Antik MX5308 Manual de usuario
Professional 8-in-1 TS Processor
MX5308
USER MANUAL
2015/06
2
www.antiktech.com
MX5308
8-in-1 TS Processor
License Declaration
Without the prior written permission of ANTIK Technology, no part of
this manual shall be added or removed in any form, adaptation, excerpt,
translate, reproduce or imitation.
The entire contents of this manual may be changed by ANTIK
Technology at any time without prior notice.
Specic features are subject to the actual software features.
©2015 Copyright by ANTIK Technology. ALL RIGTHT RESERVED
is a registered trademark of ANTIK Technology.
This manual covers all other product trademarks with the appropriate companies.
3
www.antiktech.com
Your digital visual world!
Contents
4 1 OVERVIEW
4 2 FEATURES
5 3 TECHNICAL SPECIFICATIONS
8 4 FRONT PANEL AND REAR PANEL INSTRUCTIONS
8 4.1 Front Panel
8 4.2 Rear Panel
9 4.3 RS-232 Serial Port
9 4.4 Management Ethernet Port
10 4.5 TS over IP Ethernet Port
11 5 OPERATION
11 5.1 Local Control
11 5.1.1 Getting Started
11 5.1.2 Main Menu
12 5.1.3 Conguration Menu
13 5.1.4 System Menu
14 5.2 Remote Control (Web)
14 5.2.1 Status
15 5.2.2 Conguration
16 5.2.2.1 Conguration-Tuner
17 5.2.2.2 Conguration-Cl
17 5.2.2.3 Conguration-Biss
18 5.2.2.4 Conguration-ASI Output
19 5.2.3 Remux
20 5.2.4 TS/IP
20 5.2.4.1 Gigabit Local
21 5.2.4.2 Gigabit Out
22 5.2.4.3 Gigabit In
22 5.2.5 System
26 6 FIRMWARE UPDATE
26 6.1 Firmware Update from USB Key
26 6.2 Firmware Update by FTP
29 6.3 Firmware Update from WEB
30 7 INSTALLATION
30 8 ACCESSORIES
4
www.antiktech.com
MX5308
8-in-1 TS Processor
4
www.antiktech.com
1OVERVIEW
MX5308 is a high-density, modular and CI decryption professional TS processor equipped with
8 independent tuners, which can be either of DVB-T/T2, DVB-S2/S, DVB-C, DTMB, ISDB-T and
ATSC types. It supports a wide range of application by combining 8 tuners processing capability
with industry standard outputs including ASI and TS/IP. MX5308 has 8 DVB common interface
slots capable of working with most of well-known CAS in the market to de-crypt multiple pay TV
services. MX5308 provides operators an ideal solution for multi receiving, re-multiplexing, de-
scrambling and TS over IP operations, the compact 8 tuners and the powerful 8 CI decryption
design make MX5308 one of the most competitive product in the head-end market.
2FEATURES
l8 x Tuners Input, Supports variety of input options DVB-T2/T/S2/S/C/DTMB/ATSC/ISDB-T
lSupports DVB-S2 Input Stream Identier (ISI, optional) and DVB-T2 Multi PLP and SFN MIP
pass through
lBuilt-in TS re-multiplexer receives from CI Slot1 to CI Slot8 and TS/IP inputs
l8×DVB-CI Slots, multi-program decryption, BISS-1 and BISS-E decryption
l8xASI output the transport stream from CI Slot1 to CI Slot8 or BISS decryption
l1x channel full duplex TS over IP ,9xchannels MPTS IP out without IP input or 128xchannels
SPTS IP out without IP inputSupport ASI output MPTS or 8 SPTS
lRemote Control and Supervision by SNMP v2, HTTP WEB and Proprietary HDMS software
lOn Site software update through IP or USB
lRSSI, received signal strength, Eb/N0, C/N and BER monitoring
lRedundency power supply
5
www.antiktech.com
Your digital visual world!
5
www.antiktech.com
Your digital visual world!
