Amica KH 17285-3 E Manual de usuario

IO-HOO-0686/3

(03.2022)

Kitchen extractor hood / kaminhaube /

kuchyňského odsavače / kuchynského odsávača

/ Hotte aspirante / Afzuigkap / Kuhinjska napa /

Kuhinjska napa

KH 17285-3 E / KH 17286-3 E /

KH 17802-1 E / KH 17801-1 E /

KH 17803 S / KH 17804 S /

KH 17285 S / KH 17286 S

OPERATING INSTRUCTIONS EN

GEBRAUCHSANWEISUNG DE

NÁVOD K OBSLUZE CS

NÁVOD NA OBSLUHU SK

NOTICE D’UTILISATION FR

GEBRUIKSAANWIJZING NL

UPUTE ZA UPORABU HR

NAVODILA ZA UPORABO SL

- 3 -

NOTES ON SAFETY 7

UNPACKING 10

DISPOSAL OF OLD APPLIANCE 10

OPERATION 11

KITCHEN HOOD CONTROLS 11

OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 12

CLEANING AND MAINTENANCE 13

MAINTENANCE 13

GREASE FILTER 13

ACTIVATED CHARCOAL FILTER 13

LIGHT 13

WARRANTY AND AFTER SALES SERVICE 14

WARRANTY 14

SICHERHEITSHINWEISE 16

AUSPACKEN 20

ENTSORGUNG VON ALTGERÄTEN 20

BEDIENUNG 21

STEUERUNG DER DUNSTABZUGSHAUBE 21

ANDERE WICHTIGE INFORMATIONEN ZUR BEDIENUNG DER DUNSTABZUGSHAUBE 22

REINIGUNG UND WARTUNG 22

WARTUNG 22

FETTFILTER 23

AKTIVKOHLEFILTER 23

BELEUCHTUNG 23

GARANTIE, NACHVERKAUF-SERVICE 24

GARANTIE 24

EN- Table of contents

DE- Inhaltsverzeichnis

BEZPEČNOSTNÍ POKYNY 26

VYBALENÍ 29

LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 29

OBSLUHA 30

OVLÁDÁNÍ ODSAVAČE 30

JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 31

ČIŠTĚNÍ A ÚDRŽBA 32

ÚDRŽBA 32

PROTITUKOVÝ FILTR 32

UHLÍKOVÝ FILTR 32

OSVĚTLENÍ 32

ZÁRUKA, POPRODEJNÍ SERVIS 33

ZÁRUKA 33

CS- Obsah

- 4 -

BEZPEČNOSTNÉ POKYNY POUŽÍVANIA 35

ROZBALENIE 39

LIKVIDÁCIA ZARIADENÍ 39

OBSLUHA 40

OVLÁDANIE ODSÁVAČA 40

INÉ DÔLEŽITÉ INFORMÁCIE TÝKAJÚCE SA POUŽÍVANIA ODSÁVAČA 41

ČISTENIE A ÚDRŽBA 42

KONZERVÁCIA 42

PROTITUKOVÝ FILTER 42

UHLÍKOVÝ FILTER 42

OSVETLENIE 42

ZÁRUKA, POPREDAJNÝ SERVIS 43

ZÁRUKA 43

INDICATIONS CONCERNANT LA SÉCURITÉ D'UTILISATION 45

DÉBALLAGE 49

ÉLIMINATION DES APPAREILS USAGÉS 49

UTILISATION 50

COMMANDE DE LA HOTTE 50

AUTRES INFORMATIONS IMPORTANTES RELATIVES À L’UTILISATION DE LA HOTTE 51

NETTOYAGE ET ENTRETIEN 52

ENTRETIEN 52

FILTRE À GRAISSE 52

FILTRE À CHARBON 52

ÉCLAIRAGE 52

GARANTIE, SERVICE APRÈS-VENTE 53

GARANTIE 53

AANWIJZINGEN VOOR VEILIG GEBRUIK 55

UITPAKKEN 59

VERWIJDERING VAN GEBRUIKTE APPARATUUR 59

BEDIENING 60

BEDIENING VAN DE AFZUIGKAP 60

ANDERE BELANGRIJK INFORMATIE OVER DE BEDIENING VAN DE AFZUIGKAP 61

REINIGING EN ONDERHOUD 62

ONDERHOUD 62

ANTIVETFILTER 62

ACTIEVE KOOLFILTER 62

VERLICHTING 62

GARANTIE, SERVICE 63

GARANTIE 63

SK- Obsah

FR- Table des matières

NL- Inhoudsopgave

- 5 -

HR- Kazalo

SL- Sadržaj

SIGURNOSNE NAPOMENE 65

UKLANJANJE PAKIRANJA 68

ZBRINJAVANJE POTROŠENIH UREĐAJA 68

UPORABA 69

UPRAVLJANJE NAPOM 69

OSTALE VAŽNE INFORMACIJE O UPORABI NAPE 70

ČIŠĆENJE I ODRŽAVANJE 71

ODRŽAVANJE 71

FILTER PROTIV MASNOĆE 71

UGLJENI FILTER 71

RASVJETA 71

JAMSTVO, POSLIJEPRODAJNE AKTIVNOSTI 72

JAMSTVO 72

NAVODILA ZA ZAGOTAVLJANJE VARNOSTI UPORABE 74

RAZPAKIRANJE 77

ODSTRANJEVANJE IZRABLJENIH NAPRAV 77

UPORABA 78

UPRAVLJANJE S KUHINJSKO NAPO 78

DRUGE POMEMBNE INFORMACIJE GLEDE NAVODIL ZA UPORABO NAPE 79

ČIŠČENJE IN VZDRŽEVANJE 80

VZDRŽEVANJE 80

MAŠČOBNI FILTER 80

OGLENI FILTER 80

OSVETLITEV 80

GARANCIJA, POPRODAJNE STORITVE 81

GARANCIJA 81

- 6 -

Dear customer,

From now on, your daily housework will be easier

than ever before. Your appliance is excepon-

ally easy to use and extremely ecient. Aer reading

these Operang Instrucons, operang the appliance

will be easy.

Before being packaged and leaving the manufacturer,

the appliance was thoroughly checked with regard to

safety and funconality.

Before using the appliance, please carefully read

these Operang Instrucons. By following these

instrucons carefully you will be able to avoid any

problems in using the appliance. It is important to

keep these Operang Instrucons and store them in a

safe place so that they can be consulted at any me.

