■EVP(D・H)56-100
Electric Pump
for light oil, diesel oil
INSTRUCTION
MANUAL
Contents
1・・・・・・・・Safety precautions
1～3 ・・・・・・・・Before using the device
4・・・・・・・・Parts description
5 ・・・・・・・・Place and way of use
6・・・・・・・・Specifications, drawings
7 ・・・・・・・・Warranty and service
★It is strictly prohibited to use fire.
・There is a significant risk of fire.
・Do not transfer liquids like gasoline, petroleum, solvents or chemicals.
SAFETY PRECAUTIONS
・This manual contains safety-related information. Please follow it strictly.
Before using the device, carefully read the manual (misusing the device
may result in accidents).
・Keep the manual in a safe place and refer to it when necessary.
BEFORE USING THE DEVICE
★Read and strictly follow instructions on liquid’s use.
Refer to information on liquid you wish to transfer. Read it carefully
and use the liquid properly.
★In case of direct contact with liquid, act immediately.
In case of liquid ingestion, skin contamination etc., immediately
proceed with liquid’s safety procedures and seek medical attention.
Not following the instructions may result in death or
serious injuries.
Not following the instructions may result in death or
serious injuries.
Not following the instructions may result in human
injuries and material damage.
1
★Use the device in a safe place.
Keep it away from children.
★Seek medical attention when necessary.
If you suddenly feel worse while operating the pump, immediately
discontinue the operation and seek medical attention.
★Use protective equipment.
Wear protective equipment according to liquid’s safety instructions.
★Do not assemble, reassemble or repair the pump.
All repair and service related matters are restricted to authorized
experts.
★Safety precaution when changing the liquid.
When changing the liquid you are going to transfer, remember to
remove the previous liquid and clean the device. Not doing so may
result in dangerous chemical reactions.
★Request technical service whenever required.
When the device stops operating or operates in a strange manner,
immediately turn off the device and contact technical service. Do not
use broken equipment, as it may result in accidents.
★Do not cause shock to device’s main body.
It may result in pump’s malfunction, breakdowns and leakage.
2
★EVP56-100 model has been designed for kerosene and light
oil transfer.
Do not use it for transferring other liquids.
★Liquid uplift: 1.6m.
★Do not damage the electric power cord.
Do not manipulate it, bend or pull it excessively, do not pin
it. Do not put heavy objects on the cord. It may result in
damaging the cord, in fire and in an electric shock.
★Do not run the device in a dry state.
★Do not exceed the supply power voltage range.
★In case of device’s malfunction.
If you experience device’s malfunction, immediately
disconnect the device from the power source. Contact the
vendor or manufacturer.
★Pump’s permitted temperature range: 5℃~60℃
※Please remember, that the safety measures and warnings
pointed out in this manual are not exhaustive for all possible
situations. Although we have designed our product to be as safe as
possible, persons operating and maintaining the device should
strictly follow all safety rules in the operation/maintenance area.
3
PARTS DESCRIPTION
①
Switch (ON/OFF)
③
Connection Part (Delivery, Rc1”)
②
Electric Power Cord (AC100 1.6m)
④
Connection Part (Suction, Rc1”)
4
PLACE AND WAY OF USE
Place of use
Using the device
This pump has been designed for indoor use. The device does not require special
environmental conditions, however, it is advised to use it in place with low humidity
and dust concentration.
※If the pump has been switched on and is operational, yet no suction occurs, pour
approx. 240cc of transferred liquid into pump’s delivery outlet before turning the
pump on. Avoid running the pump in a dry state, as it may be damaging to its
inner components.
2. Start the device by using a switch on the back of the pump.
5
1. Check the installation. (Hoses, piping)
EVP56-100 Technical Specifications
Model
Permitted
Liquid
Pump Specifications
Main
Body
Material
Type
Max
Delivery
Rate
Max
Delivery
Pressure
By-pass
Filter
Connection
Weight
L/min
MPa
Kg
EVP56-100
（100V）
Diesel Oil,
Kerosene・Light
Oil
FC
Vane/
Self-priming
46
0.21
Internal
Internal,
100
micron
Rc1"
9.1
Motor Specifications
Type
Voltage
Frequency
Power
Continuous Operation
Ｖ
Hz
KW(A)
Single Phase Current
AC100
50/60
0.37/0.45
Possible
DIMENSIONS
WARRANTY AND SERVICE
6
Thank you for purchasing our product! We look forward to provide you with help, advice
and service, however, please remember that the warranty does not cover all possible
cases, in which such service may be required.
①If the product has been used correctly, yet broke down, it will be repaired for free if
the breakdown has been reported within 12 months from the date of purchase.
Otherwise, the service will not be free. In both cases covering shipment and
shipment-related costs is customer’s responsibility.
②The product’s breakdown has been reported within 12 months from the date of
purchase, but:
⚫The product has been misused.
⚫The product has been repaired/serviced, however, not by AQUASYSTEM.
⚫The product has not been stored or maintained properly.
⚫There are no documents/receipts, which would prove the purchase.
⚫The product has been overused and became worn.
In such cases, service is not free.
For inquiries concerning service, please contact:
7
《Customer Service》
AQUASYSTEM Co., Ltd.
【Technical Service】Tel 0749-47-5215
