Aplex ADP-1080 Manual de usuario
ADP-1080 Display Monitor
User Manual
ReleaseDate Revision
October2005 V0.1
®2005 Aplex Technology, Inc. All Rights Reserved. Published in Taiwan
Aplex Technology, Inc.
9F-5, No. 2, Jian Pa Road, Chung Ho City, Taipei County, Taiwan
ADP-1080 User Manual 1
Warning!___________________________________
This equipment generates, uses and can radiate radio frequency energy and if not installed and
Used in accordance with the instructions manual may cause interference to radio communications.
It has been tested and found to comply with the limits for a ClassA computing device pursuant to
FCC Rules, which are designed to provide reasonable protection against such interence when
Operated in a commercial environment. Operation of this equipment in a residential area is likely
To cause interference in which case the user at his own expense will be required to take whatever
Measures may be required to correct the interference
Electric Shock Hazard – Do not operate the workstation with its back cover removed. There are
dangerous high voltages inside.
Disclaimer
This information in this document is subject to change without notice. In no event shall Aplex Technology
Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or
misuse of information in this document or in any related materials.
ADP-1080 User Manual 2
ADP-1080 User Manual 3
Table of Contents______________________
Warning!…………………………………………………………………………….……..….2
Disclaimer………………………………………………………………….…………………2
Chapter1 GettingStarted
1.1 Features………………………………………………………….…..…..…4
1.2 Specifications……………………………………………………………….4
1.3 Dimensions…………………………………...………………………….…6
1.4 Brief Description...................................................................................7
1.5 Display Mode……………………………………………………………….8
Chapter2 OSD
2.1 Front Panel Controls………….………………………………….…………9
2.2 OSD Controls………………………………………………………………..9
2.3 Main Menu…..……………………………………………………………..10
2.4 AD Board (TB-6020) OSD Functions……………………………………12
Figures
Figure 1.1: Dimensions of ADP-1080….……………………………………..6
Figure 1.2: Front View…..….………………………………………………….7
Figure 1.3: Rear View…………………..……………………………………...9
Figure A: Panelmounting……………………………………………………13
Figure B: VESAmounting…………………………………………………...13
Appendix
Panelmounting…..…………………………………………………………….13
VESAmounting…..…..………………………………………………………..13
ADP-1080 User Manual 4
Chapter 1_____________________________
1.1 Features
● 8” color active TFT LCD display
●Plastic housing and sealed touch screen
●NEMA 4/12 IP65-certified front panel
●OSD Control
●12V DC @0.9A
1.2 Specifications
Display
● Display: 8” SVGAcolor TFT LCD display
● Maximum resolution: 800 x 600 (native mode)
● Maximum colors: 256K
● Luminance: 400 cd/m²
● Viewing angle: 130˚(H), 100˚(V)
● Backlight life: 40,000 hours
● OSD controls/indicators: automatic screen, setup (OSD),
brightness, contrast, horizontal/vertical position, image lock,
color balance, video information, power on and sync detection
● Touch screen: resistive antiglare
● OS compatibility: Win 95/98, XP, 2000, NT4.0, QNX, Linux
● Power Supply: 12V DC @0.9A
Mechanical
● Construction: plastic housing and sealed touch screen
● NEMA4/12 IP65-certified front panel
● Mounting: panel mount/VESA 75 mount
● Dimensions: 230(W) x 175(H) x 55mm (D)
● Cutout Dimensions: 222(W) x 167mm (H)
● Gross Weight:
ADP-1080 User Manual 5
Environmental
● Operating temperature: 0 to 50℃ (32 to 122℉)
● Storage temperature: -20 to 60℃(-4 to 140℉)
●Relative humidity: 10 to 90% @40℃, non-condensing without touch screen
●Vibration: 1G peak, 5~500Hz (at random)
●Shock: 15G peak acceleration (11 msec.duration)
●EMC: CE, FCC Class A
Ordering Information
ADP-1080 8” industrial display monitor (plastic bezel)
ADP-1080T 8” industrial display monitor with sealed touch screen (plastic bezel)
1.3 Dimensions
Figure 1.1: Dimensions of the ADP-1080
ADP-1080 User Manual 6
1.4 Brief Description of the ADP-1080
The ADP-1080 is an 8-inch color active TFT flat panel display, which takes up a small area to operate
but brings performance to a new height, resulting in an effective work response. Given its ruggedness,
the unit features an excellent viewing ability for monitoring and control applications. It is available with
resistive touch screen that is easy to use and maintain.
The front panel of the display monitor is sealed with gasket for NEMA 4/IP 65 rating when it is
panel-mounted in a NEMArated cabinet or enclosure. VESA 75 is another mounting option.
Figure 1.2: Front View of the ADP-1080
ADP-1080 User Manual 7
Figure 1.3: Rear View of the ADP-1080
1.5 Display Mode
Display Mode Hori. Sync (KHz) Vert. Sync. (Hz)
31 60
VGA 640 x 480 38 72
38 75
35 56
SVGA 800 x 600 38 60
48 72
47 75
48 60
XGA 1024 x 768 56 70
60 75
1152 x 864 68 75
64 60
SXGA
1280 x 1024 80 75
ADP-1080 User Manual 8
Chapter 2_____________________________
2.1 Front Panel Controls
Power switch: To turn ON or OFF the power
Shift the icon to the right side or shift it up
Shift the icon to the left side or shift it down
Menu: To enter OSD menu for related icon and item.
Auto Button: One-touch auto adjustment
2.2 OSD Controls
To make any adjustment, select the following:
1. Press (Menu) to show the OSD menu or disable the OSD menu.
2. Select the icon that you wish to adjust with the ( / or +/-) key in the menu.
3. Press (Menu) and then choose the item with the ( / or +/-) key.
4. Press (Menu) and then adjust the quality with the ( / or +/-) key.
ADP-1080 User Manual 9
2.3 Main Menu
In the color menu, there are the following items:
ADP-1080 User Manual 10
zContrast
zBrightness
zGamma Correct
zColor Adjust
zExit
For picture, check out the following:
H.Position: Shift the picture to the left or right
V.Position: Shift the picture up or down
Sharpness: Fine-tuning of image sharpness
Phase: This field allows you to fine-tune the display quality
Exit: Back to icon
For function, check out the following:
zAuto Adjust
zAuto Position
zAuto Phase
zAuto Clock
zAuto Colour
zExit
