Anker A7910 Manual de usuario
Anker A7910 Pocket Bluetooth Speaker
Welcome Guide
1
Anker A7910 Pocket Bluetooth Speaker
2
Package Contents
■ Anker A7910 Pocket Bluetooth Speaker
■ Micro USB charging cable (2.3 ft)
■ AUX to Micro USB audio cable (2.3 ft)
■ Welcome Guide
Product Features
■ Ring-box size profile fits easily into your pocket, or the small side
pocket of your backpack.
■ Impressively full sound powered by a powerful 3 watt audio driver.
■ 12 hours of play time significantly outlasts other Bluetooth
speakers.
■ Non-Bluetooth devices enjoy unhampered compatibility with the
provided AUX to Micro USB audio cable.
■ NFC compatibility enables easier pairing.
■ Connects automatically to the last-connected device once
powered on.
3
Specifications
Product Model A7910
Bluetooth Standard 3.0
Product Weight 90 ± 5g / 3.2 ± 0.2oz
Product Size 45 × 45 × 45mm / 1.8 × 1.8 × 1.8in
Play Time 12 hours
Charge Time 3 hours
Input 5V / 0.5A
Operating Range 10m / 33ft
Speaker Output Power 3W
Audio Cable Type AUX to Micro USB audio cable
Supported Bluetooth Profiles A2DP, AVRCP
4
Product Model
1. Power button
2. LED indicator
3. Micro USB charging & audio 2-in-1 port
4. NFC chip location
How to T k
Press the power button for 3 seconds to turn the speaker on or o .
①
②
④
③
5
How to Pair with Your Device
1. Press the power button for 3 seconds. The speaker will turn on and
automatically enter pairing mode indicated by the flashing blue LED.
2. Activate your device’s Bluetooth function and search for the device.
3. Once the Bluetooth speaker has been detected, select the product
name “Anker A7910” to connect. (For devices with Bluetooth versions
below 3.0, press “Yes” to confirm pairing. Enter a passkey or PIN code
“0000” (4 zeros), then press the “Yes” or “OK” key to finish pairing.)
4. When the Bluetooth speaker and your device are successfully
paired, the blue LED will go on and remain on while connected.
How to Pair with a NFC-Supported Device
1. Press the power button for 3 seconds. The speaker will turn on and
the indicator will start flashing blue.
2. Enable your device’s NFC function.
3. Put your device near the NFC chip location.
4. Click “Yes” on your device’s screen to confirm Bluetooth
connection.
5. When the Bluetooth speaker and your device are successfully
paired, the blue indicator will go on and remain on while connected.
6
Note: When turning on the speaker, it will automatically connect to
the last-connected device (Bluetooth function needs to be enabled).
When pairing with an additional device, disable the Bluetooth
function on the previous device, the speaker will automatically return
to pairing mode. Then, repeat the pairing process.
How to Recharge
When the speaker’s battery is low, the speaker will announce “Battery
low”, and the red battery indicator will flash for about 10 minutes.
1. Plug the Micro USB cable into the speaker’s Micro USB charging port.
2. Insert the remaining end of the USB power wire into (a) a USB AC
adapter (not included) connected to a wall socket, or (b) a charging
computer USB port. A steady red battery indicator will show that it is
charging.
3. The red battery indicator will go off when the speaker is fully
charged.
7
LED Indicator Instructions
LED indicator Meaning
Blue indicator rapidly flashing Pairing mode
Steady blue indicator Connected to a device
Red indicator flashing Low battery
Steady red indicator Charging
Red indicator goes o Fully charged
Usage Tips
1. Power o the speaker when not in use and before storing.
2. The operational range of the speakers may be influenced by
obstructions, such as walls, pillars, etc. To ensure a stable connection,
we recommend avoiding such obstructions whenever possible and/or
shortening the distance during use.
3. To protect the long-term performance of the battery, please do not
place the speaker in high temperatures above 140°F/60℃, such as in
a hot vehicle or under direct sunlight.
4. Do not expose thespeaker or any of its supplied partsto water orliquids.
8
FAQ and Solutions
1. Why can’t the speaker connect to my device?
a. Check to ensure your device’s Bluetooth function is enabled.
b. Make sure your device is within 3ft/1m of the speaker.
c. Delete the pairing record(s) on the speaker or your device.
2. Can I use the speaker to play music while charging?
To protect the long-term performance of the battery, it is better to
charge it when the speaker is turned off, especially when the battery
is low.
3. Can I make or answer phone calls through the speaker?
No. The speaker does not feature a built-in microphone.
4. Why can’t I connect by NFC?
a. Make sure that your device supports NFC functionality.
b. Keep your mobile device close to the NFC chip location of the
speaker when attempting to connect.
c. Disable the Bluetooth connection of the speaker to other devices.
9
Warranty
Our company provides customers with a warranty of 18 MONTHS
from the date of purchase.
Contact Us
For any inquiries or comments concerning our products, please send
an email to support@ianker.com, and we will respond to you as soon
as possible. If there is any quality-related issue with the product, you
may request a REPLACEMENT OR REFUND by submitting a request
form at www.ianker.com/support.
Statement
■ We’re only able to provide after-sales service for purchases made
directly from Anker. If you purchased through a different retailer,
please contact them for any exchange or refund requests.
■ Please note that unauthorized reselling of Anker products is
prohibited.
