• INSTALLATION

W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 USA

PHONE: 262.251.3800 • 800.558.8744 USA/CANADA FAX: 262.251.7067 • 800.329.8744 U.S.A. ONLY

WWW.ALTO-SHAAM.COM

PRINTED IN U.S.A. MN-29246 • 10/10

Delivery.......................................................................... 1

Unpacking ..................................................................... 1

Safety Procedures and Precautions.............................. 2

Installation

Installation Codes and Standards............................. 3

Ventilation Requirements ........................................... 3

Positioning on Site .................................................... 4

Positioning Requirements ......................................... 5

Stand Installation ...................................................... 5

Common Specications............................................ 6

Specications, 6•10esG ............................................ 7

Specications, 10•10esG .......................................... 8

Specications, 7•14esG ........................................... 9

Specications, 10•20esG ........................................ 10

Specications, 12•18esG ........................................ 11

Specications, 20•20esG ........................................ 12

Electrical Connection ............................................... 13

Mobile Equipment Restraint..................................... 14

Ventilation Requirements ......................................... 15

Gas Supply & Installation ......................................... 16

Gas Leak Testing...................................................... 19

Gas Exhaust............................................................. 19

Water Quality Requirements .................................... 20

Water Supply & Installation ...................................... 21

Water Valve .............................................................. 22

Water Drainage......................................................... 22

CombiTouch Checklist ............................................ 23

Error Codes ............................................................. 24

Warranty

Original Equipment Limited Warranty ...................... 30

Transportation Damage and Claims......................... 31

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 1.

THE INFORMATION CONTAINED IN THIS

MANUAL IS IMPORTANT FOR THE PROPER

INSTALLATION OF THIS OVEN. PLEASE READ

CAREFULLY AND RETAIN FOR

FUTURE REFERENCE.

IMPROPER CONNECTION OF THIS APPLIANCE

WILL NULLIFY ALL WARRANTIES.

LES INFORMATIONS CONTENUES DANS CE

MANUEL SONT IMPORTANTES POUR UNE

INSTALLATION CORRECTE DE CE FOUR.

PRIÈRE DE LE LIRE ATTENTIVEMENT ET DE

LE CONSERVER POUR POUVOIR S’Y RÉFÉRER

À L’AVENIR.

UN BRANCHEMENT INCORRECT DE

CET APPAREIL ANNULERA TOUTES LES

GARANTIES.

DELIVERY

This Alto-Shaam appliance has been

thoroughly tested and inspected to ensure only

the highest quality unit is provided. Upon

receipt, check for any possible shipping damage

and report it at once to the delivering carrier.

See Transportation Damage and Claims section

located in this manual.

This appliance, complete with unattached

items and accessories, may have been delivered

in one or more packages. Check to ensure that all

standard items and options have been received

with each model as ordered.

Save all the information and instructions

packed with the appliance. Complete and return

the warranty card to the factory as soon as

possible to ensure prompt service in the event of a

warranty parts and labor claim.

This manual must be read and understood

by all people using or installing the equipment

model. Contact the Alto-Shaam Tech Team Service

Department if you have any questions concerning

installation, operation, or maintenance.

NOTE: All claims for warranty must include the

full model number and serial number of

the unit.

UNPACKING

1. Carefully remove the

appliance from the

carton or crate.

NOTE: Do not discard the

carton and other

packaging material

until you have

inspected the unit

for hidden damage

and tested it for

proper operation.

2. Read all instructions in this manual carefully

before initiating the installation of this appliance.

DO NOT DISCARD THIS MANUAL.

This manual is considered to be part of the

appliance and is to be provided to the owner

or manager of the business or to the person

responsible for training operators. Additional

manuals are available from the Alto-Shaam

Tech Team Service Department.

3. Remove all protective plastic film, packaging

materials, and accessories from the appliance

before connecting electrical power. Store any

accessories in a convenient place for future use.

CAUTION

TO PREVENT PERSONAL INJURY,

USE CAUTION WHEN MOVING OR

LEVELING THIS APPLIANCE.

