INSTRUCTION MANUAL
AOF6S
1
DEAR CUSTOMER,
The cooker is exceptionally easy to use and extremely efficient.After reading the instruction
manual,operating the oven will be easy.
Before being packaged and leaving the manufacturer,the oven was thoroughly checked with
regard to safety and functionality.
Before using the appliance,please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
It is necessary to follow the instructions in the manual carefully in order to avoid possible
accidents.
Caution!
Do not use the oven until you have read this instruction manual.
The oven is intended for housedhold use only.
The manufacturer reserves the right to introduce changes which do not affect
the operation of the appliance.
1.WARNING: The appliance and its accessible parts become hot during use. Care should be taken
to avoid touching heating elements. Children less than 8 years of age shall be kept away
unless continuously supervised.
2.This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
3.During use the appliance becomes hot. Care should be taken to avoid touching heating
elements inside the oven.
4.WARNING: Accessible parts may become hot during use. Young children should be kept away.
5.Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass
since they can scratch the surface, which may result in shattering of the glass.
2
TABLE OF CONTENTS
Safety instructions 3
Description of the appliance...... ...........7
Installation.........................................9
Operation..........................................11
Cleaning and maintenance..............................18
Baking in the oven-practical hints........................19
Techincal data......................................24
....................................
............
3
SAFETY INSTRUCTIONS
NOTE;
Ensure there is a grounded socket nearby(behind the unit)
A dedicated power circuit is recommended for the unit but not required.Additional electrical
appliances on the same circuit may exceed the current(amperage)rating for that circuit.If after
the installation of your unit.the circuit breaker trips or the fuse fails on a repeated basis,then
a dedicated circuit will likely be required.
!The appliance must be installed only by a qualified person in compliance with the
instructions provided.Incorrect installation may cause harm to persons,animals or may
damage property.
The manufacturer declines all responsibility for improper
installation which may harm persons and animals and damage property.
Important:The power supply to the appliance must be cut off before any adjustments or
maintenance work is done on it.
WARNING:
When using this product,basic precautions should always be taken,including the following:
Your built-in oven is a classified electrical appliance.As with any electrical appliance and
particularly with electric heaters,basic precautions must be followed in order to reduce the risk
of fire,burns,electrical shocks and/or other serious injuries or death.
! The appliance becomes hot during operation.Take care not to touch the hot parts inside
the oven.
! This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
While in operation direct contact with the cooker may cause burns!
! Ensure that small items of household equipment,including connection leads,do not touch
the hot oven or the hob as the insulation material of this equipment is usually not resistant
to high temperatures.
! Do not leave the cooker unattended when frying.Oils and fats may catch fire due to
overheating or boiling over.
Do not put pans weighing over 15 Kg on the opened door of the oven and pans over 25
kg on the hob.
! Do not use harsh cleaning agents or sharp metal objects to clean the door as they can
scratch the surface,which could then result in the glass cracking.
! Do not use the cooker in the event of a technical fault.Any faults must be fixed by an
appropriately qualified and authorised person.
! In the event of any incident caused by a technical fault,disconnect the power and report
the fault to the service centre to be repaired.
! The rules and provisions contained in this instruction manual should be strictly observed.
Do not allow anybody who is not familiar with the contents of this instruction manual to
operate the cooker.
! The cooker should not be cleaned using steam cleaning equipment.
4
SAFETY INSTRUCTIONS
!
!
!
!
!
!
!
!
!
!
!
!
!
The panels adjacent to the oven must be made of heat-resistant material.
!Cabinets with a veneer exterior must be assembled with glues which can withstand temp-
erature of up to 100℃.
Keep combustible materials,such as:curtans,drapes,furniture,pillows,clothing,linens,bedding,
paper,etc.,at least 3 feet(0.9 meters)from the front sides and rear of the heater.Do not use
this unit in areas where gasoline,paint or other flammable liquids or their associated vapors
may be present.
To reduce the risk of fire,do not place or install this unit in areas where the ventilation or
circulation ducts may become blocked.
The unit's power cord must be connected to a properly grounded and protected,220-240V
electrical outlet.Always use ground fault protection where required by the electrical code.To
redece the risk of fire,avoid running the power cord under rugs,carpets,etc.Keep the power
cord away from high traffic areas where it may pose a tripping hazard.
