Alinco PH3DJ-500 Manual de usuario

VHF/UHF FM HANDHELD TRANSCEIVER

User Manual

Brand name: ALINCO

Model name: DJ-500T

FCC ID:PH3DJ-500

IC:3070C-DJ500

RX;136.000~173.995MHz / 400.000~479.995MHz

A1.131031

ALINCO, INC.

Yodoyabashi Dai-bldg 13F

4-4-9 Koraibashi, Chuo-ku, Osaka 541-0043 Japan

Phone: +81-6-7636-2362 Fax: +81-6-6208-3802

http://www.alinco.com

E-mail:[email protected]

Printed in China

VHF/UHF FM amateur transceiver

All EU and EFTA member states. Operator

license is required.

144.000-148.000MHz / 420.000-450.000MHz

DJ-500T

Thank you for purchasing your new Alinco transceiver. Please read this manual

carefully before using the product to ensure full performance, and keep this

manual for future reference as it contains information on after-sales service.

In case addendum or errata sheets are included with this product, please read

those materials and keep them together with this instruction manual for future

reference.

VHF/UHF FM Transceiver

Instruction Manual

Introduction

Thank you very much for purchasing this excellent Alinco transceiver. Our products are ranked among the

finest in the world. This radio has been manufactured with state of the art technology and it has been tested

carefully at our factory. It is designed to operate to your satisfaction for many years under normal use.

Please read this manual completely from the first page to the last, to learn all the functions the

product offers. It is important to note that some of the operations may be explained in relation

to information in previous chapters. By reading just one part of the manual, you may risk not

understanding the complete explanation of the function. In addition, please understand that your

radio may be programmed by the dealer according to the local regulation, masking some of features

mentioned in this manual.Please consult your dealer for details of programming.

Before transmitting

There are many radio stations operating in proximity to the frequency ranges this product covers. Be careful

not to cause interference when transmitting around such radio stations.

■Lightning

Any person is not safe outdoor during thunderstorm and lightning. This condition is getting worse if

somebody keeps a hand-held radio; chances of being hit by lightning are doubled since lightning may hit a

radio antenna as well. At this time, there is no hand-held radio having any kind of protection against lightning

current (which is higher than10 kA.). Note also that no car provides adequate protection of its passengers or

drivers against lightning as well. Therefore, Alinco will not take responsibility for any danger associated with

using its hand-held radios outdoor or inside the car during lightning.

■About IP54 rating / Dust and splash resistant

About IP54 rating

5: Dust protected / Ingress of dust is not entirely prevented, but it must not enter in sufcient quantity to

interfere with the satisfactory operation of the equipment; complete protection against contact.

4: Splashing water / Water splashing against the enclosure from any direction shall have no harmful effect.

Test duration: 5 minutes / Water volume: 10 litters per minute / Pressure: 80~100 kN/m²

The IP54 designation provides for limited dust and splash proong of the radio per specied above. This

compatibility is factory guaranteed for a period of one year provided all the jack covers are securely in

place, any accessories connected must be specified genuine Alinco accessories and the radio has not

been disassembled by the customer. The factory has tested and made the equipment compatible to IP54

certication during engineering. However, please understand that this equipment is NOT certied IP54

compliant but is designed to remain operational when used in hard conditions and is in no way stating that

you should attempt to wash the radio for cleaning. Warranty will not cover radios that are water/dust damage

due to negligence or misuse of the product.

■ Covering ranges

You may expect a range of approx.3km/2 miles or more at high-power when located on a at, noise-free

place like on a beach. However, it may vary drastically depending on how to wear and carry the radios,

surrounding locations/conditions and static noise levels (below or near power transmission lines), etc. In

urban areas with many buildings or inside a building, such covering range will become drastically short even

to several tens of meters.

■ Emergency Kill/Stun/Revive, Alarm signal, Various scan modes, Key lock,

■ Output power selectable 5W

■ 200 PC-programmable channels

■ Li-Ion battery pack and stand-charger as standard accessories

■ Alphanumeric name tags

■ FM broadcast 76-108MHz receiver built-in

■ Selectable Battery-save parameters

■ Busy Channel Lockout

■ CTCSS/DCS Encode/Decode, DTMF/ANI, 5-Tone

■ VOX built-in

Narrow operations and more at NO extra costs.

