AORUS AD27QD Manual de usuario
- 2 -
LCD Monitor User’s Manual
Copyright
© 2018 GIGA-BYTE TECHNOLOGY CO., LTD. All rights reserved.
The trademarks mentioned in this manual are legally registered to their
respective owners.
Disclaimer
Information in this manual is protected by copyright laws and is the
property of GIGABYTE.
Changes to the specications and features in this manual may be made
by GIGABYTE without prior notice.
No part of this manual may be reproduced, copied, translated,
transmitted, or published in any form or by any means without
GIGABYTE’s prior written permission.
• In order to assist in the use of this monitor, carefully read the User
Guide.
• For more information, check on our website at:
https://www.gigabyte.com
- 3 -
LCD Monitor User’s Manual
SAFETY INFORMATION
Regulatory Notices
Federal Communications Commission Statement
This device complies with Part 15 of the FCC Rules. Operation is subject
to the following two conditions:
• This device may not cause harmful interference, and
• This device must accept any interference received including
interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed
and used in accordance with manufacturer’s instructions, may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment to an outlet on a circuit dierent from that
to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Canadian Department of Communications Statement
This digital apparatus does not exceed the Class B limits for radio noise
emissions from digital apparatus set out in the Radio Interference
Regulations of the Canadian Department of Communications.
This class B digital apparatus complies with Canadian ICES-003.
- 4 -
LCD Monitor User’s Manual
European Community Restriction of Hazardous Substances
(RoHS) Directive Statement
GIGABYTE products have not intended to add and safe from hazardous
substances (Cd, Pb, Hg, Cr+6, PBDE and PBB). The parts and components
have been carefully selected to meet RoHS requirement. Moreover, we
at GIGABYTE are continuing our eorts to develop products that do not
use internationally banned toxic chemicals.
European Community Waste Electrical & Electronic
Equipment (WEEE) Directive Statement
GIGABYTE will fulll the national laws as interpreted from the 2012/19/
EU WEEE (Waste Electrical and Electronic Equipment) directive. The
WEEE Directive species the treatment, collection, recycling and
disposal of electric and electronic devices and their components. Under
the Directive, used equipment must be marked, collected separately,
and disposed of properly.
WEEE Symbol Statement
The symbol shown below is on the product or on its
packaging, which indicates that this product must not be
disposed of with other waste. Instead, the device should be
taken to the waste collection centers for activation of the
treatment, collection, recycling and disposal procedure.
For more information about where you can drop o your waste
equipment for recycling, please contact your local government oce,
your household waste disposal service or where you purchased the
product for details of environmentally safe recycling.
- 5 -
LCD Monitor User’s Manual
Safety Precautions
Read through the following Safety Precautions before using the monitor.
• Only use the accessories that are provided with the monitor or that
which are recommended by the manufacturer.
• Keep the plastic packaging bag for the product in a place that
cannot be reached by children.
• Before connecting the monitor to the power outlet, make sure that
the voltage rating of the power cable is compatible with the power
specication in the country where you are located.
• The power cord plug must be connected to a properly wired and
grounded power outlet.
• Do not touch the plug with wet hands, otherwise easily cause
electric shock.
• Place the monitor in a stable and well-ventilated place.
• Do not place the monitor near any heat sources such as electric
radiators or direct sunlight.
• The holes or openings on the monitor are for ventilation. Do not
cover or block the ventilation holes with any objects.
• Do not use the monitor near water, drinks, or all types of liquids.
Failure to do so may result in electric shock or damage to the
monitor.
• Make sure to unplug the monitor from the power outlet before
cleaning.
• As the screen surface is easy to be scratched, avoid touching the
surface with any hard or sharp object.
• Use a soft lint-free cloth instead of a tissue to wipe the screen. You
may use a glass cleaner to clean the monitor if required. However,
never spray the cleaner directly onto the screen.
• Disconnect the power cable if the monitor is not being used for a
long period of time.
• Do not attempt to disassemble or repair the monitor yourself.
- 6 -
LCD Monitor User’s Manual
CONTENTS
Safety Information .....................................................................................................................3
Regulatory Notices...........................................................................................................3
Safety Precautions............................................................................................................5
Introduction .................................................................................................................................7
Unpacking...........................................................................................................................7
Package Contents.............................................................................................................9
Product Overview..........................................................................................................10
Getting Started.........................................................................................................................12
Installing the Monitor Base ........................................................................................12
Adjusting the Viewing Angle.....................................................................................14
Installing a Wall-Mount Bracket (Optional) ..........................................................16
Making Connections ....................................................................................................18
Using the Device......................................................................................................................19
Turning the Power On/O..........................................................................................19
Managing the Cables ...................................................................................................20
User Comfort Recommendations............................................................................20
Selecting the Input Source.........................................................................................21
Operations .................................................................................................................................22
Quick Menu......................................................................................................................22
Congure the Device Settings ..................................................................................27
Appendices................................................................................................................................37
Specications..................................................................................................................37
Supported Timing List..................................................................................................38
Troubleshooting.............................................................................................................39
Basic Care..........................................................................................................................40
Notes on USB Charging ...............................................................................................40
GIGABYTE Service Information.................................................................................40
- 7 -
LCD Monitor User’s Manual
INTRODUCTION
Unpacking
1. Open the upper cover of the packaging box. Then observe the
unpacking label attached on the inner cover.
2. Making sure the box is in the correct orientation, carefully lay the
box on the stable surface.
UP
3. Open the inner cover.
Openings
4. Grab the EPS foam assembly (through the openings) to pull it out of
the box.
- 8 -
LCD Monitor User’s Manual
5. Remove the items from the upper EPS foam.
6. Remove the upper EPS foam. Then you can remove the monitor from
the lower EPS foam.
- 9 -
LCD Monitor User’s Manual
Package Contents
The following items come with your packaging box. If any of them is
missing, please contact your local dealer.
Monitor Monitor Base Power Cable
HDMI Cable USB Cable DP Cable
Multilingual
Installation
Guide
AORUS AD27QD
Warranty Card
Cable Holder Quick Start Guide Warranty Card
CD
Note: Please keep the packaging box and packing materials for future
transportation of the monitor.
- 10 -
LCD Monitor User’s Manual
Product Overview
Front View
1
2
1Power LED 2Control button