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 2.

CAUTION

Used to indicate the presence of a hazard that

can or will cause minor personal injury, property

damage, or a potential unsafe practice if the

warning included with this symbol is ignored.

CAUTION

Used to indicate the presence of a

hazard that can or will cause minor or

moderate personal injury or property

damage if the warning included with

this symbol is ignored.

DANGER

Used to indicate the presence of

a hazard that WILL cause severe

personal injury, death, or substantial

property damage if the warning

included with this symbol is ignored.

WARNING

Used to indicate the presence of

a hazard that CAN cause personal

injury, possible death, or major

property damage if the warning

included with this symbol is ignored.

1. This appliance is intended to cook, hold

or process foods for the purpose of human

consumption. No other use for this appliance is

authorized or recommended.

2. This appliance is intended for use in commercial

establishments where all operators are

familiar with the purpose, limitations, and

associated hazards of this appliance. Operating

instructions and warnings must be read and

understood by all operators and users.

3. Any troubleshooting guides, component views,

and parts lists included in this manual are for

general reference only and are intended for use

by qualified technical personnel.

4. This manual should be considered a permanent

part of this appliance. This manual and all

supplied instructions, diagrams, schematics,

parts lists, notices, and labels must remain with

the appliance if the item is sold or moved to

another location.

NOTE: Used to notify personnel of

installation, operation, or

maintenance information that is

important but not hazard related.

SAFETY PROCEDURES

AND PRECAUTIONS

Knowledge of proper procedures is essential to the

safe operation of electrically and/or gas energized

equipment. In accordance with generally accepted

product safety labeling guidelines for potential

hazards, the following signal words and symbols

may be used throughout this manual.

CAUTION

WHEN WELDING ANY STAINLESS

STEEL COMPONENTS ON THIS

APPLIANCE,THE ELECTRONIC

CONTROL BOARDS MUST BE

ISOLATED FROM THE APPLIANCE.

NOTE

For equipment delivered for use

in any location regulated by the

following directive:

DO NOT DISPOSE OF ELECTRICAL

OR ELECTRONIC EQUIPMENT WITH

OTHER MUNICIPAL WASTE.

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 3.

INSTALLATION

SITE INSTALLATION

INSTALLATION CODES & STANDARDS

The following codes and standards are required for

installation of this oven:

AIR SUPPLY, ELECTRICAL CONNECTIONS,

WATER CONNECTIONS, AND WASTE WATER

DISCHARGE.

Installation must comply with local codes required

for gas appliances. In the absence of local codes,

installation must comply with the National Fuel

Gas Code, ANSI Z223.1 (latest edition). In Canada,

the appropriate code is the Natural Gas Installation

Code, CAN/CGA-B149.1 or the Propane Installation

Code, CAN/CGA-B. Adherence to code by a

qualified installer is essential for the following: Gas

Plumbing, Gas Appliance Installation, Commercial

Cooking Ventilation, Water and Plumbing, and

OSHA Regulations.

VENTILATION REQUIREMENTS

A steam ventilation hood is mandatory for the

operation of the oven. The ventilation hood must

be installed in accordance with local building codes

for the steam exhaust and must protrude 12-inches

to 20-inches (300 to 500mm) over the front side

of the oven. A grease filter must be located in the

protruding area of the hood. Grease filters should

be thoroughly cleaned on a regular basis following

manufacturer’s instruction. Ventilation hoods must

ensure an adequate amount of incoming air during

operation and must be operated whenever the

combination oven/steamer is used in order to avoid

the accumulation of condensation in the hood area.

See the section titled Gas Exhaust.

NOTE: Note dimensions required for doorways

and aisles for access of the oven and pallet

to the installation site. Transport the oven

in an upright and level position only. Do

not tilt the oven.

CAUTION

THE OVEN MUST REMAIN ON THE

PALLET WHILE BEING MOVED TO THE

INSTALLATION SITE BY FORK LIFT OR

PALLET LIFT TRUCK.

