Archgard OPTIMA 30 Manual de usuario

MODEL OPTIMA 30

FIREPLACE INSERT ROOM HEATER

FOR USE WITH NATURAL GAS AND PROPANE

INSTALLATION AND OPERATION INSTRUCTIONS

FOR YOUR SAFETY

DO NOT store or use gasoline or any other flammable vapors or liquids in the vicinity

of this or any other appliance

IF YOU SMELL GAS:

- Do not try to light any appliance.

- Open windows.

- Do not touch electrical switches.

- Extinguish any open flame.

- Immediately call your gas supplier from a neighbour’s phone. Follow the gas

supplier’s instructions.

- If you cannot reach the gas supplier, call the fire department.

PLEASE READ INSTRUCTIONS CAREFULLY BEFORE INSTALLING AND

OPERATING THE APPLIANCE

WARNING: Improper installation, adjustment, alteration, service or maintenance voids

all the manufacturer’s warranties and may cause property damage, personal injury or

loss of life.

Installation and service must be performed by a qualified installer, service agency or the

gas supplier.

Installer, please leave this manual with the appliance owner for future reference.

7116 Beatty Drive

Mission, BC V2V 6B4

Canada 11APR01

fire-parts.com

CONTENTS

Introduction 2

General Information 3

Appliance Description 4

Dimensions and Clearances 5 - 6

Installation Instructions 7 - 11

Operation Instructions 12 - 13

Maintenance 14

Trouble Shooting Instructions 15 - 16

Wiring Diagrams 17

Servicing 18 - 19

Important Information Form 20

Warranty 21

Parts and Accessories 22

Manufactured by Archgard Industries Ltd, British Columbia, Canada.

Patents Pending

CAUTION

Due to high temperatures, the appliance should be located out of traffic and

away from furniture and draperies.

Children and adults should be alerted to the hazards of high surface

temperature and stay away to avoid burns or clothing ignition.

Young children should be carefully supervised when they are in the same room

as the appliance.

Clothing or other flammable material should not be placed on or near the

appliance.

Any parts removed or opened for servicing of the appliance must be properly

replaced prior to operating the appliance.

The appliance must be inspected before use and at least annually by a qualified

service person. More frequent cleaning maybe required due to excessive lint

from carpeting, bedding material, etc. It is imperative that the control

compartments, burners and circulating air passageways for the appliance be

kept clean.

fire-parts.com

INTRODUCTION

Thank you for purchasing the Archgard Optima 30

The Optima 30 is one of the most advanced fireplace insert heaters on the market. It is solidly

designed using the latest technology and manufactured to the highest quality. It is our aim to

provide you with many trouble free years of reliable service.

Some of the many features are.

∗ Small Size The Optima 30 will fit into almost all masonry and factory built

wood burning fireplaces.

∗ Heater Classification The Optima 30 is classified as a heating

appliance. Therefore, it has additional safety devices built-in and

it can be operated continuously for zone heating.

∗ High Efficiency The Optima 30 has one of the highest efficiency of any gas

fireplace; which means that it is less expensive to operate.

∗ Adjustable Flame The flame aesthetics and heat output can be adjusted to suit the

owner’s moods and heating needs.

∗ Solid Construction The Optima 30 is constructed mainly of 16 and 18 gauge

aluminized and galvanized steel for long life and durability.

Please read the manual carefully prior to installation and operation of the appliance.

Proper installation, operation and maintenance of the appliance will provide you with

many years of enjoyment.

TO THE PROUD NEW OWNER

Optima 30

fire-parts.com

GENERAL INFORMATION

SPECIFICATIONS

This appliance is tested and certified to the following US and Canadian gas appliance standards.

- ANSI Z21.88a-1998/CSA 2.33a-M98, Vented Gas Fireplace Heaters,

- ANSI Z21.44-1995, CAN1-2.19-M81, Direct Vent Wall Furnaces,

- CAN/CGA-2.17-M91, Gas-Fired Appliances for Use at High Altitudes

Please contact Archgard Industries Ltd., if you have any questions regarding the certification of this

appliance.

