AMX Color Active-Matrix LCD Manual de usuario

&RORU#$FWLYH00DWUL[#/&'#0LQL07RXFK#3DQHOV

+)LUPZDUH#YHUVLRQ#*6#RU#KLJKHU,

,QVWUXFWLRQ#0DQXDO

818¨#0LQL07RXFK#3DQHOV#DQG#$FFHVVRULHV

Limited Warranty and Disclaimer

AMX Corporation warrants its products to be free from defects in material and

workmanship under normal use for a period of 3 years from date of purchase from

AMX, with the following exceptions: Electroluminescent and LCD control panels are

warranted for a period of 3 years, except for the display and touch overlay compo-

nents, which are warranted for a period of 1 year. Disk drive mechanisms, pan/tilt

heads, power supplies, modifications, MX Series products, and KC Series products

are warranted for a period of 1 year. Unless otherwise specified, OEM and custom

products are covered for a period of 1 year. AMX software products are warranted for

a period of 90 days. Batteries and incandescent lamps are not covered.

This warranty extends to products purchased directly from AMX or an authorized

AMX dealer. Consumers should inquire from selling dealer as to the nature and ex-

tent of the dealer’s warranty, if any.

AMX is not liable for any damages caused by its products or for the failure of its

products to perform, including any lost profits, lost savings, incidental damages, or

consequential damages. AMX is not liable for any claim made by a third party or

made by you for a third party.

This limitation of liability applies whether damages are sought, or a claim is made,

under this warranty or as a tort claim (including negligence and strict product liabil-

ity), a contract claim, or any other claim. This limitation of liability cannot be waived

or amended by any person. This limitation of liability will be effective even if AMX or

an authorized representative of AMX has been advised of the possibility of any such

damages. This limitation of liability, however, will not apply to claims for personal

injury.

Some states do not allow a limitation of how long an implied warranty lasts. Some

states do not allow the limitation or exclusion of incidental or consequential damages

for consumer products. In such states, the limitation or exclusion of the Limited War-

ranty may not apply to you. This Limited Warranty gives you specific legal rights.

You may also have other rights that may vary from state to state. You are advised to

consult applicable state laws for full determination of your rights.

EXCEPT AS EXPRESSLY SET FORTH IN THIS WARRANTY, AMX MAKES NO

OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED

WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR

PURPOSE. AMX EXPRESSLY DISCLAIMS ALL WARRANTIES NOT STATED IN

THIS LIMITED WARRANTY. ANY IMPLIED WARRANTIES THAT MAY BE

IMPOSED BY LAW ARE LIMITED TO THE TERMS OF THIS LIMITED

WARRANTY.

Color Active-Matrix LCD Mini-Touch Panels

Table of Contents i

Table of Contents

Introduction............................................................................. 1

Overview 1

Features 2

Related AMX Instruction Manuals 3

Sample Product Application 3

What’s in this Manual 4

What’s New 4

Installing Mini-Touch Panels.................................................. 5

Overview 5

Mounting the Mini-Touch Panels 5

UniMount- / Decor-style panels with

low-profile Back Boxes 5

UniMount- / Decor-style panels and

BB-MTP UniMount Back Box (solid surfaces) 9

UniMount- / Decor-style panels and

BB-MTP Back Box (plasterboard) 12

Rack-mount panels 16

Wiring the Mini-Touch Panels 17

Preparing captive wires 18

Wiring guidelines 18

Using the AXlink mini-XLR connector for

data and power (TiltScreen) 19

Using the AXlink mini-XLR connector and

external 12 VDC power supply (TiltScreen) 19

Using the AXlink connector for data and power 20

Using the AXlink four-pin connector and

external 12 VDC power supply 20

Cleaning the Touch Panel LCD 21

Touch Panel Basics.............................................................. 23