DANGER

IMPROPER INSTALLATION,

ALTERATION, ADJUSTMENT,

SERVICE, OR MAINTENANCE COULD

RESULT IN SEVERE INJURY, DEATH,

OR CAUSE PROPERTY DAMAGE.

READ THE INSTALLATION,

OPERATING AND MAINTENANCE

INSTRUCTIONS THOROUGHLY

BEFORE INSTALLING OR SERVICING

THIS EQUIPMENT.

DANGER

AVERTISSEMENT : UNE INSTALLATION,

UN AJUSTEMENT, UNE ALTÉRATION,

UN SERVICE OU UN ENTRETIEN NON

CONFORME AUX NORMES PEUT CAUSER

DES DOMMAGES À LA PROPRIÉTÉ, DES

BLESSURES OU LA MORT.

LIRE ATTENTIVEMENT LES DIRECTIVES

D’OPÉRATION ET D’ENTRETIEN

AVANT DE FAIRE L’INSTALLATION, OU

L’ENTRETIEN DE CET ÉQUIPEMENT.

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 4.

MINIMUM CLEARANCE REQUIREMENTS

LEFT SIDE 6” (152mm) MINIMUM

18” (457mm) SERVICE ACCESS RECOMMENDED

20” (508mm) FROM HEAT PRODUCING EQUIPMENT

RIGHT SIDE 4” (102mm)

BACK 4” (102mm) FOR PLUMBING

TOP 20” (508mm) FOR AIR MOVEMENT

BOTTOM 20” (508mm) FOR AIR MOVEMENT

NOTE: Additional clearance is needed for service

access. A minimum distance of 18-inches

is strongly recommended. If adequate

service clearance is not provided, it will be

necessary to disconnect the gas, water, and

drain to move the oven with a fork lift for

service access. Charges in connection with

inadequate service access is not covered

under warranty.

INSTALLATION

SITE INSTALLATION

POSITIONING ON SITE

Lift the oven from the pallet with a fork lift or pallet

lift truck positioned at the front of the oven. For

damage protection, the use of two wooden boards,

placed between the bottom of the oven and the lifting

forks, is strongly recommended. To avoid damage,

position the lift forks to the left of the condenser

and right of the right leg as indicated in the diagram

above.

Stand the oven in a level position. Use the adjustable

feet to overcome an uneven floor and ensure that the

unit is level.

It is strongly recommended that table top models be

mounted on a factory supplied stand or a stand that

is stable, open, and level. Recommended height is

23-inches (584mm).

Adjust the height of floor models for smooth access

of the trolley or cart. When positioning the oven,

observe the minimum space allocation requirements

shown.

To insure proper operation, the installation of this

oven must be completed by qualified technicians in

accordance with the instructions provided in this

manual. Failure to follow the instructions provided

may result in damage to the oven, building, or cause

personal injury to personnel.

NOTE: To avoid equipment damage, observe

attention label on oven for area to avoid

with lifting fork.

CAUTION

TO PREVENT PERSONAL INJURY,

USE CAUTION WHEN MOVING OR

LEVELING THIS APPLIANCE.

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 5.

INSTALLATION

SITE INSTALLATION

POSITIONING REQUIREMENTS

qIn order to ensure proper ventilation, a minimum

distance of at least 6-inches (152mm) must be kept

from the control panels side (left) of the oven and

any adjoining surfaces.

NOTE: Additional clearance is needed for service

access. A minimum distance of 18-inches is strongly

recommended. If adequate service clearance is not

provided, it will be necessary to disconnect the gas,

water, and drain to move the oven with a fork lift for

service access. Charges in connection with inadequate

service access is not covered under warranty.

q Allow a minimum of 4-inches (102mm) from the

right side of the oven to allow the door to open to at

least a 90° angle. Fully opened, the door will extend

up to a 225° angle If the oven is furnished with the

retractable door option, allow a minimum clearance

of 6-1/2 inches (165mm).

q Allow a minimum clearance of 4-inches (102mm)

from the back of the oven for plumbing connections.

qAllow a 20-inch (500mm) clearance at the top of

the oven for free air movement and for the steam

vent(s) located at the top.

qDo not install the oven adjacent to heat producing

equipment such as fryers, broilers, etc. Heat

from such appliances may cause damage to the

controls of the Combitherm. Minimum clearance

recommended: 20-inches (500mm)

Place the Combitherm oven on a stable, non-

combustible level horizontal surface. For countertop

models, the oven stand must be level. Level from front-

to-back and side-to-side by means of the adjustable

legs. In addition, the overall height of the oven should

be positioned so the operating controls and shelves may

be conveniently reached from the front.

