Amada AMWS08 Manual de usuario
Product Specifications
Caution
Application
Ring light diameter: 6 in.(15.24cm)
Stretching range of phone holder：2.4~3.3 in.(6.0cm~8.3cm)
Input voltage: 5V
Input voltage: 2A
Load weight range: 0-0.65KG
Illumination color: white/warm white/yellow(10 brightness levels for each mode)
Color temperature: 3500K~6000K
Maximum power: 8W
Maximum height of the gooseneck: 28 in.
With mobile phone holder, camera holder, microphone holder
• Do not light up for a long time when nobody is around.
• Do not operate with wet hands when in charge.
• Do not use defective power adapter.
• Try to loop the gooseneck into “S” shape which will reduce bounce and
wobble to some extent.
• Use one hand to hold phone when operate the phone screen with the other hand.
Hold phone & webcam or phone & microphone at the same time to meet
different needs.
Applicable Mobile Phone Model
• IPhone 11, 11 Pro, 11 Pro Max, XS Max, XS, XR, X, 8 Plus, 8, 7 Plus, 7,
6S Plus, 6S, SE
• Samsung Galaxy S10e, S10+, S10, S9+, S9, S8+, S8, S7 Edge, Note 9, 8, 7, M20,
J3 Pro, J3, E5, Core Max, C9 Pro, C8, C7 Pro, C7, C5 Pro, C5, A9s, A9 Star, A9,
A8s, A8, A70, A7, A6s, A60, A50, A40S, A10 Other phone model with 2.2-3.4inch
width or length
Applicable Webcam Model
• Logitech C922x C922 C930e C930 C920 C615 C930e C930 C925e; Logitech
- Brio 4K;
• Microsoft LifeCam Studio 1080p HD Webcam;
• NetGear Arlo,Arlo pro,Arlo go Security camera;
• Any Webcam with standard 1/4" screw hole;
• GoPro Hero 8/7/6/5/4/3+/3/2/1/Session; Ricoh Theta S/V, M15;
• Garmin Virb,Sony SJCAM, Xiaomi Yi,Compact Cameras(1/4"thread)
V1.0
Ring Light Stand
Instruction Manual
Model:AMWS08
Thank you for choosing this AMADA product! At AMADA we strive to provide you
with the best quality products and services in the industry. Should you have any
issues, please don't hesitate to contact at [email protected] (US/CA)
x1
Supplied Parts
Light mode switch
Brightness-
On/Off Button
Brightness+
01 02
x1
Step 1
Step 2
360 Degrees
Rotatable Ball
Option A
Option B
Microphone
(Not included)
Webcam
(Not included)
1/4" screw
Loosen
Tighten
Note: The head adaptor fits
any webcams with standard
1/4" screw hole.
MAX: 2.8 in.(7.1cm)
Or
2.4~3.3 in.
(6cm~8.3cm)
