HDMI-IP-E/R
User Manual v1.1
HDMI-IP-E and HDMI-IP-R
APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921
1
COPYRIGHT and TRADEMARK
All rights reserved by APANTA LCC, Porland, Oregon, USA. No part of this document may be
reproduced in any form or by any means without written permission from the product
manufacturer. Changes are periodically made to the information in this document. They will be
incorporated in subsequent editions. The product manufacturer may make improvements and /or
changes in the product described in this document at any time.
All the registered trademarks referred to this manual are belonging to their respective companies.
WARRANTY STATEMENT
Apantac LLC (herein after referred to as “Apantac”) warrants to the original purchaser of the
products manufactured by Apantac (the “Product,”) will be free from defects in material and
workmanship for a period of three (3) year from the date of shipment of the Product to the
purchaser.
If the Product proves to be defective during the three (3) year warranty period, the purchaser’s
exclusive remedy and Apantac’s sole obligation under this warranty is expressly limited, at
Apantac’s sole option, to:
(a)
repair the defective Product without charge for parts and labor or,
(b)
provide a replacement in exchange for the defective Product or,
(c)
if after a reasonable time, is unable to correct the defect or provide a replacement Product
in good working order, then the purchaser shall be entitled to recover damages subject to
the limitation of liability set forth below.
Limitation of Liability
Apantac’s liability under this warranty shall not exceed the purchase price paid for the defective
product. In no event shall Apantac be liable for any incidental, special or consequential damages,
including without limitation, loss of profits for any breach of this warranty.
If Apantac replaces the defective Product with a replacement Product as provided under the
terms of this Warranty, in no event will the term of the warranty on the replacement Product
exceed the number of months remaining on the warranty covering the defective Product.
Equipment manufactured by other suppliers and supplied by Apantac carries the respective
manufacturer’s warranty. Apantac assumes no warranty responsibility either expressed or implied
for equipment manufactured by others and supplied by Apantac.
HDMI-IP-E and HDMI-IP-R
APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921
2
This hardware warranty shall not apply to any defect, failure or damage:
a)
Caused by improper use of the Product or inadequate maintenance and care of the
Product;
b)
Resulting from attempts by those other than Apantac representatives to install, repair, or
service the Product;
c)
Caused by installation of the Product in a hostile operating environment or connection of
the Product to incompatible equipment;
HDMI-IP-E and HDMI-IP-R
APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921
3
Table of Contents
1.0 WHAT’S IN THE BOX (When sold in pairs) .................................................... 4!
2.0 Key Features .............................................................................................. 5!
2.1 Specifications.......................................................................................................... 5!
2.2 Front/Rear Views.................................................................................................... 6!
3.0 DIP Switches .............................................................................................. 9!
3.1 Baud Rate DIP Switch Settings............................................................................ 9!
3.2 ID DIP Switch Settings.......................................................................................... 9!
4.0 IR Blaster/Receiver Cables .......................................................................... 10!
5.0 RS-232 Serial Pinout .................................................................................. 11!
6.0!
Installation and Quick Start Guide ........................................................11!
6.1!Point to point connection................................................................................... 11!
6.2!Point to multi-point connection ........................................................................ 12!
6.3 Multple transmitters to multiple receivers........................................................ 12!
6.4!Monitoring the the HDMI-IP-E via VLC and other Software......................... 13!
7.0 OSD (On Screen Display) ............................................................................ 14!
8.0 Configuring the HDMI-IP-E via the web page ............................................... 16!
8.1 Down Scaling the output .................................................................................... 18!
8.2 Setting the streaming bitrate ............................................................................. 18!
8.3 Setting the Multicast ID and IP address........................................................... 18!
8.4 Change User Name and Password .................................................................... 21!
8.5 Communication Firmware Upgrade on HDMI-IP-E ......................................... 21!
8.6 Set IP properties and DHCP ............................................................................... 21!
8.7 Set Baud Rate....................................................................................................... 22!
8.8 Codec Firmware Upgrade on HDMI-IP-E.......................................................... 22!
9.0 Configuring the HDMI-IP-R via the web page ............................................... 23!
9.1 Codec Firmware Upgrade on HDMI-IP-E.......................................................... 23!
9.2 Set IP properties and DHCP ............................................................................... 23!
9.3 Setting the Multicast ID and IP address........................................................... 24!
9.4 Set Baud Rate....................................................................................................... 24!
Appedix A – Using VLC to Decode the Stream from HDMI-IP-E
HDMI-IP-E and HDMI-IP-R
4
1.0 WHAT’S IN THE BOX (When sold in pairs)
Note: HDMI-IP-E and HDMI-IP-R can also be sold separately
QTY
Product
Description
1
HDMI-IP-E: HDMI to
H.264 encoder/transmitter
1
!