3TECHNICAL SPECIFICATIONS
Tuner Input
DVB-S/S2 Tuner Input (ISI Factory Optional)
Connector Type 8×F type female 75Ω for Input
Input Frequency Range 950 ~ 2150MHz
Input Level -25 ~ -65dBm
Symbol Rate 2 ~ 45MBaud
Roll-off Factor DVB-S QPSK: 0.35
DVB-S2 8PSK: 0.35, 0.25, 0.2
FEC Code Rate
DVB-S QPSK: 1/2, 2/3, 3/4, 5/6, 7/8
DVB-S2 QPSK: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 8/9,9/10
DVB-S2 8PSK: 3/5, 2/3, 3/4, 5/6, 8/9, 9/10
LNB Polarity Selection Voltage 0, 13V, 18V selectable
LNB Band Selection Tone 0/22KHz selectable
Satellite Selection Command DiSEqC 1.0
ISI ID 1 ~ 255 user congurable
DVB-C Tuner Input
Connector Type 8×F type female 75Ω for Input
Input Frequency Range 51 ~ 862MHz
Input Level 51 ~ 75dBμV
Symbol Rate 1 ~ 7MBaud (ITU J.83 Annex A)
Constellation 16QAM, 32QAM, 64QAM, 128QAM, 256QAM
Bandwidth 6MHz, 7MHz, 8MHz
Input Return Loss 7dB (typ.)
DVB-T/T2 Tuner Input
Connector Type 8×F type female 75Ω for Input
Input Frequency 104 ~ 862MHz (VHF/UHF)
Input Level -20 ~ -70dBm
Constellation DVB-T: QPSK, 16QAM, 64QAM
DVB-T2: QPSK, 16QAM, 64QAM, 256QAM
Bandwidth 6MHz, 7MHz, 8MHz
FFT Mode DVB-T: 2K, 8K
DVB-T2: 1K, 2K, 4K, 8K, 16K, 32K
Guarding Interval DVB-T: 1/4, 1/8, 1/16, 1/32
DVB-T2: 1/4, 5/32, 1/8, 5/64, 1/16, 1/32, 1/64, 1/128
FEC Code Rate DVB-T: 1/2, 2/3, 3/4, 5/6, 7/8
DVB-T2: 1/2, 3/5, 2/3, 3/4, 4/5, 5/6
Input Return Loss 7dB (typ.)
DTMB Tuner Input
Connector Type 8×F type female 75Ω for Input
Input Frequency Range 46.5~866MHz
Input Level -87~-29dBm
Symbol Rate 7.56MBaud
Bandwidth 6MHz/7MHz/8MHz
6
www.antiktech.com
MX5308
8-in-1 TS Processor
Constellation 4QAM-NR,4QAM,16QAM,32QAM,64QAM
Guard Interval PN420, PN595, PN945
Roll-off Factor 0.05
Interleaving Depth 240,720
FEC Code Rate 0.4, 0.6, 0.8
ATSC Tuner Input(compatible with ITU J.83 Annex B)
Connector Type 8×F type female 75Ω for Input
Input Frequency Range 54~864MHz
Input Level -75~-7dBm(ATSC 8VSB)
Symbol Rate 10.762MBaud
Constellation 8VSB
Roll-off Factor 0.115
Bandwidth 6MHz
TS Processing
TS Input Management Demux and Remux among IP Input and CI1 to CI8 Input
TS Output Management
ASI1 to ASI8 output directly pass through the TS from CI1
to CI8,
Demux and Remux for ASI9, ASI10 output and IP output
Service and PID Management Service and PID level for Remux
PSI/SI PSI/SI table regeneration, NIT and SDT edition, LCN Edition
and Re-generation
Descrambler DVB Common Scrambling Algorithm (CSA)
BISS Mode BISS-1, BISS-E
Common Interface 8 x PCMCIA slots, compatible with major CA CAMs in the
market
ASI Output
Connector Type Daughter Board: 8xBNC female, independence output, 75Ω,
Main Board: 1 pair of BNC female, mirror output, 75Ω,
Standard DVB-ASI, EN50083-9
Output Bit Rate ≤ 200Mb/s
TS Processing
Daughter Board: ASI1 to ASI8 out pass through the TS from
CI 1 to CI8,
Main Board: ASI9 and ASI10 out from Remux
TS over IP
Connector Type 1×RJ-45, 100/1000 Base-T
Effective Bit Rate
Support 3 different mode(need to reboot unit if change the
TS/IP mode):
1. Max.430Mb/s for 9xchannels(8xchannels directly pass
through the TS from CI1 to CI8, 1xchannel output the TS
from Remux) MPTS IP out without IP in,
2. Max.430Mb/s for 128xchannels SPTS IP out the TS from
one source, without IP in,
3. Max.80Mb/s for full duplex 1xchannel MPTS
Protocol UDP/RTP, Multicast/Unicast, IGMPv3, ARP
Alarm
Connector Type 1×D-sub 9 male
Switching Condition User Dened
7
www.antiktech.com
Your digital visual world!