When placing a countertop

model on an oven

stand, position the oven

legs on the outside of

the positioning pins.

RETRACTABLE DOOR

OPTION:

6-1/2” (165 mm)

Positioning

Pins

Positioning

Pins

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 6.

INSTALLATION

COMMON SPECIFICATIONS

q CombiGuard™ BWS Blended Water System FI-28727

(INCLUDES 50 GALLON TANK, 1 MEMBRANE & 3 FILTERS)

qCombiGuard™ BWS Replacement Filter

Cartridge AMS-QT FI-29316

qCombiGuard™ BWS Replacement Filter

Cartridge SCLX2-Q FI-29317

qCombiGuard™ BWS Replacement Prefilter

Filter Cartridge CTO-Q FI-29318

CombiGuard™ Triple-Guard Water Filtration System

(INCLUDES 1 CARTRIDGE)

q 6•10, 10•10, 7•14 (CombiGuard™ 10) FI-23014

q 10•20, 12•18, 20•20 (CombiGuard™ 20) FI-28728

CombiGuard™ Triple-Guard Replacement Filter

q 6•10, 10•10, 7•14 (CombiGuard™ 10) FI-26356

q 10•20, 12•18, 20•20 (CombiGuard™ 20) FI-28744

q Fry Basket, 12” X 20” (325mm x 530mm) BS-26730

q Grilling Grate, 12” X 20” (325mm x 530mm) SH-26731

Shelf, Stainless Steel Wire

q 6•10, 10•10 SH-2903

q 7•14, 12•18 SH-22584

q 10•20, 20•20 SH-22473

q Probe, Sous Vide PR-34747

q Combitherm Cleaning Liquid — CE-24750

SPECIALLY FORMULATED FOR COMBITHERM OVENS

➥TWELVE (12) CONTAINERS/CASE, 1 QUART (C. 1 LITER) EACH

q Combiclean™ Tablets — CE-28892

SPECIALLY FORMULATED FOR COMBITHERM OVENS

➥ 90 PACKETS EACH CONTAINER

q Scale Free™ CE-27889

(CITRUS BASED, NON-CORROSIVE DELIMING PRODUCT)

CASE = FOUR 4-LB BOTTLES; 4-LB BOTTLE MAKES 10 GALLONS

qService Start-Up Check SPECIFY AS REQUIRED

AVAILABLE THROUGH AN ALTO-SHAAM FASTEAM CENTER

Ten (10) Chicken Roasting Rack

SH-22634

Six (6) Chicken Roasting Rack

(PAN NOT INCLUDED) SH-23000

Fry Basket BS-26730

Grilling Grate SH-26731

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 7.

6•10ESG

2-15/16"

(74mm)

2" (50mm)

47-5/16" (1201mm)

42-1/16" (1068mm)

40-1/8"

(1018mm)

37" (939mm)

34-5/16"

(871mm)

Water Drain

(Bottom)

21-11/16"

(550mm)

5-3/16"

(131mm)

25"

(635mm)

7-1/2"

(191mm)

6-1/4"

(159mm)

5" (125mm)

2-3/8" (60mm)

10-9/16

(267mm)

19-3/8"

(492mm)

5-11/16" (144mm)

4-1/2" (114mm)

5-9/16"

(140mm)

A = UNTREATED WATER

B = TREATED WATER

C = ELECTRICAL

D = GAS

24-1/4"

(615mm)

35-1/4"

(895mm)

30-1/2"

(774mm)

Steam

Vent

(Top)

