ARGON18 SUBITO Manual de usuario

VALID FOR MY2023 VERSION 2.1 / 2023-03-20- ARTWORK 360A/360B

Table of contents

1. Tools Needed & First Aid Kit 4

2. Frameset Inspection 5

3. Troubleshooting / Tips / Speciﬁcations 6

4. Frameset SKUs and Descriptions 7-9

5. MAHLE X35+ SKUs and Descriptions — North America 10-11

6. MAHLE X35+ SKUs and Descriptions —EU 12-13

7. Seat Post Collar Assembly 14

8. Seat Post Assembly 15

9. Rear Derailleur Hanger Adjustment 16

10. Front Derailleur Hanger Assembly 17

11. MAHLE X35+ Components Assembly 18-22

12. Cable and Housing Routing – Light 23

13. Rear Light Installation 24

14. 3D Headset Installation 25

15. Cable and Housing Routing —Mechanical Shifting 26-29

16. Cable and Housing Routing —Mech. 1X Shifting 30-32

17. Cable and Housing Routing —Elec. Wire Routing 33-36

18. Cable and Housing Routing —Elec. Wireless Routing 37-39

19. Cable and Housing Routing – Dropper Seatpost 40

20. Front Light Installation 41

21. Cable and Housing Routing – Front Grommet Selection 42

22. Headset Installation 43

23. Rear Wheel Installation 44-46

24. BB Cover installation 47

25. Chain Catcher 48

26. Rear Rack and Fender Installation 49

27. Front Fender Installation 50

28. Range Extender and Water Bottle Position 51

29. Seat Post Minimum and Maximum Insertion 52

30. Additionnal Documentation 53

To maintain the validity of the warranty, the bicycle must be fully assembled by an

authorized Argon 18 dealer. High-end components, particularly carbon parts, require

extra care during assembly.

These components must be installed using a torque wrench to ensure each bolt is at

the speciﬁed torque setting to prevent damage.

Amp up your next adventure

My Subito

Date of Purchase:

Retailer:

Size:

Serial Number:

Hub Serial Number:

4SUBITO 360A / 360B: ASSEMBLY GUIDE

1. Tools Needed & First Aid Kit

1. Bearing Cup Press

1. Seat Post Clamp 2. Spare Rear Derailleur Hanger

2. Allen Key Set 3. Torx T25 Key 4. Carbon Paste

& Grease

5. Utility Picks 6. Clean Rag

IMPORTANT:

First Aid Kit: Essential parts to always have on hand

IN CASE OF EMERGENCY…THIS MIGHT SAVE YOUR RIDE!

7. Derailler Hanger

Alignement Gauge

8. Cables and

Housing Cutter

9. Thread Locker

Medium strength

10. Isopropyl Alcohol 11. Torque Wrench 12. Cassette Lockring

80801

81253

81235

2. Frameset Inspection

Before assembling your new Subito, please verify that you have all the following:

1. Frameset parts checklist (see p.7-9)

2. MAHLE X35+ parts checklist (see p.10-13)

3. Inspect the frame for cosmetic defects (scratches, bumps, cracks,

paint defects, etc.)

4. For reference, record serial number on p.3

5. All the necessary bolts (refer to frameset parts, p.7-9)

6. For optimal shifting performance, use a derailleur alignment gauge to make sure

that the derailleur hanger is straight

No. A18 SKU# Function Description Screw Type Torque THREAD CONDITION Qty

1 80806* Chain Catcher Screw M5 x 25mm Screw Socket Head 3Nm Nylock 1

2 81248 FD Hanger Screw M5 x 16mm Screw Flat Head 3Nm Grease 2

3 81249 Water Bottle Screw M5 x 14mm Screw Button Head 3Nm Grease 4

4 200898 Battery Screw M5 x 8mm Screw Button Head 5Nm Dry 3

5 81251 BB Cover Screw M4 x 10mm Screw Button Head Hand Tighten Dry 2

7 81252 Charger Connector Screw M3 x 10mm Screw Flat Head Hand Tighten Dry 2

8 81252 One Remote Holder Screw M3 x 10mm Screw Flat Head Hand Tighten Dry 1

9 81252 Cable Clip Screw M3 x 10mm Screw Flat Head Hand Tighten Dry 1

10 81253 RD Hanger Screw M3 x 8mm Screw Flat Head 2Nm Dry 2

11 81254 PAS Sensor Screw M4 x 5mm Screw Set Screw Hand Tighten Dry 1

12 81255 Rear Disc Screw M5 x 8mm Torx Screw Button Head 4Nm Thread-Locker 6

13 80801* Seat Post Collar Screw M5 x 22mm Screw Socket Head 4Nm Grease 1

14 SP.KRYCS.273B* Seat Post Rear Screw M6 x 28mm Screw - 9.5Nm Grease 1

15 81052 Front Thru Axle M12 x 1.5 Axle - 12Nm Grease 1

16 81228 Motor Lock Nut M12 x 1.5 Nut Rear Wheel Nut 35Nm Grease 2

17 81227 Magnet Lock Nut - Casette Lockring 40Nm Grease 1

*Included with SKU

IMPORTANT:

Some of the following parts are already assembled on the frame.

When assembling the bike, you will need to adjust these parts according

to their torque speciﬁcations and fastener conditions when necessary.

6SUBITO 360A / 360B: ASSEMBLY GUIDE

IMPORTANT:

No more than 30mm of spacers can be placed between the stem and the top

cap of the 3D system. The use of more than 5mm of spacers on top of the stem

could aﬀect the eciency of the compressor. These practices will automatically

void any warranty claim against the manufacturer.