HDMI-IP-R: HDMI to
H.264 decoder/receiver
2
IR Emitter cables
2
!
12 V DC power supply with
universal adapter
HDMI-IP-E and HDMI-IP-R
APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921
5
2.0 Key Features
– HDMI 1.4 (1080P) to H.264 encoder and decoder
– Supports one pair of HDMI embedded audio
– Supports both Unicast and Multicast
– Supports up to 1080P@60Hz at 18Mbps
– Supports point to point up to 100 meters
– Compatible with CAT 5/E/6 cables
– Supports RS-232
– HDMI and HDCP compliant
– Web interface for basic configuration
2.1 Specifications
Functions/Part#
HDMI-IP-E
HDMI-IP-R
HDMI Input Connector
1 (HDMI Type A)
None
HDMI Input Color Space
HDMI: RGB 8/10/12 bit, YCbCr 4:2:2/4:4:4 8/10/12 bit,
DVI:RGB/YCbCr 4:2:2/4:4:4 8 bit
HDMI Output Connector
1 (HDMI Type A)
HDMI Output Color Space
YCbCr 4:4:4
RGB
HDMI Output Max.
Resolution
1080P@60Hz (8 bit)
LED Indicators
Power
LINK
Rj-45
IR In
None
3.5 mm jack
IR Out
3.5 mm jack
None
IR Carrier Frequency
20KHz ~ 60KHz
Baud Rate Settings
3 PIN DIP Switch
ID DIP Switch
8 PIN DIP Switch
CAT 5E cable distance
100 meters maximum
RS-232 connector
DB9 Female
Baud Rate
2400 up to 115,200 bps; data bits, 1 stop bit, no
parity
Weight
338 g
Dimension (LxW-H)
120x75x33 mm
HDMI-IP-E and HDMI-IP-R
APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921
6
Supported)Resolutions)
Resolution
Frequency(Hz)
640x480
60
800x600
60
1024x768
60
1280x768
60
1280x800
60
1280x960
60
1280x1024
60
1360x768
60
1366x768
60
1440x900
60
1400x1050
60
1440x1050
60
1600x900
60
1680x1050
60
480i
59.94/60
480p
59.94/60
576i
50
576p
50
1080i
50/59.94/60
1080p
23.98/24/25/29.98/30/50/59.94/60
720p
50/59.94/60
2.2 Front/Rear Views
HDMI-IP-E (Encoder)
Figure 4-1 HDMI-IP-E front view
1. HDMI Loop out. (YCbCr 4:4:4)
HDMI-IP-E and HDMI-IP-R
APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921
7
2. HDMI Input
3. Multicast ID DIP Switch
4. Power (12 V DC 2A)
Figure 4-2 HDMI-IP-E rear view
1. LED power indicator
2. System reset
3. Baud rate setting DIP Switch
4. IR out
5. RS-232
6. LINK
HDMI-IP-R (Decoder)
Figure 4-3 HDMI-IP-R front view
1. HDMI Output
2. Multicast ID DIP Switch
3. Power (12 V DC 2A)
Figure 4-4 HDMI-IP-R rear view
HDMI-IP-E and HDMI-IP-R
APANTAC LLC, 7470 SW BRIDGEPORT ROAD, PORTLAND, OR 97224
INFO@APANTAC.COM, TEL: +1 503 968 3000, FAX: +1 503 389 7921
8
1. LED power indicator
2. System reset
3. Baud rate setting DIP Switch
4. IR out
5. RS-232
6. LINK
HDMI-IP-E and HDMI-IP-R
9
3.0 DIP Switches
3.1 Baud Rate DIP Switch Settings
Baud Rate
PIN 1
PIN 2
PIN3
2400
OFF
OFF
OFF
4800
ON
OFF
OFF
9600
OFF
ON
OFF
19200
ON
ON
OFF
28800
OFF
OFF
ON
38400
ON
OFF
ON
57600
OFF
ON
ON
115200
ON
ON
ON
3.2 ID DIP Switch Settings
ID
PIN 1
PIN 2
PIN 3
PIN 4
PIN 5
PIN 6
PIN 7
PIN 8
0
OFF
OFF
OFF
OFF
OFF
OFF
Not
Used
Reset
1
ON
OFF
OFF
OFF
OFF
OFF
OFF
:
:
:
:
:
:
Wait
7
ON
ON
ON
:
:
:
3 Sec.
:
:
:
:
:
:
:
ON
63
ON
ON
ON
ON
ON
ON
