anko Genius Compact Stroller Manual de usuario
IMPORTANT!
PLEASE READ CAREFULLY &
KEEP FOR FUTURE REFERENCE
This product is designed to comply with Australian and New Zealand standard
AS/NZS2088:2013.
The illustrations shown in this manual are for reference only. The manufacturer reserves the right to change any specification
or feature without further notice.
Instruction Manual
Genius Compact Stroller months
0-36 kg
15
MAXIMUM
WEIGHT
OF CHILD
02
WARNING
TO AVOID INJURY OR DEATH: ALWAYS APPLY THE BRAKES
WHENEVER THE PRAM/STROLLER IS STATIONARY.
• FOLLOW THE MANUFACTURER’S INSTRUCTIONS.
• DO NOT LEAVE CHILDREN UNATTENDED.
• SECURE THE CHILD CORRECTLY IN THE HARNESS AT ALL TIMES.
• DO NOT CARRY EXTRA CHILDREN OR BAGS ON THIS PRAM/STROLLER. THE PRAM/STROLLER
MAY TIP OVER.
• MAKE SURE CHILDREN ARE CLEAR OF ANY MOVING PARTS IF YOU ADJUST THE PRAM/STROLLER.
• USE THE HARNESS AT ALL TIMES.
• DO NOT USE ANY ACCESSORIES OTHER THAN THOSE APPROVED FOR USE WITH THIS
PRAM/STROLLER BY THE MANUFACTURER.
• IT IS UNSAFE TO USE ACCESSORIES NOT APPROVED FOR USE WITH THIS PRAM/STROLLER.
• DO NOT PLACE MORE THAN 4.5 KG IN THE BASKET.
• THE MAXIMUM HEIGHT & WEIGHT OF THE CHILD USING THIS PRODUCT IS NOT TO EXCEED
96CM AND 15KG.
• NEVER LEAVE THE HARNESS BUCKLED WHEN NOT FITTED TO A CHILD IN THE PRAM/STROLLER
AS THE HARNESS CAN FORM LOOPS WHICH MAY POSE A STRANGULATION HAZARD.
• THERE IS POTENTIAL FOR FINGERS OR PARTS OF THE BODY TO BE INJURED WHEN THE
PRAM/STROLLER IS BEING FOLDED OR UNFOLDED. DUE CARE SHOULD BE EXERCISED.
• TAKE CARE WHEN USING THE PRAM/STROLLER ON STAIRS, ESCALATORS, TRAVELATORS OR
OTHER MOVING SURFACES.
• IT IS RECOMMENDED TO REMOVE THE CHILD FROM THE PRAM/STROLLER BEFORE GOING UP OR
DOWN STAIRS OR ESCALATORS.
• DO NOT LIFT THE PRAM/STROLLER BY THE ARM BAR AS IT MAY DISENGAGE.
• DO NOT LEAVE THE PRAM/STROLLER OR ITS ACCESSORIES NEAR AN OPEN FIRE OR EXPOSED FLAME.
• USE THE TETHER STRAP TO PREVENT THE PRAM/STROLLER FROM ROLLING AWAY.
• CHECK THAT THE BRAKE IS ENGAGED BEFORE PLACING A CHILD IN THE PRAM/STROLLER.
• ENSURE YOUR CHILD IS SECURED WITH A CORRECTLY ADJUSTED SAFETY HARNESS.
• DO NOT ALLOW CHILDREN TO STAND ON THE SEAT.
RETAIN FOR FUTURE REFERENCE.
READ ALL INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY AND USE
OF THIS PRAM/STROLLER. ALWAYS FOLLOW THE INSTRUCTIONS.
THE CORRECT USE AND MAINTENANCE OF THIS PRODUCT IS ESSENTIAL.
WARNING
03
WARNING
• THE UPRIGHT SEATING POSITIONS ARE NOT SUITABLE FOR A CHILD UNDER 6 MONTHS OLD.