Overview 23

Touch Panel Pages 23

Standard Buttons 24

General Buttons 24

Selection buttons 24

ii Table of Contents Color Active-Matrix LCD Mini-Touch Panels

Information buttons 25

Adjustment buttons 25

Keypad buttons 25

Decision buttons 26

Status buttons 26

Operation bars 26

Designing Touch Panel Pages ............................................. 27

Overview 27

Activating the Edit Button 27

Creating a Page 31

Adding a page 31

Setting the page color 33

Creating a Button 33

Adding a button 33

Resizing a button 35

Button Properties 35

Setting the button properties 35

Setting the button type 36

Setting the button border 37

Setting the channel code 38

Setting the variable text code 39

Setting the page flip 39

Setting the button colors for

channel-off conditions 41

Adding text to a button 42

Adding an icon to a button 43

Adding a bitmap to a button 44

Using TPDesign3 to Download Bitmaps,

Icons and Fonts 45

Button Properties for External Pushbuttons 48

Creating a Joystick 48

Adding a joystick to a page 49

Setting the joystick properties 50

Setting the channel code 50

Setting the level code 51

Creating a Bargraph 52

Adding a bargraph to a page 52

Setting the bargraph properties 53

Setting the channel code 54

Setting the level code 54

Color Active-Matrix LCD Mini-Touch Panels

Table of Contents iii

Linking the New Page to the Main Page 55

Exiting Edit Mode 58

Touch Panel Program Reference ......................................... 61

Overview 61

Setup Page 61

Beep 62

Display timer 62

Set time and date 63

Double beep 64

AXlink, output resolution, vX.XX, and

serial number 64

Set brightness 64

Protected setup 65

Show palette 66

Wireless status (optional WAV-PKM) 66

Wireless status (optional SMT-PKM) 68

Protected Setup Page 69

Baud 70

Device base 70

Device used 71

Setup password 71

Mouse button 71

Power up page 73

Wake up message 73

Auto assign 73

Page password 74

Calibrate 74

Power up message 74

System page 75

Editor 78

Page tracking 78

Sleep message 79

Function show 79

Wireless settings (optional WAV-PKM) 80

Wireless settings (optional SMT-PKM) 80

Edit button 81

Edit Bar — Button Menu Options 83

Add 83

Copy image 84

Move 84

iv Table of Contents Color Active-Matrix LCD Mini-Touch Panels

Resize 84

Delete 85

Text/image 85

Properties 89

Save 98

Paste 98

Save default 98

Set default 99

Put on top 100

Properties Page — Button Types 100

General button 101

Joystick button 105

Vertical bargraph button 106

Horizontal bargraph button 108

Properties Page — External Buttons 110

External buttons 111

Setting the external button properties 114

Edit Bar — Page Menu Options 114

Add 114

Copy 115

Rename 116

Delete 116

Page color 116

Go to 117

Popup on 117

Popup off 118

Move edit 119

Snap grid 119

Edit Bar — Quit Editor option 120

AXCESS Programming ....................................................... 123

Overview 123

AXCESS Programming Changes 123

System Send_Commands 124

Video Send_Commands 129

Colors and Programming Numbers 130

Font Styles and Programming Numbers 131

Border Styles and Programming Numbers 131

Shorthand Send_Commands 131

Color Send_Commands 136

Color Active-Matrix LCD Mini-Touch Panels

Table of Contents v

Variable Text Send_Commands 138

Shorthand Variable Text Commands 140

Button String Commands 143

Replacing the Lithium Batteries......................................... 145

Overview 145

AXT-MCA (/PB) and AXT-MCV (/PB) 145

AXU-MCA (/PB), AXU-MCV (/PB), AXM-MCA (/PB),

AXM-MCV (/PB), AXD-MCA (/PB), and

AXD-MCV (/PB) 147

Upgrading from G2 to G3 Firmware................................... 149

Overview 149

Preparing the Touch Panel for Communication 149

Backing up Touch Panel Pages 152

Configuring your communications 153

Uploading the touch panel pages 154

Upgrading the Firmware 158

Replacing the EPROMs on various

TiltScreen circuit boards 158

Replacing the memory chips in

typical touch panels 160

Calibrating the Touch Panel 162

Using TPDesign3 to Convert the File 164

Using TPDesign3 to Download the File 166

Memory Upgrade................................................................ 169

Operation 169

AXT-MCA (/PB) and AXT-MCV (/PB) 169

AXU-MCA (/PB), AXU-MCV (/PB), AXM-MCA (/PB),

AXM-MCV (/PB), AXD-MCA (/PB), and

AXD-MCV (/PB) 170

Color Guidelines ................................................................. 173

Overview 173

Colors 173

vi Table of Contents Color Active-Matrix LCD Mini-Touch Panels

Specifications..................................................................... 175

Overview 175

AXT-MCA (/PB) and AXT-MCV (/PB) 175

AXU-MCA (/PB) AXU-MCV (/PB), AXD-MCA (/PB),

and AXD-MCV (/PB) 177

AXM-MCA (/PB) and AXM-MCV (/PB) 179

Contacting AMX Sales/Technical Support......................... 181

Overview 181

U.S. AMX Sales and Technical Support Teams 181

International AMX Sales and Support Teams 182

AMX Technical Support 183

AMX Technical Support BBS 184

AMX Technical Publications 184

Index.................................................................................... 185

Color Active-Matrix LCD Mini-Touch Panels

Introduction 1

Introduction

Overview

The Color Active-Matrix Mini-Touch Panels contain a 5.5" (139.70 mm) 256-color

mini-color liquid crystal display (LCD). The self-contained enclosures use a micro-

processor to control a wide range of multimedia equipment. Using the TPDesign3

Touch Panel design program, you create custom pages with buttons, icons, sliders,

bargraphs, time displays, logos, and drawings. Figure 1shows an AXD-MCV/PB

TiltScreen.

