LS-410
Media Station
User Manual English
LS-410 User Manual
Introduction
Specifications
Package Contents
Product Appearance
Connection
Front Panel Buttons and Indicators
External Control via USB Numeric Keypad
Getting start
Overview of the Web Interface
Chapter 1 Administrator
1.1 Media I/O
1.1.1 Video inputs
1.1.1.1 Content / Cam 1 / Cam 2
1.1.1.2 Advanced conguration
1.1.2 Network device manager
1.1.3 PTZ control port
1.1.4 Audio
1.1.5 Display
1.2 Video
1.2.1 Recording
1.2.2 Streaming
1.2.3 Server
1.2.4 Content
1.2.5 Theme
1.3 Storage
1.4 Scheduler
1.5 Upload
1.5.1 Upload settings
1.5.2 Transfer settings
1.6 System
1.6.1 General settings
1.6.2 Network
1.6.3 Cloud Manager
1.6.4 Firmware
1.6.5 Conguration
1.7 Account
1.8 Mini Controller (mobile phone)
1.8.1 Page1
1.8.2 Page2
4
4
4
5
6
7
8
8
9
10
10
11
12
13
14
15
16
17
17
18
21
24
25
26
28
29
33
34
35
36
37
39
40
41
42
43
44
44
45
Table of Contents
LS-410 User Manual
Table of Contents
Chapter 2 Director
2.1 Local Director
2.1.1 Preview
2.1.2 Toolbar
2.1.2.1 Theme and Display
2.1.2.2 Recording, Streaming control and Snapshot
2.1.2.3 Playback Video
2.1.2.4 Camera Control
2.1.2.5 Settings
2.1.2.6 Others
2.2 Online Director
2.2.1 Recording controls panel
2.2.1.1 Background
2.2.1.2 Layout
2.2.1.3 Overlay
2.2.1.4 Theme
2.2.1.5 Volume control
2.2.1.6 Recording/ Streaming control and Snapshot buttons
2.2.2 Visual Sources Monitoring
2.2.3 Subtitle Editor
2.2.4 Recording/Streaming setup
Chapter 3 Video Manager
3.1 Video Management
3.1.1 Upload the recording
3.1.2 Download the recording
3.1.3 Delete the recording
3.1.4 Playback the recording
3.1.5 Edit the recording information
3.1.6 Edit the bookmark information
3.2 Snapshot Management
3.2.1 Upload the photo
3.2.2 Download the photo
3.2.3 Delete the photo
3.2.4 Preview the photo
Table of On Screen Disaplay Icons
47
47
47
48
48
49
50
52
53
54
55
56
56
56
56
57
58
58
59
61
62
63
63
64
64
64
65
66
67
67
68
68
68
69
70
LS-410 User Manual
4www.arec.com
Specifications
Featuring a compact and stand-alone design, AREC LS-410 Media Station consists of diverse features and functionality,
including multi-signals capturing, recording synchronously, codec, streaming online, live broadcasting, and web-based
monitor page, providing complete presentation or lecture capture solution.
Product Name Media Station
Model Name LS-410
Dimension 401mm(L) x 167mm(W) x 54mm(H)
Weight 2250g
Power Requirement 12V/3.34A
Power Consumption (Max.) 40W (Max.)
Operating Temperature / Humidity 0ºC ~ 40ºC / 90%
Maximum normal load description
Insert 2 IP CAM to LAN port and insert 2 video signals ( HDMI ). Using external USB
flash to record the transcoded video/audio. And output the transcoded video/audio
to HDMI and DP ports.
Introduction
Package Contents
AREC LS-410 Media Station
Quick Installation Guide
USB Keyboard
Terminal Block
Power AdapterEar Mount*
* Ear Mount. For mounting AREC Media Station in 19-inch 1U rack height.
LS-410 User Manual
5www.arec.com
Product Appearance
No. Name Brief introduction
1Audio meter Audio volume bar
2Layout function keys Control the Layout functions
3Record function keys Control the Record, Pause, Stop functions
4Front USB ports
1. For external USB storage device*
2. Firmware update via USB disk
3. Available for USB mouse, keyboard
4. Available for USB video/audio input (Note: Connecting an USB AV device
via an USB hub is not recommended. It may cause compatibility issues.)
NOTE: Can detect and record to USB storage devices using FAT32, NTFS,
Ext3, Ext4, exFAT le systems.