Follow these instrucons carefully in order to avoid

possible accidents.

Sincerely,

- 6 -

NOTES ON SAFETY

• Before using the appliance, please carefully read

this manual!

• The appliance is designed for household use only.

• The manufacturer reserves the right to introduce

changes, which do not aect operation of the ap-

pliance.

• The manufacturer shall not be liable for any dam-

age or re caused by the appliance resulting from

failure to follow instructions in this manual.

• Cooker hood is designed to remove cooking

odours. Do not use cooker hood for other pur-

poses.

• Connect the cooker hood operating in extraction

mode to a suitable ventilation duct (do NOT con-

nect the cooker to smoke or ue gas ducts, which

are in use). It requires installation of the air ex-

traction duct to the outside. The length of the

duct (usually a pipe of Ø 120 or 150 mm) should

not be longer than 4-5 m. An air extraction duct

is also required for telescopic and furniture hoods

in absorption mode.

• Cooker hood operating in air recirculation mode

requires the installation of an activated charcoal

lter. In this case, installing an extractor duct is

not required, however it is recommended to in-

stall an air guide vane (Mainly in chimney cooker

hoods).

• The cooker hood features independent lighting

and exhaust fan that can be operated at one of

several speeds.

• Depending on the type, the hood is designed to

be permanently attached to a vertical wall over

a gas or electric stove (chimney and universal

hoods); on the ceiling over a gas or electric stove

(island hoods); on the vertical built in furniture

over a gas or electric stove (telescopic and built-

in hoods). Before installing, make sure that the

- 7 -

wall/ceiling structure is strong enough to suspend

the hood. Some hoods are very heavy.

• For details of the installation distance above an

electric hob please refer to product technical

sheet If the installation instructions of the gas

cooker specify a greater distance, this must be

taken into account (Fig. 1).

• Do not leave an open ame under the hood.

When the pots are removed from the burner, set

the minimum ame. Always make sure that the

ame does not extend outside the pot, because it

causes unwanted loss of energy and a dangerous

concentration of heat.

• When cooking on fat, supervise the pans con-

stantly, because overheated fat can ignite.

• Unplug the appliance before any cleaning, replac-

ing the lter or repair work.

• Cooker hood grease lter should be cleaned at

least once a month, because the lter saturated

with fat is ammable.

• Ensure adequate ventilation (air ow) if other

equipment such as liquid fuel stoves or heaters

are operated in the room in addition the cooker

hood. When the cooker hood is simultaneously

operated with burning appliances requiring ade-

quate fresh air from the room to work properly,

their safe operation is possible if under pressure

around these appliances is a maximum of 0.004

mbar (this does not apply when the cooker hood

is used as an odour lter)

• Do not lean on the hood.

• The hood should be cleaned regularly both inside

and out (AT LEAST ONCE A MONTH, following the

indications concerning maintenance provided in

this manual)..Failure to adhere to the rules con-

cerning cleaning the hood and replacing lters

results in a re risk.

• If the power cord is damaged it should be re-

placed by a specialised service centre.

• Ensure that it is possible to disconnect the ap-

- 8 -

pliance from the mains by removing the plug or

switching o the bi-polar switch.

• This appliance is not intended for use by persons

(including children) with physical, mental or sen-

sory handicaps, or by persons inexperienced or

unfamiliar with the appliance, unless under su-

pervision or in accordance with the instructions

as communicated to them by persons responsible

for their safety.