APPLIANCE CERTIFICATION

INSTALLATION CODES

This appliance must be installed by a qualified gas appliance installer.

The installation must conform with the local codes or, in the absence of local codes, with the current

National Fuel Gas Code, ANSI Z223.1/ NFPA 54, in the US or Installation Code, CAN/CGA-B149, in

Canada. Electrical connections and grounding must conform with local code, or current National

Electrical code, ANSI/NFPA No. 70-1987, in the US and in Canada, the current Canadian Electrical

Code, CSA C22.1.

HIGH ALTITUDE INSTALLATION

When installing this appliance beyond 4500 ft. (1372 m) above sea level. The appliance must be

properly de-rated and installed according to local codes, in the absence of local codes, with the current

National Fuel Gas Code, ANSI Z223.1/ NFPA 54, in the US or Installation Code, CAN/CGA-B149, in

Canada.

Natural Gas (NG) Propane (LP)

Manifold Pressure 1.6 - 3.5 in. w.c. (0.4 - 0.9 kPa) 6.0 - 10.0 in. w.c. (1.5 - 2.5 kPa)

Min. Supply Pressure for Purpose

of Input Adjustment

4.5 in. w.c. (1.2 kPa) 11.0 in. w.c. (2.8 kPa)

Orifice Size #37 DMS (2.64 mm dia.) #53 DMS (1.51 mm dia.)

Nominal Input Rating 14,500 - 29,000 BTU/hr (4.2 – 8.5 kW) 15,500 -26,000 BTU/hr (4.3 - 7.6 kW)

Output (Fan On) @ Max. Rating 23,600 BTU/hr ( 6.9 kW) 21,300 BTU/hr ( 6.2 kW)

Output (Fan Off) @ Max. Rating 22,500 BTU/hr ( 6.6 kW) 20,300 BTU/hr ( 5.9 kW)

Altitude 0 - 4,500 ft. (0 - 1372 m) 0 - 4,500 ft. (0 - 1372 m)

Primary Air Opening 1/8 in. (4.8 mm) 1/4 in. (9.6 mm)

fire-parts.com

APPLIANCE DESCRIPTION

TOP GRILL

BOTTOM GRILL

TOP VIEW

FRONT

Optima 30

LOG SET

OPTIONAL

BRICK PANELS

FLUE CONNECTOR

PLATE

SPILL SWITCH

DRAFT HOOD

fire-parts.com

Oversize faceplate:

Standard faceplate: 38” (965mm)

DIMENSIONS AND CLEARANCES

APPLIANCE DIMENSIONS

FRONT VIEW

TOP VIEW

SIDE VIEW

MINIMUM FIREPLACE DIMENSIONS

17-1/4” (438 mm)

27” (686

15” (381

20-3/4” (527

SIDE

TOP VIEW

OS 29-

Std. 26-1/2” (673mm)

19” (483mm

1-1/2” (38mm)

4-3/4” (121mm)

20-1/4” (514mm)

21-1/2” (546mm)

11-

14” (356mm

24-

16” (406mm

fire-parts.com

DIMENSIONS AND CLEARANCES Cont...

CLEARANCES TO COMBUSTIBLES

TOP VIEW

SIDE VIEW

Clearances to Faceplate

1” (25mm) 1” (25mm)

Combustible mantle allow in shaded

area. Mantle extension maybe increased

1” (25mm) for each additional

1” (25mm) increase in clearance height.

Sidewalls or Mantle Supports

CAUTION: This appliance is designed for used in any masonry or factory built wood

burning fireplace. It cannot be enclosed by combustible material and used as

a built-in gas fireplace, unless it is installed into an Archgard zero-clearnce

box, model ZC-KIT.

6” (152 mm)

Minimum Height From Top of Door: 17 ” ( 432 mm)

Minimum Height From Bottom of Applinace: 34 ” (864 mm)

fire-parts.com

INSTALLATION INSTRUCTIONS

PRECAUTIONS

This appliance must be installed by a qualified gas installer and the installation conform to the

installation codes.

