AmazonBasics B07VYMS78Q Manual de usuario
Air Oven
Horno de Aire
Four à Air
B07VYMS78Q
English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Français . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
3
B(1 x)
A(1 x)
C(1 x)
D (3 x)
F(1 x)
I(1 x)
H(1 x)
E(1 x)
G(1 x)
4
EN
IMPORTANT SAFEGUARDS
Read these instructions carefully and retain them for future use.
If this product is passed to a third party, then these instructions
must be included.
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fire, electric shock, and/or injury to
persons including the following:
• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs. Use oven mitts or
potholders.
• To protect against electric shock, do not place cord, plugs, or
appliance in water or other liquid.
• Close supervision is necessary when any appliance is used by or near
children.
• Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking off parts, and before cleaning the
appliance.
• Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Return appliance to an authorized service facility for examination,
repair or adjustment.
• The use of an accessory not evaluated for use with this appliance
may cause injuries.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter, or touch hot
surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated
oven.
• Extreme caution must be used when moving an appliance containing
hot oil or other hot liquids.
• To disconnect, turn any control to “off”, then remove plug from wall
outlet.
• Do not use appliance for other than intended use.
• This product is for household use only.
• Do not immerse in water.
• Avoid contacting moving parts.
5
EN
CAUTION Risk of Electric Shock! Cook only in removable
container.
• This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electric shock, this plug will fit outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug. If it
still does not fit, contact a qualified electrician. Do not modify the plug
in any way.
• Be sure that handles are assembled and fastened properly.
• A short power-supply cord (or detachable power-supply cord) should
be used to reduce the risk resulting from becoming entangled in or
tripping over a longer cord.
• Longer detachable power-supply cords or extension cords are
available and may be used if care is exercised in their use.
• If a longer detachable power-supply cord or extension cord is used:
1) The marked electrical rating of the cord set or extension cord
should be at least as great as the electrical rating of the appliance;
2) The cord should be arranged so that it will not drape over the
countertop or tabletop where it can be pulled on by children or
tripped over unintentionally.
• If the appliance is of the grounded type, the cord set or extension
cord should be a grounding-type 3-wire cord.
• Leave at least 4" (10 cm) of space in all directions around the product
to ensure sufficient ventilation.
• To prevent food contact with the heat element, do not overfill the
rotating basket.
• When in operation, hot air is released through the air outlet on the
back of the product. Keep hands and face at a safe distance from the
air outlet. Never cover the air outlet.
CAUTION Hot surface! This logo indicates that
the marked area can be hot and should not be touched
without precautions.
SAVE THESE INSTRUCTIONS
6
EN
Intended Use
• This product is intended for preparing foods that require a high
cooking temperature and would otherwise require deep-frying.
Theproduct is intended only for preparing foods.
• This product is intended for household use only. It is not intended for
commercial use.
• This product is intended to be used in dry indoor areas only.
• No liability will be accepted for damages resulting from improper use
or non-compliance with these instructions.
Product Description
2 3
4
1
6
5
1Control panel 4Supply cord
2Air inlet 5Door with viewing window
3Air outlet 6Handle
7
EN
Control panel
14
13
8
12 11 10 9
7
Name Detail Function
7Display Display time/temperature
8
Time
+/– Increase/decrease cooking time
9Switch on/off
10 Rotation function (for accessories F/G/H)
11 Reheat (pre-set)
12 Light on/off
13 Pre-set programs
14 Temp +/– Increase/decrease temperature
Before First Use
• Check the product for transport damages.
• Remove all the packing materials.
• Place the product on a flat, stable and heat-resistant surface.
• Clean the product before first use.
• Before connecting the product to the power supply, check that the
power supply voltage and current rating corresponds with the power
supply details shown on the product rating label.
DANGER Risk of suffocation! Keep any packaging materials away
from children – these materials are a potential source of danger, e.g.
suffocation.
8
EN
Operation
Switching on/off
CAUTION Risk of burns! The product gets hot during and after
use. Do not touch hot surfaces with bare hands. Wear cooking gloves
during use.
• Connect the supply cord (4) to a polarized outlet.
• The product enters standby mode and the key(9) lights up on the
control panel(1).
• To switch the product on, tap the key (9). The control panel (1)
lights up.
• The key (13) and the key (9) are flashing.
• Tap the key (9), to start cooking with the pre-set cooking
program, or select a different program (see Pre-set programs).
• To stop cooking and switch the product off (standby), tap the
key(9) again.
NOTICE
The fan continues to work for around 20 seconds after
switching off. Do not open the door (5) and do not disconnect the supply
cord (4) from the outlet immediately.
NOTICE
The cooking stops automatically if the door (5) is opened.
Cooking resumes when the door is closed.
Pre-set programs
Key Temperature Time
French fries 400°F (200°C) 15 min
Pizza 360°F (182°C) 15 min
Roast 350°F (177°C) 5 min
Steaks/chops 350°F (177°C) 25 min
Fish 325°F (163°C) 15 min
Dehydrator 90°F (30°C) 2 hr
Chicken 370°F (185°C) 40 min
Baking 320°F (160°C) 30 min
Re-heating 240°F (115°C) 12 min
9
EN
Start cooking
CAUTION Risk of fire! Never use a cooking containers filled with
cooking oil or any other liquids.
CAUTION Risk of burns! The product gets hot during and after
use. Do not touch hot surfaces with bare hands. Wear cooking gloves
during use.
• Put the food on/inside the selected accessory and place it in the oven.
• Choose the pre-set cooking program by tapping on its icon.
• Select cooking time by tapping + or - icon (8).
• Select cooking temperature by tapping + or - icon (14).
• Tap the key (9), to start cooking.
Light
Tap the key (12) to switch the built-in light on and off.
Rotation
This function slowly rotates the rotating basket (F), skewers rack(G)
orthe rotisserie forks (H).
• Open the door (5). The light in the oven switches on.
• Press and hold the lock lever to release the shaft lock (fig. 1).
1
10
EN
• Use the handle tool (I) to place the shaft of the accessory (F, G, H)
into the center of the oven (fig. 2).
2
I
• Release the lock lever, to close the shaft lock. Make sure the shaft
lock is engaged.
• Remove the handle tool (I) from the oven.
• Close the door (5).
• To switch the rotation function on and off, tap the key (10).
• After cooking, use the handle tool (I) to remove the accessory (F, G, H).
• Press the lock lever, to open the shaft lock. Lift the handle tool (I)
andthe accessory (F, G, H) carefully out of the oven.
• Close the door (5).
Using the Accessories
Part
Name Function
B Frying basket Use to fry larger quantity of foods.
Always place on the drip tray (C)
insertedinto the lowest rail.
C Drip tray Use to collect oil and other residues during
frying process.
D Frying tray Use to dehydrate, fry crispy snacks and
reheat food.
E Rotisserie stand Use to place the accessory (F, G, H)
whenhot after cooking.
CAUTION Do not place the stand
inside the oven.