• Particular attention should be paid not to allow

unaccompanied children to use the appliance.

• Make sure voltage indicated on the nameplate

corresponds to the local mains supply voltage.

• Before use, extend and straighten the power cord.

• Packaging materials (bags, polyethylene, poly-

styrene, etc.) should be kept away from children

during unpacking.

• Before connecting the hood to the mains power

supply always check that the power cord is prop-

erly installed and is not trapped by the appliance.

Do not connect the appliance to the mains until

assembly is complete.

• Do not operate your kitchen hood without the al-

uminium grease lters.

• It is strictly forbidden to cook dishes under on an

open ame (ambé) under your kitchen hood.

• Always strictly adhere to regulations issued by the

competent local authorities regarding the techni-

cal and safety requirements for fume extraction.

• Failing to tighten bolts and fasteners in accord-

ance with these instructions may endanger life

and health.

• Hanging kitchen hoods operate only in air circu-

lation / odour absorber mode

• WARNING! Failure to install the screws or xing

device in accordance with these instructions may

result in electrical hazards.

- 9 -

UNPACKING

During transportation, protective

packaging was used to protect the

appliance against any damage. Af-

ter unpacking, please dispose of all

elements of packaging in a way that

will not cause damage to the environ-

ment.

All materials used for packaging the

appliance are environmentally friendly; they are

100% recyclable and are marked with the appropri-

ate symbol.

Important! Packaging materials (bags, polyethyl-

ene, polystyrene, etc.) should be kept away from

children during unpacking.

DISPOSAL OF OLD APPLIANCE

In accordance with European Directive

2012/19/EU and local legislation re-

garding used electrical and electronic

goods, this appliance is marked with

the symbol of the crossed-out waste

container. This marking indicates that

the appliance must not be disposed of

together with other household waste

after it has been used.

The user is obliged to hand it over to waste collec-

tion centre collecting used electrical and electron-

ic goods. The collectors, including local collection

points, shops and local authority departments pro-

vide recycling schemes.

Proper handling of used electrical and electronic

goods helps avoid environmental and health haz-

ards resulting from the presence of dangerous com-

ponents and the inappropriate storage and process-

ing of such goods.

Este manual sirve para los siguientes modelos

Tabla de contenidos

Idiomas:

Otros manuales de Campana de ventilación de Amica

Amica

Amica OKP6651S Manual de usuario

Amica

Amica OKM6244S Manual de usuario

Amica

Amica OKC656SW Manual de usuario

Amica

Amica KH 17382 E Manual de usuario

Amica

Amica OKC5111MW Manual de usuario

Amica

Amica ST Series Manual de usuario

Amica

Amica OMC5651B HC Manual de usuario

Amica

Amica OWS 952 T Manual de usuario

Amica

Amica SIO 655 Series Manual de usuario

Amica

Amica KHF 685 650 S Manual de usuario

Amica

Amica KH27017E Manual de usuario

Amica

Amica OKC 6462 I Manual de usuario

Amica

Amica KH 17117 E Manual de usuario

Amica

Amica OWC 952 G Manual de usuario

Amica

Amica OSC 6468 W Instrucciones de funcionamiento

Amica

Amica OKC954T Manual de usuario

Amica

Amica OWC4241BO Manual de usuario

Amica

Amica OMP6241BI Manual de usuario

Amica

Amica OKP931G Manual de usuario

Amica

Amica OTP6241I Manual de usuario

Amica

Amica OKM6652IS Manual de usuario

Amica

Amica ST 63 CW Manual de usuario

Amica

Amica OME6115I Manual de usuario

Amica

Amica OMP6252BG Manual de usuario

Manuales populares de Campana de ventilación de otras marcas

emmeti

emmeti RECUPA MED A-140 Guía

Nibe

Nibe F135 Manual de usuario

Kuppersberg

Kuppersberg INTRO 60 Instrucciones de instalación y mantenimiento

Zephyr

Zephyr Spruce AK9834BS Guía de instalación

Hisense

Hisense MH6INBG Manual de usuario

Miele

Miele DA 1255 Manual de usuario

Broan

Broan 46000 Manual de usuario

GE Profile PV977 Instrucciones originales

FALMEC

FALMEC FFRIA24W5FS Manual de usuario

Whirlpool

Whirlpool RH2600XL-1 SERIES Manual de usuario

Küppersbusch

Küppersbusch DX ISLA Manual de usuario

ETNA

ETNA AV360RVS Manual de usuario

JUNO

JUNO JDF603E6 Manual de usuario

Miele

Miele DA 6708 D Manual de usuario

Tricity Bendix

Tricity Bendix LE 150 Manual

AEG

AEG X68163BV1 Manual de usuario

AEG

AEG 125 D Manual de usuario

Smeg

Smeg KSEV97X Manual de usuario
