Anviz M-Bio Manual de usuario

PortableBluetoothEnabled

Fingerprint&RFIDDevice

M-Bio

Quick Guide v1.1

www.anviz.com

RFID Card

USB Cable Quick GuideDevice

Notiﬁcation:

Package List

POWERING A SMARTER WORLD

1. Please check if the package contains all the

items listed above. Contact the distributor if

there is any problem.

2. Please keep the product away from the

magnetic ﬁeld, and avoid causing any damage

to the device.

3. Please use the original power supply or refer

to the instruction to get the right power supply.

4. Please strictly follow the instructions to install

the product. Any damage to it caused by

incorrect operation and wiring are not under

warranty.

PortableBluetoothEnabled

Fingerprint&RFIDDevice

M-Bio

QuickGuide v1.1

Illustration for Placing Finger

Try to place your ﬁnger

covers the entire sensor.

Correct Method

Incorrect Method

DO NOT place ﬁnger

at an angle.

DO NOT place ﬁnger away

from the center of the sensor.

DO NOT place the ﬁnger

over an excessive angle.

DO NOT

take off ﬁnger during

the veriﬁcation process.

( Straighten your ﬁnger and then place it on the sensor

Ensure the ﬁnger is ﬂat and covers the entire sensor)

Always place ﬁnger in the

center of the sensor.

DO NOT slide your ﬁnger

during the ﬁngerpint

veriﬁcation process.

DO NOT just use

your ﬁngertip.

Appearance

OLED Screen

Fingerprint Sensor

RFID Reader

Area

Power Over USB Port

Power

Button

192.168.2.23 4

2021 01 10

14:20:33

Date and Time BluetoothWIFI AP Mode Battery

Operation Guide

5. Swipe Enroll

Card to end

the enrollment.

IMPORTANT:

M-Bio is suitable for USB 5V power supply only. Plug in the

power the device will automatic power on.

Add One Fingerprint per User Only:

1. Swipe

Enroll

Card

2. Place ﬁnger

4. Continue to register another user

3. Place

ﬁnger

again

Green &

Blue LEDs

light up

Blue LED

and Sensor

lights up

Green LED lights

up and display

Save Successed

1. After ﬁnish enrolling current user, the device will

continue to register another user.

2. After ﬁnish enrollment, please swipe enroll card

to exit enroll status.

Add Card Only:

Notice:

During the device in the regsiter mode without

any operation for 3 sec the M-bio will back to the

normal mode.

Operation Guide

1. Swipe

Enroll

Card

2. Swipe

User Card

4. Continue to register another user

3. Swipe

User Card

again

Green &

Blue LEDs

light up

Blue LED

and Sensor

light up

Green LED lights

up and display

Save Successed

5. Swipe Enroll

Card to end

the enrollment.

5. Swipe Delete

Card to end

the process

Operation Guide

Delete User:

Delete Fingerprint or Card

1. Swipe

Delete

Card

2. Place ﬁnger

4. Continue to delete user

3. Place

ﬁnger

again

Red and Blue

LEDs Light

Blue LED and

FingerPrint sensor

lights up

Green LED lights

up and display

delete success

After delete one user, you can continue to delete

another user or swipe Delete Card to exit delete mode.

Notice:

During the device in the delete mode

without any operation for 3 sec the M-bio

will back to the normal mode.

Notice:

Operation Guide

After delete one user, you can continue to delete

another user or swipe Delete Card to exit delete mode.

1. Swipe

Delete

Card

2. Swipe

User Card

4. Continue to delete user

3. Swipe

User Card

again

5. Swipe Delete

Card to end

the process

Red and Blue

LED Light

Blue LED and

FingerPrint sensor

lights up

Green LED lights

up and display

delete success

When you swipe card on M-Bio, Red LED

ﬂashing with long beeps means the card does

not exist in the device.

Delete Card:

192.168.2.1

2021 01 10

14:20:33

manage the device.

M-bio is default with WIFI AP

funciton.

Please connect M-Bio WIFI AP

WIFI SSID: M-bio

Default Password: 123456789

  

Please input the default address (192.168.2.234)

in the browser to login Webserver.

Account: admin

Default Password: 12345

User Name

Password
