Amica 507CE2.316EHMsG(W) Manual de usuario

INSTRUCTION MANUAL

ELECTRIC COOKER

IOAK-2422 / 8054082

(05.2013./1)

507CE2.316EHMsG(W)

DEAR CUSTOMER,

The cooker is exceptionally easy to use and extremely efcient. After reading the instruction

manual, operating the cooker will be easy.

Before being packaged and leaving the manufacturer, the cooker was thoroughly checked

with regard to safety and functionality.

Before using the appliance, please read the instruction manual carefully.

By following these instructions carefully you will be able to avoid any problems in using the

appliance.

It is important to keep the instruction manual and store it in a safe place so that it can be

consulted at any time.

It is necessary to follow the instructions in the manual carefully in order to avoid possible

accidents.

Caution!

Do not use the cooker until you have read this instruction manual.

The cooker is intended for household use only.

The manufacturer reserves the right to introduce changes which do not affect the

operation of the appliance.

TABLE OF CONTENTS

Safety instructions ............................................................................................................. 4

Description of the appliance ............................................................................................. 9

Installation..........................................................................................................................11

Operation........................................................................................................................... 13

Baking in the oven – practical hints ............................................................................... 19

Cleaning and maintenance.............................................................................................. 21

Technical data................................................................................................................... 26

SAFETY INSTRUCTIONS

Warning: The appliance and its accessible parts

become hot during use. Care should be taken to

avoid touching heating elements. Children less than 8

years of age shall be kept away unless continuously

supervised.

This appliance can be used by children aged from 8

years and above and persons with reduced physical,

sensory or mental capabilities or lack of experience

and knowledge if they have been given supervision or

instruction concerning use of the appliance in a safe

way and understand the hazards involved. Children

shall not play with the appliance. Cleaning and user

maintenance shall not be made by children without

supervision.

Warning: Unattended cooking on a hob with fat or

oil can be dangerous and may result in re.

NEVER try to extinguish a re with water, but switch

off the appliance and then cover ame e.g. with a lid

or a re blanket.

Warning: Danger of re: do not store items on the

cooking surfaces.

SAFETY INSTRUCTIONS

Warning: If the surface is cracked, switch off the ap-

pliance to avoid the possibillity of electric shock.

During use the appliance becomes hot. Care should

be taken to avoid touching heating elements inside

the oven.

Accessible parts may become hot during use. Young

children should be kept away.

Warning: Do not use harsh abrasive cleaners or

sharp metal scrapers to clean the oven door glass

since they can scratch the surface, which may result

in shattering of the glass.

Warning: Ensure that the appliance is switched off

before replacing the lamp to avoid the possibillity of

electric shock.

You should not use steam cleaning devices to clean

the appliance.

SAFETY INSTRUCTIONS

Always keep children away from the cooker.

While in operation direct contact with the cooker may cause burns!

Ensure that small items of household equipment, including connection leads, do not touch

the hot oven or the hob as the insulation material of this equipment is usually not resistant

to high temperatures.

 Do not leave the cooker unattended when frying. Oils and fats may catch re due to

overheating or boiling over.

Do not allow the hob to get soiled and prevent liquids from boiling over onto the surface

of the hob. This refers in particular to sugar which can react with the ceramic hob and

cause irreversible damage. Any spillages should be cleaned up as they happen.

Do not place pans with a wet bottom on the warmed up heating zones as this can cause

irreversible changes to the hob (irremovable stains).

 Use pans that are specied by the manufacturer as designed for use with a ceramic

hob.

If any defects, deep scratches, cracks or chips appear on the ceramic hob, stop using the

cooker immediately and contact the service centre.

Do not switch on the hob until a pan has been placed on it.

Do not use pans with sharp edges that may cause damage to the ceramic hob.

Do not look directly at the halogen heating zones (not covered by a pan) when they are

warming up.

Do not put pans weighing over 15 kg on the opened door of the oven and pans over 25

kg on the hob.

Do not use harsh cleaning agents or sharp metal objects to clean the door as they can

scratch the surface, which could then result in the glass cracking.

 Do not use the cooker in the event of a technical fault. Any faults must be xed by an

appropriately qualied and authorised person.

In the event of any incident caused by a technical fault, disconnect the power and report

the fault to the service centre to be repaired.

The rules and provisions contained in this instruction manual should be strictly observed.

Do not allow anybody who is not familiar with the contents of this instruction manual to

operate the cooker.

The appliance has been designed only for cooking. Any other use (for example for heat-

ing) does not comply with its operating prole and may cause danger.

Using energy in a respon-

sible way not only saves

money but also helps the

environment. So let’s save

energy! And this is how you

can do it:

Use proper pans for cooking.

Pans with thick, at bases can save up to 1/3

on electric energy. Remember to cover pans

if possible otherwise you will use four times

as much energy!

Match the size of the saucepan to the

surface of the heating zone.

A saucepan should never be smaller than a

heating zone.

Ensure heating zones and pan bases

are clean.

Soils can prevent heat transfer – and repeat-

edly burnt–on spillages can often only be

removed by products which cause damage

to the environment.

Do not uncover the pan too often

(a watched pot never boils!).

Do not open the oven door unnecessarily

often.

Switch off the oven in good time and make

use of residual heat.

For long cooking times, switch off heating

zones 5 to 10 minutes before nishing cook-

ing. This saves up to 20% on energy.

Only use the oven when cooking larger

dishes.

Meat of up to 1 kg can be prepared more

economically in a pan on the cooker hob.

HOW TO SAVE ENERGY

Make use of residual heat from the

oven.

If the cooking time is greater than 40 minutes

switch off the oven 10 minutes before the

end time.

Important! When using the timer,

set appropriately shorter cooking

times according to the dish being

prepared.

Only grill with the ultrafan after closing

the oven door.

Make sure the oven door is properly

closed.

Heat can leak through spillages on the door

seals. Clean up any spillages immediately.

Do not install the cooker in the direct

vicinity of refrigerators/freezers.

Otherwise energy consumption increases

unnecessarily.

During transportation, protec-

tive packaging was used to

protect the appliance against

any damage. After unpack-

ing, please dispose of all

elements of packaging in a

way that will not cause dam-

age to the environment.

All materials used for packaging the appli-

ance are environmentally friendly; they are

100% recyclable and are marked with the

appropriate symbol.

Caution! During unpacking, the packag-

ing materials (polythene bags, polystyrene

pieces, etc.) should be kept out of reach of

children.

UNPACKING DISPOSAL OF THE APPLIANCE

Old appliances should not sim-

ply be disposed of with normal

household waste, but should

be delivered to a collection and

recycling centre for electric and

electronic equipment. A symbol

shown on the product, the in-

struction manual or the packag-

ing shows that it is suitable for recycling.

Materials used inside the appliance are

recyclable and are labelled with information

concerning this. By recycling materials or

other parts from used devices you are making

a signicant contribution to the protection of

our environment.

Information on appropriate disposal centres

for used devices can be provided by your

local authority.

DESCRIPTION OF THE APPLIANCE

3, 4

5, 6

1Temperature control knob

2Oven function selection knob

3, 4, 5, 6 Heating zone control knobs

7Temperatureregulatorsignal light L

8Cooker operation signal light R

9 Oven door handle

10 Drawer

11 Ceramic hob

12 Timer

*optional

SPECIFICATIONS OF THE APPLIANCE

Cooker ttings:

Baking tray* Grill grate

(drying rack)

Roasting tray*
