Alpha Alpha CombiMax 350 Hoja de instrucciones

Installation Guidelines

To fit the

Alpha CombiMax 350 and 600

in a remote location from the boiler

These guidelines must be used in conjunction with the Installation instructions provided

with the selected combination boiler and CombiMax.

Only a CombiMax produced after February 1999 can be installed remote from the boiler.

Nepicar House, London Road,

Wrotham Heath, Sevenoaks,

Kent TN15 7RS

For Technical help or for Service call ...

ALPHA HELPLINE

Tel: 0870 3001 964

2Alpha CombiMax Remote Location

The Alpha CombiMax has been designed to fit onto the left hand side

of an Alpha 240/280 boiler. However, it is now possible (using a

CombiMax 350 or 600 produced after February 1999, i.e. from Serial

No. A906) to install it up to a distance of 1 metre from the boiler in the

positions shown in Fig. 1.

The pipework between the boiler and CombiMax must be kept as

short as possible and be no more than 1 metres in length, with the

number of bends kept to a minimum.

Notes: 1. A CombiMax produced before February 1999, i.e. before

Serial No. A906 must not be fitted remote from the boiler.

2. A CombiMax fitted remote has no casing.

1 INTRODUCTION

Fig. 1

Possiblelocations

for the CombiMax

in relation to the

boiler.

Fig. 2

1.1 CombiMax Schematic - remote location from boiler

1. Gas service cock

2. On/Off valve and filter

3. On/Off valve

4. On/Off valve and filter

5. DHW pump

6. Pressure reducing valve with filter and check valve

7. Drain point

8. DHW expansion relief valve

9. Store thermostat

10. DHW expansion vessel

11. Manual air vent

12. DHW temperature/pressure relief valve

13. DHW outlet thermostat

14. Storage cylinder

15. Boiler flow control regulator

16. Non return valve

17. Immersion heater boss

Alpha CombiMax Remote Location

2 INSTALLATION INFORMATION

If the CombiMax is to be fitted in a remote location from the boiler, it should be installed as described in the

instructions supplied with the CombiMax together with the following important points:-

2.1 Minimum Clearances Required

2.2 Wall Mounting

Thewallmountingframeandsecuritystrapsupplied,aretobeusedtosecuretheCombiMaxstoragecylindertothewall.

2.3 Casing

ThecasingcomponentssuppliedwiththeCombiMaxcannotbeusedwhenitisfittedinaremotelocationfromtheboiler.

2.4 DHW Expansion Vessel

Fit the expansion vessel near the top of the storage cylinder using the flexible hose supplied. See Fig. 3.

Fig. 3

Compiled and designed by Publications 2000, Tel (01670) 356211

These guidelines have been carefully prepared but we reserve the right to

alter the specification at any time in the interest of product improvement.

10/99/D116

Fig. 4

2.5 Filling Loop

With the CombiMax in a remote location from the boiler, the filling loop facility supplied with the boiler cannot be used

as designed. The filling loop should be discarded and its connections on the cold mains inlet valve (CombiMax) and

heating return valve (boiler) sealed, using ½" BSP threaded caps (not applicable to Alpha 240X). See Fig. 4.

2.6 Connecting Pipework

The boiler and CombiMax must be connected together as shown in Fig. 4, using 15 mm pipework. The pipework

supplied with the CombiMax can be utilised to provide the connections at the boiler and CombiMax.

2.7 Electrical Supply

Connect the electrical supply cable directly to the CombiMax terminal block as described in the CombiMax

instructions, ensuring the cable is secured with the clamping bush supplied.

The cable supplied fitted for connection to the boiler will be too short and therefore must be removed from the CombiMax

terminal block terminals 1, 2 and . A longer length cable to the same specification stated in the CombiMax instructions

must then be used to connect the electrical supply to the boiler terminal block from the CombiMax.

Note: Connect this electrical supply to the boiler as described in the boiler instructions.

Alpha Therm Limited.

Nepicar House, London Road, Wrotham Heath

Sevenoaks, Kent TN15 7RS

email: info@alphatherm.co.uk

website: www.alpha-innovation.co.uk