58-3/16" (1478mm)

15-3/16"

(385mm)

Water Drain

(Back Side)

WATER REQUIREMENTS WATER QUALITY MINIMUM STANDARDS

TWO (2) COLD WATER INLETS - DRINKING QUALITY

ONE (1) TREATED WATER INLET: 3/4” NPT*

ONE (1) UNTREATED WATER INLET: 3/4” NPT*

LINE PRESSURE: 30 to 90 psi 2.8 to 6.2 bar

WATER DRAIN: 1-1/2” CONNECTION WITH A 2” MINIMUM

AIR GAP INSTALLED AS CLOSE TO THE OVEN AS POSSIBLE

USING A WATER SUPPLY NOT MEETING ALTO-SHAAM’S MINIMUM

WATER QUALITY STANDARDS WILL VOID THIS WARRANTY.

It is the responsibility of the purchaser to ensure that incoming water supply is

compliant with the speciﬁ cations listed through adequate treatment measures.

Installation of the CombiGuardTM Water Filtration System is recommended, but

this system may not address all water quality issues present.

CLEARANCE REQUIREMENTS Contaminant

Free Chlorine

Hardness

Chloride

Alkalinity

Silica

Total Dissolved Solids (tds)

Inlet Water Requirements (untreated water)

Less than 0.1 ppm (mg/L)

Less than 3 gpg (52 ppm)

Less than 30 ppm (mg/L)

7.0 to 8.5

Less than 50 ppm (mg/L)

Less than 12 ppm (mg/L)

Less than 60 ppm

LEFT 6” (152mm) RECOMMENDED SERVICE ACCESS: 18” (457mm)

20” (508mm) FROM HEAT PRODUCING EQUIPMENT

RIGHT 4” (102mm) TOP: 20” (508mm) FOR AIR MOVEMENT

BACK 4” (102mm) BOTTOM: 5-1/8” (130mm) FOR LEGS

COUNTER-TOP INSTALLATIONS MUST MAINTAIN 4” (102mm) MINIMUM

CLEARANCE FROM COUNTER SURFACE

* Can manifold off of

one 3/4” line.

DIMENSIONS: H x W x D

EXTERIOR:

35-1/4” x 42-1/16” x 37” (895mm x 1068mm x 939mm)

EXTERIOR WITH RECESSED DOOR:

35-1/4” x 46-1/16” x 37” (895mm x 1170mm x 939mm)

INTERIOR:

17-3/4” x 17-3/8” x 26-13/16” (450mm x 440mm x 680mm)

GAS REQUIREMENTS (TYPE MUST BE SPECIFIED ON ORDER)INSTALLATION REQUIREMENTS

CONNECTED ENERGY LOAD: 45,000 Btu / hr Oven must be installed level.

Hood installation is required.

Water supply shut-off valve and back-flow preventer.

Alternate burner orifice is required for installation sites at

elevations of 2,000 feet (610m) above sea level.

HOOK-UP: 3/4” NPT

MINIMUM CONNECTED PRESSURE: 5.5” W.C. (Natural Gas)

9” W.C. (Propane)

MAXIMUM CONNECTED PRESSURE: 14” W.C.

ELECTRICAL (DEDICATED CIRCUIT REQUIRED) 6●10ESG 6●10ESG / sk

VOLTAGE PHASE CYCLE/HZ AWG AMPS kW AMPS kW

110 – 120 150/60 NEMA 5-20P, 20A, 125V Plug, AWG 12 9.2 1.05 13.7 1.57

OTHER VOLTAGES AVAILABLE: Range 200 – 415V – 1 or 3 ph, 50 or 60 Hz

WEIGHT CAPACITY

NET 400 lb est (181 kg) FULL-SIZE PANS: 20” x 12” x 2-1/2” Six (6) Five (5)

SHIP 515 lb (233 kg) GN 1/1: 530 x 325 x 65mm Six (6) Five (5)

CRATE DIMENSIONS: (L x W x H) HALF-SIZE SHEET PANS:* 18” x 13” x 1” Six (6) Five (5)

45” x 53” x 45” ON WIRE SHELVES ONLY

(1143 x 1346 x 1143mm)

72 lb (33 kg) MAXIMUM

VOLUME MAXIMUM: 45 quarts (57 liters)

*ADDITIONAL WIRE SHELVES REQUIRED FOR MAXIMUM CAPACITY

COMBITOUCHTM ESG SERIES • GAS INSTALLATION MANUAL • 8.

