steps 2–3 to install addi-

tional memory modules.

Install the MO-297 SSD

module

1. Remove the blade from the system.

2. Plug the MO297 SSD module into the

MO297 connector. When inserting the

MO297 module to the on-board connec-

tor, hold the on-board connector with two

fingers to prevent damage to the connec-

tor.

3. Fasten the MO297 SSD module to the

blade using the screws supplied with the

ACC kit. The two screws M1.6x4mm with

Nylon Patch come with the module.

4. Reinstall the blade into the system.

ATCA-8330-Quick Start Guide

Artesyn Embedded Technologies

Marketing Communications

2900 S. Diablo Way, Suite 190

Tempe, Arizona 85282

Artesyn Embedded Technologies

Lilienthalstr. 17-19

85579 Neubiberg/Munich

Germany

6. Wait until the blue LED is switched off,

then tighten the face plate screws which

secure the blade to the shelf. The switched

off blue LED indicates that the blade’s pay-

load has been powered up and that the

blade is active.

7. If necessary, connect cables to the face

plate.

6Install the Blade (cont.)

6Install the Blade

The following procedure assumes that the

system is powered. If it is unpowered, you

can disregard the blue LED and skip its

respective step.

1. Ensure that the top and bottom ejector

handles are in the outward position by

squeezing the lever and the latch together.

2. Insert the blade into the shelf by placing

the top and bottom edges of the blade in

the card guides of the shelf. Ensure that

the guiding module of the shelf and blade

are aligned properly.

3. Squeeze the lever and the latch together

and hook the lower and the upper handle

into the shelf rail recesses.

4. Fully insert the blade and lock it to the

shelf by squeezing the lever and the latch

together and turning the handles towards

the face plate.

5. If your shelf is powered, as soon as the

blade is connected to the backplane power

pins, the blue LED is illuminated. When the

blade is completely installed, the blue LED

starts to blink. This indicates that the blade

announces its presence to the shelf man-

agement controller.

Note: If an RTM is connected to the front

blade, make sure that the handles of

both the RTM and the front blade are

closed in order to power up the blade’s

payload.

Install the DSP-Module

Note:

• Some blade variants may come with DSP

modules already installed.

• The DSP-modules are sitting very close

next to each other. When extracting and

inserting modules take extra care not to

damage modules by sliding across neigh-

bor slots.

1. If necessary, remove the blade from the

system.

2. Remove the 6 screws of the DSP area cover

and remove the cover.

3. Open the locks of the DSP module socket.

Install the DSP-Module

(Cont.)

4. Press the DSP module carefully into the

socket. As soon as the DSP module is fully

inserted, the locks automatically close.

5. If necessary, repeat steps 3–4 to install

additional DSP Modules.

6. Put the DSP area cover back on and secure

it by properly fastening the 6 screws again.

Finding more information

For more information on the product, see

the ATCA-8330 Installation and Use and
