Allied Telesis www.alliedtelesis.com

Datasheet | integrated Multiservice Access Platform

ADSL48

AT-TN131-A 48 Port ADSL2+ Annex A Module

Allied T

elesis’ iMAP familyof integrated

Multiservice Access Platforms

Uncompromising ADSL

Performance for Demanding

Applications

The newest ADSL service module in the iMAP

familyis the AT-TN-131. It augments the

current product line by providing breakthrough

technology that offersindustryleading

performance in a smaller footprint and with less

power.The AT-TN-131 has been designed to

meet the most demanding triple play

applications.The card’s higher port count will

help to reduce costs while maintaining the

feature richness of the other cards in the family.

Furthermore, at the heart of the card is a high

performance Network Processor that is

designed for the most demanding traffic

applications; multi-cast video, video on demand,

voice, and data.

The 48 subscriber ports can concurrently

support any of the standard ADSL modes;

ADSL2+, G.DMT, S=1/2, or T1.413. A powerful

DSP implements all ADSL algorithms including

Annex M, Annex L, Data boost and allows

future and emerging ADSL2+ features to be

added through simple software upgrades.

In ADSL2+ mode, a subscriber port can deliver

up to 26Mbps of downstream bandwidth;

enough to support up to 5 set top boxes of

standard digital video,plus headroom for voice

and data traffic.Traffic priority can be

differentiated by service type so that voice,

video,and data can be served to multiple users

on a single port.

To enhance management, a complete set of

counters monitors ADSL performance at each

end of the link. Every performance monitor

counter can be assigned a threshold that will

generate an alarm if the threshold is exceeded.

Part of a total end-to-end solution

that delivers the highest quality and

performance In the industry

Allied Telesis is the only broadband access

vendor that provides a complete end to end

ADSL solution. Customers can optimize real

world downstream rates and DSL reach when

they use the AT-TN-131 together with our

patent pending interconnect system.This unique

system maximizes both revenue and subscriber

satisfaction. Service providers can roll out new

service with confidence and ease.

Access platforms:

•iMAP 9700 (9RU, 17 service slots)

•iMAP 9400 (3RU, 7 service slots)

•MiniMAP 9100 (1RU, 3 service slots)

Provisioning, management, and diagnostics of

subscriber ports can be accomplished from

either the iMAP command line interface or

the NMS.

Key Features

•48 ADSL2+ Ports

•Two Slot design

•ADSL Annex A

•Automatic or manual selection of ADSL2+,

G.DMT

,or T1.413 modes

•Annex L, Annex M, Data boost

QoS

•Eight Queues

•Strict Priority Scheduling

•VLAN Stacking

•VLAN Translation

Security

•Upstream Forwarding Only

•ExtensiveACL Support

Services Supported

•High Speed Internet

•VoIP

•IPTV

•Business VPN

USA Headquarters |19800 North Creek Parkway |Suite 200 |Bothell |WA 98011 |USA |T: +1 800 424 4284 |F: +1 425 481 3895

Asia-Pacific Headquarters |11 Tai Seng Link |Singapore |534182 |T: +65 6383 3832 |F: +65 6383 3830

www.alliedtelesis.com

©2006 AlliedTelesis Inc. All rights reserved. Information in this document is subject to change without notice. All company names, logos, and product designs that are trademarks or registered trademarks are the property of their respective owners. 617-000190 Rev. B

ADSL48 |AT-TN131-A 48 Port ADSL2+ Annex A Module

ADSL48

Model Description Part #

ADSL48A ADSL2+ Annex A Service Module, 48 Port AT-TN-131-A

Ordering Information

Interface Specifications

Number of ports: 48

Number of slots: 2

Backplane capacity: 1Gbps

Connector: 2x RJ-21 (Female)

Compatible CFC

CFC12, CFC24, CFC56

Port Specifications

Number of VCs per port: 4

Number of priority queues per VC: 8

Dropped packet counter: Yes

Full traffic classifier support: Yes

Full traffic classifier action support: Yes

ARP Filtering: Yes

Ingress Metering: Yes

(8Kb increment)

Peak Cell Rate Limiting per VC: Yes

Ingress Max Burst Size: 512Kbps

ADSL Standards

ITU-T G.992.1 (ADSL, S=_, G.DMT, T1.413)

ITU-T G.992.5 (ADSL2+)

Overlap and Non-overlap spectrum

Annex A with Annex L and Annex M support

Power Requirements

Maximum power: 90W

Environmental Specifications

Operating Temp: 0C to 50C

Storage Temp: -40C to 75C

Relative Humidity: 5% to 95%, non-condensing

Regulatory Approvals

NEBS Level 3

GR-1089-CORE

GR-63

FCC Part 15 Class A

EN 300386

UL/cUL 60950

VCCI

iMAP 9x00 Chassis

Model Description Part #

iMAP 9700 17-slot Chassis Group with DC Power AT-TN-250G

iMAP 9400 7-slot Chassis Group with DC Power AT-TN-251G

MiniMAP 9101 3-slot Mini Chassis with DC Power AT-TN-9101-A-80

MiniMAP 9102 3-slot Mini Chassis with AC Power AT-TN-9102-A-XX*

iMAP Common Control and Network

Model Description Part #

CFC24 24 GbE switch controller module AT-TN-401-B

CFC12 12 GbE switch controller module AT-TN-408-A

CFC56 56 GbE switch controller module AT-TN-407-A

GE3 3 x 1GbE WAN Interface Module AT-TN-301-C

XE1 1x10GbE WN Interface Module AT-TN-308-A

*Where XX = 10 for U.S. power cord

=30 for U.K. power cord

=40 for Australia power cord

=50 for Europe power cord

Accessories

Model Description Part #

Cable Optimized RJ21 Male to Optimized RJ21 Male AT-TN-C013-XXX

Cable Optimized RJ21 Male to Unterminated AT-TN-C019-XXX

MDF Kit Terminal block to RJ21 Male, 4 cable AT-TN-K022-A-XXX

Splitter Chassis 3RU, 4 Slot splitter chassis (for use in North America) AT-TN-S004-A

Splitter Card 24 Port (for use in North America) AT-TN-S101-A

XXX = Length

Related Items

Model Description Part #

RG624 ADSL2+ intelligent multiservice Gateway, 4x LAN (Annex A) AT-RG624-XX*

RG634 ADSL2+ intelligent multiservice Gateway, 4x LAN, 2x FXS (Annex A) AT-RG634-XX*