This appliance needs fresh air for safe operation and must be installed so there are provisions for

adequate combustion and ventilation air. Provide adequate clearance around air openings of the

appliance. Never obstruct front openings.

Provide adequate clearances for proper operation and servicing of the appliance.

This appliance must be properly connected to a venting system and must not be connected to a chimney

flue serving a separate solid fuel burning appliance.

GAS CONNECTIONS

Have your gas supplier or a qualified gas fitter run a gas supply line into the fireplace. The line must be

properly sized and fitted according to the installation codes. Immediately up stream of the supply

connection, the fitter shall provide a manual shut-off valve and a 1/8 NPT plugged tapping accessible for

connection to a test gauge.

CAUTION: The appliance and its individual shutoff valve must be disconnected from the gas supply

piping system during any pressure testing of that system at test pressures in execss of 1/2

psig (3.5 kPa). The appliance must be isolated from the gas supply piping systme by

closing its individual manual shutoff valve during any pressure testing of the gas supply

piping system at test pressures equal to or less than 1/2 psig (3.5 kPa). Failure to do so

will damage the appliance’s gas valve. Such damage is not cover by the manufacturer’s

warranty.

Check for proper gas supply pressure by placing a test gauge on the 1/8 NPT tap on the gas supply line.

The minimum permissible gas supply pressure is 4.5 in. w.c. (1.12 kPa) for natural gas and 11.0 in. w.c.

(2.74 kPa) for propane. Maximum gas supply pressure should never exceed 14.0 in. w.c. (3.48 kPa) or

1/2 psi. for both natural gas and propane.

Before connecting the appliance to the gas supply line, double check that the appliance you have

purchased is design for the gas type you are using. The gas type markings are located on the certification

label and also on the appliance’s gas valve.

Adequate clearance for proper installation and checking of the gas connections must be provided. All

gas connections must be checked for gas leaks.

fire-parts.com

INSTALLATION INSTRUCTIONS Cont...

ELECTRICAL CONNECTIONS

The Optima 30 comes complete with a cord and plug already installed. If you require to run an electrical

lead to the appliance follow the instructions listed below.

Have qualified electrician run a set of 120VAC supply lines to the lower left side of the fireplace before

installing the appliance. He should leave 18” (460mm) of the supply line free for ease of connection to

the appliance. Connect the electrical supply line to the appliance at the same time the gas line is being

connected to the appliance.

Flip open the bottom grill and open the cover of the fan speed controller box. Run the lines into the left

side of the appliance through the conductor clamp. Run the lines through the conductor clamp on the

controller box. Connect the ‘live’ (black) supply conductor to the free black conductor from the speed

controller with a marrette type wire connector. Connect the ‘neutral’ white supply conductor to the free

white conductor from the convection fan with a marrette type wire connector. Connect the

‘ground’ (green or bare) conductor to the box. Tighten the two conductor clamps and replace the cover

of the speed controller box.

Electrical Supply Line

to fan

to temp. snap switch

Ground

White to White

Black to Black

Fan Speed Controller

Appliance Side

Conductor Clamps

fire-parts.com

INSTALLATION INSTRUCTIONS Cont...

VENTING

The appliance is equipped with a vent safety shutoff system and a safety control system designed to

protect against improper venting of combustion products. The appliance will not function without being

connected to a proper venting system.

WARNING: Operation of this heater when not connected to a properly installed and maintain venting

system or tampering with the vent shut-off system can result in carbon monoxide (CO)

poisoning and possible death.

This appliance must not be connected to a chimney flue serving a separate solid fuel burning appliance.

The appliance maybe vented using 4 in. diameter aluminum or stainless steel flexible gas liner running

inside a masonry chimney or the flue of the factory built fireplace. The vent system must be proper

terminated with a suitable vent cap. The liner must form a complete connection from the flue collar to

the vent cap. Follow the vent component manufacturer’s instruction. Also check with local gas

authorities for proper venting methods and procedures.

