Anvil SLM0012 Manual de usuario

220

• Recommended Stocking Part

SLICER MONDIAL HEAVY DUTY DELUXE 12”

SSLLMM00001122

346 MOTOR 115V ( 30-SM-1371 ) XSLM0003

308/309/310 SHARPENER HOUSING ( 23-SM-1320 ) XSLA0049

324 BLADE 12" XSLM0009

306 TUBE SHAFT ( 09-SM-1206 ) XSLM0017

331 REGULATOR CAM ( 09-SM-1301 ) XSLS0010

375 ROLLER BRACKET (09-SM-1275) XSLM0035

382 KNIFE WIPER ( 09-SM-1284 ) XSLM0038

351 STUD FOR PLATFORM BRACKET (08-SM-1251) XSLM0041

332 BUSH FOR REGULATOR KNOB (08-SM-1232) XSLM0045

ACOMPLETE SHARPENER ASSEMBLY & COVER ( 30-SM-6093 ) XSLM0047

316 NUT FOR SHARPENER ASSEMBLY (08-SM-1211) XSLM0048

709 SPIKED PLT ASSEMBLY W/KNOB (30-SM-1359) XSLM0053

468 BLADE COVER (SM-6025) (FOR GENERAL SLICER MODEL ONLY) XSLM0060

N/S BOTTOM COVER (09-SM-1329) XSLM0082

373 PLATFORM BRACKET (FOR GENERAL SLICER MODEL) XSLM0095

372 HANDLE FOR PLATFORM CARRIAGE (09-SM-9039) XSLM0096

355 PLATFORM CARRIAGE (01-SM-1255) XSLM0115

433 DEBURRING STONE XSLM1004

434 SHARPENING STONE XSLM1009

301 REGULATOR PLATE (23-SM-1319) XSLM1023

323 ROD FOR KNIFE COVER (09-SM-1223) XSLM1024

320 BLADE PULLEY(30-SM-1220) XSLM1029

321 DRIVE BELT TB2-630 (FOR NEW MODEL) XSLM1030

468 BLADE COVER (#33) (FOR ANVIL MODEL ONLY) XSLM1033

345 CAPACITOR 10MF (SN 110598BD013 FWD ) XSLM1075

93 LOCK KNOB FOR SHAFT XSLM1093

376 HEX HUT (#08-SM-1080) XSLM1100

378 SCREW (08-SM-1282)...... XSLM1101

380 ROLLER WHEEL (06-SM-1540) XSLM1102

356 SCREW 6MA X 20 NYLON (08-SM-1256) XSLM1117

118 CARRIAGE SCREW SET (#118) (08-SM-1257) XSLM1118

CONTINUED

PART NO.

SLM0012/SLICER MONDIAL HEAVY DUTY DELUXE 12”

DESCRIPTION

CODE

221

• Recommended Stocking Part

SLICER MONDIAL HEAVY DUTY DELUXE 12”

SSLLMM00001122

PART NO.

DESCRIPTION

CODE

SLM0012/SLICER MONDIAL HEAVY DUTY DELUXE 12”

317 WASHER (14mm X 1) (#26) XSLM2026

30 DRIVE BELT TB2-34-660 ( FOR OLD MODEL) XSLM2030

462 THUMBSCREW FOR KNIFE COVER XSLM2034

345 CAPACITOR OLD TYPE ( SN 110598BD013 DOWN ) (05-SM-1245) XSLM2075

N/S BLADE COVER INSERT (FOR GENERAL SLICER MODEL) XSLM2080

N/S BLADE COVER INSERT(FOR ANVIL MODEL) XSLM2085

341 ON/OFF SWITCH (TOGGLE TYPE) XSLT1233

341 ON/OFF SWITCH (PLASTIC ROCKER TYPE) XSLA0040

374 MEAT TRAY/ LOCKING KNOB XSLS0040

308 KNOB FOR KNIFE COVER ROD XSLA0028

CONTINUED from previous page
