Arrowquip EASY FLOW Manual de usuario

EASY FLOW

CATTLE RACE

01530 632002 | [email protected]

arrowquip.co.uk

PRODUCT MANUAL

APRIL 2021

CONTENTS

Safety Precautions 1

Risk Assessment 2

Before Installing 2

Assembly Instructions

Assembling a Single Easy Flow Race 3

Kicker Panel Installation 7

Anti-Backing Bar Installation 10

Rolling Race Gate Installation 12

Between Two Races 12

Between a Race and a Kicker Panel 13

Between a Race and a Forcing Pen 15

Between a Race and a Vet Cage 16

Other Products 17

Adjusting the Easy Flow Cattle Race 17

Emergency Exit 17

Using the Removable Side Panels 18

Recommended Maintenance 18

Bill of Materials 19

Warranty 20

PLEASE FOLLOW ALL SAFETY INSTRUCTIONS PROVIDED IN THIS MANUAL

BEFORE OPERATION. ARROWQUIP DOES NOT ACCEPT RESPONSIBILITY

FOR ANY ACCIDENTS OR INJURY WHEN THIS SAFETY MANUAL HAS

NOT BEEN READ IN FULL AND KEPT WITH THE PRODUCT AT ALL TIMES.

OPERATORS OF THIS PRODUCT TAKE AND ACCEPT RESPONSIBILTY FOR

ANY HARM OR INJURY TO THE ANIMAL OR OPERATOR WHEN IT PERTAINS

TO HOW THE EQUIPMENT IS USED AND MAINTAINED.

Please keep this manual for frequent reference and to pass on to new users or owners.

SAFETY PRECAUTIONS

PLEASE FOLLOW ALL SAFETY PRECAUTIONS OUTLINED HEREIN. ANY

HARM TO THE ANIMAL OR INJURY TO THE OPERATOR WHICH OCCURS

DUE TO HOW THE PRODUCT IS OPERATED, OR RESULTING FROM A LACK

OF SAFETY PRECAUTIONS ARE THE SOLE RESPONSIBILITY OF THE

OPERATOR.

All farm machinery and equipment is potentially dangerous. Careless use of any Arrowquip

livestock equipment may cause injury or damage to persons, cattle, or property. Arrowquip

has taken precautions in the design and manufacturing of this product to ensure that it is safe

and user-friendly. Therefore, user must assume all responsibility and risk associated with the

possession and use of the equipment.

WARNING: READ BELOW BEFORE OPERATION.

DANGER:

PANELS ARE VERY HEAVY AND WILL DROP WITH EXCESSIVE

PRESSURE WHEN AN ANIMAL IS CONTAINED IN THE RACE.

FAILURE TO OPERATE THE EMERGENCY EXIT PROPERLY

MAY RESULT IN DAMAGE OR INJURY/DEATH.

SAFETY LATCHES MUST BE IN PLACE WHEN ADJUSTING THE

SIDES OF THE EASY FLOW CATTLE RACE. FAILURE TO USE

THE SAFETY LATCHES MAY CAUSE THE PANELS TO DROP,

RESULTING IN DAMAGE TO PERSONS OR PROPERTY.

1 | SAFETY PRECAUTIONS

1. Ensure the operator understands the contents of this manual before using the

equipment.

2. Donotwearloose-ttedclothing.

3. Ensuretheequipmentisonarm,level,drysurfacethatisfreeofrocksandothertrip 

hazards.

4. DO NOT ALLOW CHILDREN UNDER THE AGE OF 18 NEAR AN OPERATING

MACHINE.

5. Follow safe cattle handling procedures in other areas of the yard so that cattle are more

docile.

6. DonotmakeanymodicationstoArrowquipequipment.Non-factorymodicationsto 

the equipment can reduce the safety for the operator and livestock.

RISK ASSESSMENT

Conduct a risk assessment on procedures for which the equipment is used and establish a

safe work procedure.

1. Ensure all users of the equipment have been inducted and comply with safe working

procedure.

2. Please ensure that there are NO large or hazardous objects inside the equipment that

may cause injury to the animal or operator, or may cause the equipment to malfunction.

3. Make sure that your equipment has been cleared of ALL livestock after use.

4. Some chemicals and medicines can damage powder coat. Take all precautions and

wash after use.

Level Ground HEAVY

Partner Lift

Forklift Required

BEFORE INSTALLING

RISK ASSESSMENT | 2

PACKING LIST: 8´ EASY FLOW RACE

7002337

7001812

7002062

2004618

WING HEAD BOLT

2004619

2004616

1/2" FLANGE NUT

PACKING LIST: 10´ EASY FLOW RACE

2003908

1/2" x 3" HEX BOLT

7002337

7001812

7002062

2003891

WING HEAD BOLT

2004949

2003890

1/2" FLANGE NUT

2003908

1/2" x 3" HEX BOLT

ASSEMBLY INSTRUCTIONS

ASSEMBLING A SINGLE EASY FLOW RACE

REQUIRED TOOLS

- 3/4" Wrench

- 3/4" Socket

- 9/16" Wrench

- 9/16" Socket

- Ratchet

3 | ASSEMBLING A SINGLE EASY FLOW RACE

ASSEMBLY

1 Lay two race bows on the ground horizontally.

2 Install the top post in the race. Keep nuts loose.

B x 8 C x 8 E x 1

ASSEMBLING A SINGLE EASY FLOW RACE | 4

G x 2

3 Stand the race frame up, and position one panel on each side.

4 Insert the bottom pins on the panel into the frame on one side.

5 | ASSEMBLING A SINGLE EASY FLOW RACE

5 Insert the bottom pins on the panel into the frame on the opposite side.

6 Lift the panels up and latch into the frame. Tighten all fasteners to secure.

ASSEMBLING A SINGLE EASY FLOW RACE | 6

7Connect to crush, race or other equipment using the provided panel pins.

CONNECTING TO ADDITIONAL PRODUCTS

KICKER PANEL INSTALLATION

REQUIRED TOOLS

- 9/16" Wrench

- Alignment bar

PACKING LIST

7 | KICKER PANEL INSTALLATION

7002294

2004382

3/8" x 2 3/4"

CARRIAGE BOLT

7001811

3/8" FLANGE NUT

ASSEMBLY

1 Start with two assembled Easy Flow Races.

2008775