Features

Conformity Symbols

Tested to comply MIL-STD-810G

-Shock: Method 514.6/I,IV -Vibration: Method 516.6/I

Alert

Environment and condition of use

It is recommended that you check local traffic regulations regarding the use of a radio equipment while

driving. Some countries prohibit or apply restrictions for the operation of radios and mobile-phones while

driving.

Do not use this product in close proximity to other electronic devices, especially medical ones. It may cause

interference to those devices.

Keep the radio out of the reach of children.

In case a liquid leaks from the product, do not touch it. It may damage your skin. Rinse with plenty of cold

water if the liquid contacted your skin.

Never operate this product in facilities where radio products are prohibited for use such as aboard aircraft, in

airports, in ports, within or near the operating area of business wireless stations or their relay stations.

Use of this product may be prohibited or illegal outside of your country. Be informed in advance when you

travel.

The manufacturer declines any responsibilities against loss of life and/or a property due to a failure of this

product when used to perform important tasks like life-guarding, surveillance, and rescue.

Do not use multiple radios in very close proximity. It may cause interference and/or damage to the product(s).

Risk of explosion if battery is replaced with an incorrect type. Dispose of, or recycle used batteries according

to your local regulations.

Handling this product

The manufacturer declines any responsibilities against loss of life and property due to a failure of this product

when used with or as a part of a device made by third parties.

Use of third party accessory may result in damage to this product. It will void our warranty for repair.

Be sure to reduce the audio output level to minimum before using an earphone or a headset. Excessive audio

may damage hearing.

Do not open the unit without permission or instruction from the manufacturer. Unauthorized modication or

repair may result in electric shock, re and/or malfunction and voids warranty.

Do not operate this product in a wet place such as in a shower room. It may result in electric shock, re and/

or malfunction, This product is splash-proof but not a complete water-proof.

Do not place the product in a container carrying conductive materials, such as water or metal in close

proximity. A short-circuit to the product may result in electric shock, re and/or malfunction.

About chargers

Do not use adapters other than having the specified voltage. It may result in electric shock, fire and/or

malfunction,Never turn on the radio while charging.

Do not plug multiple devices using an adapter into a single wall outlet. It may result in overheating and/or re.

Do not handle adapter with a wet hand. It may result in electric shock.

In case of emergency

In case of the following situation(s), please turn off the product, switch off the source of power, then

remove or unplug the power-cord. Please contact your local dealer of this product for service and

assistance. Do not use the product until the trouble is resolved. Do not try to troubleshoot the problem

by yourself.

When a strange sound, smoke and/or strange odor comes out of the product.

●

When the product is dropped or the case is broken or cracked.

●

When a liquid penetrated inside.

●

When a power cord (including DC cables, AC cables and adapters) is damaged

●

For your safety, turn off then remove all related AC lines to the product and its accessories from the wall outlet

if a thunderstorm is likely.

Maintenance

Do not open the unit and its accessories. Please consult with your local dealer of this product for service and

assistance

Securely plug the adapter into the wall outlet. Insecure installation may result in short-circuit, electronic shock and/or

re.

Do not use the adapter if the plug or socket contacts are dirty. Overheating and/or short-circuiting may result in re,

electric shock and/or damage to the product.

About transceiver

Alert

Environment and condition of use

Do not use the product in proximity to a TV or a radio. It may cause interference or receive interference.

Do not install in a humid, dusty or insufficiently ventilated place. It may result in electric shock, fire and/or

malfunction.

Do not install in an unstable or vibrating position. It may result in electric shock, re and/or malfunction when/if

the product falls to the ground.

Do not install the product in proximity to a source of heat and humidity such as a heater or a stove. Avoid

placing the unit in direct sunlight.

Be cautious of a dew formation. Please completely dry the product before use when it happens.

Be cautious of the whip antenna when carried in your shirt-pocket etc. It may make contact with your eye and

cause injury.

Do not connect devices other than specied ones to the jacks and ports on the product. It may result in damage

to the devices.

Turn off and remove the power source (AC cable, DC cable, battery, cigar cable, charger adapter etc.) from the

product when the product is not in use for extended period of time or in case of maintenance.

Never pull the cord alone when you unplug AC cable form the wall outlet.