• THE LOWEST RECLINE POSITION SHOULD BE USED TO TRANSPORT BABIES. THE BACKREST CAN BE
ADJUSTED TO A MORE UPRIGHT POSITION AS THE CHILD GROWS OLDER AND IS ABLE TO SUPPORT
ITS HEAD WITHOUT ASSISTANCE.
12° or less more than 12°
X
THE PRAM/STROLLER IS DESIGNED FOR USE ON FLAT OR GENTLY SLOPING SURFACES AND
CAN BECOME UNSTABLE ON HIGHER SLOPING OR UNEVEN SURFACES. USERS SHOULD BE
AWARE OF THE POSSIBILITY OF THE STROLLER ROLLING AWAY OR TIPPING OVER.
• WITH YOUR HAND THROUGH THE WRIST TETHER STRAP LOOP, PUSH THE PRAM/STROLLER HOLDING
BOTH HANDLES.
• THE PRAM/STROLLER CAN BE STEERED IN THE DESIRED DIRECTION - ALLOWING THE FRONT WHEELS
TO SWIVEL WILL MAKE THIS EASIER.
• THE FRONT WHEELS MAY WOBBLE OR OSCILLATE WHEN WALKING FAST. LOCKING THE FRONT SWIVEL
WHEELS WILL STOP THIS.
• THE PRAM/STROLLER CAN BE TAKEN UP KERBS BY EITHER PRESSING DOWN ON THE HANDLES,
RAISING THE FRONT WHEELS AND MOUNTING THE KERB OR TURNING THE PRAM/STROLLER AROUND
AND PULLING THE PRAM/STROLLER UP THE KERB.
• CAUTION IS REQUIRED WHEN PUSHING THE PRAM/STROLLER ACROSS STEEP SLOPES OR UNEVEN
SURFACES AS THE PRAM/STROLLER MAY BECOME UNSTABLE AND FALL OVER. ALWAYS
HOLD THE HANDLES FIRMLY.
• DO NOT RUN WITH THE PRAM/STROLLER.
• WHENEVER YOU STOP, ALWAYS APPLY THE BRAKES BEFORE YOU LEAVE THE PRAM/STROLLER.
• DO NOT HANG BAGS OR GOODS FROM THE HANDLE AS THIS COULD CAUSE THE PRAM/STROLLER TO
TIP OVER. USE THE STORAGE BASKET.
WARNING
04
This CAUTION Symbol is shown at certain
steps in this Instruction Manual to highlight
the danger of being injured by moving parts.
MANUAL HANDLING TECHNIQUES
The SMART lifting technique;
This technique can be used to pick up small light loads from low levels.
Size up the Load;
• Assess the load (size, shape and weight).
• Assess whether the load needs to be moved.
• Where is it going to be placed? Check that there are no obstructions.
• Assess whether mechanical or human assistance is required. Move the load as close to
the body as possible.
• A load is heavier to lift or carry if it is not close to the body.
• The whole hand should be used to ensure a firm grip. Always bend your knees.
• Maintain balance.
• Keep feet apart and in a comfortable position.
• Minimise lower back bending.
• Bend knees at a large angle as possible but not at a right angle - use a semi squat in
preference to a full squat. Raise the load with your legs.
• Achieve the lift smoothly and without jerkiness.
• Maintain the normal curvature of the spine to allow the force of the load to be distributed
evenly from the spine to the pelvis. Turn your feet in the direction that you want to move
the load.
• Avoid unnecessary bending, twisting and reaching.
• Change direction by turning your feet and not your back.
• To set the load down, squat down, keep your head up and let your legs do the work.
Remember to ‘THINK TALL’ - chest lifted, shoulders relaxed, chin tucked in and head level.