Avoid the use of an extension cord,which may overheat and cause a fire.
When transporting or storing the unit,keep it in a dry location,free from dust,excessive
vibration or other factors,which may damage the unit.
Do not operate any oven with a damaged cord or plug or after the heater malfunctions,has
been dropped or danaged in any manner.Return oven to authorized service facility for
examination,electrical or mechanical adjustment,or repaired.
Use this oven only as described in this manual.Any other use not recommended by the
manufacturer may cause fire,electric shock,or injury to persons.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Never add cold water to food on a hot universal tray or baking tray or directly onto food in a hot
oven.The steam created could cause serious burns or scalding and the sudden change in
temperature can damage the enamel.
Do not lift the oven by the handle.
If the supply cord is damaged, it must be replaced by a special cord or assembly available from
the manufacturer or its service agent.
! Care should be taken to avoid touching heating elements inside the oven.
! Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass
since they can scratch the surface, which may result in shattering of the glass.
! This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety.
! Children should be supervised to ensure that they do not play with the appliance.
! The appliance is for indoor use only.
! Unplug the appliance from the outlet when not in use and before cleaning.
! Warning - Ensure that the appliance is switched off before replacing the lamp to avoid the
possibility of electric shock.
! After installed, must possible to unplug the appliance.
!Do not open the oven door unnecessarily
often.
5
HOW TO SAVE ENERGY
Using energy in a respon-
sible way not only saves
money but also helps the
environment.So let's save
energy!And this is how you
can do it:
! Switch off the oven in good time and
make use of residual heat.
For long cooking times,switch off oven
This saves up to 20% on energy.
Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker hob.
! Make use of residual heat from the
oven.
If the cooking time is greater than 40
minutes switch off the oven 10 minutes
before the end time.
Important!When using the timer,set
appropriately shorter cooking times
according to the dish being
prepared.
! Make sure the oven door is properly
closed.
Heat can leak through spillages on the door
seals.Clean up any spillages immediately.
! Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.
cooking,
5 to 10 minutes before finishing
6
UNPACKING DISPOSAL OF THE APPLIANCE
During transportation,protec-
tive packaging was used to
protect the appliance against
any damage.After unpack-
ing,please dispose of all
elements of packaging in a
way that will not cause dam-
age to the environment.
All materials used for packaging the appli-
ance are environmentally friendly;they are
100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking,the packag-
ing materials(polythene bags,polystyrene
pieces,etc.)should be kept out of reach of
children.
Old appliances should not sim-
ply be disposed of with normal
household waste,but should
be delivered to a collection and
recycling centre for electric and
electronic equipment.A symbol
shown on the product,the
instruction manual or the packaging shows
that it is suitable for recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this.By recycling materials or
other parts from used devices you are making
a significant contribution to the protection of
our environment.
Information on appropriate disposal centres
for used devices can be provided by your
local authority.
▲
▲
1 Oven function selection knob
7
DESCRIPTION OF THE APPLIANCE
1
3
2
4
2 Temperature control knob
3 Indicator lamp
4 Handle
5
Timer
12
COOKINGTIMECONTROLPANEL
oc
5
8
SPECIFICATIONS OF THE APPLIANCE
*optional
Baking tray
G rill rack
2
9
INSTALLATION
!The kitchen area should be dry and aired
and equipped with efficient ventillation.
When installing the oven,easy access to
all control elements should be ensured.
!This is a built-in oven, and its back wall
and one side wall can be placed next to a
high piece of furniture or a wall.Coating
or veneer used on fitted furniture must be
applied with a heat-resistant adhesive
(100℃).This prevents surface deforma-
tion or detachment of the coating.
! Make an opening with the dimensions
given in the diagram for the oven to be
fitted.
!Make sure the mains plug is disconnected
and then connect the oven to the mains
supply.
!Insert the oven completely into the open-
ing without allowing the four screws in the
places shown in the diagram to fall out.
590-595
600
560
560
40
Product Dimensions Aperture Dimensions
Height: 595 mm 590 mm – 595 mm
Width: 595 mm 560 mm
Depth: 575 mm 560 mm (min)
