APC-3X14 User Manual 1

APC-3514/3714/3914

Panel PC User Manual

Release Date Revision

July. 2011 V1.0

Aplex Technology, Inc.

15F-1, No.186, Jian Yi Road, Zhonghe District, New Taipei City 235, Taiwan

Tel: 886-2-82262881 Fax: 886-2-82262883 E-mail: [email protected] URL: www.aplex.com.tw

APC-3X14 User Manual 2

Warning!___________________________________

This equipment generates, uses and can radiate radio frequency energy and if not installed and

used in accordance with the instructions manual, it may cause interference to radio communications.

It has been tested and found to comply with the limits for a Class A computing device pursuant to

FCC Rules, which are designed to provide reasonable protection against such interference when

operated in a commercial environment. Operation of this equipment in a residential area is likely

to cause interference in which case the user at his own expense will be required to take whatever

measures may be required to correct the interference.

Disclaimer

This information in this document is subject to change without notice. In no event shall Aplex Technology

Inc. be liable for damages of any kind, whether incidental or consequential, arising from either the use or

misuse of information in this document or in any related materials.

Electric Shock Hazard – Do not operate the machine with its back cover removed. There are

dangerous high voltages inside.

APC-3X14 User Manual 3

Packing List

Accessories (as ticked) included in this package are:

□ AC Power Cable

□ Driver & Manual CD Disk

□ Other.___________________(please specify)

Safety Precautions

Follow the messages below to prevent your systems from damage:

◆ Avoid your system from static electricity on all occasions.

◆Prevent electric shock. Don‘t touch any components of this card when the card is

power-on. Always disconnect power when the system is not in use.

◆Disconnect power when you change any hardware devices. For instance, when you

connect a jumper or install any cards, a surge of power may damage the electronic

components or the whole system.

APC-3X14 User Manual 4

Table of Contents______________________

Warning!…………………………………………………………………………….……..….2

Disclaimer………………………………………………………………….…………………2

Packing List…………………………………………………………………………………..3

Safety Precautions…………………………………………………………………………..3

Chapter 1 Getting Started

1.1 Specifications……………………………………….……………………..6

1.2 Dimensions………………………………...………………………….......8

1.3 Installation of HDD………………………………………………………….11

1.4 Installation of PCI Add on…………………………………………………..12

1.5 Brief Description…………………………………….……………………....13

1.6 Panel Mounting …………………………………………….……………....14

Chapter 2 Hardware

2.1 Main Board……………………………………………………………........15

2.2 Installing the Memory……………………………….………………...….16

2.3 Installing the Jumpers………………………...……………………………17

2.4 Installing the Connectors.......................................................................21

Chapter 3 BIOS Setup

3.1 Entering Setup……………………………………...……………………….32

3.2 BIOS setup program………………………….…………………………....33

3.3 BIOS menu screen…...................………………………………………...35

Chapter 4 Installation of Drivers

4.1 Intel Chipset Software Installation Utility.………………………………...62

4.2 VGA Driver Installation……………………………………………..…….66

4.3 LAN Driver Installation…………………………………………………….71

4.4 AC’97 Codec Audio Driver Installation…………………………………..74

APC-3X14 User Manual 5

Chapter 5 Touch Screen Installation

5.1 Introduction to Controller Board..………………..…………..……………78

5.2 Windows 2000/XP USB Driver Installation for 6000 Boards……….….79

Figures

Figure 1.1: APC-3514 Dimensions……………………………………..…....8

Figure 1.2: APC-3714 Dimensions…………………………………………..9

Figure 1.3: APC-3914 Dimensions…………………………………………..10

Figure 1.4: Front View ……………………………………………………….13

Figure 1.5: Rear View………………………………………………………...13

Figure 1.6: Panel Mounting…………………………………………………..14

Figure 2.1: Mainboard Overview………………………………………….....15

Figure 5.1 Birdeye’s View of Control Board…………………………………78

Appendix A

Watchdog Timer…………………………………..………..............................94

Watchdog Function…………………………………………...........................95

APC-3X14 User Manual 6

Chapter 1 Getting Started

1.1 Specifications

Model

No.

Specs

APC-3514 APC-3714 APC-3914

CPU

Intel Atom N270 1.6 GHz processor with FSB 533 MHz

Chipset

Intel 945GSE+ Intel ICH7M

System Memory

1 x 200-pin DDR2 533 MHz SO-DIMM slot, up to 2 GB

Display Size

15” 1024x768 TFT LCD 17” 1280x1024 TFT LCD 19” 1280x1024 TFT LCD

Maximum Colors

16.7M

Viewing Angle (H/V)

150/140 170/160 170/160

Luminance (cd/m²)

300 350 350

Backlight Lifetime

50,000 Hours

Touch Screen Type

Resistive (optional)

External I/O Port

Standard I/O:

4 x USB 2.0 ports

2 x RJ-45 ports (GbE)

2 x COM ports (RS-232)

1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x VGA port

1 x Audio MIC, Line-in,

Line-out

1 x 3-pin DC Power Input

Terminal Block

Standard I/O:

4 x USB 2.0 ports

2 x RJ-45 ports (GbE)

2 x COM ports (RS-232)

1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x VGA port

1 x Audio MIC, Line-in,

Line-out

1 x 3-pin DC Power

Input Terminal Block

Standard I/O:

4 x USB 2.0 ports

2 x RJ-45 ports (GbE)

2 x COM ports (RS-232)

1 x PS/2 Keyboard

1 x PS/2 Mouse

1 x VGA port

1 x Audio MIC, Line-in,

Line-out

1 x 3-pin DC Power

Input Terminal Block

Expansion Slot

1 x 32-bit PCI Slot

Storage Support

1 x 2.5" SATA HDD

1 x CF Slot (internal)

Power Supply

DC 11~32V

OS support

Windows XP Pro, XP Embedded, Windows Embedded Standard 7

Construction

Heavy-duty Steel Chassis

IP Rating

Front Panel IP 65

Mounting

Panel / VESA 75x75 Mount

Dimensions (WxHxD)

410x310x90.8 mm 439x348x94.3 mm 484x400x94.3 mm

Net Weight

8.5kgs 11.5kgs 12kgs

Operating

Temperature

0~50℃

Storage Temperature

-20~60℃

APC-3X14 User Manual 7

Relative Humidity 10~90% @40

℃

(non-condensing)

Certificate CE / FCC Class A

APC-3X14 User Manual 8

1.2 Dimensions

Figure 1.1: Dimensions of the APC-3514

APC-3X14 User Manual 9

Figure 1.2: Dimensions of the APC-3714

APC-3X14 User Manual 10

Figure 1.3: Dimensions of the APC-3914