10•10ESG

21-11/16"

(550mm)

5-3/16"

(131mm)

42-1/16" (1068mm)

40-1/8"

(1018mm)

37" (939mm)

34-5/16"

(871mm)

Water Drain

(Bottom)

5" (125mm)

5-9/16"

(140mm)

40-1/8" (1019mm)

33-7/8" (860mm)

44-15/16" (1141mm)

25"

(635mm)

7-1/2"

(191mm)

6-1/4" (159mm)

2-15/16"

(74mm)

2" (50mm)

47-5/16" (1201mm)

2-3/8" (60mm)

10-9/16

(267mm)

19-3/8"

(492mm)

5-11/16" (144mm)

4-1/2" (114mm)

A = UNTREATED WATER

B = TREATED WATER

C = ELECTRICAL

D = GAS

ASteam

Vent

(Top)

58-3/16" (1478mm)

15-3/16"

(385mm)

Water Drain

(Back Side)

DIMENSIONS: H x W x D

EXTERIOR:

44-15/16” x 42-1/16” x 37” (1141mm x 1068mm x 939mm)

EXTERIOR WITH RECESSED DOOR:

44-15/16” x 46-1/16” x 37” (1141mm x 1170mm x 939mm)

INTERIOR:

27-3/8” x 17-3/8” x 26-13/16” (695mm x 440mm x 680mm)

GAS REQUIREMENTS (TYPE MUST BE SPECIFIED ON ORDER)INSTALLATION REQUIREMENTS

CONNECTED ENERGY LOAD: 68,000 Btu / hr Oven must be installed level.

Hood installation is required.

Water supply shut-off valve and back-flow preventer.

Alternate burner orifice is required for installation sites at

elevations of 2,000 feet (610m) above sea level.

HOOK-UP: 3/4” NPT

MINIMUM CONNECTED PRESSURE: 5.5” W.C. (Natural Gas)

9” W.C. (Propane)

MAXIMUM CONNECTED PRESSURE: 14” W.C.

ELECTRICAL (DEDICATED CIRCUIT REQUIRED) 10●10ESG 10●10ESG / sk

VOLTAGE PHASE CYCLE/HZ AWG AMPS kW AMPS kW

110 – 120 150/60 NEMA 5-20P, 20A, 125V Plug, AWG 12 9.2 1.05 13.7 1.57

OTHER VOLTAGES AVAILABLE: Range 200 – 415V – 1 or 3 ph, 50 or 60 Hz

WEIGHT CAPACITY

NET 300 lb est (136 kg) FULL-SIZE PANS: 20” x 12” x 2-1/2” Ten (10) Nine (9)

SHIP 457 lb (207 kg) GN 1/1: 530 x 325 x 65mm Ten (10) Nine (9)

CRATE DIMENSIONS: (L x W x H) EST HALF-SIZE SHEET PANS:* 18” x 13” x 1” Ten (10) Nine (9)

45” x 53” x 48” ON WIRE SHELVES ONLY

(1143 x 1346 x 1219mm)

120 lb (54 kg) MAXIMUM

VOLUME MAXIMUM: 75 quarts (95 liters)

*ADDITIONAL WIRE SHELVES REQUIRED FOR MAXIMUM CAPACITY

WATER REQUIREMENTS WATER QUALITY MINIMUM STANDARDS

TWO (2) COLD WATER INLETS - DRINKING QUALITY

ONE (1) TREATED WATER INLET: 3/4” NPT*

ONE (1) UNTREATED WATER INLET: 3/4” NPT*

LINE PRESSURE: 30 to 90 psi 2.8 to 6.2 bar

WATER DRAIN: 1-1/2” CONNECTION WITH A 2” MINIMUM

AIR GAP INSTALLED AS CLOSE TO THE OVEN AS POSSIBLE

USING A WATER SUPPLY NOT MEETING ALTO-SHAAM’S MINIMUM

WATER QUALITY STANDARDS WILL VOID THIS WARRANTY.