WARNING
Frame
Canopy
Bumper Bar
Adjust Button
Brake Pedal
Footrest
Rear Wheel
Basket
Front Wheel
Swivel Lock
Safety Buckle
Fold Handle
Handle
Rear Wheel(L) x1Front Wheel x2
Rear Wheel(R) x1
Bumper Bar
Stroller Components
Seat
05
D
(3) Place foot on the Grey Lock Pedal then lift
handle of stroller up until a ‘click’ is heard (Fig. D).
CHECK that the stroller is completely latched
open every time you open the stroller and before
continuing with the rest of the assembly steps.
E
(1) Open storage latch (Fig. A).
(2) Lift handle of stroller up (Fig. B & C).
A
C
B
1. To Open Stroller
06
Lock Pedal
Assembly of Stroller
07
(5) Attach Rear wheels (L&R) to stroller as
(Fig. A). A ‘click’ will he heard. CHECK that
the wheel is securely attached by pulling
on wheel assembly.
To release wheel for easy transport or storage,
remove Rear wheel by pushing button (Fig. B).
A
B
(4) Slide each front wheel assembly onto the
mounting post at the front of the stroller (Fig. A).
A ‘click’ will be heard. Pull wheel to
CHECK and ensure that it is secure.
To release wheel for easy transport or storage,
push the wheel release tab on the inside of the
stroller frame and pull the wheel away from
the stroller (Fig. B).
A
B
2. Front Wheels
3. Rear Wheels
A
B
A
B
(7) Parking and releasing the brake:
Using your foot, push the brake lever down
to park (Fig. A).
Push the brake lever up to release (Fig. B).
(6) Opening / closing the Bumper Bar: Press
the bumper into the slots to install. It will click
into place (Fig. A).
Press the buttons on two sides of the arm
together to release the bumper bar (Fig. B).
4. To Use Bumper Bar
5.
Using The Brakes
08
A
B
WARNING:
WHEN A CHILD
IS IN THE STROLLER, KEEP THE ARM BAR
ATTACHED TO THE FRAME AT ALL TIMES.
WARNING:
ALWAYS
APPLY THE BRAKES WHEN THE STROLLER
IS STATIONARY.
(9) To raise: Hold the footrest front and raise
it to up position (Fig. A).
To lower: Pull Buttons 1 outwards on both
sides of the footrest and hold while lowering the
footrest to the lower position (Fig. B).
A
(8) Push the swivel lock switch fully down
to lock the front wheel. Press the swivel lock
switch fully up to allow the wheel to swivel
(Fig. A).
A
B
1
1
7.
Footrest
09
6. Swivel Wheel
WARNING:
THE FOOTREST
FEATURE IS PROVIDED FOR YOUR CHILD’S
COMFORT. THE FOOTREST IS NOT DESIGNED
TO SUPPORT EXTRA WEIGHT. DO NOT ALLOW
CHILDREN TO STAND OR SIT ON THE FOOTREST.
(10) For upright sitting position:
Pull the webbing on both sides outwards to
adjust the backrest upright (Fig. A).
For reclined laying position:
Pull the buckle downwards for the backrest
to recline into laying position (Fig. B).
A
B
8.
Adjusting The Backrest
10
WARNINGS:
• THE UPRIGHT POSITIONS ARE NOT SUITABLE FOR CHILDREN LESS THAN
6 MONTHS OLD.
• THE LOWEST RECLINE POSITION SHOULD BE USED TO TRANSPORT BABIES.
THE BACKREST CAN BE ADJUSTED TO A MORE UPRIGHT POSITION AS THE
CHILD GROWS OLDER AND IS ABLE TO SUPPORT ITS HEAD
WITHOUT ASSISTANCE.
NOTE: IF THE CHILD IS SITTING IN THE SEAT, SUPPORT THE BACKREST
AS IT RECLINES. IF YOU HAVE DIFFICULTY ADJUSTING THE BACKREST,
YOU MAY NEED TO REMOVE THE CHILD FROM THE SEAT TO ALLOW YOU
TO RAISE OR LOWER THE BACKREST WITH EASE.