5Power Power on/off the device
6Indicator Red/Green dual color to show device status
7Reset button Long push to reset to default settings
8HDMI inputs HDMI input source for PC, Cameras
9HDMI loop out HDMI loop through from adjacent input port
10 Audio input Balanced audio-in with a 5-pin Phoenix connector
11 Audio input Line audio input / Mic audio input
12 Audio output Line audio output
13 RS-232 Captive screw connector for control over RS-232
14 Ethernet port RJ-45 Ethernet connector for WAN connection
15 Video output HDMI output (preview recording with on-screen GUI)
16 Ethernet port RJ-45 Ethernet connector for LAN connection
17 Back USB port Function same as front ports
18 Video output DisplayPort output (inputs monitoring or multi-source display)
19 Video output HDMI output (inputs monitoring or multi-source display)
20 Power port 12V/ 3.34A
Front
Back
1 2
4 6
3 5
7 16
15 17 19 20
8 10 13 1411 129 18
LS-410 User Manual
6www.arec.com
Connection
LS-410 User Manual
7www.arec.com
Front Panel Buttons and Indicators
Button/ Indicator Display method of indicator Product status
Record / Pause / Stop
buttons with indicators
Record button glows
red continuously. Recording in progress.
Record button flashes red rapidly. Recording is paused.
Record button flashes red slowly. Recording is being nalized.
Audio meter L/R
From 0 to 10 steady green lights. Showing the volume's high/low of
audio line out L/R
Power indicator
Steady green. Boot up completed.
Power indicator
Solid red. The device is booting up or shutting
down
Solid green. Boot up completed.
Fast flashing green. Firmware updating.
Slow flashing green. Uploading the video files or copying
les to front USB storage.
Fast flashing red. The storage is abnormal or the system
is overheating.
Slow flashing red. The device is in sleep mode.
Button Brief introduction
Overlay
Overlay cycling.
Output Switcher
Switch image sources to monitor individual image inputs.
LS-410 User Manual
8www.arec.com
External Control via USB Keypad
Insert the keyboard into the Media Station's USB hole, let USB numeric keypad as function keys to control the Media Station.
Button Brief introduction Button Brief introduction
1Theme 1 Backspace All input volume mute/unmute
2Theme 2 -All input volume down
3Theme 3 +All input volume up
4Theme 4 Enter Record
5Theme 5 ESC Power off
6Theme 6 Z • z Change Background
7Theme 7 X • x Change Layout
8Theme 8 C • c Change Overlay
9Theme 9 V • v Live streaming on/off
/Pause B • b Playback last record video
*Stop A • a All output volume up
0Change Display S • s All output volume down
.Snapshot D • d All output volume mute/unmute
Caps Lock Recording Start / Stop G • g Local director control panel on/off
Getting start
Log in Administrator with default username admin and password admin, then entering System Administration
webpages.
Connect the video output port to a screen with an HDMI cable. Make your PC and Media Station on the same physical LAN,
and enter the IP address displayed in the lower right side of the screen in your browser to access the System Administration
webpage.
Connect PC to the setting port(LAN) of the Media Station with standard network cable. Open up the browser, and input
192.168.11.254 in the URL column. You will then connect with LS-US2 webpage interface.
Way 2:
Way 1:
10.5.0.118
LS-410 User Manual
9www.arec.com
Overview of the Web Interface
LS-410 web interface has three user types, which are described in detail in the following chapters :
Online Director
For quick start recording, log in Online director from the initial login page with default
username director and password director. This user also has access to Video Manager
web pages.Log in with Administrator account, can switch to Administrator page.
Administrator
To setup the device, log in Administrator with default username admin and password
admin, then entering System Administrator webpages. The admin account provides the
user all three type of privileges.
Mini Controller For mobile device quick start recording, log in Mini Controller from the initial login page
with Administrator or Online Director account.
Video Manager
If you only need to access to the recordings, log in Video Manager with default username
video and password video.Log in with Administrator account, can switch to Administrator
page.
LS-410 User Manual
10www.arec.com
Chapter 1 Administrator
The Administrator web pages provide a system administration interface of the LS-410: it can perform Media I/O, Video,
Storage,Scheduler,Account, Upload, System settings and conrm operations. The Media I/O settings make sure each input
source are properly connected, and adjust the audio volume. The Video setting pages congure the recording, streaming, and
other functions which dene the content being recorded. System are pages contain basic settings and information of this
device.Click icon can switch to Video Manager page.
1.1 Media I/O
The pages within Media I/O include the following :
Video inputs Select the signal type, video source and PTZ control method for each input.
Network device manager List out all the connected network cameras and Auto-Tracking Mount.
PTZ control port Set LS-410 back USB-to-RS-232 serial port to drive PTZ cameras.
Audio Adjust the volume and select the audio input source.
Display Set the LS-410 on screen display language, video output settings and color adjustment.