Control & Monitoring
Connector Type 1×RJ-45, 10/100 Base-T, for equipment IP Control
Remote Control SNMP, HTTP (Web Interface), Proprietary HDMS (Headend
Device Management System)
Local Control LCD display and 6-key keypad
Serial Port 1×RS-232 D-sub female, for debug use only
Equipment Upgrade USB,WEB http and FTP
Physical
Dimension 505mm x 445mm x 45mm
Weight 7.9kg
Power Supply AC 90V ~ 250V, 50/60Hz
Power Consumption 30W (exclusive of LNB power)
Operating temperature 0 ~ 45℃
Storage temperature -10 ~ 60℃
Operating Humidity 10 ~ 90%, non-condensed
Certication
EMC: EN 55024:1998+A1:2001+A2:2003, EN 55022:2006+A1:2007, EN 61000-3-2:2006, EN
61000-3-3:2008
FCC: Part 15 Class B
LVD: EN 60950-1:2006 + A11:2009
* For more information about digital audio pass through, please contact our sales representative.
8
www.antiktech.com
MX5308
8-in-1 TS Processor
4 OVERVIEW
4.1 FRONT PANEL
Name Function
LED Power When turned on, the Green LED indicates that power is available. When
turned off, the power is not available or failed
LED Warning LED ON:
LED OFF:
LED Alarm
LED ON: Alarm or alarms happen to the equipment, For alarm description,
please refer to details in the table 10.
LED OFF: The equipment works properly
LED Tuner Lock LED ON: Tuner input is locked,
LED OFF: Tuner is un- locked.
LCD Display Display menus, submenus and its parameters
Cursor Keys UP, DOWN, LEFT, RIGHT. Used to navigate through the menu system
ENTER key Conrm a selection then return to previous menu
EXIT Key Exit and return to previous menu
Control RJ-45 Ethernet port for equipment control and supervision
Control USB port for rmware upgrade
TS/IP RJ-45 TS over IP port
4.2 REAR PANEL
Name Description
Alarm
RS-232 Serial port for equipment debug use
9
www.antiktech.com
Your digital visual world!
Tuner In-1/4 Tuner signal input port 1~4
ASI Out-1/4 ASI Output ports in mirror 1~4
Common Interface To insert CI CAM modules, maximum two CI modules 1~4
Tuner In-5/8 Tuner signal input port 5~8
ASI Out-5/8 ASI Output ports in mirror 5~8
Common Interface To insert CI CAM modules, maximum two CI modules 5~8
ASI Out-9/10 ASI Output ports in Remux 1~2
Power Supply Double Power Supply,AC 90~250V 50-60Hz input
4.3 RS-232 SERIAL PORT
The RS-232 port is used for equipment software debug use, its pin denition is shown in the table.
The parameter settings are:
● No Parity bit
● 38400 Bauds
● 8 data bits
● 1 Stop bit
Pin Pin Function
1N.C.
2TXD
3RXD
4N.C.
5GND
6N.C.
7N.C.
8N.C.
9N.C.
4.4 MANAGEMENT ETHERNET PORT
The Management port is used to remote control and supervise the equipment through IP, it’s also
for the software update. Its factory setting is as following:
l IP address: 10.10.70.48
l Sub Mask: 255.255.255.0
l Gateway: 10.10.70.1
Both web based control software and proprietary HDMS software are using this port.
Notice: When apply default setting to MX5308, the above settings for IP will not be affected, this is
for maintaining the connectivity of the unit to the IP Network.
10
www.antiktech.com
MX5308
8-in-1 TS Processor
4.5 TS OVER IP ETHERNET PORT
The TS over IP port is an option by adding the daughter board inside the rack. The default setting
is as following:
l IP address:10.10.10.10
l 2nd IP address: 10.10.10.20
l Sub Mask:255.255.255.0
l Gateway:10.10.10.1
Depending on the option selected by the customer, this TS over IP port is either 10/100 Base-T or
100/1000 Base-T compliant to the IEEE 802.3 specications.