IMPORTANT:

The MAHLE X35+ system is shipped to retailers in Demo mode. When the bike

is sold, it must be taken out of Demo mode. Please see related documentation

on our B2B portal. Demo mode will allow for a maximum of 50km of riding, after

which the motor will stop working.

3. Troubleshooting / Tips / Specifications

Brakes

Use only flat mount disc brakes. The frame is compatible with

160/180mm disc rotors. The rear caliper installation does not require an adapter

for 160mm discs. Refer to 140mm disc rotor brake manufacturer's instructions.

Rear mount thickness: 30mm.

The fork is compatible with 140/160mm disc rotors. An adapter might be required

for front caliper installation. Consult brake manufacturer's instructions.

Tire Clearance

700c The largest tires that can be installed must be no wider than 40mm

for the front and rear wheels. If fenders are installed, the tires must

be no wider than 35mm.

650c The largest tires that can be installed must be no wider than 45mm

for the front and rear wheels. If fenders are installed, the tires must

be no wider than 40mm.

Seat Post

Ø 27.2mm

The saddle clamp is compatible with saddle rail up to 9 x 7mm.

Seat Post Collar

Ø 31.8mm

Bottom Bracket

BB86 (Press-ﬁt)

Headset

Argon18 exclusive, FSA No 69 SRS + IST2 3D Press-ﬁt

(Bearing 1 1/2”, 36° x 45° Top and Bottom

+ FSA TH-881-1 Compressor included)

4.1 Frameset SKUs and Descriptions

100165

100569 (360A)

100570 (360B)

100166

80801

81254

8080581239 &

81252 (screw)

80804

81242

80551

81249

80988

80808

100312

38446

80806 81240

200898

81255

80985

80826

8055080549

80264

100314

81241 &

81251 (screws)

80811

100163 &

100164 (Bracket)

100313

81234

81045 SP.SUBI.273A.LIGHT

81052

FK.SUBR.M-XL.360A

FK.SUBR.XXS-S.360A

FK.SUBG.M-XL.360B

FK.SUBG.XXS-S.360B

81054

81235 &

81253 (screws)

81238 &

81248 (screws)

81252

100571 (360A)

100572 (360B)

100315

200845

200829

100316

8SUBITO 360A / 360B: ASSEMBLY GUIDE

4.2 Frameset SKUs and Descriptions

No. Name A18 SKU# Qty

1 Subito Frame Not available as spare part. 1

2 Subito Fork (XSS/XS/S)

-OR-

Subito Fork (M/L/Xl)

FK.SUBR.XXS-S.360A

FK.SUBG.XXS-S.360B

FK.SUBR.M-XL.360A

FK.SUBG.M-XL.360B

3 Subito Seatpost With Hole SP.SUBI.273A.LIGHT 1

4 Seatpost Collar 31.8mm 80801 1

5 Rear Derailleur Hanger 81235 1

6 FD Hanger Removable 81238 1

7CS Wire Clip 81239 1

8 FD Plug 81240 1

9 BB Opening Cover 81241 1

10 FD Cable Stopper 81242 1

11 Oblong Plug 80549 1

12 Cable Guide Oblong 80550 1

13 Chain Catcher (Incl. Small/Large, Washer and Screw) 80806 1

14 Plastic Plug M5 80264 9

15 Long Grommet Mechanical 80985 2

16 Long Plug Grommet 80804 4

17 Long Grommet Di2 80805 3

18 Rear Brake Oblong Cable Guide 80551 2

19 Oblong Plug 80826 1

20 Foam Liner 80811 3

21 FSA Headset NO.69/SRS System 100312 1

22 A18 Front Thru Axle M12 x 1.5 x 119 81052 1

23 A18 Thru Axle Lever 81054 1

24 Fender Bracket 80808 1

25 Battery Holder 38446 1

26 FD Hanger Screw 81248 2

27 Water Bottle Screw 81249 4

28 Battery Screw 200898 3

29 BB Cover Screw 81251 2

4.3 Frameset SKUs and Descriptions

No. Name A18 SKU# Qty

30 Charger Connector, One Remote Holder and Cable Clip Screw 81252 4

31 RD Hanger Screw 81253 2

32 PAS Sensor Screw 81254 1

33 Rear Disc Screw 81255 6

34 IST2 SRS Custom Cap

100569 (360A)

-OR-

100570 (360B)

35 IST2 25mm Cap

100571 (360A)

-OR-

100572 (360B)

36 IST2 25mm Column 200845 1

37 IST2 Sleeve 200829 1

38 Dirt Guard Kit, Two Parts 80988 1

39 CS Protector (Same as Dark Matter, Refer to Subito Installation Instructions) 81045 1

40 Chainsuck Guard 81234 1

41 LiteMove Front Light + Cable 450mm 100163 1

42 LiteMove Front Light Bracket 100164 1

43 LiteMove Rear Light 100165 1

44 LiteMove Cable Connector 100166 1

45 Connector Housing FEMALE Socket, 2 pin, Rectangular, Waterproof 100313 1

46 Connector Housing MALE Socket, 2 pin, Rectangular, Waterproof 100314 1

47 Connector Crimp PIN JWPF, 22-26 AWG 100315 2

48 Connector Crimp SOCKET JWPF, 22-26 AWG 100316 2

10 SUBITO 360A / 360B: ASSEMBLY GUIDE

81226 81232

5.1. MAHLE X35+ SKUs and Descriptions – North America

North American Version North American Version

81217

Available Separately

81184 (314A) 700C

81192 (314B) 650B

*81233*

81183 (314A) 700C

81185 (314B) 650B

81227

81228

81219 81223

81230

8122981218

81225

81231

81220

North American Version

81563 200753