Connecting the Vent Liner to the Appliance

The appliance has a detachable flue connection plate for ease of installation. Remove the screw holding

the flue connection plate and slide out the plate. After the flexible gas liner has been properly installed in

the fireplace, attach the collar of the plate to the liner with screws or a clamp. Before placing the

appliance into the fireplace, check the hearth of the fireplace to see if it is level with the front of the

fireplace. If it is not, measure the depth of the hearth. Loosen the three screws of the leveling “L”

bracket at the back of the appliance. Lower it to the measurement obtained and tighten the screws. Make

sure the gas and electrical supply line are properly connected to the appliance. Slide the appliance into

the fireplace, and at the same time slide the flue connection plate back onto the top of the appliance. Do

not slide the appliance completely into the fireplace yet. Re-fasten the flue plate with the screw. Check

the leveling of the appliance. Attach the faceplate to the appliance before sliding the appliance all the

way into the fireplace.

FACEPLATE

- Remove the door.

- Fasten the faceplate to the appliance. The return flange on the inside of the faceplate sides fits on the

inside of the mounting rails on the appliance. Screw the faceplate to the appliance at the locations

shown with the black screws provided.

SCREW

LOCATIONS

fire-parts.com

Tabla de contenidos

Otros manuales de Chimenea de interior de Archgard

Archgard

Archgard EURO-25 Manual de usuario

Archgard

Archgard OPTIMA 30 - 1 Manual del propietario

Archgard

Archgard Optima 34 Manual de usuario

Archgard

Archgard Marquis AGDVT-38D Manual de usuario

Archgard

Archgard Chalet 1800I Manual del propietario

Archgard

Archgard 31-DVIM33C-2 Manual de usuario

Archgard

Archgard EURO 25-1 Manual de usuario

Archgard

Archgard Marquis DVR-38 Manual del propietario

Archgard

Archgard 25-BVI20N-3 Manual del propietario

Archgard

Archgard 22-DVI24N-3 Manual de usuario

Archgard

Archgard Sereno 41 Manual de usuario

Archgard

Archgard Chantico 31 Manual de usuario

Archgard

Archgard DV-520NG Manual del propietario

Archgard

Archgard DVR 36-H Manual del propietario

Archgard

Archgard NORTHFIRE 3400 3400-DVTR20N-2 SN 8605 Manual de usuario

Archgard

Archgard Pele 345-DVTE31LN-1 Manual de usuario

Archgard

Archgard Northfire 42-dvt40n Manual de instrucciones

Archgard

Archgard 72-DVTE30P-2 Manual de usuario

Archgard

Archgard Pele 345 Series Manual de usuario

Archgard

Archgard 72-DVTE30P-2-ERG Manual de usuario

Archgard

Archgard Optima 32-1 Manual del propietario

Archgard

Archgard NorthFire-DVT36E Manual de usuario

Archgard

Archgard EURO 25 --1 Instrucciones de funcionamiento

Archgard

Archgard Euro 65 Manual del propietario

Manuales populares de Chimenea de interior de otras marcas

Brigantia

Brigantia 35-DVRS31N-2 Manual del propietario

Nordpeis

Nordpeis Bergen Manual de usuario

Superior

Superior BCT2536TMN Manual de usuario

Quadra-Fire

Quadra-Fire 5100I-GD-B Manual de usuario

Renaissance

Renaissance RUMFORD 1000 Manual de usuario

Lacunza

Lacunza IV-800 Manual de usuario

Baxi

Baxi 940 Instrucciones de uso

Dru

Dru Maestro 60/2 Tall RCH Manual de usuario

Diamond Fireglass

Diamond Fireglass SS-O22 Manual de usuario

HearthStone

HearthStone Windsor Bay 8830 Manual de programación

Napoleon

Napoleon ASCENT B42 Manual de usuario

Enviro

Enviro E33GI Manual de usuario

Smeg

Smeg L30 FABE Instrucciones de montaje

KEDDY

KEDDY K700 Manual de usuario

Godin

Godin 3451 Manual de usuario

Jøtul

Jøtul Jotul GI 535 DV IPI New Harbor Manual de usuario

Austro Flamm

Austro Flamm Heidi Back 2.0 945048 Manual de usuario

Desa

Desa CCFPDFT Manual de operación
