CABINET PARTS
1
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
3−09 Litho In U.S.A. (mat) (eeb) Part No. W10268064 Rev. A
REFRIGERATOR
CABINET PARTS
2
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10175445
Owners Manual
W10183296
Energy Tag
W10238840
Tech Sheet
2 Cabinet (Not a
Servicable Part)
3 Plug, Button (3)
M0310731 Black
4 12249902 Label, Fill Tube
5 12580304 Roller Assembly
7 10351006 Pin, Center Hinge
8 12606103 Bolt, Adjusting
(Rear)
9 12992602 Screw
10 12477501 Cover, Fill Tube
11 12992201 Screw
12 12990521 Screw (8)
13 A3076901 Plug, Button
14 12992403 Screw (3)
15 Hinge, Center
12607104ED
Black
16 10354002 Foot Brake (2)
17 Cover, Corner
12587703B
Black
18
12566606ED
Hinge, Top
20 12991302 Screw (8)
21 Cover, Hinge
12477601B
Black
22 Grille Assembly
(Includes Clips)
W10236650
Black
25 12990511 Screw (9)
26
12906303WD
Bracket, Foot
27
W10217701
Cover, Water Valve
28
W10210978
Cover, Unit
29 12820505 Insulation, Sound
30
W10210987
Tube, Drain
33 B5759655 Gasket
REFRIGERATOR LINER PARTS
3
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
REFRIGERATOR LINER PARTS
4
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 12806301 Bracket, Control
and Lights
3 12816501 Overlay
4 12806406 Housing,
Electronic Control
5 12868513 Board, Control
6 C3680310 Switch, Light
7 12806501 Cover, Light
8 12806601 Housing, Light
9
W10194422V
Bulb, Light (2)
10 12570701 Socket, Light (2)
11 12806801 Insert,
Damper Cover
12 12990604 Screw (2)
13 12806701 Cover, Damper
14 13012402 Insulation
15
W10196393
Control, Damper
16 12002355 Thermistor
17 M0310343 Plug Button
Following Parts Not Illustrated
12868701 Harness, Controls
(Refrigerator)
(Includes # 16)
FREEZER LINER PARTS
5
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
FREEZER LINER PARTS
6
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Seviceable Part)
2 A3189392 Gasket, Foam (2)
3 12002497 Gear (2)
(Includes RH & LH)
4 12804901 Cover, Light
5
12812901WD
Shaft
6 12570701 Socket, Light
8 12990521 Screw (8)
9
W10194422V
Bulb, Light
10 12476401 Housing, Frz. Light
11 12226110 Cover, Evaporator
12 12990101 Screw (7)
13 Bracket, Door
W10122147
Left
W10122148
Right
14 12805001 Housing, Lighting
15 13058002 Clip, Evap. Motor
16 12466105 Switch, Light
18 Bracket, Basket
12812303 Left
12812304 Right
19
W10120018
Slide, Drawer (2)
20 A3189394 Gasket, Bottom
21 Bracket, Slide
W10128118
Left
W10128119
Right
22 13024803 Cover, Fan Shroud
23 13057901 Shroud, Evap.Fan
24 2169142 Fan, Evaporator
25
W10121318
Grommet (2)
26
W10128551
Motor, Evaporator
27 D7753903 Funnel, Drain
(Incl. # 28 & 29)
28 M0500703 Seal
29 B8381501 Gasket
30 12002355 Thermistor
31 12815301 Cover, Thermistor
32 12990501 Screw (6)
33 12991603 Screw
Following Parts Not Illustrated
13014801 Harness, Lights
(Freezer)
REFRIGERATOR DOOR PARTS
7
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
REFRIGERATOR DOOR PARTS
8
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(w/ Insulation)
Stainless Steel
W10203482
Left
W10182772
Right
3 12744905 Door, Compartment
4 12369502 Tray, Dairy
5 12557204 Bucket (2)
(Medium)
6 12528501 Nameplate
8 Gasket, Door
Magnetic
W10164031
Black
9 Handle, Door
W10159105
Stainless Steel
10 12991703 Screw
11 Closure, Door
12029505B
Black
13 Bushing
10961006B
Black
14 12557904 Retainer, Door
15 12990504 Screw
17 Stop, Door
10447112 Black
18 13001201 Mount, Handle
20 12557202 Bucket (2)
(Small)
FREEZER DOOR PARTS
9
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
FREEZER DOOR PARTS
10
For Model: ABL1922FES3, ABR1922FES3
(Stainless Steel) (Stainless Steel)
W10268064
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
(w/ Insulation)
W10174587
Stainless Steel
2 Handle, Door
W10159105
Stainless Steel
3 13001201 Mount, Handle
4 Gasket, Door
W10164033
Black
5 12991703 Screw
