Ariens Classic LM 21 Guía de configuración

437775 Rev. 2 03.01.12 BY

ILLUSTRATED PARTS LIST

MODEL NUMBER LM 2152CMDAE

PRODUCT NUMBER 961 41 02-42

MFG. ID. NUMBER 96141024200

ROTARY LAWN MOWER - - MODEL NUMBER LM 2152CMDAE (96141024200) PRODUCT NO. 961 41 02-42

46 45

ROTARY LAWN MOWER - - MODEL NUMBER LM 2152CMDAE (96141024200) PRODUCT NO. 961 41 02-42

KEY PART

NO. NO. DESCRIPTION

1 532 18 45-76 Handle, Upper (Includes Foam Grip)

2 532 19 60-05 Handle, Lower

3 532 40 54-16 Spring, Rear Door, RH

4 532 19 47-88 Guide, Rope, Side

5 532 13 20-04 Nut, Hex Lockwasher Insert 1/4-20

6 532 06 64-26 Wire, Tie

7 532 19 15-74 Bolt, Handle 5/16-18 x 1.75

8 532 19 19-38 Knob, Handle

9 532 42 65-05 Bail, Flat, Auto-Walk, Orange

10 532 18 88-21 Bolt, Carriage

11 532 75 11-53 Nut, Hex, Centerlock 5/16-18 UNC

12 532 05 17-93 Cotter, Hairpin

13 532 40 54-15 Spring, Rear Door, LH

14 532 75 06-34 Screw

15 532 43 00-34 Bracket, Upstop

16 532 40 88-88 Rear Door Assembly

17 532 18 41-93 Bolt, Rear Door

18 532 19 81-70 Plug, Mulcher

19 532 43 87-14 Kit, Lawn Mower Housing

20 532 19 40-29 Handle Bracket Assembly, LH

21 532 19 40-31 Handle Bracket Assembly, RH

22 532 42 88-67 Screw, Hex Washer Head

23 532 16 31-83 Bolt, Hex Head 5/16-18 x 5/8

24 873 80 05-00 Nut, Hex, with Lock Washer Insert 5/16-18

25 532 16 13-33 Bafﬂe, Side

26 532 16 34-09 Screw 12 x 5/8

29 532 42 59-23 Cable, Operator Presence

30 532 42 11-76 Blade Adapter / Pulley

31 532 19 93-77 Blade, 21”

KEY PART

NO. NO. DESCRIPTION

32 532 85 10-74 Washer, Hardened

33 532 85 02-63 Lockwasher, Helical Spring 3/8

34 532 85 10-84 Screw, Hex Head 3/8-24 x 1.38

37 532 15 04-06 Bolt, Engine

38 - - - Engine, Briggs & Stratton, Model

Number 124T05-5492-B1 (order

parts from engine manufacturer)

39 532 41 06-76 Grassbag

40 532 41 19-51 Frame, Grassbag

41 532 18 21-66 Danger Decal

42 532 05 45-83 Screw

45 532 19 13-41 Mulcher Door Assembly

46 532 19 12-10 Deﬂector, Discharge

47 532 08 83-49 Nut, Hex

48 532 42 90-01 Belt Retainer

59 532 18 27-48 Grip, Handle, Foam, Smooth

61 532 16 34-09 Screw, Hi-Lo Thread

62 532 40 80-02 Box, Battery

63 532 18 95-89 Battery

64 532 19 24-36 Charger, Battery

65 532 18 61-59 Screw

66 532 19 73-63 Wiring Harness

67 532 18 03-31 Key

68 532 19 48-47 Key Start Switch

69 532 19 48-48 Nut, Cap

- - 532 18 21-91 Warning Decal (not shown)

- - 532 43 77-69 Operator’s Manual, European

- - 532 43 77-71 Operator’s Manual, Scandinavian

- - 532 43 77-72 Operator’s Manual, East Bloc

- - 532 43 77-73 Operator’s Manual, Baltic

NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

Failure to do so could be hazardous, damage your lawn mower and void your warranty.

ROTARY LAWN MOWER - - MODEL NUMBER LM 2152CMDAE (96141024200) PRODUCT NO. 961 41 02-42

37 38

28 29

ROTARY LAWN MOWER - - MODEL NUMBER LM 2152CMDAE (96141024200) PRODUCT NO. 961 41 02-42

1 532 43 31-60 Drive Control Assembly

(Includes Cable)

6 532 18 16-98 Screw, Phillips Head #10 x 5/8

7 532 40 07-23 Mounting Bracket, Drive Control

9 532 40 62-58 Cable, Drive Control

11 532 40 65-58 Spring, Return

13 532 41 92-13 Gear Case Assembly, Complete

14 532 19 34-43 Pulley, Drive

15 532 08 83-48 Washer, Flat

16 532 40 71-47 Rod, Connecting

17 532 40 96-16 Spring, Extension

18 532 41 88-66 Spring Selector

19 532 19 00-69 Knob, Selector Spring

20 812 00 00-22 E-Ring

21 532 41 24-50 Bearing Support

22 532 19 10-39 Bearing, Ball

23 532 16 45-55 Retainer, Drive Assembly, Stamped

24 817 06 04-10 Screw, Tapping, Hex Head 1/4-20 x 3/4

25 532 43 26-70 Drive Cover Assembly

(Includes Mounting Screw and Pushnut)

28 812 00 00-58 E-Ring 7/16

29 532 18 94-03 Cover, Dust, Wheel

31 532 40 48-45 Pawl, Drive

32 532 41 35-70 Wheel & Tire Assembly, Rear

33 532 40 91-48 Nut, Hex, Flangelock 3/8-16

34 532 85 12-26 Washer

35 532 41 09-22 Shaft Assembly, Rear

36 532 41 09-33 Shaft Assembly, Front

37 532 16 14-63 Retainer, Front Shaft

38 532 16 34-09 Screw #12 x 5/8

39 532 40 70-59 Bolt, Shoulder, Semi-Gimlet Point

40 532 41 13-24 Wheel & Tire Assembly, Front 8 x 2

41 532 40 48-35 Pinion

42 532 19 74-80 O-Ring

44 532 40 65-80 V-Belt

47 532 06 77-25 Washer 1/2 x 1-1/2 x .134

49 532 16 34-09 Screw, Hi-Lo Thread

50 532 41 31-04 Belt Keeper

KEY PART

NO. NO. DESCRIPTION

KEY PART

NO. NO. DESCRIPTION

NOTE: All component dimensions given in U.S. inches. 1 inch = 25.4 mm. IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.

Failure to do so could be hazardous, damage your lawn mower and void your warranty.