Figure 2lists the panel types and product names described in this manual.

Note

This manual describes proce-

dures and software related to

the new G3 firmware touch

panels. G3 refers to firmware

version 3.xx or higher. G2 or

lower refers to firmware ver-

sions 2.xx or lower.

Figure 1

AXD-MCV/PB TiltScreen

Note

Decor-style (AXD) touch pan-

els consist of a faceplate and

overlay that fit on top of ex-

isting panels.

2Introduction Color Active-Matrix LCD Mini-Touch Panels

Color Mini-Touch Panel types and product names

Non-Video Panels Video Panels

Panel types Standard Pushbuttons Standard Pushbuttons

Decor-style AXD-MCA AXD-MCA/PB AXD-MCV AXD-MCV/PB

TiltScreen AXT-MCA AXT-MCA/PB AXT-MCV AXT-MCV/PB

Rack-mount AXM-MCA AXM-MCA/PB AXM-MCV AXM-MCV/PB

UniMount AXU-MCA AXU-MCA/PB AXU-MCV AXU-MCV/PB

Features

The touch panel features include:

•5.5" (139.70 mm) diagonal display — 3.05" x 4.06" (77.5 mm x 103.1 mm)

HW LCD

•256-color active-matrix mini-touch-sensitive LCD

•320 x 240 pixel (HV) screen resolution

•512 KB of base memory

•An angle-adjustable TiltScreen panel for personal viewing convenience

•Decor-style touch panels provide a secured faceplate to prevent tamper-

ing

•12 programmable pushbuttons (six on each side)

•512 KB of memory

•Microsoft®mouse compatible (UniMount and rack-mount models)

•Panel programming, pages, and drawings are uploaded and downloaded

using TPDesign (Windows®) 16-bit or TPDesign3 (Windows) 32-bit touch

panel design programs

•PAL- , SECAM-, and NTSC- compatible video input port (optional)

•Internal four-pin header for mouse control (UniMount and rack-mount

models only)

•Unicode®character support for far-eastern languages such as Chinese

Figure 2

Color Mini-Touch Panel types

and product names

Note

TPDesign3 is used to convert

G2 or lower panel pages into

G3 firmware pages.

Note

Characters for middle-eastern

languages such as Arabic are

not supported within the

Unicode fonts because they

are bi-directional. Buttons

with Unicode fonts can only

be created and edited using

TPDesign3 Touch Panel De-

sign Program.

Otros manuales para Color Active-Matrix LCD

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Panel táctil de AMX

AMX

AMX D-1901-PAN Manual de lista de piezas

AMX

AMX Modero NXD-1200V Manual de usuario

AMX

AMX Modero ViewPoint MVP-7500 Manual de lista de piezas

AMX

AMX Modero Viewpoint MVP-5200i Manual de usuario

AMX

AMX AXU-LC Guía

AMX

AMX NXD-435 Manual de usuario

AMX

AMX AXU-MLC Guía

AMX

AMX Modero NXD-1200VG Manual de usuario

AMX

AMX 10.4 TOUCH PANELS (G3 FIRMWARE) Manual de usuario

AMX

AMX AXD-CV6 Manual de usuario

AMX

AMX AXT-CP Manual de usuario

AMX

AMX Modero NXD-1200VG Manual de lista de piezas

AMX

AMX Electroluminescent LCD Touch Panels Manual de usuario

AMX

AMX MXT-1000 Manual de lista de piezas

AMX

AMX Modero NXT-CV7 Instrucciones de uso

AMX

AMX Modero G5 Manual de usuario

AMX

AMX Modero ViewPoint MVP-7500 Manual de lista de piezas

AMX

AMX AXT-CV Guía

AMX

AMX AXB-TPI/3 Manual de usuario

AMX

AMX modero NXD-CV10 Manual de lista de piezas

AMX

AMX Modero X Series Instrucciones de funcionamiento y mantenimiento

AMX

AMX MXD-1900L-PAN Manual de usuario

AMX

AMX MVP-8400ii Manual de lista de piezas

AMX

AMX Modero ViewPoint MVP-5100 Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

Sartorius

Sartorius X3 PR 5410 Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario

B&R Industries

B&R Industries MAPPC900-ENG Manual de usuario

FEC

FEC PP-9635 Manual de usuario
