User ManUal
The Leader in Personal Storage
Copyright © Apricorn, Inc. 2006. All rights reserved.
Windows® and MS-DOS® are registered trademarks of Microsoft Corp.
Cryptainer® is a trademark of Cypherix.
Second Copy 2000® is a trademark of Centered Systems.
All other trademarks and copyrights referred to are the property of their
respective owners.
without the explicit permission of the copyright holder.
Distribution of the work or derivative work in any standard (paper) book form
for commercial purposes is prohibited unless prior permission is obtained
from the copyright holder.
DOCUMENTATION IS PROVIDED AS IS AND ALL EXPRESS OR IMPLIED
CONDITIONS, REPRESENTATIONS AND WARRANTIES, INCLUDING
ANY IMPLIED WARRANTY OF MERCHANTABILITY, FITNESS FOR A
PARTICULAR PURPOSE OR NON-INFRINGEMENT, ARE DISCLAIMED,
EXCEPT TO THE EXTENT THAT SUCH DISCLAIMERS ARE HELD TO BE
LEGALLY INVALID.
Table of ConTenTs
Page #
1. Introduction ............................................................. 2
2. Getting to know your MicroKey FLASH ................... 3
• System Requirements ................................. 3
• Package Contents ....................................... 3
3. Set-Up .................................................................... 5
• USB Installation .......................................... 5
• Special Features ........................................ 6
• OS Installation ............................................. 7
• Disconnecting .............................................. 8
9
• Cryptainer ................................................... 9
• Second Copy .............................................. 12
5. Technical Support ................................................. 15
• Frequently Asked Questions ....................... 15
• Troubleshooting ........................................
16
• Contact Information .................................... 17
• RMA Policy ................................................. 17
• Warranty ..................................................... 18
Pg 2
Thank you for the purchase of your new USB MicroKey FLASH. Please
take a few moments to read this manual and familiarize yourself with the
MicroKey FLASH and all of the software programs that come with it.
protective aluminum shell. It was engineered to be simple, small and fast,
and it’s unique design sets a new standard for mobile storage. The MicroKey
data storage. It connects to any computer using a standard USB 2.0 port.
This combination offers extra storage capacity and ultra fast downloads in a
small, simple device.
But portable storage should also be durable and secure, so the MicroKey
FLASH was designed to offer maximum protection from the outside
world. The robust MicroKey electronics are protected inside a crush-proof
unauthorized access.
This package includes the following items:
Apricorn USB MicroKey FLASH:
A USB 2.0 ruggedized memory key; providing up to 8GB of storage,
protected inside a tiny, crush-proof Aluminum shell. The MicroKey
FLASH comes with a soft carrying case and USB extension cable
Cryptainer:
bit or AES 256-bit encryption.
Second Copy:
Backup software for your MicroKey FLASH. Use this program to backup
1. InTrodUCTIon
Pg 3
A. System Requirements
Hardware and Software requreiments:
- Pentium CPU (recommended)
- 128MBs RAM (recommended)
- USB Port (MicroKey FLASH supports USB
2.0, but will work on USB 1.1 ports at slower
speeds)
- CD ROM drive
Operating systems supported:
Microsoft: Windows 2000
Windows XP
Apple: Mac OS 9.x (supports USB 1.1 mode only)
Mac OS X 10.x
2 GeTTInG To know yoUr MICrokey flasH
B. Package Contents
CD-ROM
Cryptainer backup software
Second Copy backup software
Soft carrying case
MicroKey FLASH
USB extension cable
Data Transfer Rates:
Power Supply: 100% Bus powered(+5V from standard USB
connector, no external power cable required)
Interface: Hi-Speed USB 2.0
IDE (UDMA mode 2)
Data transfer rate:
Read speed: 3.7 - 6MB/sec. read rate
Write speed: 1.5 - 5MB/sec. write rate
Case: 2 piece Aluminum alloy
Shock - non operating: 2000G
Shock - operating: 2000G
Weight: 75g (approx 2.5oz)
Dimensions:
Approvals: FCC, CE & Hi-Speed USB 2.0, RoHS
compliant
System Requirements: Hardware: Pentium CPU, 32MBs RAM, USB,
CD disk drive
Software: Windows 2000, XP, Mac OS 9.2
and later
rules for radiated and conducted emission, Part 15,
Subpart B, for class B equipment.
The MicroKey FLASH USB controller has been tested by
the USB-IF, and is approved as a USB 2.0 “High Speed
Pg 5
"
3
5"
3
5
A. USB Installation
connect to any USB1.1 or USB 2.0 port on your computer.
1) Locate a USB port on your Laptop or Desktop computer.
2) Insert the MicroKey FLASH into the USB port.
3) Wait a few moments for the OS
to install device drivers.
are installed and the Microdrive is connected to your computer.
5) Optional Extension Cable
3. seT-Up
Use the optional extension cable if the USB ports
are located at the back of your desktop computer (or
if you just need extra space to work). Connect the
USB extension cable to the USB port, then connect
the MicroKey FLASH to the extension cable.
Pg 6
The MicroKey FLASH also has
the USB connector, which can
direction. If space between
USB ports is tight, rotate the
swivel head so you can connect
the MicroKey FLASH without
removing other USB devices.
Soft Carrying Case
When not in use, store the MicroKey FLASH in it’s soft carrying case.
Your MicroKey FLASH has an extremely strong aluminum alloy shell,
but the soft carrying case will provide added protection from dust,
moisture and scratches.
B. Special Features
Swivel Head Connector
Pg 7
C. Windows 2000 / Windows XP Installation
Once installed correctly in the USB port, Windows will automatically
detect the MicroKey FLASH and initialize the drive. The MicroKey
uses device drivers already included in the operating system. When
properly installed, the installation is completely automatic and no
D. Mac OS 9.X and 10.x Installation
Once installed correctly in the USB port, the Mac OS will automatically
detect the MicroKey FLASH and mount the drive. The Mac OS also uses
system, and the installation is completely automatic. Once the installation
is complete, a new drive should appear on your Mac Desktop.
Pg 8
E. Disconnecting the MicroKey FLASH
Windows 2000 and XP
1. Locate the system tray on your Windows Desktop (the system tray is the
part of the taskbar that displays the date and time).
in the system tray.
3. Follow the instructions to remove the device from your computer.
NOTE: To protect against unexpected data loss, Windows checks that
removed. If you receive an error message that says
“The device cannot
Close all
then repeat the procedure.
Macintosh
1. Dismount the Drive by dragging the Drive icon into the trash can.
2. Wait a few seconds. Once the LED has turned off, you can safely remove
the MicroKey FLASH drive.