It is the responsibility of the purchaser to ensure that incoming water supply is

compliant with the speciﬁ cations listed through adequate treatment measures.

Installation of the CombiGuardTM Water Filtration System is recommended, but

this system may not address all water quality issues present.

CLEARANCE REQUIREMENTS Contaminant

Free Chlorine

Hardness

Chloride

Alkalinity

Silica

Total Dissolved Solids (tds)

Inlet Water Requirements (untreated water)

Less than 0.1 ppm (mg/L)

Less than 3 gpg (52 ppm)

Less than 30 ppm (mg/L)

7.0 to 8.5

Less than 50 ppm (mg/L)

Less than 12 ppm (mg/L)

Less than 60 ppm

LEFT 6” (152mm) RECOMMENDED SERVICE ACCESS: 18” (457mm)

20” (508mm) FROM HEAT PRODUCING EQUIPMENT

RIGHT 4” (102mm) TOP: 20” (508mm) FOR AIR MOVEMENT

BACK 4” (102mm) BOTTOM: 5-1/8” (130mm) FOR LEGS

COUNTER-TOP INSTALLATIONS MUST MAINTAIN 4” (102mm) MINIMUM

CLEARANCE FROM COUNTER SURFACE

* Can manifold off of

one 3/4” line.

Otros manuales para COMBITOUCH SERIES 6 10ESG

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Horno de Alto-Shaam

Alto-Shaam

Alto-Shaam 500-TH-II SERIES Instrucciones de instalación y funcionamiento

Alto-Shaam

Alto-Shaam 7.14ESG Over Manual de usuario

Alto-Shaam

Alto-Shaam Vector VMC-F3E Manual de usuario

Alto-Shaam

Alto-Shaam 500-TH SERIES Manual de usuario

Alto-Shaam

Alto-Shaam 500-TH/III Manual de usuario

Alto-Shaam

Alto-Shaam Combitherm 6.10ESiN Manual de usuario

Alto-Shaam

Alto-Shaam 1200-TH/III Instrucciones de instalación y funcionamiento

Alto-Shaam

Alto-Shaam 10.18 ES / ESi Manual de usuario

Alto-Shaam

Alto-Shaam 767-SK Series Manual de usuario

Alto-Shaam

Alto-Shaam Halo Heat 1000-TH-I Manual de usuario

Alto-Shaam

Alto-Shaam COMBITOUCH SERIES 20 20ESG Manual de usuario

Alto-Shaam

Alto-Shaam Halo Heat 767-SK/III Manual de uso y cuidado

Alto-Shaam

Alto-Shaam Combitherm 6.10ESiN Manual de usuario

Alto-Shaam

Alto-Shaam AR-7T Manual de usuario

Alto-Shaam

Alto-Shaam 600-LVD Manual del propietario

Alto-Shaam

Alto-Shaam Combitherm CT PROFORMANCE Series Manual de usuario

Alto-Shaam

Alto-Shaam COMBITHERM CTC Series Guía de inicio rápido

Alto-Shaam

Alto-Shaam 6-10ML Manual de usuario

Alto-Shaam

Alto-Shaam Vector H Series Manual de usuario

Alto-Shaam

Alto-Shaam 2800/S-RTM Manual de usuario

Alto-Shaam

Alto-Shaam CT Express Combitherm CTX4-10E Manual de usuario

Alto-Shaam

Alto-Shaam Low Temperature Cook & Hold Oven 750-TH-II Manual de usuario

Alto-Shaam

Alto-Shaam Vector H Series Manual de usuario

Alto-Shaam

Alto-Shaam Halo Heat 767-SK/III Instrucciones de instalación y funcionamiento

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
